KitchenAid FREESTANDING AND SLIDE-IN GAS RANGES User Manual

INSTALLATION INSTRUCTIONS

30" (76.2 CM) FREESTANDING AND SLIDE-IN

GAS RANGES

INSTRUCTIONS POUR L’INSTALLATION

DES CUISINIÈRES AUTOPORTANTES ET

ENCASTRABLES DE 30" (76,2 CM)

Table of Contents/Table des matières..................................................................................2

IMPORTANT:

Save for local electrical inspector's use.

Installer: Leave installation instructions with the homeowner. Homeowner: Keep installation instructions for future reference.

IMPORTANT :

À conserver pour consultation par l'inspecteur local des installations électriques.

Installateur : Remettre les instructions d'installation au propriétaire. Propriétaire : Conserver les instructions d'installation pour référence ultérieure.

W10118262A

TABLE OF CONTENTS

TABLE DES MATIÈRES

RANGE SAFETY .............................................................................2

INSTALLATION REQUIREMENTS................................................4

Tools and Parts ............................................................................4

Location Requirements................................................................4

Electrical Requirements ...............................................................7

Gas Supply Requirements ...........................................................7

Countertop Preparation ...............................................................8

INSTALLATION INSTRUCTIONS..................................................9

Unpack Range..............................................................................9

Measure for Proper Height...........................................................9

Adjust Leveling Legs..................................................................10

Install Anti-Tip Bracket...............................................................10

Remove Warming or Storage Drawer........................................11

Verify Anti-Tip Bracket Location ................................................11

Level Range................................................................................11

Make Gas Connection ...............................................................11

Electronic Ignition System .........................................................13

Replace Oven Racks and Warming or Storage Drawer............15

Complete Installation .................................................................15

GAS CONVERSIONS....................................................................16

LP Gas Conversion ....................................................................16

Natural Gas Conversion.............................................................18

ANTI-TIP BRACKET TEMPLATE ................................................39

SÉCURITÉ DE LA CUISINIÈRE ...................................................21

EXIGENCES D’INSTALLATION...................................................22

Outillage et pièces......................................................................22

Exigences d'emplacement.........................................................22

Spécifications électriques ..........................................................25

Spécifications de l’alimentation en gaz .....................................25

Préparation du plan de travail....................................................26

INSTRUCTIONS D'INSTALLATION.............................................27

Déballage de la cuisinière ..........................................................27

Mesures pour une hauteur appropriée ......................................27

Réglage des pieds de nivellement .............................................28

Installation de la bride antibasculement ....................................28

Retrait du tiroir-réchaud ou du tiroir de remisage .....................29

Vérification de l'emplacement de la bride antibasculement......29

Réglage de l’aplomb de la cuisinière.........................................29

Raccordement à la canalisation de gaz.....................................30

Système d'allumage électronique..............................................31

Réinstallation des grilles du four et du tiroir-réchaud

ou du tiroir de remisage .............................................................33

Achever l’installation ..................................................................34

CONVERSIONS POUR CHANGEMENT DE GAZ.......................34

Conversion pour l'alimentation au propane...............................34

Conversion pour l'alimentation au gaz naturel ..........................37

GABARIT POUR LA BRIDE ANTIBASCULEMENT....................39

RANGE SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

You can be killed or seriously injured if you don't immediately

DANGER

WARNING

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

follow instructions.

can be killed or seriously injured if you don't

You instructions.

WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death.

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this

–

or any other appliance. WHAT TO DO IF YOU SMELL GAS:

–

Do not try to light any appliance.

•

Do not touch any electrical switch.

•

Do not use any phone in your building.

•

Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's

•

instructions. If you cannot reach your gas supplier, call the fire department.

•

Installation and service must be performed by a qualified installer, service agency or

–

the gas supplier.

In the State of Massachusetts, the following installation instructions apply:

■ Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by

the State of Massachusetts.

■ If using a ball valve, it shall be a T-handle type.

■ A flexible gas connector, when used, must not exceed 3 feet.

WARNING

Tip Over Hazard A child or adult can tip the range and be killed. Connect anti-tip bracket to rear range foot. Reconnect the anti-tip bracket, if the range is moved. Failure to follow these instructions can result in death or serious burns to children and adults.

INSTALLATION REQUIREMENTS

Tools and Parts

Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here.

Tools needed

■ Tape measure

■ Flat-blade screwdriver

■ Phillips screwdriver

■ Level

■ Hand or electric drill

■ Hammer

■ Wrench or pliers

■ Pipe wrench

■ ¹⁵⁄₁₆" combination wrench

■ ³⁄₈" nut driver

■ ¹⁄₈" (3.2 mm) drill bit (for

wood floors)

■ Marker or pencil

■ Masking tape

■ Pipe-joint compound

resistant to LP gas

■ ³⁄₁₆" (4.8 mm) carbide-tipped

masonry drill bit (for concrete/ceramic floors)

■ Noncorrosive leak-detection

solution

For LP/Natural Gas Conversions

■ ½" combination wrench

■ 7 mm combination wrench

■ 7 mm nut driver

■ Size T20 TORX

®†

screwdriver

Rear Filler Strip (optional)

The filler strip may be used to fill a gap between the rear of the slide-in range and the wall in a freestanding range cutout.

Parts supplied

Check that all parts are included.

A. Anti-tip bracket B. Plastic anchors (2) C. #10 x ¹⁄₂" screws (2)

■ Anti-tip brackets must be securely mounted to subfloor.

Thickness of flooring may require longer screws to anchor bracket to subfloor. Longer screws are available from your local hardware store.

Parts needed

Check local codes and consult gas supplier. Check existing gas supply and electrical supply. See “Electrical Requirements” and “Gas Supply Requirements” sections.

A. Filler strip B. Countertop C. Countertop cutout

To order, see the “Assistance or Service” section of the Use and Care Guide. Order Part Number W10113902A (black), W10113903A (white) or W10113904A (biscuit).

Location Requirements

IMPORTANT: Observe all governing codes and ordinances. Do not obstruct flow of combustion and ventilation air.

■ It is the installer’s responsibility to comply with installation

clearances specified on the model/serial rating plate. The model/serial rating plate is located inside the oven door on the right-hand side oven door trim.

■ The range should be located for convenient use in the

kitchen.

■ Recessed installations must provide complete enclosure of

the sides and rear of the range.

■ To eliminate the risk of burns or fire by reaching over heated

surface units, cabinet storage space located above the surface units should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a range hood or microwave hood combination that projects horizontally a minimum of 5" (12.7 cm) beyond the bottom of the cabinets.

■ All openings in the wall or floor where range is to be installed

must be sealed.

■ Do not seal the range to the side cabinets.

■ Cabinet opening dimensions that are shown must be used.

Given dimensions are minimum clearances.

■ The floor anti-tip bracket must be installed. To install the anti-

tip bracket shipped with the range, see “Install Anti-Tip Bracket” section.

†®TORX is a registered trademark of Textron Innovations Inc.

■ Grounded electrical supply is required. See “Electrical

Requirements” section.

■ Proper gas supply connection must be available. See “Gas

Supply Requirements” section.

■ Contact a qualified floor covering installer to check that the

floor covering can withstand at least 200°F (93°C).

■ Use an insulated pad or ¼" (0.64 cm) plywood under range if

installing range over carpeting.

IMPORTANT: Some cabinet and building materials are not designed to withstand the heat produced by the oven for baking and self-cleaning. Check with your builder or cabinet supplier to make sure that the materials used will not discolor, delaminate or sustain other damage.

Product Dimensions

Mobile Home - Additional Installation Requirements

The installation of this range must conform to the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 (formerly the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD Part 280). When such standard is not applicable, use the Standard for Manufactured Home Installations, ANSI A225.1/NFPA 501A or with local codes.

In Canada, the installation of this range must conform with the current standards CAN/CSA-A240-latest edition, or with local codes.

Mobile home installations require:

■ When this range is installed in a mobile home, it must be

secured to the floor during transit. Any method of securing the range is adequate as long as it conforms to the standards listed above.

Freestanding Range

F**

A. 5³⁄₄" (14.6 cm) B. 30" (76.2 cm) C. 41³⁄₄" (106 cm) overall height

with leveling legs screwed all the way in.

D. 36" (91.4 cm) cooktop trim

height with leveling legs screwed all the way in*

E. Model/serial number plate

(located on the right-hand side oven door trim)

F. 2 7

¹⁄₄

" (69.2 cm) max. from handle to standoff at back of range**

Slide-in Range

E**

A. 30⁹⁄₁₆" (77.6 cm) B. 35⁵⁄₈" (90.5 cm) height to

underside of cooktop edge with leveling legs screwed all the way in*

C. Model/serial number plate

(located on the right-hand side oven door trim)

D 30" (76.2 cm)

E. 27¼" (69.2 cm) from

handle to standoff at back of range**

F. 23" (58.4 cm) countertop

notch to rear of cooktop

*Range can be raised approximately 1" (2.5 cm) by adjusting

the leveling legs.

**When installed in a 24" (61 cm) base cabinet with 25" (63.5 cm)

countertop; front of oven door protrudes 1" (2.5 cm) beyond 24" (61 cm) base cabinet.

*Range can be raised approximately 1" (2.5 cm) by adjusting

the leveling legs.

**When installed in a 24" (61 cm) base cabinet with 25" (63.5 cm)

countertop; front of oven door protrudes 1³⁄₄" (4.4 cm) beyond 24" (61 cm) base cabinet.

Installation Clearances

Cabinet opening dimensions shown are for 25" (64 cm) countertop depth, 24" (61 cm) base cabinet depth and 36" (91.4 cm) countertop height.

Freestanding Ranges Slide-In Ranges

A. 18" (45.7 cm) upper cabinet to countertop B. 13" (33 cm) upper cabinet depth C. 30" (76.2 cm) min. opening width D. For minimum clearance to top of the cooktop, see NOTE. E. 30" (76.2 cm) min. opening width

F. This shaded area recommended for installation of rigid gas pipe. G. 6" (15.2 cm) available area for gas and electric installation H. Grounded outlet

I. 7" (17.8 cm)

J. 1¹⁄₂" (3.8 cm)

K. 4¹⁄₂" (11.4 cm)

L. 5" (12.7 cm) min. clearance from both sides of the range to the

side wall or other combustible material.

M. Cabinet door or hinge should not extend into the cutout.

A. 18" (45.7 cm) upper cabinet to countertop B. 13" (33 cm) max. upper cabinet depth C. 30" (76.2 cm) min. opening width D. For minimum clearance to top of the cooktop, see NOTE.

E. 30" (76.2 cm) min. opening width F. This shaded area recommended for installation of rigid gas pipe.

G. 6" (15.2 cm) available area for gas and electric installation

H. Grounded outlet

I. 7" (17.8 cm)

J. 1¹⁄₂" (3.8 cm)

K. 4¹⁄₂" (11.4 cm)

L. 5" (12.7 cm) min. clearance from both sides of the range to the

side wall or other combustible material for models KGSS907 and KGRS807. 2" (5.1 cm) min. clearance for model KGSK901

M. 22

¹⁵⁄₁₆

" (58.3 cm) opening depth

N. ¾" (1.9 cm) radius both corners

O. Cabinet door or hinge should not extend into the cutout.

NOTE: 24" (61 cm) minimum when bottom of wood or metal cabinet is protected by not less than ¹⁄₄" (0.64 cm) flame retardant millboard covered with not less than No. 28 MSG sheet steel, 0.015" (0.4 mm) stainless steel, 0.024" (0.6 mm) aluminum or

0.020" (0.5 mm) copper. 30" (76.2 cm) minimum clearance between the top of the cooking platform and the bottom of an unprotected wood or metal cabinet. If installing a range hood or microwave hood combination above the range, follow the range hood or microwave hood combination

installation instructions for dimensional clearances above the cooktop surface.

Electrical Requirements

Gas Supply Requirements

WARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death,

fire, or electrical shock.

IMPORTANT: The range must be electrically grounded in accordance with local codes and ordinances, or in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70 or Canadian Electrical Code, CSA C22.1.

This range is equipped with an electronic ignition system that will not operate if plugged into an outlet that is not properly polarized.

If codes permit and a separate ground wire is used, it is recommended that a qualified electrical installer determine that the ground path is adequate.

A copy of the above code standards can be obtained from:

National Fire Protection Association

One Batterymarch Park

Quincy, MA 02269

CSA International

8501 East Pleasant Valley Road

Cleveland, OH 44131-5575

■ A 120 volt, 60 Hz., AC only, 15-amp fused, electrical circuit is

required. A time-delay fuse or circuit breaker is also recommended. It is recommended that a separate circuit serving only this range be provided.

■ Electronic ignition systems operate within wide voltage limits,

but proper grounding and polarity are necessary. Check that the outlet provides 120-volt power and is correctly grounded.

■ The wiring diagram is located on the underside of the storage

drawer or below the warming drawer in a clear plastic bag. NOTE: The metal chassis of the range must be grounded in

order for the control panel to work. If the metal chassis of the range is not grounded, no keypads will operate. Check with a qualified electrician if you are in doubt as to whether the metal chassis of the range is grounded.

WARNING

Explosion Hazard Use a new CSA International approved gas supply line. Install a shut-off valve. Securely tighten all gas connections. If connected to LP, have a qualified person make sure

gas pressure does not exceed 14" (36 cm) water column.

Examples of a qualified person include: licensed heating personnel,

authorized gas company personnel, and authorized service personnel.

Failure to do so can result in death, explosion, or fire.

Observe all governing codes and ordinances. IMPORTANT: This installation must conform with all local codes

and ordinances. In the absence of local codes, installation must conform with American National Standard, National Fuel Gas Code ANSI Z223.1 - latest edition or CAN/CGA B149 - latest edition.

IMPORTANT: Leak testing of the range must be conducted according to the manufacturers instructions.

Type of Gas

Natural gas:

This range is design-certified by CSA International for use with Natural gas or, after proper conversion, for use with LP gas.

■ This range is factory set for use with Natural gas. See “Gas

Conversions” section. The model/serial rating plate located on the right side oven door trim has information on the types of gas that can be used. If the types of gas listed do not include the type of gas available, check with the local gas supplier.

LP gas conversion:

Conversion must be done by a qualified service technician. No attempt shall be made to convert the appliance from the gas

specified on the model/serial rating plate for use with a different gas without consulting the serving gas supplier. See “Gas Conversions” section.

Gas Supply Line

■ Provide a gas supply line of ¾" (1.9 cm) rigid pipe to the

range location. A smaller size pipe on longer runs may result in insufficient gas supply. Pipe-joint compounds that resist the action of LP gas must be used. Do not use TEFLON tape. With LP gas, piping or tubing size can be ½" (1.3 cm) minimum. Usually, LP gas suppliers determine the size and materials used in the system.

†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.

®†

Flexible metal appliance connector:

■ If local codes permit, a new CSA design-certified,

4 - 5 ft (122 - 152.4 cm) long, ½" (1.3 cm) or ¾" (1.9 cm) I.D., flexible metal appliance connector may be used for connecting range to the gas supply line.

Burner Input Requirements

Input ratings shown on the model/serial rating plate are for elevations up to 2,000 ft (609.6 m).

For elevations above 2,000 ft (609.6 m), ratings are reduced at a rate of 4% for each 1,000 ft (304.8 m) above sea level (not applicable for Canada).

■ A ½" (1.3 cm) male pipe thread is needed for connection

to the female pipe threads of the inlet to the appliance pressure regulator.

■ Do not kink or damage the flexible metal tubing when

moving the range.

Rigid pipe connection: The rigid pipe connection requires a combination of pipe

fittings to obtain an in-line connection to the range. The rigid pipe must be level with the range connection. All strains must be removed from the supply and fuel lines so range will be level and in line.

■ Must include a shutoff valve:

The supply line must be equipped with a manual shutoff valve. This valve should be located in the same room but external to the range. It should be in a location that allows ease of opening and closing. Do not block access to shutoff valve. The valve is for turning on or shutting off gas to the range.

Gas Supply Pressure Testing

Line pressure testing above ½ psi gauge (14" WCP)

The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psi (3.5 kPa).

Line pressure testing at ½ psi gauge (14" WCP) or lower

The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½ psi (3.5 kPa).

Countertop Preparation

(for Slide-in Ranges Only)

The cooktop sides of the slide-in range fit over the cutout edge of your countertop.

If you have a square finish (flat) countertop and the opening width is 30" (76.2 cm), no countertop preparation is required.

Formed front-edged countertops must have molded edge shaved flat ³⁄₈" (1.0 cm) from each front corner of opening.

Tile countertops may need trim cut back ³⁄₈" (1.0 cm) from each front corner and/or rounded edge flattened.

30"

(76.2 cm)

³⁄₈"

(1.0 cm)

A. Gas supply line B. Shutoff valve “open” position C. To range

Gas Pressure Regulator

The gas pressure regulator supplied with this range must be used. The inlet pressure to the regulator should be as follows for proper operation:

Natural gas:

Minimum pressure: 5" WCP Maximum pressure: 14" WCP

LP gas:

Minimum pressure: 11" WCP Maximum pressure: 14" WCP Contact local gas supplier if you are not sure about the inlet

pressure.

30 ¾"

(78.1 cm)

If countertop opening width is greater than 30" (76.2 cm), adjust the ³⁄₈" (1.0 cm) dimension.

Countertop must be level. Place level on countertop, first side to side, then front to back. If countertop is not level, range will not be level. Range must be level for satisfactory baking conditions.

INSTALLATION INSTRUCTIONS

Unpack Range

WARNING

2. Measure from the floor to the underside of the range cooktop.

Excessive Weight Hazard

Use two or more people to move and install range. Failure to do so can result in back or other injury.

1. Remove shipping materials, tape and protective film from the

range. Keep cardboard bottom under range. Remove oven racks and parts package from inside oven.

2. To place range on its back, take 4 cardboard corners from the

carton. Stack one cardboard corner on top of another. Repeat with the other 2 corners. Place them lengthwise on the floor behind the range to support the range when it is laid on its back. Using 2 or more people, firmly grasp the range and gently lay it on its back on the cardboard corners.

3. Pull cardboard bottom firmly to remove.

Measure for Proper Height

Slide-In Ranges:

1. Measure the distance of the countertop to the floor. Measure

at all 4 locations corresponding to the 4 corners of the underside of the range cooktop, as shown.

A. Distance from the floor to

underside of range cooktop

B. Grate

3. Your leveling height will be the difference between the

2 measurements you have just taken.

C. Cooktop surface D. Range side frame

Freestanding Ranges:

1. Measure the distance of the countertop to the floor.

2. Measure from the top of the range cooktop trim to the floor.

Measure at locations marked A, B, C, D.

A. Distance from the top of the range

cooktop trim to the floor

3. Your leveling height will be the difference between the

2 measurements you have just taken.

Adjust Leveling Legs

1. If range height adjustment is necessary, use a wrench or

pliers to loosen the 4 leveling legs. This may be done with the range on its back or with the range

supported on 2 legs after the range has been placed back to a standing position.

NOTE: To place range back up into a standing position, put a sheet of cardboard or hardboard in front of range. Using 2 or more people, stand range back up onto the cardboard or hardboard.

WARNING

or serious burns to children and adults.

2. Adjust the leveling legs to the correct height. Leveling legs

can be loosened to add up to a maximum of 1" (2.5 cm). A minimum of ³⁄₁₆" (5 mm) is needed to engage the anti-tip bracket.

NOTE: If height adjustment is made when range is standing, tilt the range back to adjust the front legs, then tilt forward to adjust the rear legs.

3. When the range is at the correct height, check that there is

adequate clearance under the range for the anti-tip bracket. Before sliding range into its final position, check that the antitip bracket will slide under the range and onto the rear leveling leg prior to anti-tip bracket installation.

4. If countertop is not flush with cabinet opening edge, align

template with overhang.

If cabinet opening is wider than that specified in the “Location Requirements” section, adjust template so range will be centered in cabinet opening.

5. To mount anti-tip bracket to wood floor, drill two ¹⁄₈" (3.2 mm)

holes at the positions marked on the bracket template. Remove template from floor.

To mount anti-tip bracket to concrete or ceramic floor, use a ³⁄₁₆" (4.8 mm) masonry drill bit to drill 2 holes at the positions marked on the bracket template. Remove template from floor.

6. Tap plastic anchors into holes with a hammer.

7. Align anti-tip bracket holes with holes in floor. Fasten anti-tip

bracket with screws provided.

Install Anti-Tip Bracket

Contact a qualified floor covering installer for the best procedure for drilling mounting holes through your type of floor covering.

Before moving range, slide range onto shipping base, cardboard or hardboard.

1. Remove template from the anti-tip bracket kit (found inside

the oven cavity) or from the back of this manual.

2. Place template on the floor in cabinet opening so that the left

edge is against cabinet and top edge is against rear wall, molding or cabinet.

3. Tape template into place.

Depending on the thickness of your flooring, longer screws may be necessary to anchor the bracket to the subfloor. Longer screws are available from your local hardware store.

8. Move range close enough to opening to allow for final

electrical connection. Remove shipping base, cardboard or hardboard from under range.

9. Move range into its final location making sure rear leveling leg

slides into anti-tip bracket.

10. If installing the range in a mobile home, you must secure the

range to the floor. Any method of securing the range is adequate as long as it conforms to the standards in the “Location Requirements” section.

11. Continue installing your range using the following installation

instructions.

Remove Warming or Storage Drawer

Remove the warming or storage drawer to gain access to the lower section of the range. This will be necessary for some of the following installation steps.

To Remove Warming Drawer:

1. Open drawer to its fully open position.

2. Locate the black loops on both sides of the drawer.

If range is not level, pull range forward until rear leveling leg is removed from the anti-tip bracket.

Use a wrench or pliers to adjust leveling legs up or down until the range is level. Push range back into position. Check that rear leveling leg is engaged in the anti-tip bracket.

NOTE: Range must be level for satisfactory baking performance.

Make Gas Connection

WARNING

A. Loop

3. Pull both loops forward at the same time, then pull drawer out

another inch.

4. Holding the drawer by its sides, not its front, gently pull it all

the way out.

To Remove Storage Drawer:

1. Pull drawer straight out to the first stop.

2. Lift up the back of the drawer and pull out.

Verify Anti-Tip Bracket Location

IMPORTANT: On models with a warming drawer, the rear range foot must be viewed from the front and slightly to one side of the range.

1. Making sure the anti-tip bracket is installed:

■ Look for the anti-tip bracket securely attached to floor.

■ Slide range back so rear range foot is under anti-tip

bracket.

Explosion Hazard Use a new CSA International approved gas supply line. Install a shut-off valve. Securely tighten all gas connections. If connected to LP, have a qualified person make sure

gas pressure does not exceed 14" (36 cm) water column.

Examples of a qualified person include: licensed heating personnel,

authorized gas company personnel, and authorized service personnel.

Failure to do so can result in death, explosion, or fire.

Typical rigid pipe connection

A combination of pipe fittings must be used to connect the range to the existing gas line. Your connections may be different, according to the supply line type, size and location.

1. Apply pipe-joint compound made for use with LP gas to all

pipe thread connections.

2. Using a pipe wrench to tighten, connect the gas supply to the

range.

2. If installing the range in a mobile home, you must secure the

range to the floor. Any method of securing the range is adequate as long as it conforms to the standards in the “Location Requirements” section.

Level Range

Place rack in oven. Place level on rack and check levelness of the range, first side to side; then front to back.

A. Gas pressure regulator B. 90° elbow (must have

½" male pipe thread) C. Nipple D. Union E. Black iron pipe

F. Manual gas shutoff valve G. ½" or ¾" gas pipe H. Nipple

I. Union

J. 90° elbow

Typical flexible connection

1. Apply pipe-joint compound made for use with LP gas to the

smaller thread ends of the flexible connector adapters (see B and G in the following illustration).

2. Attach one adapter to the gas pressure regulator and the

other adapter to the gas shutoff valve. Tighten both adapters.

3. Use a ¹⁵⁄₁₆" combination wrench and channel lock pliers to

attach the flexible connector to the adapters. Check that connector is not kinked.

4. Test all connections by brushing on an approved

noncorrosive leak-detection solution. If bubbles appear, a leak is indicated. Correct any leak found.

5. Remove cooktop burner caps and grates from parts

package. Align notches in burner caps with pins in burner base. Burner caps should be level when properly positioned. If burner caps are not properly positioned, surface burners will not light.

A. Gas pressure regulator B. Use pipe-joint compound. C. Adapter (must have ½" male

pipe thread)

D. Flexible connector

E. Manual gas shutoff valve F. ½" or ¾" gas pipe

G. Use pipe-joint compound.

H. Adapter

Complete Connection

1. Locate gas pressure regulator at rear of storage or warming

drawer compartment. NOTE: On models with a warming drawer, an access cover

must be removed from the gas pressure regulator.

A. Burner base B. Burner cap C. Burner grate

6. Place burner grates over burners and caps as shown in the

following illustration. When properly installed the grates should not overlap the console.

Freestanding Models

A. Gas pressure regulator

IMPORTANT: Do not remove the gas pressure regulator.

2. Check that the gas pressure regulator shutoff valve is in the

“ON” position. The valve is on when the lever is parallel to the floor.

A. Gas pressure regulator shutoff valve

3. Open the manual shutoff valve in the gas supply line. The

valve is open when the handle is parallel to the gas pipe.

A. Closed valve B. Open valve

A. Opening in grate for wok insert to be

Slide-In Models

A. Large flange with rounded corner must be at

rear corner of the cooktop

located over left front burner.

+ 28 hidden pages
