9.2mmX1.9mm SIDE VIEW
Part Number: AA9219/2EC High Efficiency Red
Features
z LOW POWER CONSUMPTION.
z IDEAL FOR BACKLIGHTING.
z RoHS COMPLIANT.
Package Dimensions
Description
The High Efficiency Red source color devices are made with
Gallium Arsenide Phosphide on Gallium Phosphide Orange
Light Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the leads emerge from the package.
4. Specifications are subject to change without notice.
SPEC NO: DSAD1399 REV NO: V.6 DATE: MAY/23/2007 PAGE: 1 OF 4
APPROVED: WYNEC CHECKED: Allen Liu DRAWN: Y.L.LI ERP: 1201000548
Selection Guide
V
Part No. Dice Lens Type
Iv (mcd) [2]
@ 20mA
iewing
Angle [1]
Min. Typ. 2θ1/2
AA9219/2EC High Efficiency Red (GaAsP/GaP) WATER CLEAR 18 50
Notes:
1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. Luminous intensity/ luminous Flux: +/-15%.
Electrical / Optical Characteristics at TA=25°C
Symbol Parameter Device Typ. Max. Units Test Conditions
λpeak Peak Wavelength High Efficiency Red 627
λD [1] Dominant Wavelength High Efficiency Red 625
Δλ1/2 Spectral Line Half-width High Efficiency Red 45
C Capacitance High Efficiency Red 15
F [2] Forward Voltage High Efficiency Red 4 5 V IF=20mA
V
R Reverse Current High Efficiency Red
I
Notes:
1.Wavelength: +/-1nm.
2. Forward Voltage: +/-0.1V.
10 uA VR = 5V
nm I
nm I
nm I
pF V
F=20mA
F=20mA
F=20mA
F=0V;f=1MHz
100
°
Absolute Maximum Ratings at TA=25°C
Parameter High Efficiency Red Units
Power dissipation 150 mW
DC Forward Current 30 mA
Peak Forward Current [1] 160 mA
Reverse Voltage 5 V
Operating/Storage Temperature -40°C To +85°C
Lead Solder Temperature [2] 260°C For 3 Seconds
Lead Solder Temperature [3] 260°C For 5 Seconds
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
3. 5mm below package base.
SPEC NO: DSAD1399 REV NO: V.6 DATE: MAY/23/2007 PAGE: 2 OF 4
APPROVED: WYNEC CHECKED: Allen Liu DRAWN: Y.L.LI ERP: 1201000548
