Kingston KSM26LQ4-64HCM User Manual

Memory Module Specifi cations

KSM26LQ4/64HCM

64GB 4Rx4 8G x 72-Bit PC4-2666
CL19 Load Reduced w/Parity 288-Pin DIMM

DESCRIPTION

Kingston's KSM26LQ4/64HCM is a 8G x 72-bit (64GB)
DDR4-2666 CL19 SDRAM (Synchronous DRAM) load reduced
w/ parity, 4Rx4, ECC, memory module, based on thirty-six 4G x
4-bit DDP FBGA components. The SPD is programmed to
JEDEC standard latency DDR4-2666 timing of 19-19-19 at 1.2V.
Each 288-pin DIMM uses gold contact fingers. The electrical
and mechanical specifications are as follows:

FEATURES

• Power Supply: VDD = 1.2V

• VDDQ = 1.2V

• VPP = 2.5V

• VDDSPD = 2.41V to 2.75V

• Functionality and operations comply with the DDR4 SDRAM datasheet

• 16 internal banks

• Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for

the banks in the same or different bank group accesses are available

• Data transfer rates: PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600

• Bi-Directional Differential Data Strobe

• 8 bit pre-fetch

• Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)

• Supports ECC error correction and detection

• On-Die Termination (ODT)

• Temperature sensor with integrated SPD

• This product is in compliance with the RoHS directive.

• Per DRAM Addressability is supported

• Internal Vref DQ level generation is available

• Write CRC is supported at all speed grades

• CA parity (Command/Address Parity) mode is supported

SPECIFICATIONS

CL(IDD)

Row Cycle Time (tRCmin)

Refresh to Active/Refresh
Command Time (tRFCmin)

Row Active Time (tRASmin)

Maximum Operating Power

UL Rating

Operating Temperature

Storage Temperature

* See IDD Table (page 2)

Module Assembly

DRAM: HYNIX (C-DIE)

RCD: Montage

19 cycles

46.25ns(min.)

350ns(min.)

32ns(min.)

*

94 V - 0

o

C to +85o C

0

o

C to +100o C

-55

kingston.com

Continued >>

Document No. 4808998A 05/20/19 Page 1

continued

IDD Specifications

IDD

Symbol 2666 Symbol 2666

IDD0

IDD0A

IDD1
IDD1A
IDD2N

IDD2NA
IDD2NT

IDD2NL
IDD2NG
IDD2ND

IDD2NP

IDD2P
IDD2Q
IDD3N

IDD3NA

IDD3P

IDD4R
IDD4RA
IDD4RB

IDD4W
IDD4WA
IDD4WB
IDD4WC
IDD4WP

IDD5B
IDD5F2
IDD5F4

IDD6N

IDD6E

IDD6R

IDD6A

IDD7
IDD8

4391
4409
4435
4453
4229
4229
4589
3725
4229
4157
4229
3454
4013
4949
4949
4246
5364
5454
5418
5401
5473
5203
5401
5707
7775
6767
6425
2112
2616
1392
2616
7110
1176

unit

mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA

IPP0

IPP1
IPP2N
IPP2P
IPP3N
IPP3P
IPP4R

IPP4W

IPP5B

IPP5F2
IPP5F4

IPP6N
IPP6E
IPP6R
IPP6A

IPP7

IPP8

IPP

272
290
230

230
1152
1152

515

515
1523
1073

929

418

562

338

562

641

230

unit

mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA

kingston.com

Document No. 4808998A Page 2
