Knightsbridge VFRDGICC Installation Instructions

INSTALLATION & MAINTENANCE MANUAL

VFRDGICxx / VFRSGICxx / VFRSHGICxx

GENERAL INSTRUCTIONS

These instructions should be read carefully and retained after installation by the
end-user for future reference and maintenance.
These instructions should be used to aid the installation of the following
products: VFRDGICxx / VFRSGICxx / VFRSHGICxx

SAFETY

• This product must be installed in accordance with the latest edition of the IEE Wiring
Regulations (BS7671) and current Building Regulations. If in any doubt, consult a qualified
electrician

• Please isolate mains prior to installation or maintenance

• Please note the IP (Ingress Protection) rating of this fitting when deciding the

location for installation

• If used under insulation, the insulation should be laid unbroken over the fitting (not packed
around it). Only mineral wool style insulation may be used

• This product is Class I and must be earthed

• The VFRDGICxx and VFRSGICxx series is IP20 rated, the VFRSHGICxx

series is IP65 (IP20 from above)

INSTRUCTIONS – VFRxxxx

Part code

Cut-out

VFRDGICxx

72mm

VFRSGICxx

84mm

VFRSHGICxx

72mm

INSTALLATION

• Provide power to the required point of installation

• Cut a suitable hole in the mounting surface as per the cut-out details
(see Fig. 1) ensuring not to infringe with any joists, gas/water pipes or electrical cables

Part code Cut-out

VFRDGICxx 72mm

VFRSGICxx 84mm

VFRSHGICxx 70mm

Fig. 1

• Fold out the terminal bracket until it locks

into position (see Fig. 2)

Fig. 2

• Open the terminal access cover with the aid of a slotted screwdriver (see Fig. 3)

Fig. 3

• Connect the fitting to the mains supply ensuring that correct polarity is observed
(see Fig. 4): L - Live (Brown), E - Earth (Green/Yellow), N - Neutral (Blue)

Fig. 4

Replace Fig 4

Replace Fig 6

• Ensure the strain relief is used to secure the mains input cable

• Loop in/loop out wiring can be achieved with the push-fit terminal block

• Lift both spring clips on the sides of the fitting and push into the ceiling (see Fig. 5)

Fig. 5

• Remove the bezel by turning anti-clockwise 45°, insert a suitable GU10 lamp into the lock ring
lamp clip and connect a lamp to the lamp holder (see Fig. 6)

Fig. 6

• Push the lamp and lock-ring up into position in the body of the downlight and secure the

lock-ring by turning clockwise 45°

• For VFRSHGICxx series, please ensure both gaskets are in place. One gasket is

pre-installed with the bezel and the second gasket should be installed around the
base of the fitting (see Fig. 7)

• Switch on and check for correct operation.

Fig. 7

GENERAL

This product should be recycled in the correct manner when it reaches the end of its life.
Check local authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which
may damage the product.
This product is dimmable dependent on lamp type.

WARRANTY

This product has a warranty of 1 year from date of purchase. Failure to install this product
in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper
use, or removal of the batch code will invalidate the warranty. If this product should fail
within its warranty period, it should be returned to the place of purchase for a free of
charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML
Accessories reserve the right to alter product specification without prior notice.
