FROG Leap Infuzer™
infuzer
Mineral Dispensing System
Model 7800
For Pools up to 25,000 Gallons
System Includes the
FROG Leap Anti-Bac Mineral Pac
Patented Mineral Disinfectant
Customer Service 800-222-0169
www.kingtechnology.com
1
TABLE OF CONTENTS
FROG Leap Introduction 3
Swimming Pool Tips 4
Start-up and Operation 5-6
Replacing FROG Leap Anti-Bac Mineral Pac 7
Using FROG Leap Depth Charge, Reveille, Torpedo Pac 8
Using FROG Leap ALL-OUT 9
Troubleshooting 10
Parts List 11
Replacing Control Dial O-Rings 12
Replacing Cap O-Rings and Knobs 12
Winterizing 13
Above Ground Filter Installation 14
Above Ground Base Installation 15
Warranty 16
For information on King Technology’s entire product
line, visit our website at www.kingtechnology.com
2
Welcome to easier pool care courtesy of FROG Leap. With FROG Leap, your pool water will look and feel
infuzer
A
L
L
-
O
U
T
A
L
L
-
O
U
T
REVEILLE
A
L
L
-
O
U
T
better without a lot of work or a lot of chlorine. This system† controls bacteria using a combination of
minerals and reduced chlorine levels. Chlorine lasts 2X longer with FROG Leap Mineral System.
There are 4 main parts to the FROG Leap System: The FROG Leap Infuzer, the FROG Leap Anti-Bac
Mineral Pac, FROG Leap ALL-OUT (90-day Algae Preventative) and the FROG Leap Torpedo Pac. Plus FROG
Leap offers easy and effective FROG Leap Pool Wake Up and FROG Leap Pool Hibernation convenience
packs for opening a pool in the spring and closing for the winter.
Part 1
FROG Leap Infuzer™
The water treatment center
that controls the flow of
water to each part of the
FROG Leap System.
For Above Ground Pools
up to 25,000 gallons.
Part 2
FROG Leap Anti-Bac
Mineral Pac™
Holds the minerals and
fits inside the FROG Leap
Infuzer.
THE FROG LEAP ANTI-BAC
MINERAL PAC MUST BE
REPLACED EVERY SIX MONTHS
OR AFTER ONE POOL SEASON
WHICHEVER IS SHORTER.
Part 3
FROG Leap ALL-OUT™
Use with the FROG Leap
System for a 90-Day AlgaeProtection Guarantee.
Part 4
FROG Leap
Torpedo Pac™
Pre-filled with chlorine
tablets and fits inside the
FROG Leap Anti-Bac Mineral
Pac.
FROG Leap
Pool Wake Up!™
An easy 3-step pool
opening program that
effectively removes
contaminants, prevents
algae and sets a chorine
residual with precise
dispensing and no
touching chemicals!
FROG Leap REVEILLE, FROG Leap DEPTH CHARGE and FROG LEAP ALL-OUT
FROG Leap
†FROG LEAP Mineral System consists of the FROG LEAP minerals silver chloride and carbonate used in conjunction with 0.5 ppm chlorine. The FROG LEAP
Anti-Bac Mineral Pac must be used in conjunction with the FROG LEAP Torpedo Pac (EPA Reg. No.: 53735-2), an EPA registered chlorine pool product or a
chlorine delivery device.
Anti-Bac Mineral Pac sold inside FROG Leap Infuzer and separately for replacements.
FROG Leap
Torpedo Pac and FROG Leap ALL-OUT, along with FROG Leap Pool Wake Up
and FROG Leap Pool Hibernation, are sold separately.
FROG Leap
Pool Hibernation™
An easy 2-step pool closing
program that effectively
removes contaminants and
prevents algae all winter
with precise dispensing and
no touching chemicals!
FROG Leap DEPTH CHARGE and FROG Leap ALL-OUT
3
Swimming Pool Tips
®
Start-up and Yearly Maintenance
1.
Make sure the pool has adequate circulation. The pool
water must completely circulate through the pump and
filter at least 1 to 2 times per day. This usually requires
8 to 12 hours. Check with your dealer for the proper
circulation time for your pool.
2.
3.
If your fill water is high in metals, use a sequestering
agent or metal out product at start-up only before using
the FROG Leap Anti-Bac Mineral Pac. See your local dealer
for details on using these products and always follow
manufacturers directions carefully.
After your pool is up and running
4.
smoothly, continue to test your
water for pH, total alkalinity and
chlorine with FROG® Brand Test
Strips and maintain its balance
by adding any necessary
adjustment products (see your
dealer for details).
Before beginning with any pool care program, you must
first balance your pool water. Take a water sample to your
local pool professional or use a complete test kit that will
test for the following important elements.
Water Balance Guidelines
pH: 7.2 – 7.8
Total Alkalinity: 60 – 120 ppm
Calcium Hardness: 150 – 400
Total Dissolved Solids: <1500
Stabilizer: 20 – 80 ppm
Free Chlorine: 0.5 – 1.0 ppm
5.
Check the pool’s filter gauge often and periodically clean
filter per the manufacturer’s directions. A dirty filter
will slow the flow of water which could hamper proper
circulation.
4
Start-up and Operation -
Stabilizer
REVEILLE
FROG Leap Anti-Bac Mineral Pac now with 25% More Water Polishers for easier start up.
1.
2.
Add a stabilizer or conditioner to the
pool at the beginning of the season if
the stabilizer level is below 20 ppm.
This will prevent chlorine burn off. Follow
manufacturer’s directions carefully.
Install an FROG Leap Anti-Bac Mineral
Pac into the FROG Leap Infuzer. (See
page 7 for directions.)
REPLACE THE FROG LEAP ANTI-BAC
MINERAL PAC EVERY 6 MONTHS OR
AFTER ONE POOL SEASON WHICHEVER
IS SHORTER.
Replace cap and run FROG Leap Infuzer,
with FROG Leap Anti-Bac Mineral Pac
inserted, for 10 minutes at Setting 5.
5.
6.
For a 90-day algae protection
guarantee, insert FROG Leap
ALL-OUT into FROG Leap Anti-Bac
Mineral Pac in Infuzer.
(See page 9 for directions.)
When chlorine reading is down to
1.0 ppm, which may take a few
days, insert FROG Leap Torpedo
Pac. (See page 8 for directions.)
3.
4.
Shock the pool with FROG Leap
Depth Charge to rid the water of all
contaminants. (see page 8 for FROG
Leap Depth Charge directions)
Create a chlorine residual with
FROG Leap Reveille or a chlorine
shock (see page 8 for FROG Leap
Reveille directions). THIS STEP IS
VERY IMPORTANT TO START-UP.
Always begin with chlorine in the
pool water.
If using standard chlorine shocks do not add in or
near the skimmer or into the FROG Leap Infuzer as
it could damage equipment, risk potential explosion
or discolor your pool surface.
5
Start-up and Operation
Set control dial by matching up the parameters of your pool on the chart below. THIS IS A STARTING POINT ONLY and may
7.
need to be adjusted to fit your individual pool needs. See #8 below for directions. IMPORTANT: Pump run times less than
8 hours could result in under chlorination due to inadequate flow through the System.
Above Ground
POOL SIZE
Gallons Diameter
7,000 (18’) 5.0
9,000 (21’) 5.5
12,000 (24’) 6.0
15,000 NR
20,000 NR
1/2 hp 3/4 hp 1 hp 1 1/2 hp
8 HOUR PUMP RUN TIME
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
4.5 4.0 3.5 4.5 4.0 3.0 5.0* 3.5 3.0 2.5 4.0*
5.0 4.5 4.0 5.0 4.5 4.0 5.5* 4.0 3.5 3.0 4.5*
5.5 5.0 4.5 5.5 5.0 4.5 4.0 4.5 4.0 3.5 5.0*
6.0 5.5 5.0 6.0 5.5 5.0 4.5 5.0 4.5 4.0 3.5
NR 6.0 5.5 NR 6.0 5.5 5.0 5.5 5.0 4.5 4.0
12 HOUR PUMP RUN TIME
PUMP SIZE
1/2 hp 3/4 hp 1 hp 1 1/2 hp
24 HOUR PUMP RUN TIME
PUMP SIZE
* – Bypass installation recommended. RECOMMENDED FLOW RATE: 20-60 gpm
NR – This pump size is not recommended for this size pool. Most common pool sizes
8 HOUR PUMP RUN TIME
1/2 hp 3/4 hp 1 hp 1 1/2 hp
PUMP SIZE
4.5 4.0 3.5 4.5 4.0 3.0 5.0*
5.0 4.5 4.0 5.0 4.5 4.0 5.5*
5.5 5.0 4.5 5.5 5.0 4.5 4.0
6.0 5.5 5.0 6.0 5.5 5.0 4.5
NR 6.0 5.5 NR 6.0 5.5 5.0
1/2 hp 3/4 hp 1 hp 1 1/2 hp
Find your starting dial setting by matching up the
parameters of your pool on the above chart. An above
ground pool with approximately 12,000 gallons with a 1
horse pump running 12 hours a day would require a starting
For the first week test the pool water
8.
daily for free chlorine with FROG® Brand
setting of 4.5. See example at right.
Above Ground
POOL SIZE
Gallons Diameter
7,000 (18’) 5.0
9,000 (21’) 5.5
12,000 (24’) 6.0
15,000 NR
20,000 NR
If using another means of chlorine support, follow
steps 1-5 on page 5 then continue below.
Test Strips to ensure correct dial setting.
Continue to test weekly throughout the
season.
12 HOUR PUMP RUN TIME
PUMP SIZE
After each testing, adjust the dial
up by 1/2 increment if the free
chlorine reading has dropped
below 0.5 ppm or adjust down by
1/2 increment if the reading has
risen above 1.0 ppm. Continue
this process each day until the free
chlorine reading stabilizes to at
least 0.5 ppm.
Remember to adjust dial by 1/2 increments only in
order to prevent over chlorination which may bleach pool
surfaces.
9.
Shock pool every two weeks or as needed
to maintain water quality. Follow label
directions on the shock treatment used.
Do not add shock in or near
the skimmer or into the FROG
Leap
Infuzer as it could damage
equipment, risk potential
explosion or discolor your pool
surface.
6
6.
7.
Set dial to Setting 5. Maintain a
minimum chlorine reading of 0.5
ppm with a chlorine delivery device
or hand feeding.
Shock pool every two weeks or as needed
to maintain water quality. Follow label
directions on the shock treatment used.
Do not add shock in or near
the skimmer or into the FROG
Leap
Infuzer as it could damage
equipment, risk potential
explosion or discolor your pool
surface.
Replacing a FROG Leap Anti-Bac Mineral Pac
SERIES 7800 (ORDER #01-12-7822)
NOW FITS THE FOLLOWING SYSTEMS:
FROG 4500, 5100, 5200, 6100, 6500 and 7100
Prevail 5770 and 5771
SLOT IN
ANTI-BAC
MINERAL PAC
FIN INSIDE
INFUZER
(FROG Leap Anti-Bac Mineral Pac MUST be Replaced Every Season)
1.
Check the top of the box and back label of product to make
sure you have the correct FROG Leap Anti-Bac Mineral Pac to
fit your FROG Leap Infuzer.
THE FROG LEAP ANTI-BAC MINERAL PAC MUST BE
REPLACED EVERY 6 MONTHS OR AFTER ONE POOL
SEASON WHICHEVER IS SHORTER.
2.
IMPORTANT: Remove and read the
information card.
Please note: Complete instructions for
inserting a FROG Leap Anti-Bac Mineral
Pac, and all other FROG Leap products
are included inside the FROG Leap AntiBac Mineral Pac.
3.
4.
5.
6.
Turn off pump and turn dial
to Setting 0. This reduces
the flow of water into the
unit when the cap is open.
Open cap. Stand back
to avoid inhaling chlorine
fumes from the FROG Leap
Torpedo Pac.
Find slot on side of
FROG Leap Anti-Bac
Mineral Pac and line
up with fin inside the
FROG Leap Infuzer.
Lower FROG Leap
Anti-Bac Mineral
Pac into FROG Leap
Infuzer until secure.
replacement products. DO NOT USE bulk chemical tablets
in the FROG Leap Infuzer or put anything inside the FROG
Leap Infuzer other than the appropriate FROG Leap
product as directed in the product instructions. Use of
any other product could result in damage to pool equipment or surface, unsafe pool conditions, fire or explosion.
Warranty will be VOID if the correct FROG Leap products
are not used.
Use ONLY the factory recommended FROG Leap
7.
Mark your calendar for the six month replacement of the FROG
Leap Anti-Bac Mineral Pac. Once wetted, the time-released
mineral coating of this product is effective up to 6 consecutive
months or one pool season whichever is shorter. After that time
even if you hear the spent media inside it is no longer effective
and must be replaced.
7
Replacing FROG Leap Depth Charge™, FROG Leap Reveille™ or FROG Leap Torpedo Pac
OTHER PAC
FROG LEAP
ANTI-BAC
MINERAL
PAC
PAC
TOWERS
PAC
TOWERS
COLORED
CAPS
REVEILLE
Avoid sparks, open flame or smoking when handling
FROG Leap Depth Charge, FROG Leap Reveille or FROG
Leap Torpedo Pacs.
FROG Leap Depth Charge is a one time start-up product used
to rid the water of all contaminants. FROG Leap Reveille - also
used at start up, sets the chlorine residual to help find the proper
dial setting for maintaining up to 50%* less chlorine while using
the FROG Leap Torpedo Pacs (EPA Reg. No.: 53735-2). All three
FROG Leap
Depth Charge
FROG Leap
Reveille
FROG Leap
Torpedo Pac
products sold separately.
™
1.
2.
To remove colored caps, grab onto
the lip of one cap with a pliers and
pull up until cap releases. Repeat
the process for the other cap.
Turn pac over and shake slightly until
ingredients fall into tower areas.
3.
4.
Line up the small leg of the pac
with the small opening in the FROG
Leap Anti-Bac Mineral Pac and the
large leg with the large opening.
Lower pac into FROG Leap Anti-Bac
Mineral Pac until secure.
Replace cap by hand only.
DO NOT OVER TIGHTEN.
8
5.
Run the pump and filter for each pac according to the
directions on the product label. Remove from the FROG
Leap Infuzer when empty and discard or offer for recycling.
Using FROG Leap ALL-OUT
9
0
-
D
A
Y
™
for a 90-Day Algae Protection Guarantee
If you are not using FROG Leap ALL-OUT proceed to inserting
FROG Leap Torpedo Pac. See FROG Leap ALL-OUT product
labeling for complete directions for use (EPA Reg. No. 53735-9).
*NOTE: Wait 24 hours after shocking before using this product. Avoid using other chemicals until this product has been circulated
(filtered) for at least 24 hours.
1.
Remove cap from FROG
Leap ALL-OUT without
removing seal.
For a preventive dose add:
•One FROG Leap ALL-OUT for pools up to 15,000 gallons.
•Two FROG Leap ALL-OUT for pools between 15,000 & 30,000 gallons.
5.
Turn pump on for 90 minutes
allowing FROG Leap ALL-OUT to
circulate through pool.
6.
To remove FROG Leap ALL-OUT,
turn pump off. Turn dial to
Setting 0.
2.
Insert upside down into
center of FROG Leap AntiBac Mineral Pac pushing
down firmly on key to
puncture seal.
7.
3.
4.
Replace cap by hand only.
DO NOT OVER TIGHTEN.
Turn control dial on FROG
Leap Infuzer to Setting 5.
8.
Remove FROG Leap Infuzer
cap.
Lift FROG Leap ALL-OUT up and
allow any water in the container
to drain through the FROG Leap
Infuzer before discarding in
trash.
NOTE: If water shows more
than a hint of blue inside FROG
Leap Infuzer, replace the FROG
Leap Infuzer cap, turn dial to
Setting 5 and run the pump for
one minute.
14a. If pool size requires
additional FROG Leap ALL-OUT,
repeat steps 1-8.
14b. When water is clear in
FROG Leap Infuzer, proceed to
inserting FROG Leap Torpedo
Pac.
9
Troubleshooting
For more in-depth troubleshooting, go to www.kingtechnology.com
Problem Remedy
1.
2.
3.
4.
What do I do
if the water looks
cloudy?
What do I do
if the water turns
color?
What do I do
if algae forms in or
on my pool?
What do I do
if I am under
chlorinating with
the FROG Leap
Torpedo Pac?
1. Make sure your filtration
system is working properly
(i.e. clean filter, skimmer and
pump basket).
2. Make sure circulation time
is adequate – increase pump
1. Metals in the fill water may
have been oxidized. Have the
pool tested. Shock the pool
and clean the filter until water
clarity returns.
1. Use a nonmetallic (polyquat)
algaecide per the directions on
the bottle and brush the sides
of the pool often.
2. Clean the filter and shock
the pool with chlorine daily
1. If you are unable to
maintain 0.5 to 1.0 ppm, first
make sure there are chlorine
tablets in the tower areas of
the FROG Leap Torpedo Pac
and it is installed properly. If
a correction was made, test
the water in 24 hours.
2. If still low, turn the dial up
one setting and test the
water again in 24 hours.
Continue raising the setting
by one increment each day
time if not.
3. Make sure the pool is
properly balanced
4. Shock the water to
eliminate build up of any
organic matter.
2. Algae may be trying to
form – shock the pool,
increase circulation time if
needed and clean the filter.
until water clarity returns.
3. If you are in an area of
the country that struggles
with algae growth, see your
dealer regarding a 90-day
Algae Protection Guarantee
until the proper reading is
achieved.
3. Shock the pool if the
reading has been lower than
0.5 ppm for more than one
day.
4. Make sure pump run time
is at least 6 hours on high
speed (40 gpm or higher) or
if not, bleed the air from the
back knob each time cap is
open.
(see page 4).
5. Make sure pool has a
free chlorine reading of
0.5 to 1.0 ppm.
6. Check with your dealer
for more information.
3. Check with your dealer for
more information.
using FROG Leap ALL-OUT.
See product hang tag for
guarantee details.
4. Check with your dealer for
more information.
5. Contact your dealer to have
your back pressure tested to
ensure it is at least 4 psi.
6. Check for a suction side
leak by looking for air bubbles
in your pump basket or at
the return jet. Contact dealer
for help in correcting this
situation.
7. Contact King Technology’s
Customer Service Department
at 800-222-0169.
5.
10
What do I do
if I am over
chlorinating with
the FROG Leap
Torpedo Pac?
1. If the chlorine reading is
over 3.0 ppm, remove the
FROG Leap Torpedo Pac
from the FROG Leap Anti-Bac
Mineral Pac and test the
water daily until the reading
is down to 1.0 ppm.
2. Reinsert the FROG Leap
Torpedo Pac, lower the dial
one setting and test the
water again in 24 hours. If
the reading has risen, lower
the dial one setting again.
Continue this process until
proper reading is achieved.
3. If over-chlorinating at the
lowest possible setting,
consider decreasing the
circulation time. Depending
on your pump size, you may
be circulating the water more
than is necessary.
4. Contact your dealer to
have your back pressure
tested. If over 8 psi consider
a larger eye-ball fitting in the
return jet.
5. Check to see if the
pressure relief valve is loose
or missing and replace.
It is a clear plastic piece
approximately 1” long
installed inside near the
base. If loose or missing, it
can provide another avenue
for water to reach the
chlorine.
6. Contact King Technology’s
Customer Service Department
at 800-222-0169.
Parts List Model 7800
Included with FROG Leap Infuzer 7800
REF. # DESCRIPTION QTY. INCLUDED
1 & 2 Cap w/O-Ring 1
3 Body 1
4 Pressure Relief Valve 1
5, 6, 7 Control Dial with O-Rings
and Locking Pin 1
8 & 9 Knob with O-Ring 2
10 Silicone Lubricant 1
11 Nipple Kit 1
12 Mounting Base 1
Replacement parts for FROG Leap Infuzer 7800
REF. # PART NO. DESCRIPTION
1 & 2 01-22-1418 Cap w/O-Ring
2 01-22-1920 Cap O-Ring
4 01-22-9480 Pressure Relief Valve
5, 6, 7 01-22-1443 Control Dial with O-Rings
and Locking Pin
6 01-22-1450 Control Dial O-Ring Set
8 & 9 01-22-9940 Knob with O-Ring
10 01-22-9971 Silicone Lubricant
11 01-22-1710 Nipple Kit
12 01-22-1485 Mounting Base
11
S
I
L
I
C
O
N
E
L
U
B
R
I
C
A
N
T
Replacing Cap O-Ring
Replacing Knobs
C
O
P
Y
C
O
P
Y
C
O
P
Y
C
O
P
Y
x
x
x
x
x
S
L
I
CON
E
L
U
B
R
I
C
A
N
T
Back of
FROG
LEAP
Infuzer
Front of
FROG
LEAP
Infuzer
Replacing the Control Dial O-Rings
Center of locking pin
FROG Leap Infuzer™ Maintenance
In the back of the FROG Leap
Infuzer depress center of
locking pin with a finger and
pull pin out of dial.
Turn control dial back and
forth as you pull it out of the
housing.
Hold cap in front of you
upside down with the o-ring
groove facing up. Place
one end of o-ring into cap
groove at the point closest
to you. Hold o-ring down
with the thumb and index
finger of one hand.
Take hold of the far end of
the o-ring with the thumb
and index finger of the
other hand. Roll o-ring
slightly back towards you
as you stretch the o-ring
into the remainder of the
cap groove.
Lubricate o-ring often with
Replace both o-rings. Apply
silicone lubricant that came
with your FROG Leap Infuzer
on o-rings.
silicone lubricant that
came with your FROG
Leap Infuzer. DO NOT
USE petroleum based
lubricants.
Carefully insert control dial
back into housing.
Replace locking pin by pushing
it through the slots on the dial
until it locks into place.
12
To replace, simply unscrew
old knob and replace with
the new one.
Winterizing
1.
2.
Turn pump off and turn dial
to Setting 0.
Remove cap.
4.
5.
If FROG Leap Torpedo Pac
still contains chlorine, wrap in
plastic bag and store in shed
or cool well-ventilated location
away from children, pets, cars,
motorcycles or anything metal
that can rust, pit, etc. Make
sure FROG Leap Torpedo Pac
is away from open flame.
Remove the FROG Leap AntiBac Mineral Pac and discard in
trash. Even if you hear spent
minerals inside, it is no longer
effective.
3.
Unscrew knob from the
front of FROG Leap Infuzer.
Allow all water to drain.
6.
Replace the cap and
knob loosely.
13
HOSE ADAPTER
TOOLS NEEDED
Screwdriver
Pipe Wrench
Above Ground, Filter Installation
INCLUDED WITH FROG
Leap Infuzer
Pipe Thread Tape
or Sealant
One 6” X 1 1/2” TBE
PVC Nipple
MATERIALS NEEDED
One Hose Adapter
1 1/2” X 1 1/2” X 1
1/4”
One Section of
1 1/2” Flex Hose
(provided with filter)
1.
Apply pipe thread tape or
sealant to each threaded end
of nipple.
Apply pipe thread tape or
4.
sealant to threaded end
of hose adapter.
2.
Screw one end of nipple
into the filter return.
Tighten turning 1 to 2
revolutions with wrench.
DO NOT OVER TIGHTEN.
Screw adapter into the other
5.
side of FROG Leap Infuzer.
Hand tighten. Finish tightening
by turning 1 to 2 revolutions
with wrench.
DO NOT OVER TIGHTEN.
Screw either side of
3.
FROG Leap Infuzer on
to open nipple end until
upright and secure.
One
Hose Clamp
RECOMMENDED
Corrosion Resistant
Check Valve
14
6.
Attach return section of hose
to the adapter with clamp.
Tighten clamp with screwdriver.
7.
If using a FROG Leap Torpedo
Pac, installing a corrosion
resistant check valve is
recommended.
HOSE
CLAMP
HOSE
ADAPTER
HOSE
CLAMP
HOSE
ADAPTER
TO POOL
1 1/2" OR 1 1/4"
FLEX HOSE
1 1/2" X 1 1/2" X 1 1/4"
HOSE ADAPTER
HOSE
CLAMP
FILTER &
PUMP
TOOLS NEEDED
TO POOL
PUMP
FILTER
Above Ground, Base Installation
Screwdriver
Pipe Wrench
Materials Needed
Pipe Thread
Tape
or Sealant
One 6” X 1 1/2” TBE
PVC Nipple
Two Sections
of 1 1/2” Flex Hose (one
provided with filter)
The FROG Leap Infuzer should always be
installed between the filter and pool (or between
heater and pool if applicable).
Apply pipe thread tape or
1.
sealant to the threaded end of
both hose adapters.
• Never install FROG Leap Infuzer
before the heater.
• Any additional sanitizing
equipment that is installed with
FROG Leap Infuzer must be
installed after FROG Leap Infuzer
(never before) on the return line
to the pool.
Screw adapters into each end of FROG
2.
Leap Infuzer. Hand tighten. Finish
tightening by turning 1 to 2 revolutions
with wrench. DO NOT OVER TIGHTEN.
Two
Hose Clamps
Recommended
Corrosion Resistant
Check Valve
Attach the filter section of flex hose to one hose adapter
3.
and the return section of flex hose to the other hose
adapter with clamps and tighten with screwdriver. Bi-flow
valve design allows water flow in either direction.
10 X 1 1/4” Phillips
Pan Head Screws with
Washers
Option
1 1/2” Male Adapter
(slip x MPT)
or
2” Female Adapter
(slip x FPT)
When installing with hard
PVC pipe, use either a
female adapter on the
outside port threads or
a male adapter on the
inside port threads.
If using a FROG Leap Torpedo Pac installing a
4.
corrosion resistant check valve is recommended.
For better stability, FROG Leap
5.
Infuzer may be mounted on a
base using Phillips pan head
screws. One in front and two in
back.
15
FROG Leap Infuzer™ Two-Year Limited Warranty
King Technology, Inc. warrants to the original purchaser this unit
will be free from any defects in workmanship and/or material, for
a period of two (2) years from the date of original purchase. This
warranty covers body, cap and control dial, but specifically excludes
o-rings. King Technology at its option may replace any defective
parts or the entire unit without charge after it is determined
what is needed to correct any deficiency. Replacement parts
with the exception of o-rings are warranted for the remainder
of the original warranty. To extend the limited warranty from two
years to ten years, simply complete the warranty card that came
with your unit and return it to King Technology within 30 days of
purchase and installation.
1. To obtain warranty service, you must deliver the unit to King
Technology or its nearest authorized dealer. Shipping expenses
are the purchaser’s responsibility. The name of the nearest
authorized dealer can be obtained by writing or calling King
Technology at the address and telephone number provided
below. Proof of purchase is required when requesting warranty
service. Purchaser must present the sales receipt or other
documentation verifying proof of purchase.
2. This warranty does not cover defects caused by:
Modification, alteration, repair or service of the unit contrary
to the accompanying instructions; physical abuse to or misuse
of the product or operation or installation in a manner contrary
to the accompanying instructions. This warranty also excludes
all costs arising from the installation, adjustment, removal or
replacement of defective units or parts. This warranty also
excludes any and all claims arising out of the chemicals used
in the product or their characteristics.
3. CAUTION - Read carefully – Failure to follow these
instructions will void the warranty. Do not add shock in or
near skimmer.
A. This unit is not designed for shock treatment of pools.
See your pool dealer or distributor for further information
concerning shock treatments.
B. Control dial settings higher than needed can result in
excess sanitizers being discharged into the pool. If the
sanitizer level goes unmonitored, it can result in bleaching or
discoloration of areas around the pool inlet or in some cases
bleaching or discoloration of the entire pool liner or paint.
C. Excess trichlor in the pool can create health hazards to
bathers. Consult each chemical manufacturer’s warnings and
cautions for specifics.
D. Misuse or failure to use the proper FROG Leap Anti-Bac
Mineral Pac and FROG Leap Torpedo Pac may cause damage
to equipment or personal injury. This warranty will be null and
void, if this unit is not used with the recommended FROG
Leap Anti-Bac Mineral Pac and FROG Leap Torpedo Pac.
4. This warranty is the exclusive warranty for the FROG Leap
Infuzer. This warranty is not transferable. KING TECHNOLOGY
MAKES NO REPRESENTATION OR WARRANTY OF ANY
KIND, EXPRESS OR IMPLIED, AS TO MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER
MATTER CONCERNING THE FROG LEAP INFUZER. Any
express warranty not provided herein, and any remedy for
breach of contract but which for this provision might arise
by implication or operation of law is hereby excluded and
disclaimed. THE EXCLUSIVE REMEDY FOR ANY CUSTOMER
IS THE REPAIR OR REPLACEMENT OF THE UNIT, AND THE
RECOVERY OF DAMAGES WILL NOT EXCEED THE PURCHASE
PRICE OF THE UNIT. IN NO EVENT WILL KING TECHNOLOGY BE
LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL OR
PUNITIVE DAMAGES FROM ANY CAUSE.
5. Under no circumstance shall King Technology be liable to
purchaser or any other person for any damage or loss incurred
because of any chemicals used in the product or their physical
characteristics, or interruption of service of the product, or
any resulting special, incidental or consequential damages or
losses. Some states do not allow the exclusion or limitation of
incidental consequential damages, so the above limitation or
exclusion may not apply to you.
Manufactured by: KING TECHNOLOGY, INC.
530 11th Avenue South, Hopkins, MN 55343 U.S.A.
952-933-6118 • 800-222-0169 • FAX 952-933-2206
www.kingtechnology.com
16
Made in U.S.A.
U.S. Patents D540,906; D551,971; 6,190,547; 6,210,566;
6,217,892; 6,383,507; 6,544,415; 6,551,609; 6,652,871;
7,604,018 and other U.S. and Foreign patents pending.
20-48-2022
553101143N
Loading...
