KJB C1562 Specsheet

Item Number: C1562

Air Purifier Camera for
Zone Shield®
QUAD/QUAD LCD

Images:

Product Features:

• Easy Remote view with no IP Set-up Required

• Connect and Record up to 4 cameras with Quad View

• Get 64 plus hours of recording time with 32Gb SD card

• Wireless transmission up to 700 feet with no interference

• RCA and USB Compatible

• Optional Built-in Screen with QUAD LCD models

• Add a Night Vision hidden camera for after dark recording

Product Specs:

• Camera Specs:

• Image Sensor: 1/4" micron sensor

• Resolution:740x480 pixels

• Video System: NTSC

• White Balance: Auto Tracking

• S/N Ratio: >45 db

• Sensitivity:>11.5V/lux-s @550nm

• System Requirements:

• Microsoft Windows XP or Windows 7 (.NET Framework 3.5 higher)

• Display card: Independent display card and support DirectX 9.0 or
higher

• Internet Explorer 8 or higher

• Memory: 1GB

• CPU: 2.0GHz or higher(only support x86 and x64)

• Transmitter

• Channels Hopping: 24 channels

• Frequency: 2408.625 ~ 2470.5 MHz

• Power Consumption: 12V 270mA (with camera) 12V 120mA (w/o
camera)

• Power: 12V

• Resolution / Frame Rate: 640x480@30fps

• Transmission distance: 150M (line of sight)

Product Includes:

• Covert Camera and Wireless Transmitter
