Welcome!
This is the user manual for Modley, a multi-effect delay plug-in effect available for iPad (AUv3) and
Mac & Windows (AU/VST/AAX). It has been designed and developed by Klevgrand, a small studio
in Stockholm, Sweden. Modley is a modulation delay with effect insert capabilities, which lets you
design the whole delay signal with several carefully selected effect modules, to create unique
signal flows.
Get the iOS version at the App Store
Get the AU / VST / AAX version at klevgrand.se
LICENSING (DESKTOP ONLY)
Until unlocked, the plug-in will output 1 second of silence now and then. To unlock the full version,
click the Authorize label (bottom right corner) and type/paste your license key.
Basic concepts
Modley consists of three effect racks - Pre, Loop and Post. Each rack has four slots where effect
modules can be inserted. Depending on where an effect is inserted, it will process the audio in
different stages of the chain. Depending on what the Feedback parameter is set to, a certain
amount of the signal from the Loop rack’s output will loop back to its input.
klevgrand.se
MODLEY – DOCS ( / )1 8
© 2019 Klevgränd Produkter AB
Modley
Multi effect delay
CAUTION!
The flexibility of Modley makes the delay loop sensitive for self oscillation.!
Be careful when adjusting the insert parameters in the loop.
Pre rack
Applies effects before
the delay loop.
Loop rack
Applies effects to the
delay loop. Those effects
will be applied to the
input signal each delay
bounce.
Post rack
Effects after the delay
delay loop.
Feedback
User Interface
1. PRE RACK
Inserted effects will be processed once from left to right, before entering the loop rack
2. LOOP RACK
Inserted effects will be processed from left to right. The feedback control (8) sets the amount of
signal to be routed back from the loop output to the input.
3. POST RACK
Inserted effects will be processed from left to right after leaving the loop rack.
4. EFFECT SLOT
Press the hamburger icon (𑁔) to select an effect to insert. To remove an effect, select the topmost
item EMPTY from the list. To change position of an insert, press and drag anywhere on the insert
where there are no interactive items. All inserts can be bypassed using the bypass switch to the
top left on each insert.
5. PRESET
Click to open a popup window with selectable presets, or step with the arrow buttons.
6. DELAY TIME
Controls the overall delay time, applied before entering each loop.
7. SYNC
Delay time as note values (synced to the host’s BPM)
klevgrand.se
MODLEY – DOCS ( / )2 8
© 2019 Klevgränd Produkter AB
56789101113121234
8. FEEDBACK
Sets the amount to be re-routed from the loop rack’s output to its input. A high feedback can
quickly increase the signal, so be careful.
9. FREEZE
Freezes the current delay signal.
10.FREEZE MODE
Pre
Freezed signal is fed through the loop rack chain.
Post
Freezed signal is not processed by the rack chain.
11.MODULATION
Mix
The level of the delay modulation
Depth The depth of the delay modulation
Freq The speed of the delay modulation
12.LIMITER THRESHOLD
Sets the output limiter threshold
13.MASTER MIX
Dry/Wet mix
Inserts
Each effect rack provides 4 slots with selectable effects, processed from left to right. It is possible
to change the order of the effects within the rack, and they all can be bypassed. You can use
automation for all of the effects, and their parameters are named with convention ”[Rack name]
Slot [Slot] param [Parameter index]” for example ”Pre Slot 1 param 1”.
COMPRESSOR
Simple one-knob compressor with the ability to switch between
fast and slow attack and release.
Fast/Slow
Swaps between fast and slow compressor settings.
Sustain
Amount of compression
Output
Output level
klevgrand.se
MODLEY – DOCS ( / )3 8
© 2019 Klevgränd Produkter AB
PANNER
Modulates the left/right stereo position.
Pan
Left right position
Rate
Modulation speed
Width
Depth of modulation
Waveform
Sinewave or square wave modulation
Sync
Sync to host
DELAY
A stereo delay with highpass and lowpass filtering and sync.
LP
Lowpass filter frequency
HP
Highpass filter frequency
Time
Delay time
Feedback
Feedback amount
Sync
Sync to host bpm
PHASER
A flexible phaser effect
Freq
LFO Speed
Depth
LFO Amplitude
Center
Center frequency
Feedback
Wet feedback level
Mix
Dry / Wet mix
Stages
Number of stages to be used
klevgrand.se
MODLEY – DOCS ( / )4 8
© 2019 Klevgränd Produkter AB
CHORUS
Stereo
Stereo width
Mix
Dry / Wet mix
Speed
LFO Speed
Amount
Wet signal max offset time amount
REVERB
Simple but good sounding reverb.
Damping
Damping amount
Mix
Dry / Wet mix
Width
Stereo width
Size
Room size (Decay time)
VIBRATO
Alters pitch controlled by an LFO. The LFO signal can be skewed
and have an offset phase on the right channel.
Duty
Alters the shape of the LFO
Phase
Right channel phase offset
Freq
LFO Speed
Depth
Amount of vibrato.
PITCHER
A rough pitch shifter
Pitch
Pitch shift amount
Gain
Gain adjust"
klevgrand.se
MODLEY – DOCS ( / )5 8
© 2019 Klevgränd Produkter AB
TREMOLO
Alters volume controlled by an LFO. The LFO signal can be skewed
and have an offset phase on the right channel.
Duty
Alters the shape of the LFO
Phase
Right channel phase offset
Depth
LFO Amplitude
Freq
LFO Speed
Sync
Sync to host bpm
EQUALIZER
An equalizer with low cut, high cut and 2 shelf filters.
Lo cut
Low cut frequency (20 to 120 Hz)
Lo shelf
Low shelf frequency (80 to 500 Hz)
Lo gain
Low shelf gain (-24 to 24 dB)
Hi shelf
High shelf frequency (1.6 to 18 kHz)
Hi gain
High shelf gain (-24 to 24 dB)
Hi cut
High cut frequency (7.5 to 20 kHz)
FLANGER
Feedback
Wet feedback level
Ton e
LP Filter frequency
Mix
Dry / Wet mix
Speed
LFO Speed
Amount
Wet signal max offset time amount
klevgrand.se
MODLEY – DOCS ( / )6 8
© 2019 Klevgränd Produkter AB
BOOSTER
Boosts the signal by adding bass, treble and/or gain.
Bass
Bass boost amount
Treble
Treble boost amount
Boost
Gain boost amount
DISTORTION
A distortion effect that distorts in several stages, mixing tube
saturation and soft clippping.
Ton e
High shelf filter with attenuation
Output
Output level
Drive
Amount of distortion
TAPE SATURATION
Quality
Frequency response control
Gloss
Saturation character
Input
Input level
Output
Output level
Mix
Dry / Wet mix
FILTER
A classic resonant low/high-pass filter with selectable orders
Type
Lowpass or highness
Orders
Filter steepness
Frequency
The cutoff frequency
Resonance
Resonance amount
klevgrand.se
MODLEY – DOCS ( / )7 8
© 2019 Klevgränd Produkter AB
MULTIBAND GATE
A four band spectral gate with fixed attack times.
Thrs Bass
Bass threshold level
Thrs Low Mid
Low mid threshold level
Thrs High Mid
High mid threshold level
Thrs Treble
Treble threshold level
Release
Release time coefficient (each band has different release times, and this parameter affects those
relatively)
Specifications / System requirements
Mac
Windows
iOS
64 bit AU/VST/AAX plug-in
64 bit VST/AAX plug-in
AUv3 plug-in
macOS 10.9+
OpenGL
Windows 7+ with SP1 or higher
iPad Air 2 or better
iOS 9.1+
klevgrand.se
MODLEY – DOCS ( / )8 8
© 2019 Klevgränd Produkter AB
