KitchenAid KHMB732OB, KHMB732VB, KHMB732, KHMB732WH INSTALLATION INSTRUCTIONS AND OPERATION MANUAL

7 Speed Cordless Hand Mixer

KHMB732

PARTS AND FEATURES

5

3

6

	4
	9
	7
2	8
1

10

1	Upright stance	6	Charging port
2	Motor body	7	Speed controller
3	Stainless steel turbo beatersTM II	8	Handle
4	Eject button	9	Charger adapter
5	Battery status indicator	10	Charger adapter pin

2

PRODUCT SAFETY

<![if ! IE]> <![endif]>ENGLISH

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

1.Read all instructions.

2.To protect against risk of electrical shock, do not put the Motor body of Cordless Hand Mixer, Charger adapter, cord, or electrical plug in water or other liquid.

3.This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety. Close supervision is necessary when any appliance is used by or near children. Children should be supervised to ensure that they do not play with the appliance.

4.Turn the appliance OFF before assembling or disassembling parts and before cleaning. To unplug the charger, grasp the plug and pull from the outlet. Never pull from the power cord.

5.Do not use an extension cord. Plug charger directly into an electric outlet.

6.Use only with the charger provided with the appliance. Do not attempt to use this charger with any other product. Likewise, do not attempt to charge this appliance with any other charger.

7.Do not incinerate this appliance even if it is severely damaged. The batteries can explode in a fire.

8.Avoid contacting moving parts. Keep hands, hair clothing, as well as spatulas and other utensils away from beaters and accessories during operation to reduce the risk of injury to persons or damage to the Cordless Hand Mixer.

3

PRODUCT SAFETY

9.Do not operate any appliance or Charger adapter with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Contact the manufacturer at their customer service telephone number for information on examination, repair, or adjustment.

10.The use of attachments not recommended or sold by KitchenAid may cause fire, electric shock, or injury.

11.Do not use the appliance outdoors.

12.Do not let cord hang over edge of table or counter.

13.Never leave the appliance unattended while it is in operation.

14.Do not let cord contact hot surface, including the stove.

15.Remove beaters or accessories from the Cordless Hand Mixer before washing.

16.Refer to the “Care and Cleaning” section for instructions on cleaning the surfaces in contact with food.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

ELECTRICAL REQUIREMENTS

Charger adapter: Input: 120 Volts 60 Hz

Cordless Hand Mixer: Voltage: 12 Volts

NOTE: If the plug does not fit fully in the outlet, contact a qualified electrician. Do not modify the plug in any way.

LITHIUM-ION BATTERY OPERATED PRODUCT DISPOSAL

Always dispose the battery operated products according to federal, state, and local regulations. Contact a recycling agency in your area for recycling locations.

4

GETTING STARTED

BEFORE FIRST USE

1.Charge the battery until the Battery status indicator turns solid green.

2.Clean all the parts. (see "Care and Cleaning" section).

3.Remove all packaging materials, if present.

BATTERY STATUS

	Battery	% Battery Status	Full Charge*	Quick Charge**
	Status
	Green	30 % to 100 %
	Yellow	15 % - 30 % (Consider Charging)	200 cookies	1 cake batter
	Red	Lower than 15 % (Need to charge soon)

<![if ! IE]>

<![endif]>ENGLISH

*Full Charge:

The Cordless Hand Mixer will be fully charged in 2 hours. The Battery status indicator pulses when it charges and turns to solid green with a full charge.

The Cordless Hand Mixer will prepare approximately 200 cookies, based on 4 batches of chocolate chip cookies when following the recommended battery maintenance.

**Quick Charge:

In 10 minutes the Cordless Hand Mixer will quick charge. The Cordless Hand Mixer will stir up a cake batter recipe with one quick charge when following the recommended battery maintenance.

NOTE: Make sure to charge the battery, when the Battery status indicator is yellow. NOTE: It is best to store the Cordless Hand Mixer at room temperature.

BATTERY CHARGING

1

First, slide the Speed controller to "O" position and insert the Charger adapter pin into the Charging port.

2

Plug the Charger adapter into a grounded electrical outlet.

5

BATTERY CHARGING

3

The Battery status indicator pulses when it charges. It will be fully charged in 2 hours and the Battery status indicator turns solid green.

PRODUCT ASSEMBLY

1

IMPORTANT: Make sure that the Speed controller is at "O" position before attaching and removing Stainless steel turbo beatersTM II.

3

D

B

C

A

Insert the Stainless steel turbo beatersTM

II without a collar (A) into the smaller opening (C) and Stainless steel turbo beatersTM II with a collar (B) into the larger opening (D). Align and push to lock into place. Both the Stainless steel turbo beatersTM II will click in.

2

A B

There are two Stainless steel turbo beatersTM II. One is without a collar (A) and another with a collar (B).

6

PRODUCT USAGE

NOTE: Make sure the Cordless Hand Mixer is charged before use.

1

2

Always start mixing at the lowest speed,	To increase the speed, slide the Speed
and by sliding the Speed controller,	controller forward ( ). To decrease
increase the speed according to the	the speed, slide the Speed controller
recipes.	backward ( ).

3

<![if ! IE]>

<![endif]>ENGLISH

When finished, slide the Speed controller to "O" position.

CARE AND CLEANING

IMPORTANT: Make sure the Speed controller is at "O" before attaching or removing Stainless steel turbo beatersTM II.

1

Press the Eject button to release the

Stainless steel turbo beatersTM II from the Cordless Hand Mixer.

2

Always remove the Stainless steel turbo beatersTM II from the Cordless Hand Mixer before cleaning. Wash in dishwasher, or by hand in warm, soapy water. Rinse and wipe dry.

7

CARE AND CLEANING

3

Wipe the Cordless Hand Mixer with a damp cloth. Dry with a soft cloth.

NOTE: To avoid damage to the Cordless Hand Mixer, do not immerse in water.

For detailed information about the Cordless Hand Mixer:

Visit www.kitchenaid.com/quickstart for additional instructions with videos,

inspiring recipes, and tips on how to use and clean your Cordless Hand Mixer.

TROUBLESHOOTING GUIDE

	Problem	Solution
	If the Cordless Hand Mixer fails	Check if the product is charged.
		Charge the battery when the Battery status indicator is red
	to start:
		or when the Battery is completely drained.
	If the Cordless Hand Mixer is not	If you have a circuit breaker box, make sure that the circuit
	getting charged:	is closed.
	If the problem cannot be	See the “Warranty and Service” sections.
		Do not return the Cordless Hand Mixer to the retailer.
	corrected:
		Retailers do not provide service.

8

WARRANTY AND SERVICE

KITCHENAID® CORDLESS HAND MIXER WARRANTY FOR THE 50 UNITED STATES, THE DISTRICT OF COLUMBIA, PUERTO RICO, AND CANADA

This warranty extends to the purchaser and any succeeding owner for the Cordless Hand Mixer operated in the 50 United States, the District of Columbia, Puerto Rico, and Canada.

Length of Warranty:	One Year Full Warranty from date of purchase.
KitchenAid Will Pay	Hassle-Free Replacement of your Cordless Hand Mixer
for Your Choice of:	See the next page for details on how to arrange for
	service, or call the Customer eXperience Center
	toll-free at 1.800.541.6390.
	OR
	The replacement parts and repair labor costs to correct
	defects in materials and workmanship.
	Service must be provided by an Authorized
	KitchenAid Service Center.
KitchenAid Will	A. Repairs when your Cordless Hand Mixer is used in
Not Pay for:	other than normal single family home use.
	B. Damage resulting from accident, alteration,
	misuse or abuse.
	C. Any shipping or handling costs to deliver your
	Cordless Hand Mixer to an Authorized Service Center.
	D. Replacement parts or repair labor costs for the
	Cordless Hand Mixers operated outside the 50 United
	States, District of Columbia, Puerto Rico,
	and Canada.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED TO THE EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY

BE IMPOSED BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD ALLOWED BY LAW. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS OR EXCLUSIONS ON HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.

IF THIS PRODUCT FAILS TO WORK AS WARRANTED, CUSTOMER’S SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT ACCORDING TO THE TERMS OF THIS LIMITED WARRANTY. KITCHENAID AND KITCHENAID CANADA DO NOT ASSUME ANY RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. This warranty gives you specific legal rights and you may also have other rights which vary from state to state or province to province.

<![if ! IE]>

<![endif]>ENGLISH

9

WARRANTY AND SERVICE

HASSLE-FREE REPLACEMENT WARRANTY – 50 UNITED STATES, DISTRICT OF COLUMBIA, AND PUERTO RICO

We’re so confident the quality of our products meets the exacting standards of KitchenAid that, if your Cordless Hand Mixer should fail within the first year

of ownership, KitchenAid will arrange to deliver an identical or comparable replacement to your door free of charge and arrange to have your original

Cordless Hand Mixer returned to us. Your replacement unit will also be covered by our one year limited warranty. Please follow these instructions to receive this quality service. If your Cordless Hand Mixer should

fail within the first year of ownership, simply call our toll-free Customer eXperience Center at

1-800-541-6390 Monday through Friday. Please have your original sales receipt available when you call. Proof of purchase will be required to initiate the claim. Give the consultant your complete shipping address. (No P.O. Box numbers, please.) When you receive your replacement Cordless Hand Mixer, use the carton and packing materials to pack up your original Cordless Hand Mixer.

HASSLE-FREE REPLACEMENT WARRANTY – CANADA

We’re so confident the quality of our products meets the exacting standards of the KitchenAid brand that, if your Cordless Hand Mixer should fail within the first year of ownership, KitchenAid Canada will replace your Cordless Hand Mixer with an identical or comparable replacement. Your replacement unit will also be covered by our one year limited warranty. Please follow these instructions to receive this quality service. If your Cordless Hand Mixer should fail within the first year of ownership, take the Cordless Hand Mixer or ship collect to an Authorized KitchenAid Service Center.

In the carton include your name and complete shipping address along with a copy of the proof of purchase (register receipt, credit card slip, etc.). Your replacement Cordless Hand Mixer will be returned prepaid and insured. If you are unable to obtain satisfactory service in this manner call our toll-free Customer eXperience Center at 1-800-807-6777.

Or write to us at:

Customer eXperience Center KitchenAid Canada

200 - 6750 Century Ave.

Mississauga, ON L5N 0B7

ARRANGING FOR SERVICE AFTER THE WARRANTY EXPIRES, OR ORDERING ACCESSORIES AND REPLACEMENT PARTS

In the United States and Puerto Rico:

For service information, or to order accessories or replacement parts, call tollfree at 1-800-541-6390 or write to: Customer eXperience Center, KitchenAid Small Appliances, P.O. Box 218, St. Joseph, MI 49085-0218

Outside the United States and Puerto Rico:

Consult your local KitchenAid dealer or the

store where you purchased the Cordless Hand Mixer for information on how to obtain service.

For service information in Canada:

Call toll-free 1-800-807-6777.

Or write to:

Customer eXperience Center KitchenAid Canada

200 - 6750 Century Ave.

Mississauga, ON L5N 0B7

®/™ ©2019 KitchenAid. All rights reserved. Used under license in Canada.

10

PIÈCES ET CARACTÉRISTIQUES

5

3

6

	4
	9
	7
2	8
1

10

<![if ! IE]>

<![endif]>FRANÇAIS

	1	Position verticale	6	Port de recharge
	2	Moteur	7	Commande de vitesse
	3	Batteurs en acier inoxydable	8	Poignée
		Turbo BeatersTM II	9	Adaptateur du chargeur
	4	Boutons d’éjection
			10	Broche de l’adaptateur du chargeur
	5	Témoin d’état de pile

11
