KOBE IN2636SQB-1200, IN2648SQB-1200, IN2642SQB-1200 Installation Instructions And Operation Manual

KOBE Brand Range Hood

Model No.

IN2642SQB-1200
IN2648SQB-1200

IN2636SQB-1200

PREMIUM IN-026 SERIES

INSTALLATION INSTRUCTIONS

AND OPERATION MANUAL

IMPORTANT

READ THIS FIRST

READ BEFORE INSTALLATION

1. Carefully check all contents of packages.

2. Thoroughly inspect the unit for any shipping damages, cosmetic damages

or defects.

3. Have a certified contractor/electrician test the unit before installation.

IF THERE IS ANY PROBLEM:

1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL

PACKAGING MATERIAL.

2. Have your original invoice as proof of purchase and product serial number

ready.

3. Contact your merchant for product replacement due to shipping damages,

cosmetic damages or defects.

4. For all other issues, call 1-877-BUY-KOBE (289-5623), or e-mail to

[e-mail] .

NO RETURN, NO REFUND, NO EXCHANGE IF:

1. PRODUCT HAS BEEN INSTALLED

2. KNOCK-OUT HOLES HAVE BEEN PUNCTURED

3. MISSING ORIGINAL PACKAGING MATERIAL

AND/OR PARTS

CONTENTS

[ENGLISH]

- READ AND SAVE THESE INSTRUCTIONS -

IMPORTANT SAFETY INSTRUCTIONS .................................................................................... 1

COMPONENTS OF PACKAGE ................................................................................................. 3

INSTALLATION ......................................................................................................................... 4

OPERATING INSTRUCTIONS .................................................................................................. 7

SPECIFICATIONS ....................................................................................................................12

MEASUREMENTS & DIAGRAMS .............................................................................................13

PARTS LIST .............................................................................................................................16

CIRCUIT DIAGRAM ..................................................................................................................18

TROUBLE SHOOTING .............................................................................................................19

WARRANTY .............................................................................................................................20

WARRANTY INFORMATION FORM ........................................................................................22

- READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -

A L L W I R ING MUST BE DONE BY A PROFESSIO N A L A N D I N

A C C O R D A N C E W IT H N A T I O N A L A N D L O C A L E L E C T R I C A L C O D E S

IMPORTANT SAFETY INSTRUCTIONS

- PLEASE READ THIS SECTION CAREFULLY BEFORE INSTALLATION -

WARNING

:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY,
OBSERVE THE FOLLOWING:

1) Installation and electrical wiring must be done by qualified professionals and in accordance with all
applicable codes and standards, including fire-rated construction.

2) When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hidden
utilities.

3) Ducted fans must be vented to the outside.
a) Before servicing or cleaning unit, open the light panel and SWITCH POWER OFF AT SERVICE

PANEL.

b) Clean all grease laden surfaces frequently. To reduce the risk of fire and disperse air properly,

make sure to vent air outside. DO NOT vent exhaust air into wall spaces, attics, crawl spaces or
garages.

NOTE - This warranty is void without an authorized agent’s receipt or if unit is

damaged due to misuse, poor installation, improper use, mistreatment,
negligence or any other circumstances beyond the control of KOBE
RANGE HOODS authorized agents. Any repair carried out without the
supervision of KOBE RANGE HOODS authorized agents will
automatically void the warranty.

- KOBE RANGE HOODS will not be held responsible for any damages to
personal property or real estate or any bodily injuries whether caused
directly or indirectly by the range hood.

WARNING

: TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE

TOP GREASE FIRE:

1. Keep all fan, baffle/spacer/filter/oil tunnel/oil container and grease-laden surfaces clean. Grease
should not be allowed to accumulate on fan, baffle/spacer/filter/oil tunnel/oil container.

2. Always turn hood ON when cooking.

3. Use high settings on cooking range ONLY when necessary.

4. Do not leave cooking range unattended when cooking.

5. Always use cookware and utensils appropriate for the type and amount of food prepared.

6. Use this unit only in the manner intended by the manufacturer.

7. Before servicing, switch power off at service panel and lock service panel (if possible) to prevent
power from switching on accidentally.

8. Clean ventilating fan frequently.

1

What to Do In The Event Of a Range Top Grease Fire

• SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner.
KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go
out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.

• NEVER PICK UP A BURNING PAN – You May Get Burned.

• DO NOT USE WATER, including wet dishcloths or towels – a steam blast will result.

• Use an extinguisher ONLY if:
a) You have a Class A, B, C extinguisher and know how to operate it.
b) The fire is small and contained in the area where it started.
c) The fire department has been called.
d) You can fight the fire with your back to an exit.

What to Do If You Smell Gas

-

Extinguish any open flame.

-

Do not try to turn on the lights or any type of appliance.

-

Open all doors and windows to disperse the gas. If you still smell gas, call the Gas Company and
Fire Department right away.

CAUTION

1. For general ventilation use only. Do not use to exhaust hazardous or explosive materials and vapors.

2. To reduce the risk of fire, use metal ductwork only. Sufficient air is needed for proper combustion and
exhaustion of gases through the flue (chimney) to prevent back drafting.

3. Follow the heating equipment manufacturer’s guideline and safety standards such as those published
by the National Fire Protection Association (NFPA), and the American Society for Heating,
Refrigeration and Air Conditioning Engineers (ASHRAE), and code authorities.

4. Activating any switch may cause ignition or an explosion.

5. Due to the size and weight of this hood, installation by 2 persons is recommended.

ELECTRICAL SHOCK HAZARD – Can result in serious injury or death.
Disconnect appliance from electric power before servicing. If equipped,
the fluorescent light bulb contains small amounts of mercury, which must
be recycled or disposed of according to Local, State, and Federal Codes.

2

COMPONENTS OF PACKAGE

(Must keep all material for returns or refunds)

Range Hood Box

{A} KOBE Range Hood
{B} Warranty Registration Card
{C} Quick Reference Guide
{D} Baffle Filter x 2 (36”),
X 3 (42” & 48”)
{E} Oil Tunnel
{F} Stainless Steel Spacer x 2 (For 36” & 48”)
{G} Remote Control
{H} Power Cord
{I} Twist-on Wire Cap

{A}

{B} {C}

3

{D} {E}

Handle is included

{F} {G}

{H} {I}

(AAA Batteries not included.)

TABLE 1

-

FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.koberangehoods.com OR CONTACT
KOBE RANGE HOODS AT [phone].

INSTALLATION

PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING

Calculation Before Installation

To calculate installation, please refer to TABLE 1. (All calculation in inches.)

- FOR UNDER THE CABINET -

A = Height of Floor to Ceiling
B = Height of Floor to Counter Top

(Standard: 36")

C = Height of Counter Top to Wood Frame Bottom

(Minimum 27" to 30")

D = Height of Wood Frame

SAFETY WARNING

HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF REMOVING
ANY PARTS FOR INSTALLING, CLEANING OR SERVICING.

NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR.

4

Determine the proper location for the Power Supply Cable.

THIS RANGE HOOD MUST BE PROPERLY GROUNDED.

Preparation Before Installation

NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS
FROM ENTERING THE VENT OPENING.

•

Decide the location of the venting pipe from the hood to the
outside. Refer to Figure 1.

•

A straight, short vent run will allow the hood to perform more
efficiently.

•

Try to avoid as many transitions, elbows, and long run as
possible. This may reduce the performance of the hood.

•

Temporarily wire the hood to test for proper operation before
installing.

•

Important: Peel protective film off the hood, if any.

•

Use duct tape to seal joints between pipe sections.

CAUTION

install the hood, turn off the power in an electric range at
the main electrical box. SHUT OFF THE GAS BEFORE
MOVING A GAS RANGE. And use a protective covering to
protect cooktop and/or countertop from damage.

: If moving the cooking range is necessary to

Custom Hood Preparation

1. The custom hood frame must be designed based on the shape
and the weight of the hood. Refer to Measurements and
Diagrams of hood on Page 13-15.

2. A sturdy base (3/4 inch thick plywood recommended) is needed
to sustain the weight of hood.

3. It is recommended to install front & rear stud support (not
included). Refer to Figure 2. For safety purposes, extra
installation holes on the side of the hood are provided. Prepare
the side stud support if needed.

4. Determine and mark the centerlines on the base of the wood
frame where the hood will be installed.

5.
Make a wiring access hole using a drill bit. Install the wire
cable and seal the gap around hole.

6. Cut out the opening where the hood will be installed. (Refer to
Figure 3 for appropriate dimensions based on width of hood.)

Wiring to Power Supply

CAUTION

install the hood, turn off the power in an electric range at
the main electrical box. SHUT OFF THE GAS BEFORE
MOVING A GAS RANGE. RISK OF ELECTRICAL SHOCK.

MAKE SURE THIS IS DONE BY QUALIFIED ELECTRICIAN
IN ACCORDANCE WITH ALL APPLICABLE NATIONAL AND
LOCAL ELECTRICAL CODES. BEFORE CONNECTING
WIRES, SWITCH POWER OFF AT SERVICE PANEL AND
LOCK SERVICE PANEL TO PREVENT POWER FROM
BEING SWITCHED ON ACCIDENTALLY.

7. Temporarily wire the hood to test for proper operation before
installing. If the hood does not operate, check the circuit breaker
or house fuse. If the hood is still not working, disconnect power
supply and check the continuity of all wire connections.

8. If hood is operating normally, connect three wires (black, white
and green) to house wires and cap with wire connectors.

: If moving the cooking range is necessary to

5

Figure 1

Figure 2

Figure 3

IN2636SQB-1200 (36”)

IN2642SQB-1200 (42”)

IN2648SQB-1200 (48”)

9. Store wires in the wiring box.

Duct Work Installation

10. Determine and make all necessary cuts in the wall or ceiling for

the ductwork. Note: Install the ductwork before installing the

hood.

11. Use steel 8” round pipe to connect the ductwork above to the
exhaust of the hood. The hood is preinstalled with a rectangular
to 8” round transition (Refer to Figure 4). Use duct tape to make
all joints secure and air tight.

12. Please refer to local codes for the usage of a damper (not
included).

Hood Installation

NOTE: USE HAND TOOLS ONLY. DO NOT OVER TIGHTEN
SCREWS. IT MAY CAUSE DAMAGE TO THE HOOD.

13. Remove the light panel by removing screws located at the bottom
of the hood (8 screws for 36” & 42” and 11 screws for 48”) Refer
to Figure 5 as reference. Carefully remove the light support
panel.

14. Position the hood inside the custom wood frame, and secure the
hood to the front and rear stud support ( Refer to Figure 2) by
using the front and rear mounting holes (Screws not included).

15. For a more secure installation, use the mounting holes located
on the side of the hood

16. Make sure hood is secure before releasing.

17. Re-install the light support panel. (Do not over tighten screws.)

CAUTION

RELEASING

: MAKE SURE HOOD IS SECURE BEFORE

Final Assembly

18. Install the oil tunnel into recess support near rear of hood.
Refer to Figure 6.

19. Install baffle filters. Angle baffle filter toward back of hood ①
. Push baffle filter up until almost level ②. Slide forward into
recess behind the front of hood ③. Lower baffle filter ④. Slide
back until it fits into resting position ⑤. Refer to Figure 6.

Figure 4

Figure 5

Figure 5

Figure 6

6

OPERATING INSTRUCTIONS

This KOBE hood is equipped with five electronic push buttons with LED display, a wireless remote control, a double
horizontal squirrel cage blower with stainless steel baffle filters and two LED lights.

The five control buttons are Power Control (On/Off & 3-Minute Delay Shut-Off), Speed Control (High, Medium, Low &
QuietMode™), ECO Control, Timer Control and Light Control. Refer to Figure 14.

Figure 14

Note: For best results, turn the range hood to QuietMode™ prior to any preparation or cooking. Adjust speed as
needed.

Power Control

Press Power Control to turn On/Off the range hood. Hood will power on at Low speed.
Output Display:

3-Minute Delay Shut-Off Control

Delay Shut-Off Control powers down the range hood after 3 minutes. Press the Power Control to activate
Delay-Shut off. The Timer Indicator will automatically begin to count down from the default 3 minutes. When
the time is up, the unit will completely power off.

To bypass the 3-Minute Delay Shut-Off, press the Power Control again to completely power down the unit.

7

Speed Control
(Each press of Speed Control will cycle the fan through Low, Medium, High and QuietMode™.)

Output Display will indicate:

= QuietMode™ Speed

= Low Speed

= Medium Speed

= High Speed

ECO Control

The ECO function is set to turn on the range hood on QuietMode™ setting for 10 minutes every hour
to remove excess moisture, microscopic particles and odors for better kitchen air quality.

ECO is independent from the power function.

To activate ECO when the unit is powered off, press the ECO Control. The ECO icon will be displayed
to show that it is active. To deactivate it, press the ECO Control again. The icon will turn off, indicating
it has been deactivated.

To activate ECO when the unit is powered on, press the ECO Control. The ECO icon will be displayed
to show that it has been activated. In order for ECO to take effect, the unit must be turned off. If
the fan is running, power it off by pressing the Power Control. The unit will automatically shut down in
3 minutes. To power down immediately, Press the Power Control again to power down the unit. Once
the unit is powered off, the ECO icon will remain displayed, indicating that it is active. To deactivate it,
press the ECO Control again. The icon will turn off, indicating it has been deactivated.

NOTE: Must open door or windows to create sufficient make-up air when ECO is operating.
Output Display when ECO is active:

Light Control

(Lights are controlled independently from Power Control. Turning the power off will not turn the lights off.)

Press Light Control to turn lights ON. Press Light Control again to DIM the lights. Press Light Control
again to turn lights OFF.

Timer Control

The Timer Control allows users set their range hood to automatically turn off. The timer ranges from 1 min.
to 99 mins.

8

To activate the timer, the fan must be on (High, Medium, Low, or QuietMode™). As the fan is running,
toggle the timer by pressing the Timer Control. The Timer Indicator will flash, indicating it is ready to be set.
Press the Timer Control to set desired time, starting from 1 min. up to 99 mins. When finished setting time,
the timer will begin to automatically count down.

Baffle Change Indicator

The display will indicate when baffle filter needs cleaning. Press and hold the Power Control for 5 seconds

to reset the Baffle Change Indicator.

9

Remote Control
The six control buttons for the wireless remote control are Power Control (On/Off & 3 Minute Delay Shut-Off), Light Control,

ECO Control, Timer Switch Control and Speed Controls (High, Medium, Low & QuietMode™).

NOTE: Requires 2 AAA Batteries. Batteries not included.

Power Control

Press Power Control to turn hood ON and OFF. Hood will power on at Low speed.

3-Minute Delay Shut-Off Control

Delay Shut-Off Control powers down the range hood after 3 minutes. Press the Power Control to activate
Delay-Shut off. The Timer Indicator will automatically begin to count down from the default 3 minute setting.
When the time is up, the unit will completely power down. To bypass the 3 minute Delay Shut-Off, press
the Power Control again to completely power off the unit.

Light Control

(Lights are controlled independently from Power Control. Turning the power off will not turn the lights off.)

Press Light Control to turn lights ON. Press Light Control again to DIM the lights. Press Light Control
again to turn OFF lights.

Speed Control

Press the Speed Control to activate the fan. The fan will start on Low speed. Each press of the Speed
Control button will cycle through the various speeds.

Press to cycle from High, Medium, Low and QuietMode™
Press to cycle from Low, Medium, High and QuietMode™.
Press Power Control to activate 3-Minute Delay

Timer Control

While the fan is running, press the Timer Control to activate the Timer. The Time Indicator will flash,
indicating it is ready to be set. Use the arrow keys to set the desired time.

Press of will decrease the time by 1 minute. Each press of will increase the time by 1 minute.
When finished setting desired time, the timer will automatically begin to count down or press the Timer

Control to immediately begin the countdown.
If the timer is not set ( OR ) within 6 seconds, the unit will automatically exit Timer Control Mode

and arrow keys will return to speed function control.

10

ECO Control

To activate ECO when the unit is powered off, press the ECO Control. The ECO icon will be displayed
to show that it is active. To deactivate it, press the ECO Control again. The icon will turn off, indicating
it has been deactivated.

To activate ECO when the unit is powered on, press the ECO Control. The ECO icon will be displayed
to show that it has been activated. In order for ECO to take effect, the unit must be turned off. If
the fan is running, power it off by pressing the Power Control. Then press the Power Control again to
power down the unit. Once the unit is powered off, the ECO icon will remain displayed to indicate that
it is active. To deactivate it, press the ECO Control again. The icon will turn off, indicating it has been
deactivated.

For optimal performance, clean the range hood surface and baffles regularly.

To Clean Hood Surface

CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS.

*** Regular care will help preserve its fine appearance.

1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth.

2. If hood looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the surface of the hood. Avoid getting

cleaning solution onto or into the control panel. Follow directions of the stainless steel cleaner. Caution: Do not
leave on too long as this may cause damage to hood finish. Use soft towel to wipe off the cleaning solution, gently
rub off any stubborn spots. Use dry soft towel to dry the hood.

3. DO NOT allow deposits to accumulate or remain on the hood.

4. DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause rusting.

5. DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with stainless steel

for extended periods. Many of these compounds contain chemicals, which may be harmful. Rinse with water after
exposure and wipe dry with a clean lint free cloth.

To Clean Baffle Filter/Oil Tunnel
CAUTION: DRAIN OIL FROM BAFFLE FILTER, SPACERS & OIL TUNNEL REGULARLY TO PREVENT

OVERFLOW.

1. Remove all the baffle filters, spacers and oil tunnel.

2. Using a sponge, wash with warm soapy water. Dry completely before returning into place.

CAUTION: SHARP EDGES
(Note: Baffle Filters are top rack dishwasher safe.)

11

MODEL / SIZE

COLOR

CONSUMPTION / AMPERE

VOLTAGE

NUMBER OF

BLOWERS

BLOWER

TYPE: CENTRIFUGAL

EXHAUST

CONTROLS

LIGHTS

HOOD DIMENSION

HOOD WEIGHT (lbs)

Net Gross

Blower

Air Capacity (cfm)

QuietMode™

Low Medium

High

Sone*

dB

SPECIFICATIONS

IN2636SQB-1200 / 36”
IN2642SQB-1200 / 42”
IN2648SQB-1200 / 48”

Stainless Steel
580W / 5.0A

120V 60Hz
2

Double Horizontal Squirrel Cage
Top Transition Rectangular to 8” Round

5 Push-Button Controls with LED Display

- Timer Control,

- 3-Minute Delay Shut-Off

- Wireless Remote Control

- ECO Control
LED Lights 3W x 2 – 36”, Dual Level Lighting

LED Lights 3W x 3 – 42” & 48”, Dual Level Lighting

(IN2636SQB-1200) 34-3/8” x 22-1/2” x 12”

(W X D X H)

IN2636SQB-1200 57lbs 69.5lbs
IN2642SQB-1200
IN2648SQB-1200 66lbs 81.5lbs

(IN2642SQB-1200) 40-3/8” x 22-1/2” x 12”
(IN2648SQB-1200) 46-3/8” x 22-1/2” x 12”

62lbs 72lbs

350 475 900 1200

1.6 2.8 7.0 8.0

46.5 53.5 67.5 70.0

* One Sone is equivalent to 40 decibels.
**Specifications subject to change without notice.

12

MEASUREMENTS & DIAGRAMS

 All ( ) are in millimeter.
 All inch measurements are converted from millimeters. Inch measurements are estimated.

MODEL NO: IN2636SQB-1200
IN2642SQB-1200
IN2648SQB-1200

Side View

Top View

13

Bottom View

MODEL NO: IN2636SQB-1200 (36”)

MODEL NO: IN2642SQB-1200 (42”)

MODEL NO: IN2648SQB-1200 (48”)

14

Front View

MODEL NO: IN2636SQB-1200 (36”)

MODEL NO: IN2642SQB-1200 (42”)

MODEL NO: IN2648SQB-1200 (48”)

15

NO. DESCRIPTION

MODEL/SI

ZE PART NO.

PARTS LIST

MODEL NO ：IN2636SQB-1200 (36”)

：IN2642SQB-1200 (42”)
：IN2648SQB-1200 (48”)

1 Ducting Transition
2 Hood Casing

3 Processor Board
4 Capacitor
5 Electric Component Support
6 Motor Bracket
7 Blower System
8 Bottom Casing IN2636SQB-1200

9 Baffle Filter Support IN2636SQB-1200

10 Oil Tunnel IN2636SQB-1200

11 Stainless Steel Spacer

12 Baffle Filter
13 Control Unit Support
14 Control Unit
15 Light Panel

Light Panel
Light Panel

16 LED Light (3W)

IN2636SQB-1200
IN2642SQB-1200
IN2648SQB-1200

IN2642SQB-1200
IN2648SQB-1200

IN2642SQB-1200
IN2648SQB-1200

IN2642SQB-1200
IN2648SQB-1200
IN2636SQB-1200
IN2648SQB-1200

IN2636SQB-1200
IN2642SQB-1200
IN2648SQB-1200

L1-0505-0004
10-2636B-1200
10-2642B-1200
10-2648B-1200
L1-0404-2636-B
L1-0401-0120-10
L1-0201-2636-12
L1-0233-2642
L1-0302-0120-802DE
L1-0302-0120-802RE
B101-2636-09-12
B101-2642-09-12
B101-2648-09-12
B101-2636-30-12
B101-2642-30-12
B101-2648-30-12
B101-2636-28-12
B101-2642-28-12
B101-2648-28-12
B101-3636-14B
B101-3648-14B
L1-0214-0191
L1-0207-2630
L1-0404-2636-A
B101-2636-06-12
B101-2642-06-12
B101-2648-06-12

16

MODEL NO ：：：：IN2636SQB-1200 (36”)
：：：：IN2642SQB-1200 (42”)
：：：：IN2648SQB-1200 (48”)

CIRCUIT DIAGRAM

MODEL NO. : IN2636SQB-1200 (36”)

MODEL NO. : IN2642SQB-1200 (42”)

IN2648SQB-1200 (48”)

18

Issue

Possible Cause

Solution

TROUBLE SHOOTING

After Installation,
motor and lights
are not working.

Lights are
working, but
motor(s) is not.

Motor(s) is
working, but
light(s) is not.

The range hood
is vibrating.

The range hood
is not venting
out correctly.

Cold air is
coming into the
home.

The power is not on. Make sure the circuit breaker and the unit’s power is

ON. Use a voltage meter to check the power supply.
The wire connection is not secure. Check and tighten wire connection.
The control panel and processor board
wiring are disconnected.

The control panel and processor board is

Check wire continuity from control panel to processor

board.

Replace the control panel or processor board.
defective.
The motor(s) is defective.
The capacitor(s) is defective.
The control panel or processor board is
defective.

Replace the motor.

Replace capacitor(s).

Replace the control panel or processing board.
The LED light(s) is defective. Replace the LED light.

The LED light transformer is defective. Replace the LED light transformer.
The control panel or processor board is
defective.
The blower system is not secure.

The turbine impeller/squirrel cage is not
balanced.
Hood is not secured in place.

The range hood is installed outside of the
manufacture recommended clearance.

Replace the control panel or processing board.

Tighten the turbine impeller/squirrel cage and air

chamber.

Replace the turbine impeller/squirrel cage.

Check the installation of hood, tighten the mounting

bracket.

Adjust the clearance between the range hoods and

cook top to 27” to 30”. For Island range hood, the

clearance between the range hoods and cook top is

30” to 36”.
There is no make-up air inside the house. Open the window to enhance the performance of the

range hood by creating a sufficient make-up air.
Obstacle blocking the pipe work.

The pipe size is smaller than the
suggested pipe size.

Remove all obstacles from the duct work.

Change the ducting according to the manufacture

suggestion.
The pipe connection is not properly sealed. Check the pipe installation.

The damper is not properly installed or is
missing from the installation.
The damper is not installed.

Check the damper installation.

By installing the damper, it will help to eliminate air

backflow.

19

WARRANTY

WARRANTY CERTIFICATE

KOBE Range Hoods (referred to herein as “we”or “us”) warrants to the original purchaser
(referred to herein as “you” or “your”) all products manufactured or supplied by us to be free from
defect in workmanship and materials as follows:

TWO-YEAR LIMITED WARRANTY FOR PARTS AND LABOR ON KOBE PREMIUM/BRILLIA
SERIES:

For two years from the date of your original invoice from a KOBE authorized dealer, we will, at
our sole discretion, choose to repair or replace the product free of charge that failed due to
manufacturing defects.

It is your sole responsibility to ensure the product is readily accessible for the service technician
to perform repairs. The service technician will not, under any circumstance, remove, alter

or modify any fixture built around and/or connected to the product to gain access to
perform repairs.

During the two-year Limited Warranty period, additional charges may apply which include but
are not limited to:

• Service technician travel charges if the requested service location is 30-miles out of
KOBE’s authorized service area

• Parts shipping expenses

• Un-installation of defective product and Installation of replacement product

Warranty Exclusions:

This warranty does not cover, including but not limited to the following:

a. Improper installation.
b. Any repair, alteration, modification not authorized by KOBE.
c. Duct alteration, modification and connection.
d. Incorrect electric current, voltage or wiring.
e. Normal maintenance and service required for the product.
f. Consumable parts such as light bulbs and carbon filters.
g. Improper usage of the product that it is not intended for, such as commercial use, outdoor

use and multi-family use.

h. Normal wear and tear.
i. Chips, scratches or dents by abuse or misuse of the product.
j. Damages caused by accident, fire, flood and other Acts of God.
k. Expenses incurred for service located outside of the designated service area.
l. Purchases from unauthorized dealers.
m. Removal fees of defective product and Installation fees associated with replacement

product.

20

If we determine that the warranty exclusions listed above apply or if you fail to provide all
necessary documentation for warranty service, you will be responsible for all expenses
associated with the requested service, including parts, labor, shipping, travelling and any other
expense related to the service request.

To qualify for warranty service, you must:

1. Have the ORIGINAL proof of purchase

2. Be the ORIGINAL purchaser of the product

3. Have the model number

4. Have the serial number

5. Have a description of the nature of any defect in the product or part

TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS
SERVICE CENTER:

KOBE SERVICE CENTER (USA ONLY)
Tel: [phone]-KOBE (5623)
E-mail: [e-mail]

For service in Canada and to report a problem, please contact:
Phone: [phone]
Email: [e-mail]

21

WARRANTY INFORMATION FORM

Fill in the blanks and keep this paper with the original invoice in a
safe place for future service purpose.

1. Date of purchase :

2. Model No. :

3. Serial No. :

For warranty service or spare parts purchase contact:

KOBE Service Center (USA ONLY)
Toll Free: 1-855-800-KOBE (5623)
Email: [e-mail]

For service in Canada and to report a problem, please contact:

Phone: [phone]
Email: [e-mail]

Your notes:

22

hood is made for use in the USA and CANADA only. We do not

recommend using this hood overseas as the power supply may not be compatible

Using a KOBE hood overseas

Unis et au Canada

seulement. Il n’est pas recommandé d’utiliser cette hotte à l’étranger puisque

l’alimentation électrique pourrait ne pas être compatible et enfreindre le code de

à l’étranger est à votre propre

ha sido fabricada para ser utilizada

No recomendamos la utilización de esta

e la fuente de energía podría no ser

Utilizar una campana

KOBE Range Hoods

11775 Clark Street

Arcadia, CA 91006 USA

www.koberangehoods.com

This KOBE
and may violate the electrical code of that country.

is at your own risk and will void your warranty.

Cette hotte KOBE est fabriquée pour usage aux États-

l’électricité de ce pays. L’usage de la hotte KOBE

risque et la garantie sera annulée.

Esta campana de extracción KOBE
únicamente en EE.UU. y CANADÁ.
campana en el extranjero debido a qu
compatible y podría violar el código eléctrico de dicho país.
KOBE en el extranjero será a su propio riesgo y anulará la garantía.

Ver 150505
Information subject to change without notice.
