Deluxe Moses Basket Stand
IMPORTANT: read the instructions carefully before use and keep them for
future reference. The child may be hurt if you do not follow these instructions.
Your child’s safety is your responsibility. If you have a query with this product
or require replacement parts, please contact 01692 408802.
Lay out the parts on a soft level surface and compare to the parts checklist
below. Do not discard any packaging until you are sure that you have all the
parts.
Keep children clear during assembly as pack contains small parts which may
present a choking hazard.
Parts:
Woodscrew x 6
Strap x 2
Frame
A cross-point screwdriver is required for assembly.
Moses Basket Stand Assembly 1. Opening the Stand.
Ensure that the stand is placed on a firm, horizontal and level floor.
Open the stand.
Rotate the metal locking mechanism as shown. Make sure the bar
locates securely over the opposite wooded cross dowel.
Moses Basket Stand Assembly 2. Securing the Metal Locking Mechanism
?
Moses Basket Stand Final Assembly
Woodscrew x 3
Strap
Attach the Straps to the Frame at the end where there are two holes
close together, using two Woodscrews. As shown above, the Frame has
small holes drilled in it to locate the Woodscrews correctly.
Place your basket centrally on the stand and fold one of the Straps
around it. Choose the nearest fitting screw holes in the Strap and Frame
and secure using a Woodscrew.
Repeat for the other Strap.
IMPORTANT: Once the straps have been secured to the frame, the screws
should not be removed.
Moses Basket Stand After Use - Folding the Stand
The stand must be folded and stored safely after use. To fold the stand, lift
the metal latching stay, then lower the frame slightly passing latching stay
through the frame. Lift stand by hoops to close.
Safety notes:
WARNING -YOUR CHILDREN’S SAFETY IS YOUR RESPONSIBILITY.
The stand must be fully erected and locked before your carry cot is placed
into it.
This product has been designed and manufactured to: BSEN 1466:2004
+A1:2007
The stand is designed for a carry cot with maximum dimensions at the base
of 800 x 320mm and a minimum of 670 x 270mm
WARNING - Use only on a firm ground which is horizontal, level and dry.
WARNING - Do not let other children play unattended near the carry cot and
stand.
WARNING - Do not use if any part is broken, damaged or missing.
There are no user replaceable parts present.
Do not place carry cot and stand in close proximity to a wall or other
obstacle; this is intended to prevent entrapment.
The stand is not intended for use as a bath stand and should not be used for
any other purpose than as a carry cot stand.
Do not rock the carry cot whilst in the stand.
When not in use the stand should be folded and stored safely away from
children.
4770-2
Care instructions:
The Metal Locking Mechanism can be cleaned with a damp cloth (and wipe
dry). The frame can be wax polished.
Do not use abrasives cleaners or bleach.
Do not allow older children to use it as a toy or climbing frame.
kiddicare.com
Club Way
Cygnet Park
Hampton
Peterborough
Cambs
PE7 8JA
www.kiddicare.info
Customer Care Hotline For This Product 01692 408802
