INSTALLATION & MAINTENANCE MANUAL
230V
50Hz
IP
54
LANT3x / LANT4x
02
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end user for future
reference and maintenance.
These instructions should be used to aid installation of the following products:
LANT3 / LANT3W / LANT4 / LANT4W
SAFETY
• Installation of this luminaire should only be carried out by a qualified electrician or competent
person to the latest Building and current IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress of Protection) rating of this luminaire when deciding the location for
installation
• This product is Class II double insulated
• This product is non-dimmable
• This product is IP54 rated
INSTALLATION
• Provide power to the required point of installation. Suitable IP rated junctions boxes should be used
where required
• Remove the 2 screws on the front of the luminaire (see Fig 1)
Fig 1
Remove screws
from these locations
• Using the baseplate as a template, mark the location of the
fixing holes, and drill the holes ensuring not to infringe with
any joists, gas or water pipes or electrical cables
• Feed the mains cable through the rubber grommet to retain
the IP rating and secure the baseplate to the desired surface
Connect Live (brown) and Neutral (blue) to the 2-way
terminal block (see Fig 2)
