PRODUCT DISCONTINUED – FOR INFORMATION ONLY

KINGSTON SMARTMEDIA

www.kingston.com

Kingston SmartMedia™

Products: SM/16, SM/32, SM/64, SM/128

Kingston’s SM (SmartMedia) memory cards offer an
incredible combination of high storage capacity, fast
data transfer rates and great flexibility. SmartMedia
offers the speed of a memory chip and the portability
of a floppy, with enhanced capacity, all in the palm
of your hand. With SmartMedia capacities ranging
from 16MB to 128MB you are sure to find the
capacities you need. Most commonly used in such
devices as Digital Camera’s, PDA’s and other portable
products, SmartMedia provides an easy method for		Optional Accessories
quickly downloading and transferring digital files
		• FCR-U2SM+ - USB SM Media Reader
from your computer to the Internet. By using a SM
Reader (see Optional Accessories) it is also possible to		• FCR-U26/1 - USB 6 in 1 Media Reader
upload files from your SM card to your Computer via		• FCR-U2CFSM+ - USB CF/SM Media Reader
the USB or parallel port.		• PCREAD/SM - Parallel Port SM Media Reader

Product Highlights

Specifications
• Dimensions	1.77'' x 1.45'' x .003''
	45mm x 37mm x 76mm
• Memory Type	NAND Flash/TSOP package
• Weight	1.8 grams
• Endurance	1,000,000 program/erase cycles
• Data Retention	10 years
• Operating Temperature	0 ° to ++60 °C
• Operating Current	40 µA max
• Media Transfer Rate	Up to 3.5MB/sec
• Interface Transfer Rate	Up to 8MB/sec
• Average Seek Time	10.8 ms
• MTBF	250,000 hrs (power on hour)
• Shock Resistance	1000G
• Vibration Resistance	15G
• Power Consumption
Read	56mA max
Write	14mA max
• Warranty	5 Years
