KitchenAid WAR488BSL Installation Manual

C O M P A C T

R E F R I G E R AT O R

U s e & C a r e G u i d e

For ques tions about features , operation/performanc e, p arts or s ervice,

ca ll: 1- 866- 568-0386 in the U.S ; in C anada , 1- 866- 457- 1539 .

ww w.w hirlp ool. co m or www.whirlpo ol.c a

or visit our webs ite at...

R E F R I G E R AD OR

C O M P A C T O

M a n u a l d e u s o y c u i d a do

P ara c onsu ltas sobre c arac terísticas , op eración/des empeño, partes o s ervicio,

llame al: 1-86 6-56 8-03 86 e n EE .U U. o 1- 866- 457- 1539 en C ána da.

o visite nues tro s itio de internet e n...

ww w.whirlpo ol.c om

WAR 488B S L

R É F R I G É R A T E U R

C O M P A C T

G u i d e d’u t i l i s a ti on et d ’en t r et i en

Au C anada , p our as sis tanc e, c ompos ez le 1- 866 -56 8-0 386

ou visitez notre s ite web à...

ww w.w hirlp ool. ca

Table of C ontents/Índice/Table des ma tières .. .. .. . 2

T a b l e of C on t e n ts / Í n d i c e / T a bl e des ma t i èr es

AS S IS TAN CE OR S E R VIC E .... ... ... ......... ..... .... 2

R E FR I GE R AT OR SAF E TY . ... ...... .... ... ... .... ... .... 2

IN STAL LAT ION INS TR U CTIO NS ... ... ... ... ... ... . 3

R E FR I GE R AT OR US E ... .... ... ... ... .... ... .... ... ... .... 6

R E FR I GE R AT OR FE ATUR E S .... ... .... ... .... ... ... . 6

DO OR FE AT UR E S .... ..... ...... ... ... ... ... ... ... ... ... ... . 7

R E FR I GE R AT OR C AR E .. ... ... .... ... .... ... .... ... .... .. 7

TR OU B LE S HO OTIN G.. ... ......... ..... ...... ... ... ... ... . 9

WAR R ANTY ...... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... . 10

AY UD A O SE R VIC IO TÉ C NIC O ... ... ...... ..... ... 11

S EGUR IDAD DE L R E FR IGE R ADO R . ... ... ... .. 11

IN STR UC C IO NE S D E INS TA LAC IÓN ... ... ... . 12

US O DE S U R E FR IG E RAD OR . ... .... ... ... .... ... . 1 5

C AR AC TE R ÍS T IC AS D EL R E F RIG E RAD OR 15

C AR A CTE R ÍS TIC AS D E L A PU E R TA .. ... ... .. 16

C UIDA DO D E S U R E FR IG ER ADOR . ... ... ... ... 16

S OL UC IÓ N DE P R OB L EMAS .... ... ... ... ... ... ... . 18

GAR A NT ÍA ... ... ... ... ... ... ... ... ... ... ... ... ... ...... ..... .... 19

A s s i s t a n c e o r S e r v i c e

If you need assistanc e or servic e, first see the “Troubleshooting” sec tion. Additional help is available. C all us at 1-866- 568-0386 from anywhere in the U.S .A. In C anada, call 1-866- 457- 1539.

K ee p this boo k and your s a le s s lip together for future referenc e. You mus t pro vide proof o f purcha se or ins talla tion da te for in-warranty s ervic e.

Write down the following information a bout your appliance to help you obtain as s istanc e or service if you ever need it. You will need to know your c omplete model number and serial number. You c an find this information on the model and serial number plate, located on the back, top, left-hand corner of the refrigerator.

AS S IS T ANC E OU S ER VIC E . .... ... .... ... ... .... ... . 20

S ÉC UR ITÉ DU R É FR IGÉ R AT EU R .... ... ... ... ... 20

IN ST R UC TIO NS D ’IN S TA LL AT IO N... .... ... ... . 2 1

UTIL IS AT ION DU R É FR IG É RATE UR .. ... ... ... 24

C AR AC TÉ RIS TIQUE S

DU R É FR IG ÉR AT EUR .... ...... ... ... ... ... ... ... ... ... . 24

C AR AC TÉ R IS TIQ UE S DE L A P OR TE .. ..... ... 25

E NT R ET IE N DU R É FR IG ÉR AT EUR ... ... ... ... . 25

DÉ P ANNAG E .... ... ... ... ...... ... ...... ........... ...... ... .. 27

GAR A NT IE . ... ...... ..... .... ..... ...... ... ... ... ... ... ... ... ... 28

De ale r nam e____________________________________________________

S erial numb er __________________________________________________

Addr es s ________________________________________________________

P ho ne number __________________________________________________

Model num ber __________________________________________________

P urc has e da te __________________________________________________

R E F R I G E R AT O R S A F E T Y

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

You can be killed or seriously injured if you don't immediately

DA N G E R

WA R N I N G

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

IM P OR TAN T S A F E T Y I NS T R UC T IO NS

WAR NIN G:



P lug into a grounded 3 prong outlet.



Do not remove ground prong.



Do not us e an adapter.



Do not us e an extens ion cord.



D isconnec t power before s ervicing.



R eplac e all parts and panels before operating.

To reduce the ris k of fire, elec tric shock, or injury when us ing your refrigerator, follow these ba s ic prec autions :

S A VE T HE S E I NS T R U C T I ON S

follow instructions.

can be killed or seriously injured if you don't

You instructions.



R emove doors from your old refrigerator.



Use nonfla mmable cleaner.



K eep flammable materials and vapors , such as gasoline, away from refrigerator.



Use two or more people to move and install refrigerator.

Proper Disposal of Your Old Refrigerator

WARNING

Suffocation Hazard Remove doors from your old refrigerator. Failure to do so can result in death or brain damage.

IMPORTANT: Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators are still dangerous – even if they will sit for “just a few days.” If you are getting rid of your old refrigerator, please follow these instructions to help prevent accidents.

INSTALLATION INSTRUCTIONS

Before You Throw Away Your Old Refrigerator or Freezer:

■ Take off the door.

■ Leave the shelves in place so that children may not easily

climb inside.

Unpack the Refrigerator

WARNING

Excessive Weight Hazard

Use two or more people to move and install refrigerator.

Failure to do so can result in back or other injury.

Remove the Packaging

■ Remove tape and glue residue from surfaces before turning

on the refrigerator. Rub a small amount of liquid dish soap over the adhesive with your fingers. Wipe with warm water and dry.

■ Do not use sharp instruments, rubbing alcohol, flammable

fluids, or abrasive cleaners to remove tape or glue. These products can damage the surface of your refrigerator. For more information, see “Refrigerator Safety.”

■ Dispose of/recycle all packaging materials.

When Moving Your Refrigerator:

Your refrigerator is heavy. When moving the refrigerator for cleaning or service, be sure to protect the floor. Always pull the refrigerator straight out when moving it. Do not wiggle or “walk” the refrigerator when trying to move it, as floor damage could occur.

Important information to know about glass shelves and covers:

Do not clean glass shelves or covers with warm water when they are cold. Shelves and covers may break if exposed to sudden temperature changes or impact, such as bumping. For your protection, tempered glass is designed to shatter into many small, pebble-size pieces. This is normal. Glass shelves and covers are heavy. Use special care when removing them to avoid impact from dropping.

Location Requirements

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as gasoline, away from refrigerator.

Failure to do so can result in death, explosion, or fire.

To ensure proper ventilation for your refrigerator, allow at least 5" (13 cm) between the back of the cabinet and the wall. When installing your refrigerator, leave at least 3" (7.5 cm) clearance on each side.

Clean Before Using

After you remove all of the packaging materials, clean the inside of your refrigerator before using it. See the cleaning instructions in “Refrigerator Care.”

NOTE: It is recommended that you do not install the refrigerator near an oven, radiator, or other heat source. Do not install in a location that receives direct sunlight or heat. Do not install the refrigerator in a location where the temperature will fall below 55°F (13°C).

(7.5 cm)

3" (7.5 cm)

Reverse the Refrigerator Door

(optional)

IMPORTANT: All graphics referenced in the following instructions are included later in this section after “Final Steps.” The graphics shown are for a right-hand swing door (hinges factory installed on the right).

Tools needed: No. 2 Phillips screwdriver

Remove Door and Hinge

1. Turn the refrigerator control OFF, and remove food and door

bins from doors.

2. Unplug refrigerator or disconnect power.

(13 cm)

Electrical Requirements

WARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

Before you move your refrigerator into its final location, it is important to make sure you have the proper electrical connection.

Recommended Grounding Method

A 115 Volt, 60 Hz., AC only 15- or 20-amp fused, grounded electrical supply is required. It is recommended that a separate circuit serving only your refrigerator be provided. Use an outlet that cannot be turned off by a switch. Do not use an extension cord.

NOTE: Before performing any type of installation, cleaning, or removing a light bulb, shut cooling OFF by turning the control to the “0” position, as shown. Disconnect the refrigerator from the electrical source. When you are finished, reconnect the refrigerator to the electrical source and reset the temperature control to the desired setting. See “Using the Control.”

WARNING

Excessive Weight Hazard

Use two or more people to move and install refrigerator.

Failure to do so can result in back or other injury.

3. Place the refrigerator on its back.

4. Remove the bottom right leveling leg. See Graphic 3.

5. Using the Phillips screwdriver, remove the the screws from the

lower hinge assembly. See Graphic 3.

6. Pull the door downward to remove it from the cabinet.

Reverse Door Swing (optional)

1. Remove the upper hinge pin from the right side of the cabinet.

See Graphic 2.

2. Remove the plastic cap from the top left-hand side of the door

and reinstall it on the top right-hand side of the door, in the previous pin location. See Graphic 1.

3. Reinstall the hinge pin on the left-hand side of the cabinet.

Align the hole in the door with the hinge pin and push up until the hinge pin is inserted into the top of the door.

4. Remove the two retaining screws on the bottom left side of

the cabinet and reinstall them and the fixed foot on the right side in the former lower hinge assembly screw positions. See Graphic 4.

5. With the door closed, reinstall the lower hinge assembly on

the left side of the refrigerator. See Graphic 3.

6. Reinstall leveling leg. See Graphic 3.

Final Steps

1. Stand the the refrigerator upright and check all holes to make

sure that hole plugs and screws are in place.

2. Check the door for aligment and for a seal against the cabinet.

3. Let stand upright for 60 minutes before reconnecting power.

WARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

4. Plug into a grounded 3 prong outlet.

5. Reset the control. See “Using the Control” section.

6. Return all removable door parts to door and food to

refrigerator.

Top Hinge

A. Plastic Cap

A. Top Hinge Pin

Bottom Hinge

C D

A. Fixed Foot B. Screw Washers C. Spacers D. Retaining Screws

A. Hinge Washer B. Bottom Hinge Pin C. Leveling Leg

D. Screw Washers E. Spacers F. Hinge Screws

D E

Level the Refrigerator

There is one adjustable leveling leg located on the hinge side of the refrigerator. If the refrigerator seems unsteady, adjust the refrigerator’s tilt using the instructions below.

Adjust the leg to level the refrigerator:

■ To raise, turn the leveling leg counterclockwise.

■ To lower, turn the leveling leg clockwise.

NOTE: Having someone push against the top of the refrigerator takes some weight off the leveling leg which makes it easier to turn.

REFRIGERATOR USE

Using the Control

The temperature control is located at the top of the cabinet.

REFRIGERATOR FEATURES

Important information to know about glass shelves and covers:

Refrigerator Shelves

The shelves in your refrigerator are adjustable to match your individual storage needs.

Storing similar food items together in your refrigerator and adjusting the shelves to fit different heights of items will make finding the exact item you want easier. It will also reduce the amount of time the refrigerator door is open, and save energy.

To Remove and Replace a Shelf/Frame:

1. Remove the shelf/frame by tilting it up at the front and lifting it

out of the shelf supports.

2. Replace the shelf/frame by guiding the rear shelf hooks into

the shelf supports. Tilt the front of the shelf up until rear shelf hooks drop into the shelf supports. Make sure that the shelf is firmly in position.

IMPORTANT:

■ Wait 24 hours for your refrigerator to cool completely before

adding food. If you add food before the refrigerator has cooled completely, your food may spoil.

■ The control is set correctly when milk or juice is as cold as you

like.

■ Changes in the room temperature or opening the door

frequently will affect the internal refrigerator temperature.

To tur n ON:

Before first use, or if the refrigerator has been out of use for some time, set the temperarture control to the maximum position for 2 to 3 hours. Once the interior has reached the desired temperature, adjust the control to the desired setting.

To turn OFF:

Turn the control to the “0” position. Turning the temperature control to the “0” position stops cooling in the refrigerator, but it does not disconnect the refrigerator from the power supply.

Food Storage Guide

Storage times will vary according to the quality and type of food, the type of packaging or wrap used (should be airtight and moisture-proof), and the storage temperature. Seal the package or container to avoid taste and odor transfer throughout the product.

Food should not touch the rear wall of the refrigerator.

Crisper and Crisper Cover

To remove and replace the crisper:

1. Lift the front of the crisper and slide outward.

2. Replace the crisper by inserting the rear of the crisper into the

slots and sliding it back into place.

To remove and replace the crisper cover:

1. Lift the front of the cover and slide outward.

2. Replace the cover by inserting the rear of the cover into the

slots and sliding it back into place.

Beverage Dispenser

The beverage dispenser stores eight, 12 oz (354.9 mL) cans in the refrigerator door.

Wine/Bottle Rack

The wine/bottle rack can be installed only directly above the crisper cover as shown. The rack will hold five 750 mL bottles of wine.

DOOR FEATURES

Adjustable Shelf and Bins

To Remove and Replace the Shelf or Bins:

1. Remove the bin by lifting it and pulling it straight out.

2. Replace the bin by sliding it in above the desired support and

pushing it down until it stops.

REFRIGERATOR CARE

Cleaning

WARNING

Explosion Hazard Use nonflammable cleaner. Failure to do so can result in death, explosion, or fire.

Clean the refrigerator about once a month to avoid buildup of odors. To avoid odor transfer and drying out of food, wrap or cover foods tightly. Wipe up spills immediately.

Cleaning

NOTE: Do not use abrasive or harsh cleaners such as window

sprays, scouring cleansers, flammable fluids, cleaning waxes, concentrated detergents, bleaches or cleansers containing petroleum products on plastic parts, interior and door liners or gaskets. Do not use paper towels, scouring pads, or other harsh cleaning tools.

1. Unplug refrigerator or disconnect power.

2. Hand wash, rinse, and dry removable parts and interior

surfaces thoroughly. Use a clean sponge or soft cloth and a mild detergent in warm water.

3. Wash metal exteriors with a clean sponge or soft cloth and a

mild detergent in warm water. Dry thoroughly with a soft cloth.

4. Plug in refrigerator or reconnect power.

Defrosting

Your refrigerator defrosts automatically. Inside the refrigerator cabinet (behind the crisper drawer and under the evaporator plate) there is a drain trough. This trough collects water droplets that fall from the evaporator plate during the defrost cycle, and then channels the water down a drain tube.

NOTE: To keep water from overflowing the trough and freezing on the bottom of the cabinet keep the trough and drain tube clear of ice and food particles.

To remove ice from the drain trough:

Slowly pour ³⁄₄ cup (180 mL) of hot water over the drain trough to melt the ice.

To remove food particles from the drain tube:

Dislodge any food particles by inserting a plastic straw down the drain tube.

Changing the Light Bulb

NOTES:

■ The light bulb is located behind the temperature control at the

top of the cabinet.

■ Not all appliance bulbs will fit your refrigerator. Be sure to

replace the bulb with an appliance bulb of the same size, shape, and wattage (no greater than 15 watts).

1. Unplug the refrigerator or disconnect power.

2. Using a Phillips screwdriver, remove the screw located on the

left-hand side of the light shield. Pull the light shield straight down.

3. Replace the burned-out light bulb with an appliance bulb no

greater than 15 watts.

4. Replace the light shield.

5. Plug in refrigerator or reconnect power.

Vacation and Moving Care

Vacations

If you choose to turn the refrigerator off before you leave, follow these steps.

1. Remove all food from the refrigerator.

2. Turn the temperature control to the “0” position and unplug

the refrigerator.

3. Clean the refrigerator. See “Cleaning.”

4. Tape a rubber or wood block to the top of the door to prop it

open far enough for air to get in. This stops odor and mold from building up.

A. Evaporator plate B. Drain tube

Manual Defrosting

Under some circumstances ice formation on the inner back wall can occur. If ice formation increases to between 0.12" and 0.20" (3 mm and 5 mm), the refrigerator should be manually defrosted.

1. Remove food from refrigerator.

2. Turn temperature control to the “0” position and leave the

door open.

3. After defrosting is complete, turn the temperature control to

the desired setting and close the refrigerator door.

Moving

When you are moving your refrigerator to a new home, follow these steps to prepare it for the move.

1. Remove all food from the refrigerator.

2. Turn the temperature control to the “0” position and unplug

the refrigerator.

3. Clean the refrigerator. See “Cleaning.”

4. Take out all removable parts, wrap them well, and tape them

together so they don’t shift and rattle during the move.

5. Tape the doors shut and tape the power cord to the

refrigerator.

When you get to your new home, put everything back and refer to the “Installation Instructions” section.

TROUBLESHOOTING

Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.

Refrigerator Operation

Your refrigerator will not operate

WARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

■ Is the power supply cord unplugged? Plug into a grounded

3 prong outlet.

■ Has a household fuse blown, or has a circuit breaker

tripped? Replace the fuse or reset the circuit.

■ Is the temperature control on? Turn the temperature control

knob to the operating position. See “Using the Control.”

■ New installation? Allow 24 hours following installation for the

refrigerator to cool completely.

The door will not close completely

■ Are the shelves out of position? Put the shelves back into

their correct positions. See “Refrigerator Features” for more information.

WARNING

Explosion Hazard Use nonflammable cleaner. Failure to do so can result in death, explosion, or fire.

■ Is the gasket sticking? Clean the gasket and the surface that

it touches. Rub a thin coat of paraffin wax on the gasket following cleaning.

The door is difficult to open

WARNING

The motor seems to run too much

Your new refrigerator may run longer than your old one due to its high-efficiency compressor and fans. The unit may run even longer if the room is warm, a large food load is added, the door is opened often, or if the door has been left open.

The refrigerator seems noisy

Refrigerator noise has been reduced over the years. Due to this reduction, you may hear intermittent noises from your new refrigerator that you did not notice from your old model. Below are listed some normal sounds with explanations.

■ Pulsating - fans/compressor adjusting to optimize

performance.

■ Hissing/Rattling - flow of refrigerant, movement of water

lines, or from items placed on top of the refrigerator.

■ Popping - contraction/expansion of inside walls, especially

during initial cool-down.

■ Water running/dripping - may be heard when water melts

during defrosting and runs into the drain pan.

Explosion Hazard Use nonflammable cleaner. Failure to do so can result in death, explosion, or fire.

■ Is the gasket dirty or sticky? Clean the gasket and the

surface that it touches. Rub a thin coat of paraffin wax on the gasket following cleaning.

Temperature and Moisture

Temperature is too warm

■ Door opened often or left open? Allows warm air to enter

refrigerator. Minimize door openings and keep door fully closed.

■ Is the control set correctly for the surrounding conditions?

See “Using the Control.”

■ Large load of food added? Allow several hours for the

refrigerator to return to normal temperature.

+ 19 hidden pages
