Kingston KSM32RS4-32HAR User Manual

Memory Module Specifi cations

KSM32RS4/32HAR

32GB 1Rx4 4G x 72-Bit PC4-3200
CL22 Registered w/Parity 288-Pin DIMM

DESCRIPTION

Kingston's KSM32RS4/32HAR is a 4G x 72-bit (32GB)
DDR4-3200 CL22 SDRAM (Synchronous DRAM) registered w/
parity, 1Rx4, ECC, memory module, based on eighteen 4G x
4-bit FBGA components. The SPD is programmed to JEDEC
standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each
288-pin DIMM uses gold contact fingers. The electrical and
mechanical specifications are as follows:

FEATURES

• Power Supply: VDD = 1.2V

• VDDQ = 1.2V

• VPP = 2.5V

• VDDSPD = 2.41V to 2.75V

• Functionality and operations comply with the DDR4 SDRAM datasheet

• 16 internal banks

• Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for

the banks in the same or different bank group accesses are available

• Data transfer rates: PC4-3200, PC4-2933, PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600

• Bi-Directional Differential Data Strobe

• 8 bit pre-fetch

• Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)

• Supports ECC error correction and detection

• On-Die Termination (ODT)

• Temperature sensor with integrated SPD

• This product is in compliance with the RoHS directive.

• Per DRAM Addressability is supported

• Internal Vref DQ level generation is available

• Write CRC is supported at all speed grades

• CA parity (Command/Address Parity) mode is supported

SPECIFICATIONS

CL(IDD)

Row Cycle Time (tRCmin)

Refresh to Active/Refresh
Command Time (tRFCmin)

Row Active Time (tRASmin)

Maximum Operating Power

UL Rating

Operating Temperature

Storage Temperature

*See IDD Specifications (page 2)

Module Assembly

DRAM: HYNIX (A-DIE)

RCD: Rambus

22cycles

45.75ns(min.)

350ns(min.)

32ns(min.)

*

94 V - 0

o

C to +85o C

0

o

C to +100o C

-55

kingston.com

Continued >>

Document No. 4809491A 05/08/20 Page 1

continued

IDD Specifications

IDD

Symbol 3200 Symbol 3200

IDD0

IDD0A

IDD1
IDD1A
IDD2N

IDD2NA
IDD2NT

IDD2NL
IDD2NG
IDD2ND

IDD2NP

IDD2P
IDD2Q
IDD3N

IDD3NA

IDD3P

IDD4R
IDD4RA
IDD4RB

IDD4W
IDD4WA
IDD4WB
IDD4WC
IDD4WP

IDD5B
IDD5F2
IDD5F4

IDD6N

IDD6E

IDD6R

IDD6A

IDD7
IDD8

1268
1270
1441
1503
1130
1131
1282

909
1119
1100
1151

744
1068
1364
1364
1000
2610
2640
2615
2337
2429
2218
2343
2970
7543
5468
4715

604

893

353

895
3650

271

unit

mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA

IPP0

IPP1
IPP2N
IPP2P
IPP3N
IPP3P
IPP4R

IPP4W

IPP5B

IPP5F2
IPP5F4

IPP6N
IPP6E
IPP6R
IPP6A

IPP7

IPP8

IPP

38
38
24
24
31
31
31
31

1167

778
643

75

128

39
109
198

24

unit

mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA

kingston.com

Document No. 4809491A Page 2
