INSTALLATION & MAINTENANCE MANUAL
BATS2 / BATS4 / BATS5 / BATS5H
BATS6 / BATS6H / BATS5UHL / BATS6UHL
Page 2
GENERAL INSTRUCTIONS
These instructions should be read carefully and retained after installation by the
end user for future reference and maintenance.
These instructions should be used to aid installation of the following products:
BATS2 / BATS4 / BATS5 / BATS5H / BATS6 / BATS6H / BATS5UHL / BATS6UHL
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring
Regulations (BS7671) and current Building Regulations. If in any doubt, consult a
qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed
the rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location
for installation
• This product is for indoor use only
• This product is Class I and must be earthed
• This product series is IP20 rated
Page 3
Squeeze
INSTALLATION
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please
confirm with the manufacturer of the sensors that they are compatible with LED luminaires.
• Provide power to the required point of installation (refer to BS7671 for correct cabling
methods)
• Squeeze the sides and hinge the diffuser away from the fitting (see Fig. 1)
• Mark the location of the fixing holes and drill the holes
ensuring not to infringe with any gas/water pipes or
electrical cables. The fitting can also be mounted over
conduit boxes: for distance between fixing centres
please see below:
Fig. 1
Part Code Distance (mm)
BATS2 415
BATS4 600
BATS5 / BATS5H / BATS5UHL 600
BATS6 / BATS6H / BATS5UHL 600
Page 4
• Ensuring correct polarity is observed, carefully wire as shown in Fig. 2. Two cables can be
Distance (mm)
415
600
600
600
Squeeze
inserted into the push-fit terminal block in order to achieve loop-in / loop-out wiring
Fig. 2
• Switch on and check for correct operation
WARNING
This luminaire must be disconnected from the circuit if subjected to any high voltage or
insulation resistance testing. Irreparable damage will occur if this instruction is not followed.
GENERAL
This product contains a light source of energy efficiency class E (BATSx, BATSxH) /
D (BATSxUHL) to Regulation (EU) No. 2019/2015.
This product contains a non-replaceable LED light source and a control gear which can be
replaced by a professional.
Page 5
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which
may damage the product.
This product is non-dimmable
This product should be dismantled for disposal when it reaches the end of its life. Please
see website for dismantling instructions.
This product should be recycled in the correct manner when it reaches the end of its life.
Check local authorities for where facilities exist.
WARRANTY
This product has a warranty of 5 years from date of purchase. Failure to install this
product in accordance with the current edition of the IEE Wiring Regulations (BS7671),
improper use, or removal of the batch code will invalidate the warranty. If this product
should fail within its warranty period, it should be returned to the place of purchase for
a free of charge replacement. ML Accessories does not accept responsibility for any
installation costs associated with the replacement product. Your statutory rights are not
affected. ML Accessories reserve the right to alter product specification without prior notice.
Page 6
INTERNATIONAL
INTERNATIONAL
CONTACT DETAILS
INTERNATIONAL
CONTACT DETAILS
CONTACT DETAILS
ML Accessories Limited LU5 4LT
www.mlaccessories.co.uk
52
-20~
50°C
TA
DCAUG21_V3
