KitchenAid KUIS18PNJW7, KUIS18PNJB7 User Manual

CABINET LINER AND DOOR PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

ICE CUBE

MAKER

10−05 Litho In U.S.A. (tpm)

1

Part No. 8214597

CABINET LINER AND DOOR PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

2313788 Use & Care Guide
2313728 Service &

Wiring Sheet

2 3400886 Screw 8−18 x 1 1/4
3 2208354 Bin, Door
4 2185678 Spacer
5 2217394 Cover, Wiring
6 489442 Screw
7 Panel, Exterior

2208352W White

2208352B Black
8 2217298 Panel, Interior
9 2217467 Tube, Air Vent

10 2208377 Insulation
11 2208367 Clamp, Half
12 8281265 Screw
13 Bracket, Door

2217466 Left Side

2217465 Right Side
14 489503 Clamp
15 2217295 Gasket, Door
16 2208535 Clip
17 Nameplate

2212760 White

2212762 Black
18 Hinge

2208425 Left Side

2208426 Right Side

Illus. Part

No. No. DESCRIPTION

19 2208401 Shim, Hinge
20 Handle, Door

2208440W White

2208440B Black
21 688983 Screw
22 2208399 Assembly,

Unit Cover

23 Screw, Handle

8281188 White

8281186 Black
24 2217227 Ballast−Back, IM
25 2217225 Pad, Foam
26 2185691 Channel, Wiring
27 Endcap, Door

2208350W White

2208350B Black
28 2208459 Tube, Drain
29 2208386 Scoop
30 3400884 Screw 8−18 x 5/8
31 8533996 Clamp
32 Panel, Lower

2208382W White

2208382B Black
33 2208487 Bracket, Spring
34 2208417 Pin, Hinge
35 489048 Screw, Ground
36 2208480 Spring

Illus. Part

No. No. DESCRIPTION

37 Endcap, Panel

2208383W White

2208383B Black
38 2208529 Dampener, Spring
39 489423 Screw
40 2208449 Holder, Scoop
42 3374849 Leg, Leveler (4)
43 2208384 Insulation
45 2185690 Shield, Electrical
46 2217296 Gasket, Top Panel
47 Grill, Front

2217206W White

2217206B Black
48 489474 Screw 8−18 x 1
49 Cabinet & Liner

(NOT SERVICED)

50 Top

2929701W White

2929701B Black
51 941839 Hole Plug
52 692400 Nut, Push−In
53 3400240 Nut,

Leg Leveler
54 2208434 Strike, Magnet
55 3400916 Washer
56 8281191 Screw
57 488208 Screw

2

8214597

EVAPORATOR, ICE CUTTER GRID AND WATER PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

8214597

3

EVAPORATOR, ICE CUTTER GRID AND WATER PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

Illus. Part

No. No. DESCRIPTION

1 2185758 Valve, Complete

Water
2 2217286 Tube, Plastic
3 488208 Screw
4 2185523 Dispenser, Water
5 2217269 Evaporator
6 627018 Nut, Compression
7 841707 Insert, Tube
8 2172593 Tube, Water Fill
9 488660 Nut, Speed

10 836667 Spacer
11 2208539 Fastener, Pushnut
12 489443 Screw
13 2185625 Reservoir,

Water Slide

14 2185626 Tube
15 2185673 Hose, Overflow
16 2217378 Support,

Reservoir Bracket

17 2313603 Bracket, Front

and Rear

18 2313602 Bracket, Side

Left and Right

19 2185681 Harness, Grid
20 2208427 Support, Bracket

Evaporator/Grid

21 2313604 Guide, Ice Grid
22 2208533 Tube
23 487627 Ball Sleeve
24 487857 Nut, Ball Sleeve
25 8281193 Screw
26 3400886 Screw 8−18 x 1 1/4
27 8281192 Screw
28 2313601 Grid Assembly

(Complete)

29 2174754 Wire, Grid Cutter
30 2208365 Cover, Grid
31 8281228 Thumbscrew
32 8201653 Reservoir, Water
33 3400884 Screw 8−18 x 5/8
34 2185696 Cap, Drain
35 3400909 Nut, Push−In

4

8214597

PUMP PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

Illus. Part

No. No. DESCRIPTION

1 2217220 Pump, Water

(Complete)
2 3400884 Screw 8−18 x 5/8
3 2185677 Cover, Pump
4 2185585 Bracket, Connector

Assembly

8214597

5

CONTROL PANEL PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

Illus. Part

No. No. DESCRIPTION

1 2185738 Box, Control
2 2185657 Transformer
3 2185592 Assembly, Switch

(ALSO ORDER #4)
4 2208317W Overlay
5 2304016 Control Board
6 2149705 Switch, Plunger
7 2185694 Lens, LED
8 2185692 Wiring Harness

Grid/ Light

9 745362 Bulb

12 2313633 Thermostat, Bin
13 2185825 Clamp
14 2187836 Wiring Harness,

Main to Pump

15 3400884 Screw
16 2187256 LED Assembly
18 3400850 Screw 8−16 x 3/8
20 2313635 Thermister,

Ice Control

6

8214597

UNIT PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

8214597

7

UNIT PARTS

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

Illus. Part

No. No. DESCRIPTION

1 2217434 Bracket, Fan Mtg.
2 2185675 Pad, Foam
3 2190685 Blade, Fan
4 2188537 Motor, Fan
5 2313636 Wiring Harness,

Complete Unit
(Includes
Power Cord)

6 304392 Screw 8−18 x 1/2
7 2208370 Compressor

(Includes
Illus. 11,18,
20,21 & 23)

8 A201435 Clip, Mounting

9 A201441 Shim (4)
10 2185960 Clamp (Power Cord)
11 Grommet (4)

2217318 Production
4387558 Service

12 2208415 Tube, Process

Illus. Part

No. No. DESCRIPTION

13 489423 Screw
14 489472 Screw
15 759112 Coil, Solenoid
16 2208413 Valve, Body
17 2187835 Wiring Harness,

Condenser Fan

18 Overload

2217223 Production
4387938 Service

(Includes Relay)
19 2155774 Strap
20 Relay, Start

2217224 Production
4387938 Service

(Includes

Overload)
21 Cover, Terminal

2208371 Production
4387731 Service

22 2208534 Pump, Drain

Illus. Part

No. No. DESCRIPTION

23 Drier

2209223 Production

4387019 Service
24 2217398 Condenser
25 489505 Clamp
26 2208432 Tube, Drain
27 2217397 Pad, Foam (2)
28 488500 Screw
30 2217423 Base, Unit
32 486692 Nut, Speed
33 489494 Screw 8−32 x 3/4
34 851095 Wire Tie
35 2185788 Clamp
36 3400884 Screw

REFRIGERANT CHARGE

6.5 OZ. (R134A)

8

8214597

OPTIONAL PARTS (NOT INCLUDED)

For Models: KUIS18PNJW7, KUIS18PNJB7

(White−Pump Model) (Black−Pump Model)

Illus. Part

No. No. DESCRIPTION

Parts Not Illustrated and

Optional Parts (Not Included)

8171307 Cleaner, Icemaker

503695 Sealer, Cork

(1/4 Pound)

797403 Cement, Insulation

(1 Oz.)

505587 Sealer, Mastic

(1 Qt.)

212643 Sealer, Gum

(22 Pcs. 3/16" x 7")

479976 Kit, Insulation

(5 Pcs. 3" x 24"
x 48")

978025 Valve, Access

(1/4")

978026 Valve, Access

(5/16")

978027 Valve, Access

(3/8")

978028 Valve, Access

(1/2")

978029 Valve, Access

(5/8")

978030 Valve, Access

(3/4")

8214597

9
