Kiddicare Swinging crib Instruction Manual
swinging crib
Instruction Manual
Important: Keep for future reference, read carefully
Kiddicare
Club Way,
Cygnet Park,
Hampton,
Peterborough,
Cambridgeshire PE7 8JA
Customer Care: hello@kiddicare.com
Care
Warning: The crib/cradle should be locked in the fixed position when a child is
unsupervised init.
Warning: Do not use the crib/cradle if any part is broken, or missing and use only spare
parts approved by Kiddicare
Warning: Be aware of the risk of open fires and other sources of strong heat, such as
electric bar fires, gas fires, etc in the near vicinity of the crib/cradle.
We recommend you use a mattress size 85 x 43cm for this crib/cradle. The thickness of
the mattress chosen shall be such that the internal vertical height (surface of the mattress
to the upper edge of crib sides) is at least 200mm in the highest position of the base.
Safety
Complies with BS EN 1130 1997
A child’s safety is your responsibility.
Do not use the body of the cradle without its frame.
The crib/cradle should be placed on a horizontal floor.
When a child is able to sit, kneel or to pull itself up, the crib/cradle shall not be used
anymore for this child.
Young children should not be allowed to play unsupervised in the vicinity of the crib/
cradle.
Maintenance
All assembly fitting should always be tightened properly and that care should be taken that
no screws are loose, because a child could trap parts of the body or clothing (e.g. strings,
necklaces, ribbons for babies dummies, etc.), which would pose a risk of strangulation.
From time to time, check your crib/cradle for loose screws, and worn parts. Replace or
adjust the parts as needed.
Cleaning
Your crib can be cleaned by wiping with a damp cloth and drying with a soft clean cloth.
Do not use abrasives, bleach, alcohol or ammonia based household polishes.
2 3
parts parts
Tools required
Measure
10 20 30 40 50 60 70 80 90 100 1100
(millimeters)
x1
x1
x1
A B C
D
G
x2
x1 x1
x6
E
H
F
I
x2
x1
Allen Key
x1
x2
x4
J K L
M
P Q
x2
x2 x2
N
x1
O
x1
x8
included
not
included
cross head screwdriver
