Kira Home KLAL1588 Installation & Assembly

ITEM #: RV-CF6214-4

For any replacement parts or installation issues, please Contact Us!
Email: [e-mail]
Facebook/Instagram: @KiraHomeDecor
Phone: [phone]

IMPORTANT SAFETY INSTRUCTIONS

• To avoid injury or damage, mount only on a surface that is sturdy.

• To avoid electric shock, make sure the electricity is turned off at the main
circuit breaker panel. If you are replacing an existing fixture, turn off the
following in order: fixture, wall switch, and main fuse or breaker box.

Note: Some types of fuses must be unscrewed to shut the power off.

• If you are unclear as to how to proceed, please consult a licensed
electrician.

UNPACK THE FIXTURE: Check the contents of the box. Box should contain all items on the parts diagram.

INSTALLATION INSTRUCTIONS

1. Measure the fixture’s Canopy (D) height with measuring tape. Adjust Canopy Screws (E) on Mounting Plate

(A) to the height of measured Canopy (D) plus 1/4" to allow them to protrude through Canopy (D) during
installation. Lock Canopy Screws (E) in place with the hex nuts.

2. Secure Mounting Plate (A) to the junction box (not included) using Mounting Screws (B) provided. Ensure
Mounting Plate (A) is positioned with Canopy Screws (E) pointing away from the junction box.

3. Place Canopy (D) against the ceiling by inserting Canopy Screws (E) through the appropriate holes located
on Canopy (D). Adjust Canopy Screws (E) and hex nuts until 1/4' of the threaded portion is visible. Remove
Canopy (D) from the ceiling and set it aside.

Note: If 1/4" of Canopy Screws (E) are not visible, remove Canopy (D) and re-adjust Canopy Screws
(E) to proper length and lock them in place with the hex nuts.

4. Using the wire graph below, connect the appropriate wires from the fixture to the corresponding wires in the

electrical junction box (not included) and secure Wire Connectors (C).

A. Connect the ground wire (bare copper or green) from

your fixture to the:

1) ground wire in the junction box, or

2) ground screw in the junction box

B. Connect the BLACK house wire to fixture hot wire

that corresponds to diagram (black, round & smooth,
white/grey with tracer, brown/gold without tracer).

C. Connect the WHITE house wire to fixture neutral wire

that corresponds to diagram (white, ribbed/ridged,
white/grey without tracer, brown/gold with tracer).

5. Place all wires and Wire Connectors (C) back into the junction box.

6. Place Canopy (D) against the ceiling, ensuring Canopy Screws (E) are protruding through the holes in

Canopy (D). Secure the fixture in place to Mounting Plate (A) with Decorative Caps (F).

Note: If the fixture does not sit flush against the ceiling, remove the fixture and readjust Canopy
Screws (E) and hex nuts.

7. Install light bulbs (not included) into the sockets.

Enjoy your new fixture!

ITEM #: RV-CF6214-4 - PARTS DIAGRAM

HELPFUL TOOLS: Safety Goggles, Screwdriver, Ladder, Measuring Tape
