INSTALLATION & MAINTENANCE MANUAL
LEDBAT9 / LEDBAT17
LEDBAT22 / LEDBAT26
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
LEDBAT9 / LEDBAT17 / LEDBAT22 / LEDBAT26
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation
• This product is for indoor use only
• This product is Class II double insulated
• This product is IP20 rated
INSTALLATION
Note - If this product is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires.
• Provide power to the required point of installation
• Mark the location of the fixing holes for the mounting clips. The mounting clips should be spaced so as to
distribute the weight of the luminaire evenly
• Drill the holes for the mounting clips ensuring not to infringe with any any gas/water pipes or electrical cables
