OVEN PARTS
27" BUILT−IN ELECTRIC
DOUBLE OVEN
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
5−09 Litho in U.S.A. (amd)(bay)
1
Part No. W10269252 Rev. A
OVEN PARTS
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8304336 Installation
Instructions
W10162179
W10220954
W10220955
8304335 Easy Set Guide
9762761 English
9759133 French
W10153090
2
3 Hinge Receiver
4455606 Right
4455605 Left
W10105790
4
5 8303829 Exhaust,Vent Slope
W10181198
6
W10204469
7
8 4449809 Screw
9 4452158 Tube, Vent
W10169756
10
Use & Care Guide
Tech Sheet
English
French
Safer Cooking Tips
Bracket, Base
Bumper, Door (2)
Divider, Vent
Top Chassis
Lens, Light
Illus. Part
No. No. DESCRIPTION
W10009940
11
W10169757
12
13 3400832 Screw (2)
14 8304629 Frame, Front
15 8304494 Gasket, Door
16 3196176 Screw
17 4449040 Screw
18 4449154 Screw
19 4451477 Support, Insulation
20 4450038 Screw (2)
21 Mounting Rail,Side
8303677BL
8303677WH
8303678BL
8303678WH
22
W10195935
23 4449743 Screw
24 4449748 Screw
25 4455641 Side, Chassis
26 8304304 Back, Chassis
27 Liner, Oven
Oven Light
Assembly
Bulb, Light
Right
Black
White
Left
Black
White
Latch, Mortorized
(Not serviceable)
Illus. Part
No. No. DESCRIPTION
28 8304452 Thermal Fuse 105C
W10131825
29
30 8303724 Vent, Center
31 8303772 Base, Chassis
32 8304478 Retainer, Gasket
33 8303517 Cover, Back
34 Trim, Bottom Vent
8303706BL
8303706WH
W10216231
35 4448444 Grommet, Mounting
W10169348
37
Sensor
Black
White
Stainless
Rail
Bracket,
Thermostat
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8303966 Insulation, Wrap
8303968 Insulation, Back
2
W10269252
CONTROL PANEL PARTS
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
W10269252
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
8303717BL
8303717WH
W10216220
2 8303687 Support, Appliance
4 8304333 Keyboard, Glass
W10172472
5
6 8303720 Backer, Control
7 8303887 Bracket,
8 4449154 Screw
9 3400832 Screw
W10119142
10
11 8304441 Resistor, Drop
12 4449809 Screw
Black
White
Stainless
Manager
Touch
User Inferface
Enclosure (2)
Appliance Manager
3
OVEN DOOR PARTS
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
Illus. Part
No. No. DESCRIPTION
1 8304522 Bumper, Door
W10174288
2
3 3196183 Screw
4
8304580BL
5 Bracket, Door
8304377 Right
8304378 Left
8303738BL
6
7 8303732 Glass, Inner
8 4449743 Screw
9 Cover, Hinge
W10137044
W10137043
Hinge, Door (2)
Vent, Door Top
Door Liner
Right
Left
Illus. Part
No. No. DESCRIPTION
10 8304523 Seal
8304361BL
11
12 Door Glass,
8304001 Black
8304003 White
W10237352
8304002 Black
8304004 White
W10237353
Bracket, Handle
Assembly
Lower Includes #17
Stainless
Door Glass,
Assembly
Upper No Badge
Stainless
4
Illus. Part
No. No. DESCRIPTION
13 Door Handle
8303775BL
8303775WH
8303775SS
8303745BL
15
16 8303754 Door, Top Bracket
17 Badge
8304603BL
8304603WH
8304603SS
Black
White
Stainless
Frame,Door Side(2)
Black
White
Stainless
W10269252
INTERNAL OVEN PARTS
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
W10269252
Illus. Part
No. No. DESCRIPTION
1 8304602 Element, Broil
Shield
2 9760774 Element, Broil
3 4449154 Screw
4 4448715 Rack, Oven
6 9760768 Element, Bake
7 4455036 Tray, Bake
8 4450039 Cover, Bake Tray
9 4449809 Screw
5
TOP VENTING PARTS
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
Illus. Part
No. No. DESCRIPTION
1 9752759 Relay (2)
2 8304643 Duct, Air Outlet
3 4449809 Screw
4 8303972 Blower, 60mm
6 8285593 Connector, Cover
W10111628
7
8 4450118 Nut
9 4449868 Block, Terminal
10 3400080 Screw
11 8303722 Vent, Control
12 Side, Control Top
8303518 Right
8304255 Left
13 8303520 Back, Control
14 8304220 Cover, Top
7103P027−60
15
Transformer,
Control
Panel
Nut (3)
6
W10269252
OPTIONAL PARTS (NOT INCLUDED)
For Models:KEBK276SBL04, KEBK276SWH04, KEBK276SSS04
(Black) (White) (Stainless)
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
261869 Cord Brown
72032 Black
PAINT, SPRAY
350930 White
261900 Citrine White
830864 Black
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
WIRING HARNESS PARTS
W10143473
W10171562
8304051 Harness, Wire
8304439 Conduit, Double
4450800 Screw,Ground
4454842 Tie, Cable
Harness,
Door Latch
Harness, Main
Communication
Miscellaneous
4448950 Screw, Install (4)
98997 Clip
W10269252
7
