KJB C1176 Specsheet
Earphone-Style Wired CCD Camera (Item: C1176)
Miniature-sized earphone-type wired camera, for covert surveillance
application use. Features a high-resolution camera and a low-power
consumption CMOS camera. The Earphone-Style Wired CCD Camera
is compatible with our line of portable DVR units, includin
• High resolution at 640x480
• Low power consumption
• Angle of view 66.5 degrees
• Video System: NTSC & PAL
• Video Size: 640x480
• Resolution: 480 TV lines
• Image Sensor: CMOS 1/4 inch
• Min Illumination: 3 LUX / 30 IRE @ F2.0
• Video Output: 1.0V p-p Composite at 75 ohm
• Lens: 3.59mm
• Angle of View: 66.5 degrees
• Power Supply Voltage: DC 5V
• Power Supply Current: 10mA
• Dimensions: 0.7L� 0.9�W x 1.0�H
• Camera Weight: 0.88oz
• Switching Cables
• Battery Holder (9V � Not included)
