INSTALLATION & MAINTENANCE MANUAL
MLRCTM2
Page 2
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following product:
MLRCTM2
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
• This product is for indoor use only
• This product is Class I and must be earthed
• This product is IP44 rated
INSTALLATION
Note - If this product is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires.
• Provide power to the required point of installation
• Remove the mirror from the base by unfastening the four screws on the sides
• Using the base as a template, mark the location for, and drill the fixing holes ensuring not to infringe with any
gas/water pipes or electrical cables (see Fig. 1)
Page 3
Fig. 1
• Feed the mains cable through the rubber grommet on the rear of the fitting to retain IP rating
• Ensuring the pullcord is at the bottom, secure the base to the surface using the screws, washers and wall
plugs provided
• Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown),
E - Earth (green/yellow), N - Neutral (blue)
• Refasten the mirror to the base ensuring to align the cut-outs for the shaver socket and pullcord
• Switch on and check for correct operation
Page 4
WARNING
This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
This product contains a light source of energy efficiency class D to Regulation (EU) No 2019/2015.
This product contains an LED light source and a control gear which can be replaced by a professional.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product. A glass cleaning solution may be used on the mirror surface.
This product is non-dimmable.
This product should be dismantled for disposal when it reaches the end of its life. Please see website for
dismantling instructions.
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.
Page 5
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
Page 6
INTERNATIONAL
INTERNATIONAL
CONTACT DETAILS
INTERNATIONAL
CONTACT DETAILS
CONTACT DETAILS
ML Accessories Limited LU5 4LT
www.mlaccessories.co.uk
101
DCJUL21_V1
