KIP 3100 User Manual

KATSURAGAWA ELECTRIC CO., LTD.

KIP 3100 User’s Guide

Version A.4 May 14, 2009

-Please read this USER’SGUIDE
beforeusing the printer.

-Please keep this USER’S GUIDE
for future reference.

(1)

Thank you for purchasing the Multi-Function Printer KIP 3100.

This USER'S GUIDE contains functional and operational explanations for the KIP 3100.
Please read this USER'S GUIDE carefully before using the Printer.
Please keep this USER'S GUIDE for future reference.

1. When this product is installed in North America.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.

2. When this product is installed in Europe
This equipment complies with the requirements in Pub.22 of CISPR Rules for a Class B
computing device.
Operation of this equipment in a residential area may cause unacceptable interference to radio
and TV reception requiring the operator to take whatever steps are necessary to correct the
interference.

Do not install Machine around other electronic equipment or other precision instruments.
Other devices may be effected by electrical noise during operation.

If the Machine is installed near other electronic equipment, such as a TV or a radio,
interference to said equipment, such as noise or flickering, may occur.
Use a separate power line and install the PRINTER as far as possible from said equipment.

The International

ENERGY STAR ® Office Equipment Program is an international program that

promotes energy saving through the penetration of energy efficient computers and other office
equipment. The program backs the development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which business proprietors can
participate voluntarily. The targeted products are office equipment such as computers, monitors,
printers, facsimiles, copiers, scanners, and multifunction devices. Their standards and logos are
uniform among participating nations.

The symbol shown indicates that this product conforms to Directive
2002/96/EC of the European Parliament and the council of 27 January
2003 on waste electrical and electronic equipment (WEEE) and does not
apply to countries outside of EU.

As an ENERGY STAR ® Partner, Katsuragawa Electric Co., Ltd. has determined
that this product meets the

ENERGY STAR ® guidelines for energy efficiency.

The symbol shown indicates that this product conforms to
SJ/T11364-2006 of People’s Republic of China Electronic
Industry Standard and does not apply to countries outside of
People’s Republic of China.

The symbol shown indicates that this product conforms to GB
18455-2001 11364-2006 of National Standard of the People’s
Republic of China and does not apply to countries outside of
People’s Republic of China.

인증받은 자의상호; 케이아이피비즈니스솔루션코리아주식회사
제조자; TAIWAN SANKEI CO., LTD.
제조국가; 대만

(2)

Safety Warnings

The following warnings are very important in order to safely use this product.
These notes are important in preventing danger to the operator or operation of the printer.

The following symbols are found throughout the USER’S Manual and have the following meaning:

WARNING

This WARNING mark means that there is a possibility of death or serious
injury if you ignore or do not follow the said instruction.

CAUTION

This CAUTION mark means that there is a possibility of injury or physical
damage if you ignore or do not follow the said instruction.

When marked with this symbol, “DO NOT ATTEMPT”

When marked with this symbol, “pay close attention to”

(3)

WARNING

1. The Power source should be as follows:
In U.S.A. : 120V plus/minus10%, 50/60Hz, 15A or higher
In Europe : 220-240V plus6% or minus10%, 50/60Hz, 10A or higher

2. Use a circuit with a dedicated breaker.

3. Install the product as close to the wall outlet as possible.

4. If you wish to move the printer, please contact your service personnel.

Ground the product with a correct ground source or you may be electrically
shocked.

1. Do not plug in the printer into a multi-wire connector in which some other
equipment is plugged into.
It may cause a fire due to outlet overheating.

2. Do not damage the Power Cord by stepping on or placing heavy items
on it.
If the Power Cord is damaged, it may cause a fire or you may receive
an electric shock. REPLACE THE CORD IF DAMAGED!

1. Do not put a flower vase, a flowerpot or any water-filled item on the
product.
Spilt water could cause a fire or an electric shock.

2. If the product generates an abnormal smell or noise, turn it off and
unplug it from the wall electrical outlet immediately.

1. Do not remove the screw and do not open the cover if not instructed to
do so in this User’s Manual. If you ignore this warning, you may be burnt
or receive an electric shock due to a hot item or electrically charged part
inside of the printer.

2. Do not disassemble or tamper with the printer.
It may result in a fire or an electrical shock.

Do not throw the toner into a fire or other sources of heat, as it can
explode.

(4)

CAUTION

There are hot items inside of the printer.
Take great care not to touch these items when you remove mis-fed media.

Do not pull the cord when you unplug the printer as you may damage the
Power Cord.

Do not install the printer in a humidified room or a dusty room.
Also, do not install the printer on an unstable floor as injuries may occur.

1. Unplug the printer before you move it.
The power cord may be damaged and it may result in a fire or electric
shock.

2. If you do not use the printer for a long duration (holidays, company
shutdown) turn off and unplug the printer from the outlet for safety.

Ventilate the room well if you print in a small area.

(5)

aaaPOWER CORD INSTRUCTIONaaa

The installation of (or exchange to) a power plug which fits in the wall outlet of the
installation location shall be conducted in accordance with the following:

WARNING
Select a power plug which meets the following criteria;

- The plug has a voltage and current rating appropriate for the product’s rating
marked on its name plate.

- The plug meets regulatory requirements for the area.

- The plug is provided with a grounding pin or terminal.

If the appropriate plug does not fit the wall outlet in the installation, the customer shall
install an appropriate outlet.

Connector Type:

Configuration Standard Rating Usually found in

IEC60320:C13 10A 250V

15A 125V

Plug Type: Model Rating 220-240V

Configuration Standard Rating Usually found in

CEE7/7 10A 250V European countries

KS C 8305 10A 250V Korea

AS/NZS 3112 10A 250V Australia

New Zealand

GB1002
GB2099.1

10A 250V China

IRAM 2073 10A 250V Argentina

BS 1363 10A 250V United Kingdom

SASO 2203 10A 250V Saudi Arabia

BS 546A
IS-1293
SABS-1293

15A 250V United Kingdom

India
South Africa

SEV 1011 10A 250V Switzerland

Chapter 1 Before Use 1-1

Chapter 1

Before Use

page

1. 1 Installation Requirements 1- 2

1. 2 Originals Prohibited from Duplication 1- 3

1. 3 Features 1- 4

1. 4 Specifications 1- 5

1. 5 Appearance 1- 7

1. 5. 1 Front view 1- 8

1. 5. 2 Rear view 1- 9

1. 6 Specifications for the Scan Original 1-10

1. 7 Specifications for the Printing Paper 1-13

1. 7. 1 Papers not available to use 1-13

1. 7. 2 Keeping the paper in the custody 1-14

1. 7. 3 Treatment against environmental condition 1-15

Chapter 1 Before Use 1-2

1. 1 Installation Requirements

The following conditions are required for installation of the equipment.

1. Power source should be rated as follows.
In U.S.A. : 120V plus/minus 10%, 50/60Hz, 15A or higher
In Europe : 220-240V plus 6% or minus10%, 50/60Hz, 10A or higher

2. The equipment must be on an exclusive circuit.

3. The outlet must be near the equipment and easily accessible.

1. Make sure to connect this equipment to a grounded outlet.

2. For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near
the equipment and shall be easily accessible.

The site temperature range = 10 to 32 degrees Centigrade, with the humidity between
15% to 85% RH. (NON CONDENSING)
Keep the printer away from water sources, boilers, humidifiers or refrigerators.

1. The installation site must not have open flames, dust or ammonia gases.

2. The equipment must not be exposed to the air vents from air conditioners.
It may affect the image quality.

3. The equipment should not be exposed to the direct sunlight.
Please draw curtains to block any sunlight.
When you open the Movable Unit, do not expose the Photoconductive Drum
to strong (intense) light as this will damage the Drum.

Ozone will be generated while this equipment is use, although the quantity generated
is within safe levels. (see certifications)
Ventilate the room, if required.

Keep ample room around the equipment to ensure comfortable operation.
(Refer to the following figure.)
The equipment must be leveled and the floor strength must be ample to sustain the
weight of the equipment.

KIP 3100

L* R*

(Front)

(Rear)

30cm/12” or larger when the
standard tray is installed

80cm/32” or larger (2 rolls)

65cm/26” or larger (1 roll)

*L + R = 35cm/14”
(R must be larger than L)

Chapter 1 Before Use 1-2

1. 1 Installation Requirements

The following conditions are required for installation of the equipment.

1. Power source should be rated as follows.
In U.S.A. : 120V plus/minus 10%, 50/60Hz, 15A or higher
In Europe : 220-240V plus 6% or minus10%, 50/60Hz, 10A or higher

2. The equipment must be on an exclusive circuit.

3. The outlet must be near the equipment and easily accessible.

1. Make sure to connect this equipment to a grounded outlet.

2. For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near
the equipment and shall be easily accessible.

The site temperature range = 10 to 32 degrees Centigrade, with the humidity between
15% to 85% RH. (NON CONDENSING)
Keep the printer away from water sources, boilers, humidifiers or refrigerators.

1. The installation site must not have open flames, dust or ammonia gases.

2. The equipment must not be exposed to the air vents from air conditioners.
It may affect the image quality.

3. The equipment should not be exposed to the direct sunlight.
Please draw curtains to block any sunlight.
When you open the Movable Unit, do not expose the Photoconductive Drum
to strong (intense) light as this will damage the Drum.

Ozone will be generated while this equipment is use, although the quantity generated
is within safe levels. (see certifications)
Ventilate the room, if required.

Keep ample room around the equipment to ensure comfortable operation.
(Refer to the following figure.)
The equipment must be leveled and the floor strength must be ample to sustain the
weight of the equipment.

KIP 3100

15cm/6”
or wider

15cm/6”
or wider

(Front)

(Rear)

30cm/12” or larger when the
standard tray is installed

80cm/32” or larger (2 rolls)

65cm/26” or larger (1 roll)

Chapter 1 Before Use 1-3

1. 2 Originals Prohibited from Duplication

It is not necessarily allowed to copy every kind of original.
You may be punished by the law if only you possess the copy of some kind of original.
We recommend you to consider enough before you copy such original.

[Originals prohibited from copying by the law]

1. It is not allowed to copy Currency (Bill, Money, Bank Note, etc.), Government issued
Negotiable Instruments (National Bonds, Security, Local Debt Bonds, etc.).

2. It is not allowed to copy Foreign Currency or Foreign Negotiable Instruments.

3. It is not allowed to copy unused postal stamps or government postcards without permission
to make replica from Government.

4. It is not allowed to copy Government issued revenue stamps, certificate stamps which are
prescribed by Liquor Tax Act or the Commodity Tax Act.

[Special items to be cared]

1. It is warned by the government to copy private issued securities (stock certificate, draft,
check, goods ticket, etc.), commutation ticket or book of tickets, excluding that some specific
company copies such originals as many as it requires for its own business.

2. We recommend you not to copy freely such originals as government issued passport, public
or private issued licenses, automobile inspection certification, IDs and tickets like pass or
meal.

Reference Law Prohibited items to copy

Regulations to control fake currency and
Bond.

Currency (Bill, Money, Bank Note, etc.),
Government issued Negotiable Instruments
(National Bonds, Security, Local Debt Bonds,

etc.)
Control Law against Forged & faked
Foreign Currency, Bill, Bank Note and Bond

Foreign Currency or Foreign Negotiable

Instruments
Forged postal stamps control law Unused postal stamps or government postcards
Forged revenue stamps control law Government issued revenue stamps, and

certificate stamps prescribed by Liquor Tax Act

or Commodity Tax Act
Currency similarity securities Control Law Private issued securities (stock, draft, check,

goods ticket, etc.), commutation or book tickets

[Originals protected by the copyright]

It is prohibited to copy such originals as book, music, paintings, printed copy, maps, drawings,
movie and pictures which are protected by the copyright, except for personnel or family use or
similar purpose.

Chapter 1 Before Use 1-4

1. 3 Features

(1) KIP 3100 Digital Printer is a Multi-Function Printer for scan, copy and print large format

documents. Some of these features may be optional.

(2) The operation speed is 80mm/s (5.8 D / minute landscape).

(3) The maximum print width is 914mm (36 inches) wide, and the minimum one is 210mm or 8.5”.

The maximum print length is 6,000mm (19.7 feet) (for 36 inch wide media), and the minimum
one is 210mm or 8.5 inches.

(4) 600dpi Calibrated LED Head and the KIP Image Process System is used for the highest image

quality.

(5) The combination of KIP Contact Development System and mono-component minute toner can

produce a high definition line, distinctive grayscale and consistent solid black.
The KIP HDP process generates no Waste Toner.

Chapter 1 Before Use 1-5

1. 4 Specifications

1. 4. 1 General

Subject Specification
Model KIP 3100
Configuration Console
Power consumption

(Maximum)

1,440W (Including Scanner & Controller Unit)

Power consumption
(Low power mode)

43.6W

Acoustic noise Idling Max. 60db

Printing Max. 65db

Impulse sound Max. 70db EN ISO 7779
Ozone Max. 0.05ppm (Measurement method under UL Standard)
Dimensions 1266mm (Width) x 600mm (Depth) x 1107mm (Height)

(UI is not included)
Weight About 485lbs (219kg) (1 roll)

About 511lbs (232kg) (2 roll)
Environmental condition
for usage

(Temperature)

50 to 89.6 F (10 to 32 degrees Centigrade)

(Humidity)

15 to 85% RH
Interface Network Interface (10 BASE-T / 100 BASE-TX)

Input power In the US : 120V plus/minus 10%, 50/60Hz, 12A

In Europe : 220-240V plus 6% or minus 10%, 50/60Hz, 7A

NOTE

The above specifications are subject to change without notice.

Chapter 1 Before Use 1-6

1. 4. 2 Printer part

Subject Specification
Printing method LED Array Electro photography
Photoreceptor Organic Photoconductive Drum
Print speed 80mm per second

(Inch) 3.4ppm/E 5.8ppm/D Landscape

(Metric) 3.3ppm/A0 5.6ppm/A1 Landscape
Print head LED Array
Resolution of print head 600dpi x 600dpi
Print width Maximum 36” or 914mm

Minimum 11” or 297mm (roll media)

8.5” or 210mm (cut sheet)

Print length Maximum

(Standard) 19.7ft (6,000mm) for 36” / A0 wide (plain paper)

or “5 x Standard length” (plain paper)

“2 x Standard length” (tracing paper)

“1 x Standard length” (film)

(Option) 75ft (24,000mm)

Minimum 8.5” or 210mm

Warm up time Shorter than 4 minutes 30 seconds

(At 23

o

C, 60%RH, the rated voltage, and plain paper is used)

First print time 18 seconds (D Landscape)

(At 23

o

C, 60%RH, the rated voltage, and plain paper is used)
Fusing method Heat and Pressure Rollers
Development method Dry type non-magnetic mono-component toner
Media (Recommended Media)

US model:
Bond Paper 64g/m

2

to 80g/m2, US Bond (PB-20)
Vellum US Vellum (XV-20)
Film 4MIL (PF-4DDME)
Europe/Asia model:
Plain Paper 64g/m

2

to 80g/m2, Oce Red Label (75g/m2)
Tracing Paper Oce Transparent Paper (80g/m

2

)

Film Oce 3.5MIL

Storage of consumables (Toner cartridge)

Store the cartridge within the temperature range from 0 to
35 degrees Centigrade and within the humidity range from 35
to 85% RH.

NOTE

The above specifications are subject to change without notice.

NOTE

If the print is longer than 6,000mm, its image quality or the
reliability of paper feeding is not guaranteed.

Chapter 1 Before Use 1-7

1. 4. 3 Scanner part

Subject Specification
Scanning method Contact Image Sensor (CIS)

(5 pieces of A4 sized CIS)

Light source LED (R/G/B)
Setting of original Face up
Starting point of scan Center
Scan width Max: 36” or 914.4mm

Min : 279.4mm

Scan length Max: 19.7ft or 6,000mm (Including the margin area)

Min : 8.5” or 210mm (Including the margin area)

Margin area 3mm from leading, trailing and both side edges
Optical resolution 600dpi
Digital resolution 200 / 300 / 400 / 600 dpi
Original transportation Sheet through type
Transportable original
thickness

Max: 1.60mm
Min : 0.05mm

Scanning speed 65 mm per second

NOTE

The above specifications are subject to change without notice.

NOTE

If the original is thicker than 0.6mm, its image quality is not
guaranteed.

Chapter 1 Before Use 1-8

1. 5 Appearance

1. 5. 1 Front view

No. Name Function

1 Main Switch You can turn on/off the KIP 3100.
2 Original Guides Feed the original under the Scanner Unit along the Original

Guides.

3 User Interface This is a Touch Screen, and many kinds of user operation

are available.

4 Emergent Stop Button Press this button when you would like to stop copying or

scanning emergently.
5 Original Tray These trays catch the original ejected from the Scanner Unit.
6 Scanner Unit Read the original with this unit when you make scan or copy.
7 Toner Hatch

(Original Table)

Open the Toner Hatch when you replace the Toner Cartridge.

Also put the original here and then feed it into the Scanner

Unit when you make scan or copy.
8 Engine Unit Open Lever Pull up these levers when you open the Engine Unit.

9 Bypass Feeder Feed a cut sheet paper from the Bypass Feeder.

10 Roll Deck Roll paper can be set here.

(You can set 1 roll paper normally, but 2 roll paper are

available if you install the optional 2nd Roll Deck.)

11 Print Tray Prints are stacked here after the ejection.
12 Counter It counts the total amount printing.
13 Stylus Use this to press buttons on the touch screen.

1

4

6

2

9

10

12

7

11

3

5

8

13

Chapter 1 Before Use 1-9

1. 5. 2 Rear view

No. Name Function

1 Exit Cover Open the Exit Cover when you remove the paper misfed

inside the Fuser Unit.

2 LAN Port Connect the LAN Cable to connect the KIP 3100 to the

network. (Do not connect a telephone line)

3 Dehumidify Heater Switch

(Optional in the US)

Turn on the Dehumidify Heater with this switch when you

would like to dry the paper in the humid season.
4 Breaker It is possible to shut off supplying the AC power.
5 Inlet Socket Connect the Power Cord here.
6 Print Guide Trays These trays guide the prints to the Print Tray.
7 COM Port (Optional) Connect the cable from the Optional Device.

(D-Sub Connector 9 pins: 12VDC max.)
8 USB Port 5VDC max.

1

2

4

5

7

3

6

8

Chapter 1 Before Use 1-10

1. 6 Specifications for the Scan Original

A scan original must satisfy the following specifications.

Thickness 0.05mm to 1.6mm
Width 279.4mm to 914.4mm
Length 210mm to 6,000mm

Do not scan the following kinds of originals. The original or the scanner may damage.

Sticked with paste

Torn

Folded (Leading edge)

Excessively curled
(a diameter of 50 mm or
less)

Paste

Chapter 1 Before Use 1-11

Not square

Wet

Metal or fabric material

Rough surface
(Carbon paper for example)

Clipped or stapled

KIP KIP

KIP KIP

KIP KIP

Wet

Metal Fabric

Clipped Stapled

Rough surface

Chapter 1 Before Use 1-12

The following kinds of originals can be read with using a carrier sheet.
Image quality or the reliability of paper feeding for them is not guaranteed.

Patched

Punched

Chapter 1 Before Use 1-13

1. 7 Specifications for the Printing Paper

1. 7. 1 Papers not available to use

Do not use the following kinds of printing paper. Doing so may damage the print engine.

Excessively curled
(a diameter of 50 mm or
less)

Folded

Creased

Torn

Punched

Chapter 1 Before Use 1-14

Pre-printed

Extremely slippery
Extremely sticky
Extremely thin and soft
OHP Film

1. 7. 2 Keeping the paper in the custody

Keep the paper in the custody taking care of the following matters.

1. Do not expose the paper to the direct sunlight.

2. Keep the paper away from high humidity. (It must be less than 70%)

3. Put the paper on a flat place

4. If you will keep the paper in the custody, which you have already unpacked, put it into the
polyethylene bag to avoid the humidity.

CAUTION

Do not use the paper with staple, or do not use such conductive paper as aluminium foil and
carbon paper.
The above may result in a danger of fire

NOTE

(1) Print image may become light if printed on a rough surface of the paper.

(2) Print image may become defective if the print paper has an excess curl.

(3) It will become a cause for paper mis-feed, defective print image or paper creasing if you
use a paper that does not satisfy the specification.

(4) Do not use a paper of which surface is very special, such as thermal paper, art paper,
aluminium foil, carbon paper and conductive paper.

(5) Do not use papers with unpacked (exposed in high / low temperature & humidity) in a
long period. Such papers may result in mis-feed, defective image or paper creasing.

(6) Tracing paper exposed to air over a long period tends to cause a defective printing.
Removing one round on the surface of the tracing roll paper from the beginning is
recommended.
Refer to [2.3 Replacement of Roll Paper] on page 2-5.
