Document No. Hub-091017.A00
Nucleum
Page 1 of 4
Nucleum
Live the Moment™
Document No. Hub-091017.A00
Nucleum
Page 2 of 4
TABLE OF CONTENTS
INTRODUCTION 3
SPECIFICATIONS 3
REQUIREMENTS 3
NUCLEUM OVERVIEW 4
Document No. Hub-091017.A00
Nucleum
Page 3 of 4
Specifications
Power pass-through supported
Ports
o USB-C (power input)
o USB-C (data)
o HDMI
o USB-A (x2)
o SD
o microSD
USB-C Data: USB 3.1 Gen 1 (5Gb/s)
USB-A Data: USB 3.1 Gen 1 (5Gb/s)
HDMI Standard v1.4b (supports 4K @30Hz)
o HDCP not supported
SD Card Reader supports SD/SDHC/SDXC UHS I-II
o SD spec version 4.0
o SD card capacity up to 2TB
o Up to 104MB/s
microSD Card Reader supports microSD/microSDHC/microSDXC UHS I
o SD spec version 4.0
o SD card capacity up to 2TB
o Up to 104MB/s
Operating Temp: 0-70 C
Storage Temp: -25-85 C
Requirements
PC or MAC with a USB-C connection.
Windows 10, Windows 8/8.1, Windows 7, Mac OS X (v.10.9.x +), Linux (v. 2.6.x +), Chrome OS.
Introduction
Use the mouse, monitor, and accessories you’ve grown to love with your new notebook or desktop. With
a single USB-C hub, you can connect up to 7 devices at once and keep your creativity flowing. The
Nucleum has you covered whether you want to connect to a larger monitor or need to offload footage.
The Nucluem also allows you to power your MacBook while simultaneously charging an iPhone and
running your external hard drive.
* MacBook and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
Document No. Hub-091017.A00
Nucleum
Page 4 of 4
USB-C
(Power)
Side 1
USB-A
USB-AUSB-C
(Data)
SD and microSD Slots
Side 2
HDMI
Side 3
Nucleum Overview
USB-A – USB 3.1 Gen 1 port allows you to plug in your keyboard, mouse, and USB drive to your
MacBook or PC. The port will also charge your phone.
USB-C (Power) - plug in your MacBook power adapter to keep the battery charged while using the
Nucleum and all of its ports (for power only).
USB-C (Data) – this port allows you to transfer your data, charge your phone, or use any of your
USB-C accessories (video and USB Power Delivery (PD) is not supported through this port).
USB-A - USB 3.1 Gen 1 port allows you to plug in your keyboard, mouse, and USB drive to your
MacBook or PC. The port will also charge your phone.
SD and microSD Slots – insert your SD or microSD card to the Nucleum to copy, move, or edit your
pictures and documents.
HDMI – mirror or extend your screen by plugging your extra monitor to the HDMI port on your
Nucleum. It allows you to stream 4K video.
NOTE: DON’T LOSE YOUR DATA! Please make sure to safely remove any external storage device
plugged into the hub before disconnecting the AC power cable and before disconnecting from the MAC.
