SOLO-BARIC® SUBWOOFER

L7S8 | L7S10 | L7S12 | L7S15

Owner’s Manual

SOLO-BARIC L7 SUBWOOFER
OWNER’S MANUAL

L7S8 / L7S10 / L7S12 / L7S15Models:

WARNING: KICKER products are capable of producing sound levels that can permanently damage your
hearing! Turning up a system to a level that has audible distortion is more damaging to your ears than
listening to an undistorted system at the same volume level. The threshold of pain is always an indicator
that the sound level is too loud and may permanently damage your hearing. Please use common sense
when controlling volume.

SPECIFICATIONS

Model L7S8 L7S10 L7S12 L7S15

Rated Impedance [Ω]

47.2 37.5 34 26.3

Fs [Hz]

Continuous Power Handling [Watts RMS] 450 600 750 1000

Sensitivity [1W, 1m] 82.37 85.87 86.90 88.56

Xmax (Linear Excursion) [mm] .52 (13.5) .64 (16.25) .64 (16.25) .75 (19)

Re [Ω] 6.6 7.9 6.8 7.0

8.828 9.791 9.488 11.868

Qms

.802 .535 .571 .565

Qes

Qts .735 .507 .539 .539

Vas [ft³, L] .322 (9.127) 1.0 (28.347) 1.916 (54.274) 5.263 (149.048)

Outer Frame Dimension [in, cm] 8-3/16 (22.4) 10-11/16 (27.1) 12-5/8 (32) 15-5/8 (39.7)

Mounting Cutout [in, cm] 7-1/4 (18.4) 9-5/16 (23.7) 11-1/16 (28.1) 13-3/4 (34.9)

Mounting Depth [in, cm] 4-3/4 (12.1) 6-1/4 (15.9) 6 13/16 (17.3) 8 11/16 (22.1)

Frequency Response [Hz] 28–500 24–500 20–500

2 or 4 2 or 4 2 or 4 2 or 4

18–500

WIRING

Solo-Baric L7 subwoofers are available with dual 2 (ohm) or dual 4 voice coils. Both coils must be
connected to a source of amplifi cation. The dual 2 woofer will generate a 1 load if the coils are wired in
parallel or a 4 load in series. The dual 4 woofer will provide a 2 load wired in parallel or 8 load wired
in series. The terminals with the white dots are for the fi rst voice coil. The terminals with solid-red and
solid-black markings are for the second voice coil. See Figure 1.

Sound Check: Poor bass response? Check the system phasing by reversing the positive and negative
speaker connections on the subwoofer. If the bass improves, then the subwoofer was out of phase in
reference to the rest of the audio system.

2
