KitchenAid KCM111, KCM111OB, KCM112, KCM112OB User Manual

CUP/

10/12

TASSE/ TAZAS

COFFEE MAKERS / CAFETIÈRES / CAFETERA

INSTRUCTIONS / INSTRUCTIONS / INSTRUCCIONES

KCM112

10-cup Thermal Carafe

Carafe thermique de 10 tasses

Jarra térmica con capacidad para 10 tazas

W10321646B

KCM111

12-cup Glass Carafe

Carafe thermique de 12 tasses

arra de vidrio con capacidad para 12 tazas

TABLE OF CONTENTS

COFFEE MAKER SAFETY...................................3

ELECTRICAL REQUIREMENTS .........................4

KITCHENAID

FEATURES............................................................5

DISPLAY AND CONTROL PAD FEATURES......7

COFFEE BREWING SUGGESTIONS:

ADVICE FOR GREAT TASTE ..............................8

PREPARING YOUR COFFEE

MAKER FOR USE ................................................9

KITCHENAID

COFFEE MAKER

COFFEE MAKER USE..............10

TABLE DES MATIÈRES

SÉCURITÉ DE LA CAFETIÈRE .........................18

SPÉCIFICATIONS ÉLECTRIQUES ...................19

CARACTÉRISTIQUES DE LA CAFETIÈRE KITCHENAID

AFFICHAGE ET CARACTÉRISTIQUES

DES TOUCHES DE COMMANDE.....................22

SUGGESTIONS D'INFUSION DE CAFÉ : CONSEIL POUR UN ARÔME IDÉAL ...23

PRÉPARATION DE LA CAFETIÈRE POUR

UTILISATION......................................................24

UTILISATION DE LA CAFETIÈRE KITCHENAID

...............................20

..............................25

COFFEE MAKER

ENHANCED FEATURES....................................12

Pause and Pour Feature .................................12

Automatic Brew Timer ....................................12

Brew Strength .................................................12

Immediate Brew ..............................................12

Auto Brew........................................................12

COFFEE MAKER CARE ....................................13

Clean Indicator ................................................13

Clean ...............................................................13

TROUBLESHOOTING........................................14

PROOF OF PURCHASE AND

PRODUCT REGISTRATION..............................15

WARRANTY........................................................15

CARACTÉRISTIQUES AVANCÉES

DE LA CAFETIÈRE.............................................27

Caractéristique Pause and Pour

(pause et versement).......................................27

Minuterie d'infusion automatique ...................27

Degré d'infusion ..............................................27

Infusion immédiate..........................................27

Infusion automatique.......................................27

ENTRETIEN DE LA CAFETIÈRE.......................28

Témoin Clean (nettoyage) ...............................28

Clean (propre)..................................................28

DÉPANNAGE......................................................29

PREUVE D’ACHAT ET

ENREGISTREMENT DU PRODUIT ..................29

GARANTIE..........................................................30

ÍNDICE

SEGURIDAD DE LA CAFETERA.......................33

REQUISITOS ELÉCTRICOS..............................34

CARACTERÍSTICAS DE LA CAFETERA KITCHENAID

CARACTERÍSTICAS DE LA PANTALLA

Y LOS BOTONES DE CONTROL......................37

SUGERENCIAS PARA LA ELABORACIÓN DEL CAFÉ: CONSEJOS PARA OBTENER

EL SABOR IDEAL...............................................38

CÓMO PREPARAR LA CAFETERA

PARA SU USO....................................................39

USO DE LA CAFETERA KITCHENAID

................................35

...........40

CARACTERÍSTICAS SUPERIORES

DE LA CAFETERA..............................................42

Característica de Pausa y servir .....................42

Temporizador de elaboración

automática.......................................................42

Intensidad del café..........................................42

Elaboración inmediata.....................................42

Elaboración automática. .................................42

CUIDADO DE LA CAFETERA ...........................43

Indicador de Clean (Limpiar)...........................43

Limpieza ..........................................................43

SOLUCIÓN DE PROBLEMAS...........................44

PRUEBA DE COMPRA

Y REGISTRO DEL PRODUCTO........................44

GARANTÍA..........................................................45

COFFEE MAKER SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you

and others. All safety messages will follow the safety alert symbol and either the

word “DANGER” or “WARNING.” These words mean:

You can be killed or seriously injured

DANGER

if you don't immediately follow instructions.

WARNING

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

You can be killed or seriously injured if you don't follow instructions.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

■ Read all instructions.

■ Do not touch hot surfaces. Use handles or knobs.

■ To protect against electrical shock, do not immerse cord, plugs, or coffee maker in

water or other liquid.

■ Close supervision is necessary when any appliance is used by or near children.

■ Unplug coffee maker from outlet when not in use and before cleaning. Allow to cool

before putting on or taking off parts.

■ Do not operate any appliance with a damaged cord or plug or after the appliance

malfunctions or has been damaged in any manner. Return appliance to the nearest Authorized Service Facility for examination, repair or adjustment.

■ The use of accessory attachments not recommended by the appliance manufacturer

may cause injuries.

■ Do not use outdoors.

■ Do not let cord hang over edge of table or counter, or touch hot surfaces.

■ Do not place on or near a hot gas or electric burner, or in a heated oven.

■ Do not use appliance for other than intended use.

■ Do not use appliance without lid properly placed on container (carafe).

■ The container (carafe) is designed for use with this appliance. It must never be used on

a range top or in a microwave oven.

■ Do not set a hot container (carafe) on a wet or cold surface.

■ Do not use a cracked container (carafe) or a container having a loose or weakened

handle.

■ Do not clean container with abrasive cleaners, steel wool pads, or other abrasive

material.

■ This product is designed for household use only.

SAVE THESE INSTRUCTIONS

ELECTRICAL REQUIREMENTS

Do not use an extension cord. If the power

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions

can result in death, fire, or electrical shock.

Volts: 120 volts AC only Hertz: 60 Hz NOTE: This coffee maker has a 3-prong

grounded plug. To reduce the risk of electrical shock, this plug will fit in an outlet only one way. If the plug does not fit in the outlet, contact a qualified electrician. Do not modify the plug in any way.

supply cord is too short, have a qualified electrician or serviceman install an outlet near the appliance.

A short power supply cord (or detachable power supply cord) should be used to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

Longer detachable power supply cords or extension cords are available and may be used.

If a longer detachable power supply cord or extension cord is used:

■ The marked electrical rating of the

cord set or extension cord should be at least as great as the electrical rating of the appliance.

■ The cord should be arranged so that

it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord.

KITCHENAID® COFFEE MAKER FEATURES

A. Removable water tank B. Water tank lid C. Brew cavity lid D. Brew basket

E. Programmable display

F. Glass carafe (on glass carafe models only) G. Gold Tone permanent filter H. Thermal carafe (on thermal carafe models

only)

1-4 Cup Feature

This feature ensures optimum flavor even when you’re not brewing a full pot.

Automatic Brew Timer

An easy to set 24 hour brew timer will brew coffee at the selected time, day or night.

Clean Alert

The Clean Alert indicator reminds you when the coffee maker needs to be cleaned.

Pause and Pour Feature

Pause and pour lets you remove the carafe and pour a cup of coffee before brewing is finished. A special valve seals the brew basket tightly, eliminating drips.

End-Of-Brewing Tone

A tone sounds when coffee is finished brewing.

Automatic Shutoff

Coffee maker automatically shuts off 2 hours after brewing.

Brew Basket

Lift the front lid to access the removable, dishwasher-safe brew basket. The basket holds a 10-12 cup flat bottom paper coffee filter or the Gold Tone permanent filter.

Removable Water Tank

The coffee maker features a convenient removable water tank with water level indicators. Remove the tank and add water directly to the water tank or lift the lid to add water. It is recommended that the tank be hand washed.

Glass or Thermal Carafe

The 12-cup glass and 10-cup thermal carafes feature a dripless pouring spout and comfortable soft grip handle. Both carafes can be washed in the top rack of a dishwasher.

Gold Tone Permanent Filter

The high-performance Gold Tone filter eliminates the need for paper coffee filters. Coffee maker can also use paper filters, if desired. The Gold Tone filter can be washed in the top rack of a dishwasher.

Clock Display

Displays the time of day with AM and PM indicators. To save energy, the clock display goes into sleep mode and reduces the display brightness when the coffee maker is not in use.

Variable Brew Strength Selector

Allows you to select between REG and BOLD brew strengths.

DISPLAY AND CONTROL PAD FEATURES

Coffee Maker Controls

Coffee Maker Display

A. Mode button B. Auto/set button C. Brew button D. Bold button E. Up arrow button

Mode Button

Press to select program modes.

Auto/Set Button

Press to program an automatic brew time.

Brew Button

Press to select brew mode or to turn the coffee maker on or off.

Bold Button

Press to select Bold mode.

Up Arrow Button

Use the “Up Arrow” button to program the brew timer or set the time-of-day clock.

A. Auto set indicator B. Auto indicator C. 1-4 cups indicator D. Bold indicator E. Clean indicator

F. Clock/automatic

brew time display

Auto Set Indicator

Indicates coffee maker is in the Auto Set mode when lit.

Auto Indicator

Indicates coffee maker is in the Auto Brew mode when lit.

1-4 Cup Indicator

Indicates coffee maker is in the 1-4 Cup brew mode when lit.

Bold Indicator

Indicates coffee maker is in the Bold mode when lit.

Clean Indicator

This indicator will light when the coffee maker requires descaling.

Clock Display

Shows the time of day with AM or PM indicator and automatic brew time.

COFFEE BREWING SUGGESTIONS:

ADVICE FOR GREAT TASTE

Fresh Coffee Beans

Truly great coffee can only come from fresh coffee beans. To preserve the freshness of your beans, keep the beans in an opaque, airtight container and store them in a cool, dry place. Refrigeration is not recommended since condensation tends to form on the beans whenever the container is opened. Freezing can help preserve beans stored for an extended period, but it will also impair flavor.

The Right Grind

The best cup of coffee comes from coffee beans that are properly ground just before brewing. When grinding, be sure to grind your coffee to a medium grind level, the appropriate grind for automatic drip coffee makers.

Look for the KitchenAid coffee grinders at your local retailer or online at www.kitchenaid.com.

blade or burr

The Proper Amount of Ground Coffee

A good starting point is 1 tablespoon of coffee for every cup of brew water marked on the glass carafe or the water tank. Finer grinds usually require less coffee but may also produce bitterness and clog the filter.

For weaker coffee, brew using the suggested ratio of coffee grounds and water, then dilute with hot water. This maximizes flavor and minimizes bitterness.

Brew Water Purity

Great tasting coffee starts with fresh water. The removable water tank is easy to fill with water to give you great tasting coffee every time. It’s also easy to clean so you can always make your coffee with the freshest water.

Where local water is extremely poor, you may wish to use bottled water. Do not use distilled water or mineral water since they can damage your coffee maker.

Coffee Maker Cleanliness

Since the coffee oils that build up on the brew basket and carafe can go stale and impair the flavor of the brewed coffee, it’s important that these two items are cleaned daily in order to make the best tasting coffee.

PREPARING YOUR COFFEE MAKER FOR USE

Pre-Use Cleaning

Wash the brew basket, Gold Tone permanent filter, and carafe in hot, soapy water, then rinse with clean water and dry. Do not use abrasive cleansers or scouring pads.

Installing the Water Filter

Use of the water filter is strongly recommended. The filter reduces contaminants which impair the coffee flavor. Use of the filter is optional. The coffee maker will operate normally without it.

The water filter is for use only with municipally treated tap water or well water that is regularly tested for contaminants.

1. The filter consists of a long handle with a

filter cartridge at the end.

2. Place the filter cartridge in a separate

container filled with fresh, cool water. The cartridge should remain submerged in the water for 10 minutes. Rinse the filter under running water for 5 seconds after soaking.

3. Lift the water tank lid using the tab on

the rear of the lid.

4. Place the filter cartridge in the well at the

bottom of the water reservoir. Push the cartridge slightly to make sure it fits snugly.

5. Every time you install a new filter, run the

coffee maker through a complete brewing cycle without coffee. Use a full carafe of clean, cool water.

To Set the Time-of-Day Clock

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions

can result in death, fire, or electrical shock.

1. Plug into a grounded 3-prong outlet.

2. When the coffee maker is first plugged

in or when power is restored after an interruption, the brew timer display will initially show 12:00 AM.

3. Press the MODE button to enter the

Time/Clock Setting Mode. The hour digits will flash for the hour adjustment.

4. Press the “up arrow” button to increase

the hours. Holding this button increases the time faster.

5. Press the MODE button again. The

minutes digits will flash for the minutes adjustment.

6. Press the “up arrow” button to increase

the minutes. Holding this button increases the time faster.

7. Press the MODE button again. The

AM/PM digits will flash for the AM/PM adjustment.

8. Press the “up arrow” button to switch

between AM and PM.

KITCHENAID® COFFEE MAKER USE

Brewing More Than 4 Cups of Coffee

NOTE: Brew one pot of fresh, cool water

and discard before brewing the first pot of coffee (first time use only).

1. Remove the water tank and fill with

enough fresh, cool water to make the desired amount of coffee. A graduated scale on the tank measures the amount of water needed. When replacing the tank, make sure to align the holes on the top of the tank with the tabs on the back of the coffee maker housing.

For glass carafe models only, the right side of the scale (Coffee) is a measurement of coffee volume. The left side of the scale (Water) indicates the amount of water needed to produce a given number of cups.

NOTE: The filter can be inserted and coffee grounds added without removing the brew basket from the coffee maker.

A. Locking handle

5. Insert a 10-12 cup flat bottom paper

filter or the Gold Tone permanent filter into the brew basket. Do not use both types of filters at the same time. Using both filters might cause water and coffee to overflow the brew basket.

6. Fill the filter with one rounded

tablespoon of ground coffee for each cup desired. Use a medium grind appropriate for automatic drip coffee makers. Too fine a grind will produce bitterness and may clog the coffee filter.

2. For glass carafe models only, lift the

tank lid and fill the water reservoir with fresh, cool water. Water can also be poured directly into the reservoir at the back of the coffee maker.

3. After filling the reservoir, place the carafe

in the coffee maker. Make sure the lid is securely in position and the bottom of the carafe is fully seated. If the carafe is not seated, the Pause and Pour feature may not engage and may cause water and coffee to overflow the brew basket.

4. Remove the brew basket from the top of

the coffee maker by grasping the locking handle on the basket.

NOTE: Always place the filter and coffee into the removable brew basket. Do not operate the coffee maker without the brew basket in place.

7. Shake the brew basket slightly to even

out the bed of coffee. Place the basket into the coffee maker and rotate the handle toward the front of the coffee maker to lock the brew basket in place. Be sure the brew basket lid is fully closed before brewing.

8. Press the BREW button to begin

brewing coffee. If you are brewing only 1 to 4 cups of coffee, refer to the “Brewing 1-4 Cups of Coffee” section.

NOTE: Lifting the brew basket lid while coffee is brewing will interrupt the brew process and impair flavor.

9. The coffee maker will sound the

end-of-brew beeps when brewing is complete.

10. For glass carafe models only, at the end

of 2 hours, the coffee maker will automatically shut off. To turn off the coffee maker manually, press the BREW button. The outside of the carafe may be warm to the touch after brewing. Use discretion when placing the carafe on uncovered surfaces immediately after brewing.

11. Repeat steps 1-8 to brew additional

carafes of coffee. Always turn off the coffee maker and allow it to cool for 5 minutes before starting the next brew cycle.

Brewing 1-4 Cups of Coffee

NOTE: Brew one pot of fresh, cool water

and discard before brewing the first pot of coffee (first time use only).

1. Repeat steps 1-7 in the “Brewing

Coffee” section.

2. Press the MODE button 4 times to enter

the “1-4 Cup Mode.”

3. Press the BREW button. The “1-4 Cups”

indicator remains on until the coffee maker has completed the brewing cycle.

NOTE: Lifting the front lid while coffee is brewing will interrupt the brew process and impair flavor.

4. The coffee maker will sound the end-of-

brewing tone when brewing is complete.

5. For glass carafe models only, at the end

6. Repeat steps 1-5 to brew additional

carafes of coffee. Always turn off the coffee maker and allow it to cool for 5 minutes before starting the next brew cycle.

COFFEE MAKER ENHANCED FEATURES

Pause and Pour Feature

The “Pause and Pour” feature enables you to remove the carafe from the coffee maker and pour a cup of coffee before brewing is finished. When the carafe is removed, a special valve stops the flow of coffee from the brew basket. However, brewing does not stop. If the carafe is not placed back in the coffee maker within 15 seconds, water and coffee grounds will overflow the brew basket.

Automatic Brew Timer

The coffee maker can be programmed to brew coffee at a preset time, making it easy to wake up to fresh coffee every morning. To program and activate the Automatic Brew Timer:

1. Press the AUTO SET button to enter the

Auto Brew setting mode. The “Hours” indicator will flash and the “Auto Set” indicator will turn on and stay on during the Auto Brew programming cycle.

2. Press the “up arrow” button to increase

the hours. Holding this button increases the time faster.

3. Press the AUTO SET button. The

“Minutes” indicator will flash. Press the “up arrow” button to increase the minutes. Holding this button increases the time faster.

4. Press the AUTO SET button. The “AM/

PM” indicator will flash. Press the “up arrow” button to switch between AM and PM.

5. Press the AUTO SET button to exit

programming the Auto Brew setting. The “Auto Set” indicator will turn off.

Brew Strength

The coffee maker can be programmed to brew coffee at bold (BOLD) strengths (the default brew strength is regular).

To program and activate the “Bold” mode setting:

1. Press the BOLD button to select the

“Bold” indicator. NOTE: Once “Bold” is selected, it

remains on until it is turned off.

Immediate Brew

1. Press the BREW button 1 time. The

coffee maker will beep, and the Brew button light will turn on. Once the brew cycle is complete, the coffee maker will beep 3 times.

NOTE: The warming plate is automatically turned on during the brew cycle.

2. If desired, press the BREW button after

the brew cycle is complete to turn off the warming plate. The Brew button light will turn off.

Auto Brew

1. Press and hold the BREW button. The

“Auto” indicator will turn on and the brew button will flash until the coffee maker begins brewing. Once the set brew time is reached, the “Brew” button light will turn on and the coffee maker will beep.

NOTE: The warming plate is automatically turned on during the brew cycle.

2. If desired, press the BREW button after

the brew cycle is complete to turn off the warming plate. The Brew button light will turn off.

COFFEE MAKER CARE

Cleaning the Coffee Maker

1. Remove the brew basket and carafe

from the coffee maker.

2. Wash the brew basket and Gold Tone

permanent filter in hot, soapy water and rinse with hot water. Do not use abrasive cleansers or scouring pads. These parts can also be washed in the upper rack of a dishwasher.

3. Unplug the coffee maker and wipe the

housing with a warm, soapy cloth. Then wipe clean with damp cloth and dry with a soft cloth. Do not use abrasive cleansers or scouring pads.

Descaling the Coffee Maker

The coffee maker can be descaled using a packaged descaling agent or vinegar. Always mix the descaling solution using cool water.

■ When using a descaling agent, follow

the directions on the package for the recommended amounts of descaling agent and water to use.

■ When using vinegar, fill the carafe with a

solution consisting of ¹⁄₂ vinegar and ¹⁄₂ water.

Clean Indicator

Calcium deposits (scale) from water will build up in the coffee maker heat pump over time and impair brewing efficiency and coffee quality. When the coffee maker detects scale buildup, the “Clean” indicator will light. Once this occurs, descaling should be done as soon as possible to preserve the performance and life of your coffee maker.

Clean

1. Before descaling, always remove the

water filter (see the “Installing the Water Filter” section) and make sure the brew basket contains no coffee or coffee filters.

2. Run the coffee maker through a

complete Clean cycle using a full tank of the descaling solution.

3. Press the MODE button 5 times to enter

the “Clean” mode. The “Clean” indicator will flash until this programming cycle is complete.

NOTE: To cancel the Clean mode, press the MODE button.

4. Press the BREW button to start the

cleaning cycle. Once the cleaning cycle is complete, the “Clean” indicator will turn off.

5. Rinse the coffee maker by running it

through 2 brewing cycles using a full water tank of fresh, cool water each time.

6. Wash the brew basket in hot, soapy

water and rinse with hot water. The brew basket can also be washed in the upper rack of the dishwasher.

7. Reinstall or replace the water filter.

Replace the filter every 3 months under normal use. Replace it more often under heavy use.

TROUBLESHOOTING

■ If the brew timer display is not

illuminated:

Check to see whether the coffee maker is plugged into a grounded 3-prong outlet. If it is, check the fuse or circuit breaker on the electrical circuit the coffee maker is connected to and make sure the circuit is closed.

■ If only a portion of the water added to

the coffee maker actually brews:

The coffee maker requires immediate descaling. Please refer to “Descaling the Coffee Maker” in the “Coffee Maker Care” section.

■ If “Er1” appears on the brew button

timer display:

A button may be jammed. Unplug the coffee maker and press each button several times.

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions

can result in death, fire, or electrical shock.

Plug the coffee maker into a grounded 3-prong outlet.

If “Er1” appears again on the display, repeat this procedure.

■ If the problem cannot be corrected:

See the KitchenAid warranty section. Do not return the coffee maker to the retailer; retailers do not provide service.

PROOF OF PURCHASE AND PRODUCT

REGISTRATION

Always keep a copy of the sales receipt showing the date of purchase of your coffee maker. Proof of purchase will assure you of in-warranty service.

Before you use your coffee maker, please fill out and mail your product registration card packed with the unit. This card will enable us to contact you in the unlikely event of a product safety notification and assist us in complying with the provisions of the Consumer Product Safety Act. This card does not verify your warranty. Please complete the following for your personal records:

Model Number ___________________________________________________________________________ Serial Number ___________________________________________________________________________ Date Purchased__________________________________________________________________________ Store Name and Location_________________________________________________________________

KITCHENAID® COFFEE MAKER WARRANTY

Length of Warranty: KitchenAid Will Pay For: KitchenAid Will Not Pay

50 United States, the District of Columbia, Canada, and Puerto Rico:

One-year limited warranty from date of purchase.

50 United States, the District of Columbia and Canada: Hassle-free

replacement of your coffee maker. See the following page for details on how to arrange for replacement.

OR In Puerto Rico: The

replacement parts and repair labor costs to correct defects in materials and workmanship. Service must be provided by an Authorized KitchenAid Service Center. To arrange for service, follow the instructions in the “How to Arrange for Warranty Service in Puerto Rico.”

For:

A. Repairs when coffee

maker is used in other than normal single family home use.

B. Damage resulting from

accident, alteration, misuse or abuse or use with products not approved by KitchenAid.

C. Replacement parts or

repair labor costs for coffee maker when operated outside the country of purchase.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED TO THE EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD ALLOWED BY LAW. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS OR EXCLUSIONS ON HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.

+ 33 hidden pages
