Knightsbridge BL01BK Installation Instructions

INSTALLATION & MAINTENANCE MANUAL

BL01BK

GENERAL INSTRUCTIONS

These instructions should be read carefully and retained after installation by the
end user for future reference and maintenance.
These instructions should be used to aid installation of the following product:
BL01BK

SAFETY

• This product must be installed in accordance with the latest edition of the IEE Wiring
Regulations (BS7671) and current Building Regulations. If in any doubt, consult a
qualified electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this product is fitted) does not exceed
the rating of the circuit cable, fuse or circuit breaker

• Please note the IP (Ingress Protection) rating of this product when deciding the location
for installation

• This product is Class I and must be earthed

• This product is IP44 rated

INSTALLATION & MAINTENANCE MANUAL

INSTALLATION

• Provide power to the required point of installation (refer to BS7671 for correct cabling
methods). Suitable IP rated junction boxes should be used where required

• Round cable should be used for the mains supply. The use of flat cable will cause water
ingress to the fitting

• Carefully remove the fascia and glass from the luminaire housing by unfastening the two
screws on the front (see Fig. 1)

Fig. 1

• Cut a suitable recess in the mounting surface, mark the location of the fixing holes, and
drill the holes ensuring not to infringe with any gas/water pipes or electrical cables

• Feed the mains cable through the rubber grommet to retain IP rating and secure the
luminaire housing into the hole using the plugs and screws provided. Rubber washers or
sealant should be applied around the screw heads to prevent water ingress. Mortar
around the luminaire housing if necessary and allow to set before continuing

• Connect the luminaire to the mains supply ensuring the correct polarity is observed:
L – Live (brown), E – Earth (green/yellow), N – Neutral (blue). Oversleeving is provided to
help protect the incoming mains cable. The cable and terminal block should be kept away
from the lamp to prevent heat damage

• Insert a suitable E27 lamp (not included), max. 40W

• Refasten the glass (frosted side in) and chosen fascia ensuring the gasket is in place and
a tight seal is made

• Switch on and check for correct operation

• Should the protective glass be cracked or damaged it should be replaced immediately

• This fitting must not be used without the protective glass installed

WARNING

This product must be disconnected from the circuit if subjected to any high voltage or
insulation resistance testing. Irreparable damage will occur if this instruction is not followed.
This product is not suitable for direct installation in the ground, nor in a retaining wall where
the ground behind may become saturated.
This product is not suitable for installation in or near a coastal or marine environment.

GENERAL

Clean the external surfaces with a damp cloth using a mild solution of detergent and warm
water only, do not use aggressive cleaning products or solvents which may damage the
product.
Do not use any source of high-pressure washers to maintain or clean this luminaire.
This product is dimmable dependent on lamp type
This product should be recycled in the correct manner when it reaches the end of its life.
Check local authorities for where facilities exist.

WARRANTY

This product has a warranty of 1 year from date of purchase. Failure to install this product
in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper
use, or removal of the batch code will invalidate the warranty. If this product should fail
within its warranty period, it should be returned to the place of purchase for a free of
charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML
Accessories reserve the right to alter product specification without prior notice.
