KEYSTONE FIGURE 89 PNEUMATIC QUARTER TURN ACTUATORS
MODEL CODE OPTIONS AND DESCRIPTIONS - NORTH AMERICA AND EUROPE ONLY
Model / Series
89U - 002 0 1 04 N14 H 2 M F05 S14 - B04 PS3 C0A NPZ CRZ MCZ MEZ TF1
MODEL / SERIES
Code Description
89C Chemical Specs
89D ISO 5211 (Metric threaded)
89E Keystone ISO (Metric threaded)
89U Keystone Imperial + Metric threaded
Actuator Size
Pneumatic Actuator Variant
Actuator Action
Spring Rating
Air Connection
Temperature Service
Travel Stops
Flange Threading
Operator Mounting Flange
ACTUATOR ACTION
Code Description
1 DA
3 SR Fail Close (CW)
4 SR Fail Open (CWW)
Stem Connection
Bolting Options
Optional Air Connection
Coating / Painting
Nameplate Tagging
Country of Origin
Material Certification Traceability
SPRING RATING
ACTUATOR SIZE
Code Description
002 Model 002
003 Model 003
004 Model 004
006 Model 006
009 Model 009
014 Model 014
020 Model 020
032 Model 032
033 Model 033
051 Model 051
052 Model 052
084 Model 084
085 Model 085
086 Model 086
139 Model 139
140 Model 140
141 Model 141
240 Model 240
Code Description
04 4 Springs
05 5 Springs
06 6 Springs
07 7 Springs
08 8 Springs
09 9 Springs
10 10 Springs
11 11 Springs
12 12 Springs
XX Not Applicable
AIR CONNECTION
Code Description
N14 ¼" NPT
N12 ½" NPT
P14 ¼" BSPP
P12 ½" BSPP
ZZZ Special
Positive Material Identification
Functional Testing
PNEUMATIC ACTUATOR VARIANT
Code Description
0 Standard
R Reduced Spring Length
L Hybrid-SR Left (seen from the label side)
S Hybrid-SR Right (seen from the label side)
