COOKTOP PARTS
For Models: KECC508RPB03, KECC508RPW03, KECC508RPT03, KECC508RPS03
(Black) (White) (Biscuit) (Stainless)
30" ELECTRIC
BUILT−IN
CERAN COOKTOP
9−07 Litho in U.S.A.(amd)
1
Part No. W10163515 Rev. A
COOKTOP PARTS
For Models: KECC508RPB03, KECC508RPW03, KECC508RPT03, KECC508RPS03
(Black) (White) (Biscuit) (Stainless)
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8286066 Cooktop
8304571 Undercounter Oven
8286063 Tech Sheet
8286608 Use & Care Guide
Safer Cooking Tips
3191638 English
9759133 French
2 Cooktop, Glass
8286944 Black
8286968 White
8286967 Biscuit
3 246119 Screw
W10142240
4
6 9759094 Spring Locator (8)
7 3196160 Screw
8 8285240 Seal, Heat
9 8286577 Wall, Inside
10 8286535 Bracket, Bottom
11 8286554 Box, Burner
12 3192439 Seal, Limiter (4)
13 Board, Control
8285922 Black
8285923 White
14 3196537 Screw
15 8286644 Appliance Manager
16 4449745 Screw
17 8286575 Control Box
18 8285319 Cable Assembly
20 9763517 Rail, Element
21 8286344 Rail, Element
23 8285593 Cover, Harness
24 Element, Surface
8285230 1200W RF
8285938 2000/1000W RR
8285847 2500/1800/900W LF
4453907 1500W LR
25 4449868 Block, Terminal
26 3196163 Screw
27 8285426 Seal, Heat Shield
28 112432 Nut
29 9757815 Support, Module
30 4455917 Bracket, Mounting
31 3400093 Screw
Frame, Cooktop
(Stainless Only)
Module
2
W10163515
OPTIONAL PARTS (NOT INCLUDED)
For Models: KECC508RPB03, KECC508RPW03, KECC508RPT03, KECC508RPS03
(Black) (White) (Biscuit) (Stainless)
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
8286642 Tape, Foam
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150
242820 Wire, Black
14 Ga. 150
242822 Wire, Blue
14 Ga. 150
242830 Wire, Brown
14 Ga. 200
242823 Wire, Green
14 Ga. 150
242824 Wire, Orange
14 Ga. 150
242829 Wire, Red
12 Ga. 150
242825 Wire, Red
14 Ga. 150
242831 Wire, Red
14 Ga. 200
242826 Wire, White
14 Ga. 150
242827 Wire, Yellow
14 Ga. 150
242832 Wire, Yellow
14 Ga. 200
C
C
C
C
C
C
C
C
C
C
C
C
W10163515
ACCESSORY PARTS
WIRING HARNESS PARTS
W10113066
8286382 Clip, Harness
FE02313 Bushing
3400015 Screw, Ground
8286379 Conduit Assembly
Harness, Main
3
