KOBE BRILLIA SERIES INX-026OVS-INX2630SQB-600-40, INX2630SQB-700-2 Installation Instructions And Operation Manual

KOBE Brand Range Hood

Model No.

OVS-

INX2630SQB-600-40

BRILLIA SERIES INX-026

INSTALLATION INSTRUCTIONS

AND OPERATION MANUAL

IMPORTANT

READ THIS

FIRST

READ BEFORE INSTALLATION

1. Carefully check all contents of packages;

2. Thoroughly inspect the unit for any cosmetic damages or

defects;

3. Test the unit before installation;

4. Have a certified contractor/electrician do the installation.

IF THERE IS ANY PROBLEM:

1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL

PACKAGING MATERIAL.

2. Have your original proof of purchase and product serial

number ready.

3. Call 1-877-BUY-KOBE (289-5623); or e-mail to

[e-mail] to report the problem.

NO RETURN, NO REFUND, NO EXCHANGE IF:

1. PRODUCT HAS BEEN INSTALLED

2. KNOCK-OUT HOLES HAVE BEEN PUNCTURED

3. MISSING ORIGINAL PACKAGING MATERIAL AND/OR

PARTS

CONTENTS

[ENGLISH]

- READ AND SAVE THESE INSTRUCTIONS -

IMPORTANT SAFETY INSTRUCTIONS ........................................................................ 1

COMPONENTS OF PACKAGE ...................................................................................... 3

INSTALLATION ............................................................................................................... 4

OPERATING INSTRUCTIONS ....................................................................................... 9

MAINTENANCE ............................................................................................................ 13

SPECIFICATIONS ........................................................................................................ 14

MEASUREMENTS & DIAGRAMS................................................................................. 15

PARTS LIST .................................................................................................................. 17

CIRCUIT DIAGRAM ...................................................................................................... 19

TROUBLE SHOOTING ................................................................................................. 20

WARRANTY .................................................................................................................. 21

WARRANTY INFORMATION FORM ............................................................................ 23

- READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -

A L L W I R ING MUST BE DONE BY A PROFESSIO N A L A N D I N

A C C O R D A N C E W I T H N A T I O N A L A N D L O C A L E L E C T R I C A L C O D E S

IMPORTANT SAFETY INSTRUCTIONS

- PLEASE READ THIS SECTION CAREFULLY BEFORE INSTALLATION -

WARNING

:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY,
OBSERVE THE FOLLOWING:

1) Installation and electrical wiring must be done by qualified professionals and in accordance with all
applicable codes and standards, including fire-rated construction.

2) When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hidden
utilities.

3) Ducted fans must be vented to the outside.
a) Before servicing or cleaning unit, open the light panel and SWITCH POWER OFF AT SERVICE

PANEL.

b) Clean all grease laden surfaces frequently. To reduce the risk of fire and to disperse air

properly, make sure to vent air outside. DO NOT vent exhaust air into wall spaces, attics, crawl
spaces or garages.

NOTE - This warranty is void without an authorized agent’s receipt or if unit is

damaged due to misuse, poor installation, improper use, mistreatment,
negligence or any other circumstances beyond the control of KOBE
RANGE HOODS authorized agents. Any repair carried out without the
supervision of KOBE RANGE HOODS authorized agents will
automatically void the warranty.

- KOBE RANGE HOODS will not be held responsible for any damages to
personal property or real estate or any bodily injuries whether caused
directly or indirectly by the range hood.

WARNING

: TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE

TOP GREASE FIRE:

1. Keep all fan, baffle/spacer/filter/oil tunnel/oil container and grease-laden surfaces clean. Grease
should not be allowed to accumulate on fan, baffle/spacer/filter/oil tunnel/oil container.

2. Always turn hood ON when cooking.

3. Use high settings on cooking range ONLY when necessary.

4. Do not leave cooking range unattended when cooking.

5. Always use cookware and utensils appropriate for the type and amount of food prepared.

6. Use this unit only in the manner intended by the manufacturer.

7. Before servicing, switch power off at service panel and lock service panel (if possible) to prevent
power from switching on accidentally.

8. Clean ventilating fan frequently.

1

What to Do In The Event Of a Range Top Grease Fire

• SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner.
KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not
go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.

• NEVER PICK UP A BURNING PAN – You May Get Burned.

• DO NOT USE WATER, including wet dishcloths or towels – a steam blast will result.

• Use an extinguisher ONLY if:
a) You have a Class A, B, C extinguisher and know how to operate it.
b) The fire is small and contained in the area where it started.
c) The fire department has been called.
d) You can fight the fire with your back to an exit.

What to Do If You Smell Gas

-

Extinguish any open flame.

-

Do not try to turn on the lights or any type of appliance.

-

Open all doors and windows to disperse the gas. If you still smell gas, call the Gas Company and
Fire Department right away.

CAUTION

1. For general ventilation use only. Do not use to exhaust hazardous or explosive materials and
vapors.

2. To reduce the risk of fire, use only metal ductwork. Sufficient air is needed for proper combustion
and exhausting of gases through the flue (chimney) to prevent back drafting.

3. Follow the heating equipment manufacturer’s guideline and safety standards such as those
published by the National Fire Protection Association (NFPA), and the American Society for
Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and code authorities.

4. Activating any switch on may cause ignition or an explosion.

5. Due to the size and weight of this hood, installation by 2 persons is recommended.

ELECTRICAL SHOCK HAZARD – Can result in serious injury or death.
Disconnect appliance from electric power before servicing. If equipped,
the fluorescent light bulb contains small amounts of mercury, which
must be recycled or disposed of according to Local, State, and Federal
Codes.

2

Adjustable

Liner (Sold Sepa

rately)

{J} Front Section of Liner

For the operation

COMPONENTS OF PACKAGE

(Must keep all material for returns or refunds)

Range Hood Box

{A} BRILLIA Range Hood
{B} Warranty Registration Card
{C} Instruction Manual (WEBSITE)
{D} Baffle Filter X2
{E} Oil Tunnel
{F} Stainless Steel Spacer X2
{G} Remote Control with holder
{H} Rectangular Exhaust Plate
{I} Rectangular Exhaust Adapter

{A}

{B} {C}

manual, please refer to
our website:
KOBERangehoods.com

{D} {E}

{F}

-

FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.KOBERangeHoods.com OR CONTACT
KOBE RANGE HOODS AT [phone].

{G} {H}

(AAA Batteries not included.)

{I}

{K} Rear Section of Liner

{J}

{K}

3

TABLE 1

INSTALLATION

PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING

Calculation before Installation

To calculate installation, please refer to TABLE 1. (All calculation in inches.)

- FOR UNDER THE CABINET -

A = Height of Floor to Ceiling
B = Height of Floor to Counter Top

(Standard: 36")

C = Height of Counter Top to Wood Frame Bottom

(Minimum 26" to 30")

D = Height of Wood Frame

SAFETY WARNING

HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF REMOVING
ANY PARTS FOR INSTALLING, CLEANING OR SERVICING.

NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY

OCCUR.

4

on holes on the side of the insert are provided.

le.

Preparation Before Installation

NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS
FROM ENTERING THE VENT OPENING.

•

Decide the location of the venting pipe from the hood to the
outside. Refer to Figure 1.

•

A straight, short vent run will allow the hood to perform more
efficiently.

•

Try to avoid as many transitions, elbows, and long run as
possible. This may reduce the performance of the hood.

•

Temporarily wire the hood to test for proper operation before
installing.

•

Important: Peel protective film off the hood, if any.

•

Use duct tape to seal joints between pipe sections.

CAUTION

install the hood, turn off the power in an electric range at
the main electrical box. SHUT OFF THE GAS BEFORE
MOVING A GAS RANGE. And use a protective covering
to protect cooktop and/or countertop from damage.

: If moving the cooking range is necessary to

Custom Hood Preparation

1. The custom hood frame must be designed according to the
shape and the weight of the insert. Refer to Measurements
and Diagrams on Page 18-19.

2. A sturdy base (3/4 inch thick plywood recommended) is
needed to sustain the weight of insert.

3. If an optional liner will be installed, the side of the wood frame
must be sturdy (3/4 inch thick plywood recommended).

4. It is recommended to install front & rear stud support (not
included). Refer to Figure 2. For safety purposes, extra
installati
Prepare the side stud support if needed.

5. Determine and mark the centerlines on the base of the wood
frame where the insert will be installed.

6. Determine the proper location for the Power Supply Cab
Make a wiring access hole using a drill bit. Install the wire
cable and seal the gap around hole.

7. Cut out the opening where the insert will be installed. (Figure

3)

Liner Installation

8. The custom wood frame must have a sturdy base to
accommodate the cut-out for the insert. The base must be
recessed to accommodate the height of the liner (See liner
dimension on Page 19)

9. Secure the liner to the bottom of the base using screws (not
included) appropriate for the size and material of your wood
frame.

10. Liner is made up of two sections: a large, rear section with pre­cut for insert and a front section for a total adjustable depth
between 23” and 25-3/4”.

11. Position the rear section of the liner so that it aligns with the
back edge of the custom wood frame. Use a pen to trace the
outline of the pre-cut area.

12. Install the rear section of the liner with 6 screws (not included).

13. Install the front section of the liner with 3 screws (not included)

(Additional Purchase required)

Figure 1

Figure 2

Figure 3

Figure 4

5

Hood Preparation Before Installation

CAUTION

install the hood, turn off the power in an electric range at
the main electrical box. SHUT OFF THE GAS BEFORE
MOVING A GAS RANGE.

14. Choose the required vent option. The Round Exhaust Plate is
pre-installed for top vent.

15. For Top 3-1/4” x 10” rectangular installation only:

-

Remove the pre-installed Round Exhaust Plate (Refer to
Figure 5). Keep screws to attach Rectangular Exhaust
Plate and Rectangular Exhaust Adapter.

-

Place Rectangular Exhaust Plate over vent and secure
with 2 screws (Refer to Figure 6). Place Rectangular
Exhaust Adapter over the Rectangular Exhaust plate and
secure with 10 screws (Refer to Figure 6).

-

Use remaining screws to secure exhaust plate.

For Rear Vent Options only:

NOTE: The blower is pre-installed for top vent. If
installing as rear vent, follow the steps below.

16. For Rear 6” round installation only:

-

Remove the Rear Round Vent Cover and Rear
Rectangular Vent Cover (Refer to Figure 4). Keep
screws to attach Round Exhaust Plate to rear vent.

-

Remove the pre-installed Round Exhaust Plate from top
vent (Refer to Figure 5). Attach it to the rear vent (Refer
to Figure 7) using the screws removed from vent covers.

-

Use the Round and Rectangular vent covers removed
from rear vent to seal top vent.

-

Remove the 4 screws that secure the blower system
(Refer to Figure 8). Hold the blower to keep it from
dropping as you remove screws. Keep screws to re­attach blower. Slowly rotate blower system to align with
mounting holes at the back of the insert. Secure blower
using 4 screws (Refer to Figure 9).

17. For Rear 3-1/4” x 10” rectangular installation only:

-

Remove the Rear Round Vent Cover and Rear
Rectangular Vent Cover (Refer to Figure 4). Keep
screws to attach Rectangular Exhaust Plate and
Rectangular Exhaust Adapter.

-

Place the Rectangular Exhaust Plate over vent and
secure with 2 screws (Refer to Figure 10). Place
Rectangular Exhaust Adapter over the Rectangular
Exhaust Plate and secure with 10 screws (Refer to Figure

10).

-

Use remaining screws to secure exhaust plate.

-

Remove the pre-installed Round Exhaust Plate from top
vent and keep screws (Refer to Figure 4). Use the Round
and Rectangular vent covers removed from rear to seal
top vent.

-

Remove the 4 screws that secure the blower system
(Refer to Figure 8). Hold the blower to keep it from
dropping as you remove screws. Keep screws to re­attach blower. Slowly rotate blower system to align with
mounting holes at the back of the insert. Secure the
blower using 4 screws (Refer to Figure 9).

: If moving the cooking range is necessary to

6

Figure 5

Figure 6

Figure 7

Figure 8

APPLICABLE NATIONAL AND LOCAL ELECTRICAL CODES.

Duct Work Installation

18. Determine and make all necessary cuts in the wall or ceiling
for the ductwork. Note: Install the ductwork before installing
the insert.

19. Use steel pipe to connect the exhaust on the hood to the
ductwork above. Use duct tape to make all joints secure and
air tight.

20. Please refer to local codes for the usage of a damper (not
included).

Wiring to Power Supply

SAFETY WARNING

RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE
PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY
QUALIFIED ELECTRICIAN IN ACCORDANCE WITH ALL

BEFORE CONNECTING WIRES, SWITCH POWER OFF AT
SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT
POWER FROM BEING SWITCHED ON ACCIDENTALLY.

21. Connect electrical wires.

22. Connect three wires (black, white and green) to house wires
and cap with wire connectors. Connect wires according to
their colors (i.e. black to black, white to white, and green to
green).

23. Store wires in the wiring box.

Hood Installation

NOTE: USE HAND TOOLS ONLY. DO NOT OVER TIGHTEN
SCREWS. IT MIGHT CAUSED DAMAGED TO THE HOOD.

24. Remove 10 screws located at the bottom of the insert (Refer to
Figure 11). Carefully remove the light support panel.

25. Position the insert inside the custom wood frame, and secure
the insert to the front and rear stud support ( Refer to Figure 2)
by using the front and rear mounting holes (Screws not
included).

26. For a more secure installation, use the mounting holes located
on the side of the insert

27. Make sure insert is secure before releasing.

28. Re-install the light support panel. (Do not over tighten screws.)

CAUTION

RELEASING.

: MAKE SURE HOOD IS SECURE BEFORE

7

Figure 9

Figure 10

Figure 11

Figure 12

Final Assembly

29. Install the oil tunnel into recess support near rear of hood.
Refer to Figure 12.

30. Install baffle filters. Angle baffle filter toward back of hood
①. Push baffle filter up until almost level ②. Slide forward
into recess behind the front of hood ③. Lower baffle filter ④
. Slide back until it fits into resting position ⑤. Refer to
Figure 13.

Figure 13

8

Delay Shut

-

Off

DDeellaayy SShhuutt--OOffff CCoonnttrrooll

OPERATING INSTRUCTIONS

This BRILLIA hood is equipped with five electronic push buttons with LED display, a wireless remote control, a double
horizontal squirrel cage blower with stainless steel baffle filters and two bright LED lights.

The five control buttons are Power Control (On/Off & 3-Minute Delay Shut-Off), Speed Control (High, Medium, Low &
QuietMode™), ECO Control, Timer Control and Light Control. Refer to Figure 14.

Figure 14

Note: For best results, turn the range hood to QuietMode™ prior to any preparation or cooking. Adjust speed as
needed.

Power Control

Press Power Control to turn On/Off the range hood. Hood will power on at Low speed.
Output Display:

3-Minute Delay Shut-Off Control

Delay Shut-Off Control powers down the range hood after 3 minutes. Press the Power Control to activate
Delay-Shut off. The Timer Indicator will automatically begin to count down from the default 3 minutes.
When the time is up, the unit will completely power off.

To bypass the 3-Minute Delay Shut-Off, press the Power Control again to completely power down the
unit.

Speed Control
(Each press of Speed Control will cycle the fan through Low, Medium, High and QuietMode™.)

Output Display will indicate:

= QuietMode™ Speed

= Low Speed

= Medium Speed

= High Speed

ECO Control

The ECO function is set to turn on the range hood on QuietMode™ setting for 10 minutes every hour
to remove excess moisture, microscopic particles and odors for better kitchen air quality.

ECO is independent from the power function.

To activate ECO when the unit is powered off, press the ECO Control. The ECO icon will be
displayed to show that it is active. To deactivate it, press the ECO Control again. The icon will turn off,
indicating it has been deactivated.

To activate ECO when the unit is powered on, press the ECO Control. The ECO icon will be
displayed to show that it has been activated. In order for ECO to take effect, the unit must be
turned off. If the fan is running, power it off by pressing the Power Control. The unit will automatically
shut down in 3 minutes. To power down immediately, Press the Power Control again to power down
the unit. Once the unit is powered off, the ECO icon will remain displayed, indicating that it is active.
To deactivate it, press the ECO Control again. The icon will turn off, indicating it has been
deactivated.

NOTE: Must open door or windows to create sufficient make-up air when ECO is operating.
Output Display when ECO is active:

Light Control

(Lights are controlled independently from Power Control. Turning the power off will not turn the lights off.)

Press Light Control to turn lights ON. Press Light Control again to DIM the lights. Press Light Control
again to turn lights OFF.

10

Timer Control

The Timer Control allows users to set their range hood to automatically turn off. The timer ranges from 1
min. to 99 mins.

To activate the timer, the fan must be on (High, Medium, Low, or QuietMode™). As the fan is running,
toggle the timer by pressing the Timer Control. The Timer Indicator will flash, indicating it is ready to be
set. Press the Timer Control to set desired time, starting from 1 min. up to 99 mins. When finished setting
time, the timer will begin to automatically count down.

Baffle Change Indicator

The display will indicate when baffle filter needs cleaning. Press and hold the Power Control for 5

seconds to reset the Baffle Change Indicator.

Remote Control
The six control buttons for the wireless remote control are Power Control (On/Off & 3 Minute Delay Shut-Off), Light

Control, ECO Control, Timer Switch Control and Speed Controls (High, Medium, Low & QuietMode™).

NOTE: Requires 2 AAA Batteries. Batteries not included.

Power Control

Press Power Control to turn hood ON and OFF. Hood will power on at Low speed.

3-Minute Delay Shut-Off Control

Delay Shut-Off Control powers down the range hood after 3 minutes. Press the Power Control to activate
Delay-Shut off. The Timer Indicator will automatically begin to count down from the default 3 minute
setting. When the time is up, the unit will completely power down. To bypass the 3 minute Delay Shut-Off,
press the Power Control again to completely power off the unit.

Light Control

(Lights are controlled independently from Power Control. Turning the power off will not turn the lights off.)

Press Light Control to turn lights ON. Press Light Control again to DIM the lights. Press Light Control
again to turn OFF lights.

Speed Control

Press the Speed Control to activate the fan. The fan will start on Low speed. Each press of the Speed
Control button will cycle through the various speeds.

Press to cycle from High, Medium, Low and QuietMode™
Press to cycle from Low, Medium, High and QuietMode™.

11

Press Power Control to activate 3-Minute Delay

Timer Control

While the fan is running, press the Timer Control to activate the Timer. The Time Indicator will flash,
indicating it is ready to be set. Use the arrow keys to set the desired time.

Press of will decrease the time by 1 minute. Each press of will increase the time by 1 minute.
When finished setting desired time, the timer will automatically begin to count down or press the Timer

Control to immediately begin the countdown.
If the timer is not set ( OR ) within 6 seconds, the unit will automatically exit Timer Control Mode

and arrow keys will return to speed function control.

ECO Control

To activate ECO when the unit is powered off, press the ECO Control. The ECO icon will be
displayed to show that it is active. To deactivate it, press the ECO Control again. The icon will turn off,
indicating it has been deactivated.

To activate ECO when the unit is powered on, press the ECO Control. The ECO icon will be
displayed to show that it has been activated. In order for ECO to take effect, the unit must be
turned off. If the fan is running, power it off by pressing the Power Control. Then press the Power
Control again to power down the unit. Once the unit is powered off, the ECO icon will remain
displayed to indicate that it is active. To deactivate it, press the ECO Control again. The icon will turn
off, indicating it has been deactivated.

12

MAINTENANCE

For optimal performance, clean the range hood surface and baffles regularly.

To Clean Hood Surface
CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS.

*** Regular care will help preserve its fine appearance.

1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth.

2. If hood looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the surface of the hood.
Avoid getting cleaning solution onto or into the control panel. Follow directions of the stainless steel
cleaner. Caution: Do not leave on too long as this may cause damage to hood finish. Use soft
towel to wipe off the cleaning solution, gently rub off any stubborn spots. Use dry soft towel to dry the
hood.

3. DO NOT allow deposits to accumulate or remain on the hood.

4. DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause
rusting.

5. DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with
stainless steel for extended periods. Many of these compounds contain chemicals, which may be
harmful. Rinse with water after exposure and wipe dry with a clean lint free cloth.

To Clean Baffle Filter/Oil Tunnel
CAUTION: DRAIN OIL FROM BAFFLE FILTER, SPACERS & OIL TUNNEL REGULARLY TO PREVENT

OVERFLOW.

1. Remove all the baffle filters, spacers and oil tunnel.

2. Using a sponge, wash with warm soapy water. Dry completely before returning into place.

CAUTION: SHARP EDGES
(Note: Baffle Filters are top rack dishwasher safe.)

13

SPECIFICATIONS

MODEL / SIZE OVS-INX2630SQB-600-40

COLOR Commercial Stainless Steel
CONSUMPTION / AMPERE 290W / 2.5A

VOLTAGE 120V 60Hz
NUMBER OF MOTORS 1

FAN TYPE: CENTRIFUGAL Double Horizontal Squirrel Cage
EXHAUST Top –

6” Round
3-1/4” x 10” Rectangular
Rear –
6” Round
3-1/4” x 10” Rectangular

CONTROLS 5 Push-Button with LED Display

- Timer Control

- 3-Minute Delay Shut-Off

- Wireless Remote Control

- ECO Control

LIGHTS LED Lights 3W x 2, Dual Level Lighting
HOOD DIMENSION

(W X D X H)
OPTIONAL ACCESSORIES

(W X D X H)

HOOD WEIGHT (lbs) Net Gross
OVS-INX2630SQB-600-40 42 52

Blower Air Capacity (cfm) QuietMode™ Low Medium High

Sone* 1.0 2 5.0 6.0

30” x 18-1/2” x 12”

2 Piece Adjustable Liner
Model No.: INL36252B
(34-7/16” x 23”~25-3/4” x 3”)

280 380 540 680

* One Sone is equivalent to 40 decibels.
**Specifications subject to change without notice.

14

MEASUREMENTS & DIAGRAMS

 All ( ) are in millimeter.
 All inch measurements are converted from millimeters. Inch measurements are estimated.

MODEL NO: OVS-INX2630SQB-600-40

Side View Bottom View

Back View Top View

15

Front View

Ajustable Stainless Steel Liner (Sold Separately)
Model No. INL36252B

16

PARTS LIST

NO. DESCRIPTION MODEL/SIZE PART NO.

1

Rectangular Exhaust Plate

2

Rectangular Vent Cover

3

Round Exhaust Plate

4

Rectangular Exhaust Adapter

5

Electric Component Support

6

Processor Board

7

Capacitor

8

Blower Bracket

9

Oil Tunnel IN2630SQB-700

10

Blower System

11

Bottom Casing

12

Baffle Filter Support

13

Stainless Steel Spacer

14

Baffle Filter

15

Control Unit Support

16

Control Unit

17

Light Panel Support

18

LED Light (3W)

Optional Adjustable Liner (Sold Separately)

19

Rear Section of Liner INL36252B

20

Front Section of Liner INL36252B

MODEL NO: OVS-INX2630SQB-600-40

B101-2630-17A
B101-2630-17B
B101-2630-16A
B101-2630-16B
L1-0201-2630
FA-18880-0401-B3
L1-0401-0120-01
L1-0105-2630
B101-2630-14A
40-L1-0302-A120-01
B101-2630-09
B101-2630-30
B101-2630-24
B101-2630-15
L1-0207-2630
FA-18880-0401-A3
B101-2630-06
L1-0403-0001

B103-2630-A
B103-2630-B

17

2

10

11

5

12

13

14

17

15

16

18

Optional Liner (Sold Separately)

19

20

1

3

4

6

7

8

9

18

CIRCUIT DIAGRAM

MODEL NO.: OVS-INX2630SQB-600-40

19

Issue

Possible Cause

Solution

TROUBLE SHOOTING

After Installation,
motor and lights
are not working.

Lights are
working, but
motor(s) is not.

Motor(s) is
working, but
light(s) is not.

The range hood
is vibrating.

The range hood
is not venting
out correctly.

Cold air is
coming into the

home.

The power is not on. Make sure the circuit breaker and the unit’s power is ON.

Use a voltage meter to check the power supply.
The wire connection is not secure. Check and tighten wire connection.
The control panel and processor board wiring
are disconnected.

The control panel and processor board is
defective.

The motor(s) is defective.
The capacitor(s) is defective.
The control panel or processor board is
defective.

Check wire continuity from control panel to processor

board.

Replace the control panel or processor board.

Replace the motor.

Replace capacitor(s).

Replace the control panel or processing board.
The LED light(s) is defective. Replace the LED light.

The LED light transformer is defective. Replace the LED light transformer.
The control panel or processor board is
defective.
The blower system is not secure.

The turbine impeller/squirrel cage is not
balanced.
Hood is not secured in place.

The range hood is installed outside of the
manufacture recommended clearance.

Replace the control panel or processing board.

Tighten the turbine impeller/squirrel cage and air

chamber.

Replace the turbine impeller/squirrel cage.

Check the installation of hood, tighten the mounting

bracket.

Adjust the clearance between the range hoods and

cook top to 27” to 30”. For Island range hood, the

clearance between the range hoods and cook top is

30” to 36”.
There is no make-up air inside the house. Open the window to enhance the performance of the

range hood by creating a sufficient make-up air.
Obstacle blocking the pipe work.

The pipe size is smaller than the
suggested pipe size.
The pipe connection is not properly sealed. Check the pipe installation.

The damper is not properly installed or is
missing from the installation.
The damper is not installed.

Remove all obstacles from the duct work.

Change the ducting according to the manufacture

suggestion.

Check the damper installation.

By installing the damper, it will help to eliminate air

backflow.

20

WARRANTY

WARRANTY CERTIFICATE

KOBE Range Hoods (referred to herein as “we”or “us”) warrants to the original purchaser
(referred to herein as “you” or “your”) all products manufactured or supplied by us to be free
from defect in workmanship and materials as follows:

TWO-YEAR LIMITED WARRANTY FOR PARTS AND LABOR ON KOBE
PREMIUM/BRILLIA SERIES:

For two years from the date of your original invoice from a KOBE authorized dealer, we will, at
our sole discretion, choose to repair or replace the product free of charge that failed due to
manufacturing defects.

It is your sole responsibility to ensure the product is readily accessible for the service
technician to perform repairs. The service technician will not, under any circumstance,

remove, alter or modify any fixture built around and/or connected to the product to gain
access to perform repairs.

During the two-year Limited Warranty period, additional charges may apply which include but
are not limited to:

• Service technician travel charges if the requested service location is 30-miles out of
KOBE’s authorized service area

• Parts shipping expenses

• Un-installation of defective product and Installation of replacement product

Warranty Exclusions:

This warranty does not cover, including but not limited to the following:

a. Improper installation.
b. Any repair, alteration, modification not authorized by KOBE.
c. Duct alteration, modification and connection.
d. Incorrect electric current, voltage or wiring.
e. Normal maintenance and service required for the product.
f. Consumable parts such as light bulbs and carbon filters.
g. Improper usage of the product that it is not intended for, such as commercial use,

outdoor use and multi-family use.

h. Normal wear and tear.
i. Chips, scratches or dents by abuse or misuse of the product.
j. Damages caused by accident, fire, flood and other Acts of God.
k. Expenses incurred for service located outside of the designated service area.
l. Purchases from unauthorized dealers.
m. Removal fees of defective product and Installation fees associated with replacement

product.

If we determine that the warranty exclusions listed above apply or if you fail to provide all
necessary documentation for warranty service, you will be responsible for all expenses
associated with the requested service, including parts, labor, shipping, travelling and any other
expense related to the service request.

21

To qualify for warranty service, you must:

1. Have the ORIGINAL proof of purchase

2. Be the ORIGINAL purchaser of the product

3. Have the model number

4. Have the serial number

5. Have a description of the nature of any defect in the product or part

TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS
SERVICE CENTER:

KOBE Service Center (USA Only)
Tel: [phone]-KOBE (5623)
E-mail: [e-mail]

For service in Canada or
To report a problem, please contact:
Tel: [phone]
Email: [e-mail]

22

WARRANTY INFORMATION FORM

Fill in the blanks and keep this paper with the original invoice in a
safe place for future service purpose.

1. Date of purchase :

2. Model No. :

3. Serial No. :

For warranty service or spare parts purchase contact:

KOBE Service Center (USA Only)
Toll Free: 1-855-800-KOBE (5623)
Email: [e-mail]

For service in Canada or
To report a problem, please contact:

Toll Free: 1-626-775-8880
Email: [e-mail]

Your notes:

23

This KOBE hood is made for use in the USA and CANADA only. We do not

recommend using this hood overseas as the power supply may not be

Using a KOBE

Unis et au Canada

seulement. Il n’est pas recommandé d’utiliser cette hotte à l’étranger puisque

patible et enfreindre le code de

à l’étranger est à votre

ha sido fabricada para ser utilizada

recomendamos la utilización de esta

campana en el extranjero debido a que la fuente de energía podría no ser

Utilizar una

en el extranjero será a su propio riesgo y anulará la

KOBE Range Hoods

11775 Clark Street

Arcadia, CA 91006 USA

http://www.KOBERangeHoods.com

compatible and may violate the electrical code of that country.

hood overseas is at your own risk and will void your warranty.

Cette hotte KOBE est fabriquée pour usage aux États­l’alimentation électrique pourrait ne pas être com

l’électricité de ce pays. L’usage de la hotte KOBE

propre risque et la garantie sera annulée.

Esta campana de extracción KOBE
únicamente en EE.UU. y CANADÁ. No

compatible y podría violar el código eléctrico de dicho país.

campana KOBE
garantía.

Information subject to change without notice.
VER 141128

24
