Page 1
5 CUP CORDLESS FOOD CHOPPER
5KFCR500A, 5KFCR531A
OWNER’S MANUAL
W11677395A
Page 2
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed, including the following:
1. Read all instructions. Misuse of appliance may result in
personal injury.
2. To protect against risk of electrical shock, do not put the Base
of the appliance, USB Adapter, USB Cable, or Battery in water,
or other liquid.
3. This appliance is not intended for use by children or by persons
with reduced physical, sensory, or mental capabilities, or lack
of experience and knowledge.
4. Children should be supervised to ensure that they do not play
with the appliance.
5. Turn the appliance off, remove the Battery when not in use,
before assembling or disassembling parts and before cleaning.
6. Avoid contact with moving parts. Do not override any safety
controls.
7. Do not operate any appliance with a damaged Battery, adapter
or plug, after the appliance malfunctions, is dropped or
damaged in any manner. Return appliance to the nearest
Authorised Service Facility for examination, repair, or electrical
or mechanical adjustment. This will ensure that the safety of
the appliance and accessories is maintained.
8. The use of attachments/accessories not recommended or sold
by KitchenAid may cause fire, electric shock or injury to
persons.
9. Keep hands and utensils away from the cutting blade while
chopping food to reduce the risk of severe injury to person, or
damage to the appliance. A scraper may be used, but only
when the appliance is not running.
10. Blades are sharp. Handle thoroughly.
11. To reduce the risk of injury, never place cutting blade on Base
without first putting Bowl properly in place.
12. Be certain cover is securely locked in place before operating
the appliance.
13. Do not attempt to defeat the cover interlock mechanism.
2
Page 3
14. Do not use an extension cord. Plug adapter directly into power
source.
15. Do not incinerate this appliance even if it is severely damaged.
The Battery can explode in a fire.
16. Allow the appliance to cool completely before putting on or
taking off parts, and before cleaning the appliance.
17. Refer to the “Care and Cleaning” section for instructions on
cleaning the surfaces in contact with food.
18. Disconnect the Battery from the appliance before making any
adjustments, changing accessories, or storing appliance. Such
preventive safety measures reduce the risk of starting the
appliance accidentally.
19. Prevent unintentional starting. Ensure the switch is in the
off-position before connecting to Battery, picking up or carrying
the appliance. Carrying the appliance with your finger on the
switch or energizing appliance that have the switch ON invites
accidents.
20. Recharge only with the adapter specified by KitchenAid. A
adapter that is suitable for one type of Battery may create a risk
of fire when used with another Battery.
21. Use appliances only with KitchenAid 12 V Battery. Use of any
other Battery may create a risk of injury and fire.
22. When Battery is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connection from one
terminal to another. Shorting the Battery terminals together
may cause burns or a fire.
23. Under abusive conditions, liquid may be ejected from the
Battery; avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the Battery may cause irritation or burns.
24. Do not use a Battery or appliance that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable
behaviour resulting in fire, explosion or risk of injury.
25. Do not expose a Battery or appliance to fire or excessive
temperature. Exposure to fire or temperature above 129°C
may cause explosion.
EN
3
Page 4
26. Follow all charging instructions and do not charge the Battery
or appliance outside of the temperature range specified in the
instructions. Charging improperly or at temperatures outside of
the specified range may damage the Battery and increase the
risk of fire.
27. Never service damaged Battery. Service of Battery should only
be performed by the manufacturer or authorised service
providers.
28. Do not place the appliance on or near a hot gas or electric
burner or in a heated oven.
29. Do not use the appliance for other than intended use.
30. Do not expose the appliance to rain — store indoors.
31. Do not use the appliance in rain or wet conditions.
32. Do not modify or attempt to repair the appliance or the Battery
(as applicable) except as indicated in the instructions for use
and care.
33. When emptying the Bowl or during cleaning, be careful if hot
liquid is poured into the food processor or blender as it can be
ejected out of the appliance due to sudden steaming.
34. Remove empty batteries from the appliance and safely
dispose.
35. Remove the Battery if the appliance is stored unused for a long
period.
36. If the Battery leaks, remove the Battery from the appliance and
do not use the Battery again.
37. Remove rechargeable batteries from the appliance before
charging.
38. IMPORTANT: Use only with approved USB Adapter by market.
39. This appliance is intended to be used in household and similar
applications such as:
■ staff kitchen areas in shops, offices and other working
environments;
■ farmhouses;
■ by clients in hotels, motels and other residential type
environments;
■ bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
4
Page 5
For complete details on product information, instructions and
videos, including Guarantee information, visit
www.kitchenaid.com.au or www.KitchenAid.co.nz.
ELECTRICAL REQUIREMENTS
USB Adapter:
Input: 100–240 V~, 50–60 Hz, 0.5 A
USB Output: 5 VDC, 2 A
Recommended ambient charging temperature: 5–40°C
Cordless Food Chopper:
Voltage: 12 V
External Battery (Lithium-ion): 5KRB12A
Nominal Voltage: 10.8 VDC
Maximum Voltage: 12 VDC
NOTE: If the USB Adapter does not fit fully in the power source, contact a qualified electrician.
Do not modify the USB Adapter in any way.
NOTE: Do not use or store batteries or products in locations where the temperature is less
than 10°C or more than 40°C.
LITHIUM-ION BATTERY OPERATED PRODUCT
DISPOSAL
Always dispose the Battery operated products according to federal, state, and local
regulations. Contact a recycling agency in your area for recycling locations.
EN
GETTING STARTED
BEFORE FIRST USE
1. Charge the Battery until it is fully charged.
2. Clean all the parts and accessories (see “Care and Cleaning” section).
3. Remove all packaging materials, if present.
NOTE: Some dust may be on the product. This is due to the recycled materials used in
packaging. This can be cleaned with a soft towel.
BATTERY CHARGING
USING THE USB CABLE
1. Attach the USB Cable to the adapter. Connect the other end of the USB Cable to the
Battery.
2. Plug the USB Adapter into a power source.
PRODUCT USAGE
IMPORTANT: Make sure the Battery is fully charged before using.
1. Insert the Battery on the Battery slot located at the back of the appliance, making sure it is
aligned. The LED will glow and display the Battery level for five seconds, then turn off.
2. With the Handle facing the front of the Base, place the Bowl into the slots on the Base.
3. Rotate and lower the Drive Adapter and then Multipurpose Blade or optional Whisking
Accessory in the centre of the Bowl until it rests at the bottom.
5
Page 6
4. Add ingredients to the Bowl. Place the Lid on the Bowl. Twist and lock it into place. The Lid
will click when properly locked into place.
NOTE: The Cordless Food Chopper will operate with either the Multipurpose Blade or the
Whisking Accessory in place, not both. Do not try to use both at the same time.
5. Press and hold the button downward (Speed 1 or 2) to start. The LED will light and display
the Battery level for five seconds, then turn off.
IMPORTANT: The Bowl and Lid must be locked into place for the Cordless Food Chopper
to operate.
Use the Drizzle basin to conveniently add liquid ingredients while processing dressings,
mayonnaises, sauces, and more. Use the Pour spout for easier serving.
6. Release the button (speed 1 or 2) to stop chopping.
IMPORTANT: Do not try to remove the Bowl while the motor is still running.
7. Once processing is complete, remove the Lid, Drive Adapter, and Multipurpose Blade to
use the Pour Spout.
NOTE: The LED will light and display the Battery level for five seconds, then turn off.
8. Press and hold the Battery Unlock Button to remove the Battery.
9. Recommended volume for Multipurpose Blade: raw meat (0.7 lb), cheese (0.25 lb),
vegetable (3 cup), quick pulse until desired size.
TIP: A quick pulse is one second ON and one second OFF operation. Do not operate egg
whip continuously more than 2 minutes.
CARE AND CLEANING
IMPORTANT: Allow the appliance to cool completely before putting on or taking off parts, and
before cleaning the appliance. Remove the Battery before removing or attaching parts, or
before cleaning.
1. Remove the Lid, Multipurpose Blade, and Drive Adapter.
2. Dishwasher-safe parts — top rack only: Bowl, Lid, Whisking Accessory, Drive Adapter,
and Multipurpose Blade.
3. Wipe the Base with a damp cloth. Do not immerse the Base or Battery in water.
NOTE: Mild dish soap may be used, but do not use abrasive cleaners.
NOTE: For convenient storage, always reassemble the Cordless Food Chopper after
cleaning.
FOR DETAILED INFORMATION ABOUT THE CORDLESS FOOD CHOPPER:
Visit www.kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes,
and tips on how to use and clean your Cordless Food Chopper.
ELECTRICAL EQUIPMENT WASTE DISPOSAL
DISPOSAL OF PACKING MATERIAL
The packing material is recyclable and is marked with the recycle symbol . The various parts
of the packing must therefore be disposed of responsibly and in full compliance with local
authority regulations governing waste disposal.
RECYCLING THE PRODUCT
■ By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product.
■ The symbol
should not be treated as domestic waste but must be taken to an appropriate collection
centre for the recycling of electrical and electronic equipment.
6
on the product or on the accompanying documentation indicates that it
Page 7
For more detailed information about treatment, recovery and recycling of this product, please
contact your local city office, your household waste disposal service or the shop where you
purchased the product.
CUSTOMER SERVICE
In Australia:
For any questions, or to find the nearest Authorised KitchenAid Service Centre, please find our
contact details below.
NOTE: All service should be handled locally by an Authorised KitchenAid Service Centre.
Toll free number: 1-800-990-990
Phone number: 02 49026500
Address Australia:
KitchenAid Australia Pty Ltd
6-8 Billbrooke Close
Cameron Park NSW 2285, Australia
Phone: 1-800-990-990
Mobile: 02 49026500
Email: [email protected]
In New Zealand:
Website: www.KitchenAid.co.nz
Email: [email protected]
Phone: 0800 881 200
In other countries:
For all product related questions and after-sales matters, please contact your dealer to obtain
the name of the nearest Authorised KitchenAid Service/Customer Centre.
For complete details on product information, instructions and videos, including Guarantee
information, visit our website at: www.KitchenAid.com.au.
EN
©2023 All rights reserved.
7
