KJB PV-PH10W Quick Guide

Searching P2P

1. Names and Parts 2. Package Content

WVGA (Wi-Fi ON) (IR ON)110min

Physical

Built-in Camera Module

Video Spec.

Misc.

Power

Wi-Fi Spec.

Storage & I/O

5. LED Indicators

OFF/ON OFF/IR

54

2

1

6

3

1. Camera Lens

2. IR LED

3. Power Switch

4. Wi-Fi Switch

8. Reset Buon

9. Format / Defaults Buon

10. USB Port

11. Charging LED (Green)

5. IR LED Switch

6. Holding Grip Release Buon

12. Rec LED (Red)

7. Memory Card Slot

※ Do not remove serial number scker!

Warranty is invalid if the scker is tampered.

7

Reset

8

Format

Defaults

9

10

11

Power LED (Blue)

Wi-Fi LED (Orange)

12

OFF/ON OFF/IR

PV-PH10W

1080p Phone Holder Wi-Fi DVR

Quick Guide

M/C OFF/IN

LawMate, innovation never stops

®

V1.0

User Manual

Memory Card

Phone Holder

Phone Holder DVR

USB Cable

(No Recorder)

Sucon Mount

3. Baery Charging

Plug the micro USB end of cable into and plug the other

end to an USB charger. Aer charging is complete, insert the

memory card into . The device will be ready

7

for further operaons.

●

Solid green LED - charging.

●

Green LED goes off - fully charged.

※ Note: Device cannot be powered on

if no memory card is inserted.

10

10

Format

7

Reset

Defaults

4. Format Memory Card

4.1 Insert the memory card into .

4.2 Press and hold on , then turn on the device.

9

4.3 The device will power off automacally when the memory
card is formaed successfully.

7

Lock

Adapter

Solid blue LED Power On
Solid red LED Recording On

4GB

Blinking red LED Memory Card Full
Solid orange LED P2P Connected
Blinking orange LED
Solid green LED Device Charging

6. Operaon

6.1 Power on

Slide to the right to turn on the device.

6.2 Recording

The device will start recording automacally aer power is on.

6.3 Recording Mode

The device will always record in connuous mode. To switch
to Moon Detecon Mode, please operate in PV Cam Viewer

APP.

6.4 Power off

Slide to the le to turn off the device.

6.5 Reset

When the device funcons abnormally, press .

6.6 IR LED

Switch to “IR” to turn on the IR LED and switch to “OFF”
to turn off the IR LED.

3

3

8

5

1 2 3

6.7 Wi-Fi:

Switch to “ON ” to turn on Wi-Fi funcon and switch to
“OFF” to turn off Wi-Fi. Follow the instrucons in PV Cam
Viewer Quick Guide. The orange LED will be solid on when

connected to Wi-Fi.

4

6.8 Defaults:

6.8.1 To restore Wi-Fi password and SSID, turn on the device,
press and hold for at least 3 seconds and then let go.
The red and orange LED will turn on and then off.

6.8.2 To restore all default sengs, turn on the device, press
and hold for at least 10 seconds and then let go. The

9

red and orange LED will turn on and then off.

9

10. Specificaon

Built-in Image Sensor 1/3" progressive CMOS sensor
Sensor Resoluon 2304x1536
Sensor Sensivity 3.3 Lux @ F 2.0 (IR OFF)
Lens F/No. F3.2
Focal Length 4mm
Angle of View 66°

Algorithm H.264
File Format MOV
Video Recording Mode Manual
Recording Capability 1920x1080
Frame Rate Up to 30 fps
Photo Capability 5M (2952x1944)

Wi-Fi Built-in Wi-Fi Module (IEEE 802.11b/g/n)
Wi-Fi Protocol RTSP

PV-PH10W

1080p Phone Holder Wi-Fi DVR

Quick Guide

OFF/ON

OFF/IR

7. Download Videos and Photos

7.1 Video and photo files are stored in the memory card.

7.2 There are two ways to download video / photo files.

7.2.1 Use memory card reader to download video / photo
files.

7.2.2 With the device powered on and memory card inserted,
connect the device to PC by USB connecon. It will be
recognized by PC as an external drive for use to
download the video recordings and photo files.

8. Date and Time Seng (for Windows System)

Please refer to the :Synchronize the Time” steps on the PV Cam

Viewer for Wi-Fi Cam Quick Guide.

9. Others

Please note that when you enable the IR LED, the image color will

turn black and white immediately.

4 5

Memory Type Memory Card (Support up to
Data Interface Mini USB 2.0

Date/Time Table YYYY/MM/DD, HH:MM:SS
Snapshot recording and playback video (via smartphone)

Power Input DC 5V
Power Consumpon 350mA-380mA (IR OFF) (IR ON+330mA)(Wi-Fi OFF) (Wi-Fi ON+80mA)
Charging Time 120 min (800mA)
Baery Input DC 3.7V / 1350 mA high polymers baery (XK384085)

1080P (Wi-Fi OFF) (IR OFF)180min
1080P (Wi-Fi ON) (IR OFF)150min
1080P (Wi-Fi OFF) (IR
1080P (Wi-Fi ON) (IR ON)80min
720P (Wi-Fi OFF) (IR OFF)195min

Baery Lifeme

Recording Time 160min @ 1920x1080 resoluon (16GB memory card)

Dimension 110x105x36 (mm)
Weight 117g

720P (Wi-Fi ON) (IR OFF)165min
720P (Wi-Fi OFF) (IR ON)115min
720P (Wi-Fi ON) (IR ON)95min
WVGA (Wi-Fi OFF) (IR OFF)210min
WVGA (Wi-Fi ON) (IR OFF)180min
WVGA (Wi-Fi OFF) (IR ON)130min

32GB)

ON)100min

LawMate, innovaon never stops

®

V1.0
