Knightsbridge TNXQUADMWEMW, TNXQUADMWEMBK, TNXONEMWEMBK, TNXONEMWEMW Installation Instructions

INSTALLATION & MAINTENANCE MANUAL

TNXQUADMWEMW / TNXQUADMWEMBK

TNXONEMWEMBK / TNXONEMWEMW

GENERAL INSTRUCTIONS

These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
TNXQUADMWEMW / TNXQUADMWEMBK / TNXONEMWEMBK / TNXONEMWEMW

SAFETY

• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker

• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation

• This product is Class II double insulated

• This product is IP65 rated

INSTALLATION

Note - Microwave sensors may not be suitable for all installations, for example enclosed spaces, as they are

able to detect movement through non-metallic surfaces like plasterboard and thin doors.

• Provide power to the required point of installation (refer to BS7671 for correct cabling methods). Suitable IP
rated junction boxes should be used where required

• Remove the diffuser from the luminaire housing by unscrewing the four screws

• Drill the fixing holes in the rear of the fitting. Mark the location of the fixing holes and drill ensuring not to
infringe with any gas/water pipes or electrical cables

• Feed the mains cable through the rubber grommet to retain IP rating, and secure the base to the surface
using the plugs and screws provided

• Ensuring correct polarity is observed, carefully wire as shown in Fig. 1. Two cables can be inserted into

INSTALLATION & MAINTENANCE MANUAL

(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician

the circuit cable, fuse or circuit breaker

Suitable IP rated junction boxes should be used where required

to infringe with any gas/water pipes or electrical cables

surface using the plugs and screws provided

the push-fit terminal block in order to achieve loop-in/loop-out wiring. The earth terminal is non-
functional and only provided for convenience

the push-fit terminal block in order to achieve loop-in/loop-out wiring. The earth terminal is non-functional

and only provided for convenience

Fig. 1

• The additional terminal L’ is the Slave Live, which enables the sensor to power on additional luminaires. A
max. 400W LED load can be controlled by the sensor

• Connect the battery to the inverter

• Choose the required driver output and colour temperature via the switches on the driver (see Fig. 2)

Fig. 2

• Attach the LED plate to the luminaire body by aligning the four butterfly screws on the body with the
corresponding holes on the plate then turn clockwise to lock into place (see Fig. 3)

Fig. 2

• Attach the LED plate to the luminaire body by aligning the four butterfly screws on the body with the
corresponding holes on the plate then turn clockwise to lock into place (see Fig. 3)

Fig. 3

SENSOR LAYOUT

Fig. 2

corresponding holes on the plate then turn clockwise to lock into place (see Fig. 3)

Fig. 3

SENSOR LAYOUT

DIP SWITCH LAYOUT

DIP SWITCH SETTINGS

Detection area

ON

1 2

ON ON 100%

ON - 75%

- ON 50%

- - 25%

Daylight sensor

ON

7 8 9

ON ON ON 2Lux

ON ON - 10Lux

- ON - 25Lux

ON - - 50Lux

- - - Disable*

Hold time

ON

3 4 5

ON ON ON 5S

ON ON - 30S

ON - ON 1min

ON - - 3min

- ON ON 5min

- ON - 10min

- - ON 20min

- - - 30min

* When set to disable, the daylight

sensor will switch the light
on when motion is detected
regardless of the ambient light
level

• Re-attach the diffuser to the luminaire body using the four screws

• Switch on and check for correct operation ensuring the green indicator LED is illuminated – it will flash
green if the battery is not connected, and is solid green to indicate that the battery is charging

• We recommend, on commissioning the installation, a minimum charge period of 24 hours before carrying
out an emergency duration test

WARNING

This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.

GENERAL

This product contains a light source of energy efficiency class D to Regulation (EU) No. 2019/2015 and (UK)
2021 No. 1095.
This product contains an LED light source which can be replaced by a professional and a control gear which can
be replaced by a professional.

Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
Do not use any source of high-pressure washers to maintain or clean this luminaire.
This product is non-dimmable.
This product should be dismantled for disposal when it reaches the end of its life. Please see website for

dismantling instructions.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist
The batteries in this luminaire are Lithium Ion and must be disposed of correctly. Please contact the local
authorities for the disposal of this toxic waste.

WARRANTY

This product has a warranty of 5 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.

TESTING FOR EMERGENCY LUMINAIRES

Recommended routine test procedure in accordance with BS5266:

• Daily check – check LED charge indicator is illuminated

• Monthly functional test - simulate a mains supply failure for approx. 30 seconds by operation of key switch
or switching off circuit breaker. Ensure normal supply is restored after test and ensure charge indicator is
illuminated

• Annual 3-hour duration test - simulate a mains supply failure for 3-hour continuous test by operation of key
switch or switching off circuit breaker. Ensure normal supply is restored after test and ensure charge indicator
is illuminated

• If the luminaire fails any of the above tests, please contact a qualified electrician. See below for test record
sheet

230V
50Hz

(UK) MANUFACTURER

ML ACCESSORIES LTD,

UNIT E CHILTERN PARK,

BOSCOMBE ROAD, DUNSTABLE

LU5 4LT,

WWW.MLACCESSORIES.CO.UK

IP65

SUPPLIED BY:

(EU) AUTHORISED REPRESENTATIVE

52531 ÜBACH-PALENBERG, GERMANY

-5~

°C

35

TA

02

SLV LIGHTING GROUP,

DAIMLERSTRASSE 21-23,

EMAIL: [e-mail]

MADE IN CHINA

DCFEB23_V1
