DSJ-B9 Quick Reference Guide
1
DSJ-B9 Quick Reference Guide
1
IMPORTANT NOTICE
Kirisun and our authorized partners own the intellectual property of all the parts of
this product (include accessories).
Any design and materials may not be modified, copied, extracted or translated
without the authorization of Kirisun or its authorized parities.
Due to the update or modification of the product, Kirisun owns the right to change
the specifications of software and hardware described in this manual without further
notice.
Specifications and information contained in this manual are for reference only.
Kirisun reserves the right to interpret the mistakes and errors occurring in this
manual, though all the contents are checked carefully.
DSJ-B9 Quick Reference Guide
2
SAFETY
The recorder meets the following product safety and radio disturbance
characteristics-limits and requirements:
IEC 60065: 1998 Audio, Video and Similar Electronic Apparatus-Safety
Requirements
IEC/CISPR 13-2001 Sound and television broadcast receivers and associated
equipment - Radio disturbance characteristics-Limits and methods of measurement
IEC61003-3-3:2008/IEC 61000-3-2:2001 Electromagnetic compatibility Limits
Limitation of voltage fluctuations and flicker in low-voltage supply systems for
equipment with rated current≤16A
This device complies with part 15B of the FCC Rules.
DSJ-B9 Quick Reference Guide
3
Use the Designated Accessories
Use USB cable and adapter supplied or sold by Kirisun only, or otherwise the data
cannot be read or cause damage to the product.
If you want to purchase or replace the accessories, please contact your local dealer
or Kirisun.
Product Operation Safety
Do not attempt to disassemble or modify this recorder, or it will get an electric shock
or cause malfunction.
Keep the plug of the adapter in dry and clean condition; otherwise it will cause fire
or electric shock;
Do not discard the recorder in the fire to avoid of explosion, for there is a built-in
battery.
DSJ-B9 Quick Reference Guide
4
1. Product Overview
DSJ-B9 Quick Reference Guide
5
DSJ-B9 Quick Reference Guide
6
DSJ-B9 Quick Reference Guide
7
1. On/Off Button
2. Working Status LED Indicator
3 . LED Supplemental Light
4 . Infrared Lights
5 . Wide-angle Lens
6 . Video Positioning Light
7 . MIC
8 . Battery Cover
9 . Video Button
10. Push-to-talk (PPT) Button
11. Photo Button
12 . Record Button
13 . HDMI Interface
14 . USB Interface
15 . Belt Clip
16 . Playback Speaker
DSJ-B9 Quick Reference Guide
8
17 . Reset Button
18 . HD Display
19 . Down Key
20 . Charging LED Indicator
21 . File Explorer Button
22 . Up Key
23 . Battery Cover Switch
24 . Interface Connected with Two Way Radio
2. Basic Operation
2.1 On/Off Button
z Long press this button to power on/power off the DSJ-B9.
z In the viewfinder mode, short press this button to turn on/turn off the supplemental
LED.
z In the playback mode, short press this button to exit the present mode or return to
DSJ-B9 Quick Reference Guide
9
the upper menu.
z In the screen off mode, short press this button to exit the present mode.
2.2 Video Button
z In the viewfinder mode, short press the button to record the video or save the video
and return to the viewfinder mode.
z When the recorder is power off, long press the button into the video mode directly.
2.3 Photo Button
z In the viewfinder mode, short press the button to take photos.
z In the viewfinder mode, long press the button to take continuous shooting.
z In the video mode, short press the button to take snapshot.
2.4 Record Button
z In the viewfinder mode, short press the button to record or save the recording and
return to the recording mode.
DSJ-B9 Quick Reference Guide
10
2.5 Navigation Button (Up)
z In the viewfinder mode, short press the button to turn on /turn off the supplemental
light.
z While setting the resolution to 720P, in the viewfinder or video mode, long press
the button to zoom in from1 time to 4 times.
z In the file explorer mode, short press the button to select photo, video or recording
files.
z In the video playback mode, short press the button to fast forward 2 to 64 times.
z In the video playback mode, long press the button to increase the volume.
z In the recording playback mode, long press the button to increase the volume.
2.6 Navigation Button (Down)
z In the viewfinder mode, short press the button to turn on /turn off the infrared light.
z While setting the resolution to 720P, in the viewfinder or video mode, long press
the button to zoom out from 4 times to 1 time.
DSJ-B9 Quick Reference Guide
11
z In the file explorer mode, short press the button to choose photo, video or recording
files.
z In the video playback mode, short press the button to slow down 2 to 64 times the
view.
z In the video playback mode, long press the button to reduce the volume.
z In the recording playback mode, long press the button to reduce the volume.
2.7 Menu Button
z In the viewfinder mode, short press the button to get into file explorer mode.
z Shot press the button to view the picture, play video or record voice.
z In the playback mode, short press twice to get slide view of pictures.
z In the recording playback mode, long press the button to show the present version
of the software, short press the button to exit.
