INSTALLATION & MAINTENANCE MANUAL
T02
Page 2
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following product:
T02
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this product is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
• Locate the transformer in a well ventilated area (do not cover with insulation) and keep as far away as
possible from any lamp or other source of heat
• Keep mains wiring away from contact with the transformer where possible
• This product is for indoor use only
• This product is Class II double insulated
• This product is IP20 rated
INSTALLATION
• Provide power to the required point of installation
• Connect the transformer to the mains supply using a suitable junction box, ensuring the correct polarity is
observed: L - Live (brown), N - Neutral (blue)
• Connect a suitable 12V halogen load to the secondary side of the transformer. The output cable may be
extended to a maximum of 2 metres
Page 3
• Switch on and check for correct operation
• The transformer will automatically shut off in the event of a short circuit, current overload, or thermal
overheating, and will reset once the cause of the fault has been removed
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the product.
The maximum constant ambient temperature at the point of installation should not exceed 50°C.
This product is dimmable, please check compatibility before installation.
This product should be recycled in the correct manner when it reaches the end of its life. Check local
authorities for where facilities exist.
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
Page 4
INTERNATIONAL
INTERNATIONAL
CONTACT DETAILS
INTERNATIONAL
CONTACT DETAILS
CONTACT DETAILS
ML Accessories Limited LU5 4LT
www.mlaccessories.co.uk
32
TA
50°C
DCJUN21_V2
