Table Top (1)
Rod (1)
Spider (1)
Base (1)
Column (1)
Glides (4 for
cross base, 5
Screws (8 or
12 for 48 inch
and larger
tables
Large Washer (1)
Small Washer
(1)
9x1-14 Nut
(1)
Step 4. Push threaded end of rod through the
spider. Allow the square end of rod to rest
between slots on spider.
Step 5. Align spider mount holes with pilot holes
on bottom of table to ensure centering.
Step 1. Ensure all components are present.
Step 2. Set table top on floor face down.
Step 3. Remove the washers and nut from the rod.
Step 6. Use a phillips screw driver to screw the spider to
the top. A drill can be used for easier assembly.
Step 7. Slide column over rod onto spider.
Step 8. Place the base face down onto the column.
Step 9. Place the large washer onto the rod.
Then place the small washer onto the rod.
Step 10. Start nut onto threads and tighten.
IMPORTANT: Pull up on rod while threading.
Step 11. Thread the glides into base as required.
Pedestal Table Assembly
