INSTALLATION & MAINTENANCE MANUAL
NSP1C / NSP3C / NSP4C
Page 2
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
NSP1C / NSP3C / NSP4C
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation
• This product is for indoor use only
• This product is Class I and must be earthed
• This product is IP20 rated
INSTALLATION
• Provide power to the required point of installation
• Remove the mounting bracket from the luminaire by removing the screws on the side
• Using the mounting bracket as a template, mark the location for, and drill the fixing holes ensuring not to
infringe with any gas/water pipes or electrical cables
• Fix the bracket using the screws provided
• Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown),
E - Earth (green/yellow), N - Neutral (blue) (see Fig. 1)
Page 3
Fig. 1
• Align the luminaire with the mounting bracket and refasten the screws
• insert suitable GU10 lamps
• Switch on and check for correct operation
WARNING
This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
This product is dimmable dependent on lamp type.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
Page 4
INTERNATIONAL
CONTACT DETAILS
INTERNATIONAL
CONTACT DETAILS
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
