INSTALLATION & MAINTENANCE MANUAL
CL219xxx / CS219xxx / FP219xxx
SF219xxx
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
CL219xxx / CS219xxx / FP219xxx / SF219xxx
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this product is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
• Do not overload this accessory or subject it to conditions outside its rating (LED load 5 - 150W; incandescent
/ halogen load 10 - 200W; not suitable for fluorescent lamps)
• This product is for indoor use only
INSTALLATION
• Please check compatibility with intended load before installation. Ensure a mixed load is not selected, i.e.
incandescent mixed with LED. It is recommended to use lamps/luminaires of the same brand and type on
the same switch
• Ensure the wall surface is flat and smooth
• This unit is fitted with a gasket – this must not be removed: the gasket is to stop discolouration of the plate
due to natural moisture in some wall finishes. This product must be fitted only after painting and decorating is
complete
• Screwless products only - remove the front plate by placing a medium size flat-head screwdriver in the notch
at the side and lever off gently
• Connect for one-way control (Fig. 1) or two-way control (Fig. 2), ensuring the correct polarity is observed
(terminal positions may vary). Switched Live (blue) must have brown sleeving.
• Two-way switching with a dimmer can only be achieved when there is only one dimmer in the system. Twoway dimming cannot be achieved.
ONE-WAY DIMMING CONTROL
Fig. 1
TWO-WAY DIMMING CONTROL
Fig. 2
• For a multiple gang dimmer repeat the wiring method for each dimmer unit.
• All earth connections must be made and maintained. Use green/yellow sleeving on earth conductors that are
not insulated
• Check all electrical connections are secure with all exposed copper within the terminal and no loose strands
of cable
• Fit the unit into a suitable wall box taking care not to compress, damage or trap any cables, and secure with
the screws provided. If using metal mounting boxes with four lugs, remove the top and bottom lugs or bend
fully back
• Screwless products only - clip the front plate onto the main assembly ensuring the screwdriver notch is at
the side
• Switch on and check for correct operation
• A small audible buzz may be emitted when using certain products. This is normal but may be improved by
selecting the appropriate mode (see below)
DIMMING ADJUSTMENT
To restore factory settings:
1. Switch on the power and turn the dimmer to the minimum position (anti-clockwise)
2. Press the knob 8 times (roughly twice per second)
3. The unit will increase and decrease the brightness twice to indicate that the dimmer is in configuration mode,
it will then maintain a low illumination level or switch off
To adjust the minimum dimming level:
1. After restoring factory settings, slowly adjust the brightness to a suitable level
2. Press the knob 4 times (roughly twice per second)
3. The unit will increase and decrease the brightness once the adjustment is complete
To change between trailing-edge and leading-edge mode:
1. Switch on the power and adjust the dimmer knob to the maximum position (clockwise)
2. Press the knob OFF ON and wait for the lamp to reach full brightness; immediately repeat OFF ON another 4
times, waiting for the lamp to reach full brightness each time (total 10 presses). The load will come on, and
then dip once to indicate that the dimmer is in trailing-edge mode, or twice to indicate that it is in leading
edge mode
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product and invalidate the warranty.
WARRANTY
This product has a warranty of 2 years from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
230V
50Hz
(UK) MANUFACTURER
ML ACCESSORIES LTD,
UNIT E CHILTERN PARK,
BOSCOMBE ROAD, DUNSTABLE
LU5 4LT,
WWW.MLACCESSORIES.CO.UK
IP20
11
SUPPLIED BY:
(EU) AUTHORISED REPRESENTATIVE
SLV LIGHTING GROUP,
DAIMLERSTRASSE 2123,
52531 ÜBACHPALENBERG, GERMANY
EMAIL: EPRELGROUP.SLV.COM
MADE IN CHINA
DCJUN23_V1
