Kintech PC7077ME User Manual

1

PC7077ME USER MANUAL

Brand Name: Kinwei

FCC ID: BRCPC7077ME

User Manual

2

Content

1. Preface

2. Safety Notices

3. Ready to Use

3.1 Packing List

3.2 Product Appearance

3.3 Instructions on Keys

3.4 Features Overview

4. Quick Guides

4.1 Switch On/Off

4.2 Battery Management and Charging

4.3 Operation of the Function Icons

4.4 Operation of the Function Icons on parent interface

5. Operation Details

5.1.1 Music Player

5.1.2 Video

5.1.3 Gallery

5.1.4 Recording

5.1.5 File Manager

5.1.6 Web Browser

5.1.7 Calculator

5.1.8 Clock

5.1.9 Camera

5.2.0 tf (Micro sd) Card Storage

5.2.1 APK Install and Manage

5.2.2 External Keyboard & Mouse：

6. System setting

6.1.1 WIFI Setting

6.1.2 External 3G USB Dongle：

6.1.3 External RJ45 USB Dongle

6.1.4 Sound

6.1.5 Display and wall paper

6.1.6 Screenshot

6.1.7 Storage

6.1.8 Battery

6.1.9 Apps

6.2.0 Location & security

6.2.1 Language & input

6.2.2 Backup & reset

6.2.3 Date & time

6.2.4 Accessibility

6.2.5 Developer options

6.2.6 About tablet

User Manual

3

6.2.7 Add, Move or Delete Desktop Icon

7. Firmware Upgrade

8. Troubleshooting and FAQ

1. Preface

Dear Customers,
Thanks very much for purchasing our product!
This Tablet PC is a built-in high performance Wi-Fi receiver module, supporting an external 3G
USB-DONGLE wireless network card, using broadband wireless networks, breaking through the restraint of
network cables; it will bring you into the portable media player world and fulfill your entertainment needs. It
also supports picture browsing, e-book reading, games, online chat and other functions; various settings will
fully show your individuality.
To operate this player easily, first, please read this User Manual included with the player. Then you will have
a better understanding of the operations. Before operating this player, please carefully read all data we
provide about the player, so that you will have a better understanding of the product and its operations.
The Company will not be responsible for any loss of personal data and damage caused by incorrect operation
of the Software/Hardware, artificial damages, replacement of batteries or any other accident. To avoid loss of
your data, please backup your data to your computer at all times.

Also, since we can not control any dispute from users’ misunderstanding or incorrect operation against the

manual, the Company will not take any relevant responsibility for any accidental loss potentially occurring in
the process of using this manual.
Due to constant product development, the information in this manual is subject to change without any prior
notice.
This manual is protected by copyright and no part is permitted to be copied or reproduced in any way without
prior written permission of the Company.
The Company reserves the final explanation right of this manual, warranty as well as its related information.
(Note: When compiling this manual, we are very careful to provide you completely reliable information.
However, there is inevitably some error and oversight, please understand, and we welcome your suggestions.
If any problem occurs during your use of this product, please immediately contact your local seller)

Thanks for your support and please pay attention to our other products.

2. Safety Notices

1) Please keep the Tablet PC away from strong magnetic fields in order to avoid damage to the product.

2) Please do not let the Tablet PC fall onto, rub against or knock against hard objects during use, because
this may cause surface scratches on the Tablet PC, battery damage, data loss or other damage to the
hardware.

3) Never let this product be exposed to a humid environment or rain as the water leaking into the Tablet PC
could disable it to the extent of being beyond repair.

4) Never clean the Tablet PC with any chemicals or detergent, these will damage the product surface and
corrode the finish.

5) You are recommended not to use the headset with the volume at its highest settings, please adjust the
volume to an appropriate safe level and limit the amount of time you spend using headphones to avoid
possible damage to your hearing. Excessive volume will cause permanent hearing damage.

6) Please do not cut off the power abruptly during software updates or downloading, because this may cause

User Manual

4

data loss or system errors.

7) Over-voltage, power cable strain and bending or squeezing of the power cable by heavy objects must be
avoided to prevent the possibility of overheating or fire.

8) In order to eliminate the risk of electric shock, do not touch the cable power plug with wet hands.

9) Some movies, music and pictures are under the protection of copyright, unauthorized usage is deemed as
an infringement to the laws of copyright.

10) Please don’t turn on the Tablet PC on in locations where wireless equipment is forbidden or when the
usage of the Tablet PC will cause interference and possible danger.

11) All the wireless equipment is subject to external interference and this can affect its performance.

12) Please comply with any related restrictions and rules, wireless equipment can influence the flight of the
plane; please consult the relevant airline company if you intend to use the Tablet PC on a plane.

13) Please don’t use the Tablet PC in a petrol station, or near to fuel or chemicals.

14) Please comply with any related restrictions and rules; do not use the Tablet PC where blasting operations
are in progress.

15) Only qualified maintenance personnel can install or repair the Tablet PC. Opening the Tablet PC in any
way will invalidate the warranty.

16) Please use the original accessories and battery provided with the Tablet PC, do not use the incompatible
products.

17) The Tablet PC is not waterproof, please keep it dry.

18) For the sake of data safety, please back up any important information on the Tablet PC, or keep a
handwritten record.

19) When the Tablet PC is connecting with other devices, please read the user manual for detailed safety
instructions. Don’t connect the Tablet PC to incompatible products.

20) Please upgrade device with enclosed optical disk when the device is set to operate in a different way.
Note: Android4.2 system using the MTP protocol transfer files, rather than the original MSC agreement
(ordinary U disk), currently supports the MTP protocol only (10) in Windows Media Player and Media Player,
Windows Media Player 11) and older version. If there are no updates to the above two versions of the Player,
the computer will not recognize MID or existing file cannot be copied down, etc., please correct in the
computer, which is connected with the MID above installed version of the Player, can be installed to the
computer, do not need to run for connection to the mid.

User Manual

5

Symbol

Name

Description

A

volume

volume switch

Components

Quantity

MID Device

1

Leather Case (Optional)

1

Keyboard/Mouse
(Optional)

1
TF card （ Optional ）

1

Power Adaptor

1

Earphone

1

USB Cable

1

HOST cable(optional )

1

3G USB
Dongle( optional )

1

RJ45 USB
Dongle( optional )

1
User Manual

1

CD-ROM

1

Warranty Card

1

3. Ready to Use

3.1 Packing list

3.2 Product Appearance

3.3 Instructions on Keys

User Manual

6

B

RESET

When tablet does not work press the system
reset function

C

TF card

TF card slot

D

USB/OTG/

MIC_5PIN slot

E

5VDC

5VDC charging port

F

Earphone Jack

Earphone Jack

G

MIC

microphone record hole

H

POWER

Short press the button to enter sleeping/wake
up mode, long press to switch ON/OFF

I

speaker

High fidelity speaker

J

Camera

Front Camera

K

ESC

Short press to return

L

MENU

Short press the button to enter menu function

M

Snapshot

After the camera is turned on, press this
button to take pictures

N

Camera

Rear Camera

3.4 Features Overview：

 Adopts Rockchip RK2926 as the main chip, ARM Cortex A9, max frequency at 1.0GHz.

GPU Mail-400MP2 , support ANDROIED 4.2；

 Support RAM 512M/1G DDR3（optional）；
 Build-in ROM Flash, 4GB/8GB/16GB/32GB（optional），
 Support max 32GB TF card
 7 inch TFT Screen 1024*600（optional）， capacitive multi-point touch.
 Support MPEG-1，MPEG-2,MPEG-4，H.263, H.264, AVS, VC-1, RV etc audio formats, Max resolution

support: 1920*1080/60fps。

 Support JPG、JPEG、BMP、GIF、PNG、JFIF etc picture format, max resolution support:8000*8000．
 Support MP1、MP2、MP3、WMA、WAV、OGG、OGA、APE、FLAC、AAC、M4A、3GPP etc audio formats

and multi EQ modes, and support Lyrics synchronized display or full-page display。

 Support TXT、LRC、PDF、Html、Htm、EPUB etc file formats, supports auto-browse, zoom, bookmarks,

flip over functions

 Wi-Fi ready, you can connect with broadband wireless internet and operate various software in the

Android 4.2 OS, the system preset parts of third software: Google browser, Online MP3, online novel,
online video, E-book, etc

 Supports USB-HOST function for external U-disk, Keyboard, Mouse & 3g dongle etc。
 Built-in 0.3MP front camera and 0.3MP back camera.
 Supports G-sensor screen rotation function
 Supports built-in speaker and external stereo earphone
 Supports multiple languages
 USB disk, WIN_2000 above system driver for free

Technical Specifications

User Manual

7

display
size

7 inch TFT screen

resolution

1024*600

Interface

USB port，USB OTG 2.0/USB Host2.0 (MIC 5PIN shift 4PIN HOST)

CPU

RK3026，ARM Cortex A9 Max frequency 1.0GHz

Built-in Flash

Flash Memory ：8GB

Built-in RAM

ROM：DDRIII 1GB

Capacity Expansion

Support TF Card 1GB~32GB

Power Supply

Built-in 3.7V@2500mAH (still in pending) Lithium rechargeable
battery; output:DC5V/2A Adaptor

Music Function

Play format

MP1、MP2、MP3、WMA、WAV、OGG、OGA、
APE、FLAC、AAC、M4A、3GPP

Headset max. output

（L）5mW＋（R）5mW（32Ohm）

MP3 Bit rate

8Kbps ~ 392 Kbps

WMA, WMV, Bit rate

5Kbps ~ 192 Kbps

Frequency response

20Hz-20KHz

SN ratio

90dB

Distortion

＜0.05%

Video Function
Play format

MPEG-1，MPEG-2,MPEG-4，H.263, H.264,
AVS, VC-1, RV,etc

Max Resolution

1920*1080

Ratio

4: 3、16: 9、full screen optional.

Photo Browse

Support JPG、JPEG、BMP、GIF、PNG、JFIF，max resolution support:
8000*8000.

E-book
Format

TXT、LRC、PDF、Html、Htm、EPUB etc.

Max. capacit

5M

WIFI
Main chipset

NMC1000

Transmission rate

Max54Mbps

Transmission range

Max100m

Frequency

b/g/n

Format

Format

WAV

Working
temperature

-10 ~ 50 ℃
Supported OS

Windows2000/XP/WIN7/Vista Mac OS V9.0/10.0

4. Quick Guides

4.1 Switch On/Off

●Switch ON：When the Tablet PC is in OFF mode, please press and hold the “POWER” key for 3
seconds .First start, the machine will enter the system desktop with boot screen, then it will enter parents
using guide interface. Parents can set the requirements (Note: This is the most critical set a password). After
completing the above operation, it will enter kid's System Interface. .

User Manual

8

（Boot screen）

（kid's System Interface）

●Unlock： Please press and move the icon , the display will unlock automatically

●Power Saving Mode and Locked Mode: Pressing the “POWER” key when the Tablet PC is in use will

result in the system entering SLEEP power save and locked mode. Press the “POWER” key, the Tablet PC
will return the system to unlocked mode within 2 second.

●Switch OFF：When the Tablet PC is in use, please press and hold the “POWER” key for 3 seconds, the

screen will display the power off interface, choose the power off option to confirm your selection and the
system will shut down automatically.

4.2 Battery Management and Charging

A Charge the battery at least 8-12 hours to make sure the battery is fully charged for the first time.
B Insert the adaptor into the DC slot on the Tablet PC, and connect the other side with the power socket.
Then the Power indicating lamp on the top right side of the Tablet PC will turn purple, and the desktop icon of
the battery keeps rolling to show it is charging. Note: Please wait until the battery is fully charged and do
not disconnect the adaptor when charging.

·Once the battery is fully charged, the indicating lamp will change into blue, the Icon on the desktop will

User Manual

9

stop rolling.

C When the battery is exhausted completely; please charge at least 1 minute before starting it up.
Note: In order to keep the battery working to its full potential, please pay attention to the following advice:

1) Don’t charge the power in excessively high temperatures.

2) There is no need to run down the power for this Li-ion battery, you can charge the battery even when there
is still power left in the battery without it affecting the lifespan of the battery.

3) In order to keep the battery in good condition, Make sure you charge it at least once every two weeks if the
Tablet PC hasn’t been used for a long time.

4.3 Operation of the Function Icons

◆Operation of the Function Icons on kids interface

●Select Multimedia icon to enter, display the audio player and video player two application icons

User Manual

10

select icon，show as above squares mode；select icon，display the extended loop mode；select
icon，return to the main interface。

● Application icon interface, display downloaded application

●Juegos: select Juegos icon to enter below installed game application

● Pinture: select pinture icon to enter paintpad application, Children can use the tools in the drawing board,

draw pretty cute pictures; select icon, the pictures will be Saved to the local library.

User Manual

11

● Notas: select Notas icon to enter Note application. Open Note application, make handwriting, voice memo
recording anywhere and anytime to leave a good memory.

● e-book: Select e-book icon to enter BOOK READER application. Open this application, it will show
characteristic bookshelf interface, it can collect kids favorite Electronic books like PDF, EPUB, TXT, HTML
and other formats.

User Manual

12

Tap this icon; you can let the whole earth spin up, function icons floating up, so that the whole interface

lively and interesting.

: Select this icon; fast enter the gallery, showing pictures saved there.

Select this icon to enter the date settings interface

◆ Select this icon to enter kids system setting interface

●Sistema: Enter sistena setting, it will show WIFI switch key, battery, volume switch, brightness adjustment.

●Padre: Enter Padre, tap the password to choose EXIST APP, it will quit the kids user interface to parent’s

interface.
Select Padre, it will show as below：

User Manual

13

Parent setting password interface

icon：：When the kids use the tablet pc out of time limit setting by parents, it will jump out the lock screen

reminder, child can enter the application operation again after parents’ permission, as below

This time usage management setting is the highlight of the kids tablet. Parents can effectively manage their
children's time on using tablet pc to protect children’s Eyesight. Custom setting is flexible for parents to
control the time.
Parent add APP. Select a function icon on kids interface, such as “Media”(see below picture 1) ) to show
existing application icons of parent interface(see below picture 2), set tick for the needed application, then
tablet will exist. The needed application will save to kids interface directory lined below e-book.

User Manual

14

(picture 1)

（picture 2）
Application: Enter the password setting screen, enter the password, parents can set website browsing
permission for kids, only allow the kids to browse the health website.( Note: Only to be effective after ticking

(√) . )

User Manual
