SMB-631
Portable Mini FM Radio
www.bratz.com
TM & MGA Entertainment, Inc.
©
All Right Reserved. Used under license by
The Singing Machine Co., Inc.
The Singing Machine Company, Inc.
6601 Lyons Road, Bldg. A7, Coconut Creek, FL33073-9902, USA.
TEL: (954) 596-1000 FAX: (954) 596-2000
VISIT OUR WEBSITE www.singingmachine.com
631-0707-E01
CONTROL LOCATIONS
2
1
6
3
1. VolumeKnobwithON/OFF
2. Power ON LED indicator
3. SCAN button
BATTERY INSTALLATION
1. Unscrew battery door.
2. Open battery door and clip.
3. Install 2 “AG13” batteries.
4. Close battery door / clip and replace screw.
5
4
4. RESET button
5. Earphone jack
6. Batteries compartment
OPERATION
Operating the Radio
1. Plug the included earphones into the phone jack.
2. Turn on the radio by rotating the Volume Knob in the
midway position. Thepower led indicatorwillbe turned on.
3. PresstheRESETbuttontogotothelowendofFMradio.
4. Press the FM SCAN button to search forward stations
automatically.
5. Be sure to turn off the radio after enjoying your
program.
Note:
1. Avoid leaving the volume at minimum loudness with radio
turned on. This will use up all batteries.
2. If the unit is not to be used fora prolongedperiod, such
as a month or longer, remove the batteries to prevent
possible leakage.
3. This product may need manual reset under high
electrostatic discharge.
SPECIFICATIONS:
AUDIO SECTION
Output Power(MAX)
RADIO SECTION
FM Frequency Range
EARPHONE:
POWER SECTION
DIMENSION (WxDxH)
WEIGHT 0.11lbs/50gs
12.5mW
88-108MHz
-42dB 64ohms impedance with
3.5mm earphone plug
2x“AG13”batteries
(Batteries are included)
2.8x1.1x1.9Inches/
7.2x2.7x4.8cm
PRINTED IN CHINA
WARNINGS
WARNING: TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD,
DO NOT EXPOSETHIS PRODUCT TO RAINOR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
CAUTION: TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER OR BACK. NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICINGTO QUALIFIED PERSONNEL.
COMPLIES WITH DHHS RADIATION PERFORMANCE STANDARDS,
21 CFR SUB. CHAPTERJ. THIS DEVICE COMPLIES WITH PART
15 OF THE FCC RULES, OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
CERTIFICATION:
THIS PRODUCT COMPLIES WITH 21 CFR CHAPTER 1, SUBCHAPTER
J OF DHHS REGULATIONS.
COMPLIES WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE,
PURSUANTTOPART15OFTHEFCCRULES.
Battery Precautions
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery
compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon Zinc) or old
batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged, they can overheat and rupture
(Follow battery manufacturer’s directions).
6. Rechargeable batteries are to be removed from the product before being charged.
7. Rechargeable batteries are only to be charged under adult supervision.
8. Exhausted batteries are to be removed from the product.
9.Thesupplyterminalsarenottobeshort-circuited.
Note:
A warning that excessive sound pressure from earphones and
headphones can cause hearing loss.
DO NOT OPEN
