ON : Switch-on
OFF : Switch-off
Escape : Return to previous screen
1x : ''Hold'' : measure holding
2x : ''Min/Max'' : display of minimum and
maximum values from channel 1
since last request.
3x : ''Min/Max'' : display of minimum and
maximum values from channel 2
since last request.
4x : Back to held measure.
''Function'' key
''On / off'' key''Select'' key
See table
''Functions available from main screen''
1x Level 1
2x Level 2
3x No backlight
''Backlight'' key
Vane probe thermo-anemometer
LV 101 - LV 107 - LV 110
actoolsupply.com
actoolsupply.com
actoolsupply.com
Kimo LV 101 Thermo Anemometer
Kimo LV 107 Thermo Anemometer
Kimo LV 110 Thermo Anemometer
How to change battery
1. Remove the front part at the back of the instrument
2. Remove old battery
3. Insert the new battery in accordance with proper polarity drew
inside the housing.
4. Replace the front.
Select air
velocity units
Average
calculation
1x
Start Min/Max valuesAverage value
Automatic
shut-off
Press sur to scroll down units. Validate with
Select temp.
units
Press to scroll down units. Validate with
Press to scroll down minutes. Validate with
Beep
Press to activate or to desactivate Validate with
Functions available from VELOCITY main screen
Ø of
circular area
3x
Press to select '' Circ. '' and press
Enter diameter with Validate with
Dimensions
of
rectangular
area
Press to select ''Rect.'' and press
Enter length with Validate with
Select
cone
Press to scroll down cone list Validate with
1x 1x
2x 2x
L
V
101
L
V107
L
V1
10
3x 2x
3x3x 2x
4x4x 3x
5x 4x 5x
6x 5x 6x
7x 6x 7x
Select air flow
units
Automatic
shut-off
Press to scroll down units. Validate with
Select temp.
units
Press to scroll down units. Validate with
Press to scroll down minutes. Validate with
Beep
Press to activate or to desactivate. Validate with
Back to velocity
menu
1x
2x
3x
4x
5x
Functions available from AIR FLOW main screen
Enter width with Validate with
In order to change dimensions or type of side wall vent
Number of key pressing
