KOBE Brand Range Hood

Model No. IN2630SQB-700

PREMIUM IN-026 SERIES

INSTALLATION INSTRUCTIONS

AND OPERATION MANUAL

IMPORTANT

READ THIS FIRST

READ BEFORE INSTALLATION

1. Carefully check all contents of packages.

2. Thoroughly inspect the unit for any shipping damages, cosmetic damages

or defects.

3. Have a certified contractor/electrician test the unit before installation.

IF THERE IS ANY PROBLEM:

1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL

PACKAGING MATERIAL.

2. Have your original invoice as proof of purchase and product serial number

ready.

3. Contact your merchant for product replacement due to shipping damages,

cosmetic damages or defects.

4. For all other issues, call 1-877-BUY-KOBE (289-5623), or e-mail to

info@koberangehoods.com .

NO RETURN, NO REFUND, NO EXCHANGE IF:

1. PRODUCT HAS BEEN INSTALLED

2. KNOCK-OUT HOLES HAVE BEEN PUNCTURED

3. MISSING ORIGINAL PACKAGING MATERIAL

AND/OR PARTS

CONTENTS

[ENGLISH]

- READ AND SAVE THESE INSTRUCTIONS -

IMPORTANT SAFETY INSTRUCTIONS ........................................................................ 3

COMPONENTS OF PACKAGE ...................................................................................... 5

INSTALLATION ............................................................................................................... 6

OPERATING INSTRUCTIONS ..................................................................................... 11

MAINTENANCE ............................................................................................................ 15

SPECIFICATIONS ........................................................................................................ 16

MEASUREMENTS & DIAGRAMS................................................................................. 17

PARTS LIST .................................................................................................................. 19

CIRCUIT DIAGRAM ...................................................................................................... 21

TROUBLE SHOOTING ................................................................................................. 22

WARRANTY .................................................................................................................. 23

WARRANTY INFORMATION FORM ............................................................................ 25

- READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -

A L L W I R ING MUST BE DONE BY A PROFESSIO N A L A N D I N

A C C O R D A N C E W IT H N A T I O N A L A N D L O C A L E L E C T R I C A L C O D E S

IMPORTANT SAFETY INSTRUCTIONS

- PLEASE READ THIS SECTION CAREFULLY BEFORE INSTALLATION -

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY, OBSERVE THE FOLLOWING:

1) Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction.

2) When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hidden utilities.

3) Ducted fans must be vented to the outside. a) Before servicing or cleaning unit, open the light panel and SWITCH POWER OFF AT SERVICE

PANEL.

b) Clean all grease laden surfaces frequently. To reduce the risk of fire and to disperse air properly,

make sure to vent air outside. DO NOT vent exhaust air into wall spaces, attics, crawl spaces or garages.

NOTE - This warranty is void without an authorized agent’s receipt or if unit is

damaged due to misuse, poor installation, improper use, mistreatment, negligence or any other circumstances beyond the control of KOBE RANGE HOODS authorized agents. Any repair carried out without the supervision of KOBE RANGE HOODS authorized agents will automatically void the warranty.

- KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood.

WARNING

: TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE

TOP GREASE FIRE:

1. Keep all fan, baffle/spacer/filter/oil tunnel/oil container and grease-laden surfaces clean. Grease should not be allowed to accumulate on fan, baffle/spacer/filter/oil tunnel/oil container.

2. Always turn hood ON when cooking.

3. Use high settings on cooking range ONLY when necessary.

4. Do not leave cooking range unattended when cooking.

5. Always use cookware and utensils appropriate for the type and amount of food prepared.

6. Use this unit only in the manner intended by the manufacturer.

7. Before servicing, switch power off at service panel and lock service panel (if possible) to prevent power from switching on accidentally.

8. Clean ventilating fan frequently.

What to Do In The Event Of a Range Top Grease Fire

• SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.

• NEVER PICK UP A BURNING PAN – You May Get Burned.

• DO NOT USE WATER, including wet dishcloths or towels – a steam blast will result.

• Use an extinguisher ONLY if: a) You have a Class A, B, C extinguisher and know how to operate it. b) The fire is small and contained in the area where it started. c) The fire department has been called. d) You can fight the fire with your back to an exit.

What to Do If You Smell Gas

Extinguish any open flame.

Do not try to turn on the lights or any type of appliance.

Open all doors and windows to disperse the gas. If you still smell gas, call the Gas Company and Fire Department right away.

CAUTION

1. For general ventilation use only. Do not use to exhaust hazardous or explosive materials and vapors.

2. To reduce the risk of fire, use only metal ductwork. Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) to prevent back drafting.

3. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National Fire Protection Association (NFPA), and the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and code authorities.

4. Activating any switch on may cause ignition or an explosion.

5. Due to the size and weight of this hood, installation by 2 persons is recommended.

ELECTRICAL SHOCK HAZARD – Can result in serious injury or death. Disconnect appliance from electric power before servicing. If equipped, the fluorescent light bulb contains small amounts of mercury, which must be recycled or disposed of according to Local, State, and Federal Codes.

Adjustable

Liner

(Sold Separately)

{M} Front Section of Liner

(AAA

Batteries

not

COMPONENTS OF PACKAGE

(Must keep all material for returns or refunds)

Range Hood Box

{A} KOBE Range Hood {B} Warranty Registration Card {C} Quick Reference Guide {D} Baffle Filter {E} Oil Tunnel {F} Stainless Steel Spacer {G} Remote Control {H} 6” Round Plastic Collar {I} 3-1/4” x 10” Rectangular Exhaust {J} Power Cord {K} Twist-on Wire Connector {L} Screw set

{A}

{B} {C}

{D} {E}

{F} {G}

{H} {I}

{J} {K}

{L}

Model No. INL36252B

{N} Rear Section of Liner

{M}

{N}

FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.koberangehoods.com OR CONTACT KOBE RANGE HOODS AT (626) 775-8880.

TABLE 1

INSTALLATION

PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING

Calculation before Installation

To calculate installation, please refer to TABLE 1. (All calculation in inches.)

- FOR UNDER THE CABINET -

A = Height of Floor to Ceiling B = Height of Floor to Counter Top

(Standard: 36")

C = Height of Counter Top to Wood Frame Bottom

(Minimum 26" to 30")

D = Height of Wood Frame

SAFETY WARNING

HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF REMOVING ANY PARTS FOR INSTALLING, CLEANING OR SERVICING.

NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY OCCUR.

on holes on the side of the insert are provided.

Determine the proper location for the Power Supply Cable.

Preparation Before Installation

NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING.

•

Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1.

•

A straight, short vent run will allow the hood to perform more efficiently.

•

Try to avoid as many transitions, elbows, and long run as possible. This may reduce the performance of the hood.

•

Temporarily wire the hood to test for proper operation before installing.

•

Important: Peel protective film off the hood, if any.

•

Use duct tape to seal joints between pipe sections.

CAUTION

install the hood, turn off the power in an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE. And use a protective covering to protect cooktop and/or countertop from damage.

: If moving the cooking range is necessary to

Custom Hood Preparation

1. The custom hood frame must be designed according to the shape and the weight of the insert. Refer to Measurements and Diagrams on Page 17-18.

2. A sturdy base (3/4 inch thick plywood recommended) is needed to sustain the weight of insert.

3. If an optional liner will be installed, the side of the wood frame must be sturdy (3/4 inch thick plywood recommended).

4. It is recommended to install front & rear stud support (not included). Refer to Figure 2. For safety purposes, extra installati Prepare the side stud support if needed.

5. Determine and mark the centerlines on the base of the wood frame where the insert will be installed.

6. Make a wiring access hole using a drill bit. Install the wire cable and seal the gap around hole.

7. Cut out the opening where the insert will be installed. (Figure

Liner Installation

8. The custom wood frame must have a sturdy base to accommodate the cut-out for the insert. The base must be recessed to accommodate the height of the liner (See liner dimension on Page 18)

9. Secure the liner to the bottom of the base using screws (not included) appropriate for the size and material of your wood frame.

10. Liner is made up of two sections: a large, rear section with precut for insert and a front section for a total adjustable depth between 23” and 25-3/4”.

11. Position the rear section of the liner so that it aligns with the back edge of the custom wood frame. Use a pen to trace the outline of the pre-cut area.

12. Install the rear section of the liner with 6 screws (not included).

(Additional Purchase required)

Figure 1

Figure 2

Figure 3

Figure 4

13. Install the front section of the liner with 3 screws (not included)

Hood Preparation Before Installation

CAUTION

install the hood, turn off the power in an electric range at the main electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE.

14. Choose the required vent option. The Round Exhaust Plate is pre-installed for top vent.

15. For Top 3-1/4” x 10” rectangular installation only:

Remove the pre-installed Round Exhaust Plate (Refer to Figure 5). Keep screws to attach Rectangular Exhaust Plate and Rectangular Exhaust Adapter.

Place Rectangular Exhaust Plate over vent and secure with 2 screws (Refer to Figure 6). Place Rectangular Exhaust Adapter over the Rectangular Exhaust plate and secure with 10 screws (Refer to Figure 6).

Use remaining screws to secure exhaust plate.

For Rear Vent Options only:

NOTE: The blower is pre-installed for top vent. If installing as rear vent, follow the steps below.

16. For Rear 6” round installation only:

Remove the Rear Round Vent Cover and Rear Rectangular Vent Cover (Refer to Figure 4). Keep screws to attach Round Exhaust Plate to rear vent.

Remove the pre-installed Round Exhaust Plate from top vent (Refer to Figure 5). Attach it to the rear vent (Refer to Figure 7) using the screws removed from vent covers.

Use the Round and Rectangular vent covers removed from rear vent to seal top vent.

Remove the 4 screws that secure the blower system (Refer to Figure 8). Hold the blower to keep it from dropping as you remove screws. Keep screws to re-attach blower. Slowly rotate blower system to align with mounting holes at the back of the insert. Secure blower using 4 screws (Refer to Figure 9).

17. For Rear 3-1/4” x 10” rectangular installation only:

Remove the Rear Round Vent Cover and Rear Rectangular Vent Cover (Refer to Figure 4). Keep screws to attach Rectangular Exhaust Plate and Rectangular Exhaust Adapter.

Place the Rectangular Exhaust Plate over vent and secure with 2 screws (Refer to Figure 10). Place Rectangular Exhaust Adapter over the Rectangular Exhaust Plate and secure with 10 screws (Refer to Figure 10).

Use remaining screws to secure exhaust plate.

Remove the pre-installed Round Exhaust Plate from top vent and keep screws (Refer to Figure 4). Use the Round and Rectangular vent covers removed from rear to seal top vent.

: If moving the cooking range is necessary to

Figure 5

Figure 6

Figure 7

Figure 8

APPLICABLE NATIONAL AND LOCAL ELECTRICAL CODES.

Duct Work Installation

18. Determine and make all necessary cuts in the wall or ceiling for the ductwork. Note: Install the ductwork before installing the insert.

19. Use steel pipe to connect the exhaust on the hood to the ductwork above. Use duct tape to make all joints secure and air tight.

20. Please refer to local codes for the usage of a damper (not included).

Wiring to Power Supply

SAFETY WARNING

RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY QUALIFIED ELECTRICIAN IN ACCORDANCE WITH ALL

BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT POWER FROM BEING SWITCHED ON ACCIDENTALLY.

21. Connect electrical wires.

22. Connect three wires (black, white and green) to house wires and cap with wire connectors. Connect wires according to their colors (i.e. black to black, white to white, and green to green).

23. Store wires in the wiring box.

Hood Installation

NOTE: USE HAND TOOLS ONLY. DO NOT OVER TIGHTEN SCREWS. IT MIGHT CAUSED DAMAGED TO THE HOOD.

24. Remove 10 screws located at the bottom of the insert (Refer to Figure 11). Carefully remove the light support panel.

25. Position the insert inside the custom wood frame, and secure the insert to the front and rear stud support ( Refer to Figure 2) by using the front and rear mounting holes (Screws not included).

26. For a more secure installation, use the mounting holes located on the side of the insert

27. Make sure insert is secure before releasing.

28. Re-install the light support panel. (Do not over tighten screws.)

CAUTION

RELEASING.

: MAKE SURE HOOD IS SECURE BEFORE

Figure 9

Figure 10

Figure 11

Figure 12

Final Assembly

29. Install the oil tunnel into recess support near rear of hood. Refer to Figure 12.

30. Install baffle filters. Angle baffle filter toward back of hood ① . Push baffle filter up until almost level ②. Slide forward into recess behind the front of hood ③. Lower baffle filter ④. Slide back until it fits into resting position ⑤. Refer to Figure 13.

Figure 13

OPERATING INSTRUCTIONS

This KOBE hood is equipped with five electronic push buttons with LED display, a wireless remote control, a double horizontal squirrel cage blower with stainless steel baffle filters and two bright LED lights.

The five control buttons are Power Control (On/Off & 3-Minute Delay Shut-Off), Speed Control (High, Medium, Low & QuietMode™), ECO Control, Timer Control and Light Control. Refer to Figure 14.

Figure 14

Delay Shut-Off

Delay Shut-Off Control

Note: For best results, turn the range hood to QuietMode™ prior to any preparation or cooking. Adjust speed as needed.

Power Control

Press Power Control to turn On/Off the range hood. Hood will power on at Low speed. Output Display:

3-Minute Delay Shut-Off Control

Delay Shut-Off Control powers down the range hood after 3 minutes. Press the Power Control to activate Delay-Shut off. The Timer Indicator will automatically begin to count down from the default 3 minutes. When the time is up, the unit will completely power off.

To bypass the 3-Minute Delay Shut-Off, press the Power Control again to completely power down the unit.

Speed Control (Each press of Speed Control will cycle the fan through Low, Medium, High and QuietMode™.)

Output Display will indicate:

= QuietMode™ Speed

= Low Speed

= Medium Speed

= High Speed

ECO Control

The ECO function is set to turn on the range hood on QuietMode™ setting for 10 minutes every hour to remove excess moisture, microscopic particles and odors for better kitchen air quality.

ECO is independent from the power function.

To activate ECO when the unit is powered off, press the ECO Control. The ECO icon will be displayed to show that it is active. To deactivate it, press the ECO Control again. The icon will turn off, indicating it has been deactivated.

To activate ECO when the unit is powered on, press the ECO Control. The ECO icon will be displayed to show that it has been activated. In order for ECO to take effect, the unit must be turned off. If the fan is running, power it off by pressing the Power Control. The unit will automatically shut down in 3 minutes. To power down immediately, Press the Power Control again to power down the unit. Once the unit is powered off, the ECO icon will remain displayed, indicating that it is active. To deactivate it, press the ECO Control again. The icon will turn off, indicating it has been deactivated.

NOTE: Must open door or windows to create sufficient make-up air when ECO is operating. Output Display when ECO is active:

Light Control

(Lights are controlled independently from Power Control. Turning the power off will not turn the lights off.)

Press Light Control to turn lights ON. Press Light Control again to DIM the lights. Press Light Control again to turn lights OFF.

Timer Control

The Timer Control allows users to set their range hood to automatically turn off. The timer ranges from 1 min. to 99 mins.

To activate the timer, the fan must be on (High, Medium, Low, or QuietMode™). As the fan is running, toggle the timer by pressing the Timer Control. The Timer Indicator will flash, indicating it is ready to be set. Press the Timer Control to set desired time, starting from 1 min. up to 99 mins. When finished setting time, the timer will begin to automatically count down.

Baffle Change Indicator

The display will indicate when baffle filter needs cleaning. Press and hold the Power Control for 5

seconds to reset the Baffle Change Indicator.

Remote Control The six control buttons for the wireless remote control are Power Control (On/Off & 3 Minute Delay Shut-Off), Light Control,

ECO Control, Timer Switch Control and Speed Controls (High, Medium, Low & QuietMode™).

NOTE: Requires 2 AAA Batteries. Batteries not included.

Power Control

Press Power Control to turn hood ON and OFF. Hood will power on at Low speed.

3-Minute Delay Shut-Off Control

Delay Shut-Off Control powers down the range hood after 3 minutes. Press the Power Control to activate Delay-Shut off. The Timer Indicator will automatically begin to count down from the default 3 minute setting. When the time is up, the unit will completely power down. To bypass the 3 minute Delay Shut-Off, press the Power Control again to completely power off the unit.

Light Control

(Lights are controlled independently from Power Control. Turning the power off will not turn the lights off.)

Press Light Control to turn lights ON. Press Light Control again to DIM the lights. Press Light Control again to turn OFF lights.

Speed Control

Press the Speed Control to activate the fan. The fan will start on Low speed. Each press of the Speed Control button will cycle through the various speeds.

Press to cycle from High, Medium, Low and QuietMode™ Press to cycle from Low, Medium, High and QuietMode™. Press Power Control to activate 3-Minute Delay

Timer Control

While the fan is running, press the Timer Control to activate the Timer. The Time Indicator will flash, indicating it is ready to be set. Use the arrow keys to set the desired time.

Press of will decrease the time by 1 minute. Each press of will increase the time by 1 minute.

When finished setting desired time, the timer will automatically begin to count down or press the Timer Control to immediately begin the countdown.

If the timer is not set ( OR ) within 6 seconds, the unit will automatically exit Timer Control Mode and arrow keys will return to speed function control.

ECO Control

To activate ECO when the unit is powered on, press the ECO Control. The ECO icon will be displayed to show that it has been activated. In order for ECO to take effect, the unit must be turned off. If the fan is running, power it off by pressing the Power Control. Then press the Power Control again to power down the unit. Once the unit is powered off, the ECO icon will remain displayed to indicate that it is active. To deactivate it, press the ECO Control again. The icon will turn off, indicating it has been deactivated.

MAINTENANCE

For optimal performance, clean the range hood surface and baffles regularly.

To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS.

*** Regular care will help preserve its fine appearance.

1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth.

2. If hood looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the surface of the hood. Avoid getting cleaning solution onto or into the control panel. Follow directions of the stainless steel cleaner. Caution: Do not leave on too long as this may cause damage to hood finish. Use soft towel to wipe off the cleaning solution, gently rub off any stubborn spots. Use dry soft towel to dry the hood.

3. DO NOT allow deposits to accumulate or remain on the hood.

4. DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause rusting.

5. DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with stainless steel for extended periods. Many of these compounds contain chemicals, which may be harmful. Rinse with water after exposure and wipe dry with a clean lint free cloth.

To Clean Baffle Filter/Oil Tunnel CAUTION: DRAIN OIL FROM BAFFLE FILTER, SPACERS & OIL TUNNEL REGULARLY TO PREVENT

OVERFLOW.

1. Remove all the baffle filters, spacers and oil tunnel.

2. Using a sponge, wash with warm soapy water. Dry completely before returning into place.

CAUTION: SHARP EDGES (Note: Baffle Filters are top rack dishwasher safe.)

SPECIFICATIONS

MODEL / SIZE IN2630SQB-700

COLOR Commercial Stainless Steel CONSUMPTION / AMPERE 290W / 2.5A

VOLTAGE 120V 60Hz NUMBER OF MOTORS 1

FAN TYPE: CENTRIFUGAL Double Horizontal Squirrel Cage EXHAUST Top –

6” Round 3-1/4” x 10” Rectangular Rear – 6” Round 3-1/4” x 10” Rectangular

CONTROLS 5 Push-Button with LED Display

- Timer Control

- 3-Minute Delay Shut-Off

- Wireless Remote Control

- ECO Control

LIGHTS LED Lights 3W x 2, Dual Level Lighting HOOD DIMENSION

(W X D X H) OPTIONAL ACCESSORIES

(W X D X H)

HOOD WEIGHT (lbs) Net Gross IN2630SQB-700 42 52

Blower Air Capacity (cfm) QuietMode™ Low Medium High

Sone* 1.0 2 5.0 6.0

30” x 18-1/2” x 12”

2 Piece Adjustable Liner Model No.: INL36252B (34-7/16” x 23”~25-3/4” x 3”)

300 420 590 750

* One Sone is equivalent to 40 decibels. **Specifications subject to change without notice.

MEASUREMENTS & DIAGRAMS

 All ( ) are in millimeter.  All inch measurements are converted from millimeters. Inch measurements are estimated.

MODEL NO: IN2630SQB-700

Side View Bottom View

Back View Top View

Front View

Ajustable Stainless Steel Liner (Sold Separately) Model No. INL36252B

PARTS LIST

MODEL NO: IN2630SQB-700

NO. DESCRIPTION MODEL/SIZE PART NO.

1 Rectangular Exhaust Plate 2 Rectangular Vent Cover 3 Round Exhaust Plate 4 Rectangular Exhaust Adapter 5 Hood Casing IN2630SQB-700 6 Electric Component Support 7 Processor Board 8 Capacitor x 1PCS

9 Blower Bracket 10 Oil Tunnel IN2630SQB-700 11 Blower System 12 Bottom Casing 13 Baffle Filter Support

L1-0241-0001B L1-0241-0002A L1-0241-0001A L1-0241-0002B 10-2630B-700 L1-0201-2630 L1-0404-2636-B L1-0401-0120-10 L1-0233-2630 B101-2630-14A L1-0302-0120-802RE B101-2630-09 B101-2630-15B

14 Stainless Steel Spacer {1-13/16”(46)x9-1/4”(235) 15 Baffle Filter 16 Control Unit Support 17 Control Unit 18 Light Panel Support 19 LED Light (3W)

Optional Adjustable Liner (Sold Separately)

20 Rear Section of Liner INL36252B B103-2630-A 21 Front Section of Liner INL36252B B103-2630-B

B101-2630-14B B101-2630-15 L1-0207-2630 L1-0404-2636-A B101-2630-06 L1-0403-0301

MODEL NO: IN2630SQB-700

Optional Liner (Sold Separately)

CIRCUIT DIAGRAM

MODEL NO.: IN2630SQB-700

Issue

Possible Cause

Solution

TROUBLE SHOOTING

After Installation, motor and lights are not working.

Lights are working, but motor(s) is not.

Motor(s) is working, but light(s) is not.

The range hood is vibrating.

The range hood is not venting out correctly.

Cold air is coming into the

home.

The power is not on. Make sure the circuit breaker and the unit’s power is ON.

Use a voltage meter to check the power supply. The wire connection is not secure. Check and tighten wire connection. The control panel and processor board wiring are disconnected.

The control panel and processor board is defective.

The motor(s) is defective. The capacitor(s) is defective. The control panel or processor board is defective.

Check wire continuity from control panel to processor

board.

Replace the control panel or processor board.

Replace the motor.

Replace capacitor(s).

Replace the control panel or processing board. The LED light(s) is defective. Replace the LED light.

The LED light transformer is defective. Replace the LED light transformer. The control panel or processor board is defective. The blower system is not secure.

The turbine impeller/squirrel cage is not balanced. Hood is not secured in place.

The range hood is installed outside of the manufacture recommended clearance.

Replace the control panel or processing board.

Tighten the turbine impeller/squirrel cage and air

chamber.

Replace the turbine impeller/squirrel cage.

Check the installation of hood, tighten the mounting

bracket.

Adjust the clearance between the range hoods and

cook top to 27” to 30”. For Island range hood, the

clearance between the range hoods and cook top is

30” to 36”. There is no make-up air inside the house. Open the window to enhance the performance of the

range hood by creating a sufficient make-up air. Obstacle blocking the pipe work.

The pipe size is smaller than the suggested pipe size. The pipe connection is not properly sealed. Check the pipe installation.

The damper is not properly installed or is missing from the installation. The damper is not installed.

Remove all obstacles from the duct work.

Change the ducting according to the manufacture

suggestion.

Check the damper installation.

By installing the damper, it will help to eliminate air

backflow.

WARRANTY

WARRANTY CERTIFICATE

KOBE Range Hoods (referred to herein as “we”or “us”) warrants to the original purchaser (referred to herein as “you” or “your”) all products manufactured or supplied by us to be free from defect in workmanship and materials as follows:

TWO-YEAR LIMITED WARRANTY FOR PARTS AND LABOR ON KOBE PREMIUM/BRILLIA SERIES:

For two years from the date of your original invoice from a KOBE authorized dealer, we will, at our sole discretion, choose to repair or replace the product free of charge that failed due to manufacturing defects.

It is your sole responsibility to ensure the product is readily accessible for the service technician to perform repairs. The service technician will not, under any circumstance, remove, alter

or modify any fixture built around and/or connected to the product to gain access to perform repairs.

During the two-year Limited Warranty period, additional charges may apply which include but are not limited to:

• Service technician travel charges if the requested service location is 30-miles out of KOBE’s authorized service area

• Parts shipping expenses

• Un-installation of defective product and Installation of replacement product

Warranty Exclusions:

This warranty does not cover, including but not limited to the following:

a. Improper installation. b. Any repair, alteration, modification not authorized by KOBE. c. Duct alteration, modification and connection. d. Incorrect electric current, voltage or wiring. e. Normal maintenance and service required for the product. f. Consumable parts such as light bulbs and carbon filters. g. Improper usage of the product that it is not intended for, such as commercial use, outdoor

use and multi-family use.

h. Normal wear and tear. i. Chips, scratches or dents by abuse or misuse of the product. j. Damages caused by accident, fire, flood and other Acts of God. k. Expenses incurred for service located outside of the designated service area. l. Purchases from unauthorized dealers. m. Removal fees of defective product and Installation fees associated with replacement

product.

If we determine that the warranty exclusions listed above apply or if you fail to provide all necessary documentation for warranty service, you will be responsible for all expenses associated with the requested service, including parts, labor, shipping, travelling and any other expense related to the service request.

To qualify for warranty service, you must:

1. Have the ORIGINAL proof of purchase

2. Be the ORIGINAL purchaser of the product

3. Have the model number

4. Have the serial number

5. Have a description of the nature of any defect in the product or part

TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS SERVICE CENTER:

KOBE SERVICE CENTER (USA ONLY) Tel: 1-855-800-KOBE (5623) E-mail: kobe@adcoservice.com

For service in Canada and to report a problem, please contact: Phone: 1-626-775-8880 Email: customer.service@koberangehoods.com

WARRANTY INFORMATION FORM

Fill in the blanks and keep this paper with the original invoice in a safe place for future service purpose.

1. Date of purchase :

2. Model No. :

3. Serial No. :

For warranty service or spare parts purchase contact:

KOBE Service Center (USA ONLY) Toll Free: 1-855-800-KOBE (5623) Email: kobe@adcoservice.com

For service in Canada and to report a problem, please contact:

Phone: 1-626-775-8880 Email: customer.service@koberangehoods.com

Your notes:

only. We do not

recommend using this hood overseas as the power supply may not be compatible

Using a KOBE hood overseas

Unis et au Canada

seulement. Il n’est pas recommandé d’utiliser cette hotte à l’étranger puisque

l’alimentation électrique pourrait ne pas être compatible et enfreindre le code de

à l’étranger est à votre propre

ha sido fabricada para ser utilizada

No recomendamos la utilización de esta

e la fuente de energía podría no ser

Utilizar una campana

KOBE Range Hoods

11775 Clark Street

Arcadia, CA 91006 USA

www.koberangehoods.com

This KOBE hood is made for use in the USA and CANADA and may violate the electrical code of that country.

is at your own risk and will void your warranty.

Cette hotte KOBE est fabriquée pour usage aux États-

l’électricité de ce pays. L’usage de la hotte KOBE

risque et la garantie sera annulée.

Esta campana de extracción KOBE únicamente en EE.UU. y CANADÁ. campana en el extranjero debido a qu compatible y podría violar el código eléctrico de dicho país. KOBE en el extranjero será a su propio riesgo y anulará la garantía.

Ver. 150505 Information subject to change without notice.

Kobe IN2630SQB700 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
