Keysight Technologies Truevolt Series, Truevolt 34465A, Truevolt 34460A, Truevolt 34461A, Truevolt 34470A Security Features And Volatility Documentation

Security Features and Volatility Documentation
Keysight Technologies, Inc.
Model Numbers:
34460A 34461A 34465A 34470A
Product Family:
5991-1950EN
Revision 2.0
January, 2015
© Keysight Technologies, Inc. 2013 - 2015
Page 1 of 17
Page 2 of 17
Contents
Introduction .................................................................................................................. 4
Contacting Keysight Sales and Service Offices ........................................................... 4
Product Declassification and Security ......................................................................... 4
Terms and Definitions ................................................................................................... 5
Instrument Memory and Volatility Information ............................................................ 6
Memory Clearing, Sanitization and/or Removal Procedures ..................................... 11
User and Remote Interface Security Measures ......................................................... 13
Procedure for Declassifying a Faulty Instrument ....................................................... 17
Page 3 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
Introduction
This document describes instrument security features and the steps to declassify an instrument through memory sanitization or removal. For additional information please go to www.keysight.com/find/security or www.keysight.com/find/ad and click Instrument Security in the Related Links area.
Contacting Keysight Sales and Service Offices
Assistance with test and measurement needs, and information to help you find a local Keysight office, is available at www.keysight.com/find/assist. Otherwise, please contact your designated Keysight representative.
Note: In any correspondence or telephone conversation, refer to the instrument by its model number and full serial number. With this information, the Keysight representative can determine whether your unit is still within its warranty period.
Product Declassification and Security
Model Numbers:
34460A, 34461A, 34465A, 34470A
Product Name:
34460A – Digital multimeter, 6½-digit, basic Truevolt DMM 34461A – Digital multimeter, 6½-digit, 34401A replacement, Truevolt DMM 34465A – Digital multimeter, 6½-digit, Truevolt DMM 34470A – Digital multimeter, 7½-digit, Truevolt DMM
Product Family Name:
Truevolt Series of Digital Multimeters
Page 4 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
Terms and Definitions
Clearing
As defined in Section 8-301a of DoD 5220.22-M, “National Industrial Security Program Operating Manual (NISPOM)”, clearing is the process of eradicating the
data on media before reusing the media so that the data can no longer be retrieved using the standard interfaces on the instrument. Clearing is typically used when the instrument is to remain in an environment with an acceptable level of protection.
Instrument Declassification
A term that refers to procedures that must be undertaken before an instrument can be removed from a secure environment, such as is the case when the instrument is returned for calibration. Declassification procedures include memory sanitization or memory removal, or both. Keysight declassification procedures are designed to meet the requirements specified in DoD 5220.22-M, “National Industrial Security Program Operating Manual (NISPOM)”, Chapter 8.
Sanitization
As defined in Section 8-301b of DoD 5220.22-M, “National Industrial Security Program Operating Manual (NISPOM)”, sanitization is the process of removing or
eradicating stored data so that the data cannot be recovered using any known technology. Instrument sanitization is typically required when an instrument is moved from a secure to a non-secure environment, such as when it is returned to the factory for calibration.
Keysight memory sanitization procedures are designed for customers who need to meet the requirements specified by the US Defense Security Service (DSS). These
requirements are specified in the “Clearing and Sanitization Matrix” in Appendix O
of the ODAA Process Guide for C&A of Classified Systems under NISPOM.
Secure Erase
Secure Erase is a term that is used to refer to either the clearing or sanitization features of Keysight instruments.
Page 5 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters
Memory Type
and Size
User accessible as a
mass storage device?
Writable During
Normal Operation?
Data Retained When
Powered Off?
Purpose/Contents
Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
System Flash (NAND Flash) 45 MB
No
Yes
Yes
Contains operating system, instrument firmware, and the firmware recovery image
Factory Install / Firmware Upgrade
Front panel U203 1819-0707 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
User Flash (NAND Flash) 80 MB
Yes
Yes
Yes
User data, configuration and preference files, screen capture files, instrument state files, and user reading storage
User-saved data
Front panel U203 1819-0707 (same chip as other parts, but managed separately)
NAND Flash Sanitize – See Table 1
Calibration Store (NAND Flash) 3 MB
No
Yes
Yes
Calibration constants, calibration count, secure count, security code, and calibration message
Factory or Service and user calibration
Front panel U203 1819-0707 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
Model Numbers: 34460A, 34461A, 34465A, 34470A
Instrument Memory and Volatility Information
This section contains information on the types of memory available in your instrument, including the memory size, usage, location, volatility, and sanitization procedure.
This instrument uses one NAND Flash memory chip to retain the needed system information and the user memory partition. The User memory partition is separate and independent so that the sanitization procedures may be applied to only this partition on a sector by sector basis.
Performing an instrument sanitization requires the instrument Security option (SEC) to be installed. Please refer to the Truevolt Series Operating and Service Guide for more information on available options.
Summary of instrument memory - base instrument
Page 6 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters
Memory Type
and Size
User accessible as a
mass storage device?
Writable During
Normal Operation?
Data Retained When
Powered Off?
Purpose/Contents
Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
Front panel microprocessor (Flash) 8 kB
No
No
Yes
Front panel microprocessor execution code storage
Factory Install / Firmware Upgrade
Front panel microprocessor U401 1822-3182 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
Front panel microprocessor (EEPROM) 512 Bytes
No
Yes
Yes
Stores instrument ON/OFF power state (not the power­on configuration)
Operating System or Microprocess or execution code
Front panel microprocessor U401 1822-3182 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
Front panel microprocessor (RAM) 256 Bytes
No
Yes
No
Front panel microprocessor temporary execution data
Microprocess or execution code
Front panel microprocessor U401 1822-3182 (same chip as other parts, but managed separately)
Power cycle
Main processor (ROM) 32 kB
No
No
Yes
Main processor execution code
Manufacturer programmed
Front panel U201 1822-4268 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
Model Numbers: 34460A, 34461A, 34465A, 34470A
Page 7 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters
Memory Type
and Size
User accessible as a
mass storage device?
Writable During
Normal Operation?
Data Retained When
Powered Off?
Purpose/Contents
Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
Main processor (SRAM) 8 kB
No
Yes
No
Temporary execution data
Operating System
Front panel U201 1822-4268 (same chip as other parts, but managed separately)
Power cycle
Main RAM (SDRAM) 1 G-bit
No
Yes
No
Temporary execution data
Operating System
Front panel U204 1819-0389
Power cycle
Measurement Processor (Flash) 512 kB
No
No
Yes
Processor execution code
Factory Install / Firmware Upgrade
Main board U901 1822-4407 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
Measurement Processor (SRAM) 98 kB
No
Yes
No
Data path processing
Measurement Processor Flash
Main board U901 1822-4407 (same chip as other parts, but managed separately)
Power cycle
Model Numbers: 34460A, 34461A, 34465A, 34470A
Page 8 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters
Memory Type
and Size
User accessible as a
mass storage device?
Writable During
Normal Operation?
Data Retained When
Powered Off?
Purpose/Contents
Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
Measurement Processor (ROM)
No
No
Yes
Processor execution data
Manufacturer programmed
Main board U901 1822-4407 (same chip as other parts, but managed separately)
N/A, contains no application­specific information.
Measurement Calibration (EEPROM) 64 k-bit
No
Yes
Yes
Calibration data
User calibration
Main board U904 1819-0623
N/A, contains no application­specific information.
Measurement FPGA (Flash)
1.27 M-bit
No
No
Yes
Logic Array Configuration
Factory Install / Firmware Upgrade
Main board U803 1822-3758
N/A, contains no application­specific information.
Measurement FPGA (SRAM) 166 k-bit
No
Yes
No
Data processing
Measurement FPGA Flash
Main board U803 1822-3758
Power cycle
Model Numbers: 34460A, 34461A, 34465A, 34470A
Page 9 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters
Memory Type
and Size
Is Memory user
accessible as a mass
storage device?
Writable During
Normal Operation?
Data Retained When
Powered Off?
Purpose/Contents
Data Input
Method
Location in
Instrument and
Remarks
Sanitization
Procedure
FPGA 1M-bit
No
Yes
Yes
Control interface between main processor and GPIB
Flash Memory
GPIB interface 1822-1960
N/A, contains no application­specific information.
Flash 1M-bit
No
No
Yes
Stores GPIB control FPGA program bits
Factory Install / Preprogramm ed part
GPIB interface P0001-80001
N/A, contains no application­specific information.
Model Numbers: 34460A, 34461A, 34465A, 34470A
Summary of instrument memory: 34460A-GPB, 34461A-GPB, 34465A-GPB, 34470A-GPB, 3446GPBU
Page 10 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
Memory Clearing, Sanitization and/or Removal Procedures
This section explains how to clear, sanitize, and remove memory from your instrument for all memory that may contain application-specific information and that can be written to during normal operation. This section also highlights the clearing and sanitization procedures if more than trivial, such as cycling power on your instrument.
Performing an instrument sanitization requires the instrument Security option (SEC) to be installed. Please refer to the Truevolt Series Operating and Service Guide for more information on available options.
With the instrument Security option, a single button press will completely sanitize all internal user accessible memories using the appropriate NISPOM sanitization procedure. Without this option, user files must be individually deleted or overwritten to manually clear memory.
Page 11 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters
Description and purpose
This is the user’s partition of internal storage that uses a NAND flash device.
Storage may include instrument configuration, preference and state files, screen capture images, and user reading storage for measurement results.
Size
80 MB
Memory clearing
To remove individual files from the file system on the front panel press: [Utility] > Manage Files > Action > Delete > Browse. Then select the file and press Select > Perform Delete > Yes.
To remove all files from the file system on the front panel press: [Utility] > Manage Files > Action > Delete > Browse. Then select Internal and press Select > Perform Delete > Yes.
To remove files and folders from the file system via the remote interface, use:
MMEMory:DELete {<file>|<filespec>} MMEMory:RDIRectory <folder>
See the Truevolt Series Operating and Service Guide for more information.
Memory sanitization
***********
Requires
Instrument
Security
Option
***********
Performing an instrument sanitization requires the instrument Security option (SEC) to be installed. Please refer to the Truevolt Series Operating and Service Guide for more information on available options.
On front panel press: [Utility] > Test/Admin > Security > NISPOM Sanitize > Sanitize
From the remote interface, send:
SYSTem:SECurity:IMMediate
Note: The instrument’s security setting must be unlocked to perform these
actions. Executing a sanitize operation will increment the instrument’s secure count.
This sanitizes all user-accessible instrument memory and restarts the instrument. This includes deleting and sanitizing all measurement data, user-defined state or preference information, and user-defined I/O settings. The instrument’s firmware, serial/model number, and calibration data are preserved.
This command complies with requirements in chapter 8 of the National Instrument Security Program Operating Manual (NISPOM). This command is for users, such as military contractors, who must comply with NISPOM. Specifically, the action will fully declassify all non-volatile memory using the methods specified in the June 28, 2007 DSS Memory Clearing and Sanitization Matrix.
See the Truevolt Series Operating and Service Guide for more information.
Memory removal
This memory cannot be removed without damaging the instrument. The user may remove the front panel assembly on which the memory chip resides. Remove the front panel board per the disassembly instructions in the Truevolt Series Operating and Service Guide.
Model Numbers: 34460A, 34461A, 34465A, 34470A
User Flash (NAND Flash)
Table 1
Page 12 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
User and Remote Interface Security Measures
How to determine if the instrument’s Security option is installed
From the front panel, press:
[Help] > About
From the remote interface, send:
*OPT?
A string containing “SEC” will be returned if the instrument Security option is installed.
Administrative Password
To defeat or override an instrument’s administrative password (calibration secure
override/Security option override) follow the procedure in the Truevolt Series Operating and Service Guide. This involves removing power and other
connections to the instrument, removing the instrument cover (requires tools), shorting a jumper, and cycling power. The calibration count and secure count will increment when the password is defeated using this method.
When setting a new password, the password must begin with a letter and contain 1 to 12 letters (A-Z), digits (0-9), or underscores (_).
The password never expires.
This instrument does not track or report invalid password attempts, nor does it lock-out password entry following a number of invalid password entries.
Managing Remote Interface Access
The user is responsible for providing security for the I/O ports for remote access by controlling physical access to the I/O ports. The I/O ports must be controlled because they provide access to all user settings, user states and the display image. The I/O ports include USB, GPIB, and LAN.
With the instrument Security option, modifying these settings requires the instrument password. The secure count will increment when a remote interface is disabled or enabled. See the Truevolt Series Operating and Service Guide for more information.
Page 13 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
The LAN port provides the following services, which can be selectively disabled:
a) LAN b) VXI-11 c) Sockets d) Telnet e) Web f) mDNS g) HiSLIP
To disable LAN services:
On the front panel, press:
[Utility] > I/O Config > LAN Off/On, or use [Utility] > I/O Config > LAN Settings > LAN Services, then select the
interface to enable or disable
On the remote interface, use:
SYSTem:COMMunicate:ENABle {ON|OFF}, <interface>
For mDNS on the remote interface, use:
LXI:MDNS:ENABle {ON|OFF}
To disable USB:
On the front panel, press:
[Utility] > I/O Config > USB Settings > USB SCPI Off/On
On the remote interface, use:
SYSTem:COMMunicate:ENABle {ON|OFF}, USB
To disable GPIB:
On the front panel, press:
[Utility] > I/O Config > GPIB Settings > GPIB Off/On
On the remote interface, use:
SYSTem:COMMunicate:ENABle {ON|OFF}, GPIB
USB Mass Storage Device Security
Not Supported
Controlling the USB device MTP (driverless) connection service
Page 14 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
On the front panel press:
[Utility] > I/O Config > USB Settings > File Access Off/On
On the remote interface use:
SYSTem:COMMunicate:ENABle {ON|OFF}, USBMTP
If the instrument Security option is installed, this requires that the instrument is unlocked. The secure count will increment when this port is disabled or enabled. See the Truevolt Series Operating and Service Guide for more information.
Controlling the Front Panel USB Host port
On the front panel press:
[Utility] > I/O Config > USB Settings > USB Front Off/On
On the remote interface use:
SYSTem:USB:HOST:ENABle {ON|OFF}
This requires the instrument Security option, and that the instrument is unlocked. The secure count will increment when this port is disabled or enabled. See the Truevolt Series Operating and Service Guide for more information.
Controlling the Front Panel Display
To provide basic security, you may disable the front panel display.
To disable the display on the front panel, press:
[Utility] > System Setup > User Settings > Display Options > Display OFF
Note: pressing any key will enable the display again.
To disable the display on the remote interface, send:
DISP OFF
Note: pressing Local will enable the display again.
The display is enabled when power is cycled. See the Truevolt Series Operating and Service Guide for more information.
How to disable the Front Panel during remote operation
To programmatically lock out all front panel operation and remote access over the current interface, use the SYSTem:LOCK command. See the Truevolt Series Operating and Service Guide for more information.
Page 15 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
Calibration Regulation
The instrument requires a password to unsecure the instrument before calibration. The instrument’s calibration count will increment with each successful calibration step.
Firmware Update Regulation
The instrument requires a password to unsecure the instrument before updating firmware. The instrument’s calibration count will increment with each successful update.
Instrument Specifics
Main Processor: STMicroelectronics SPEAR320S-2, ARM9926EJ-S 333MHz 289­LFBGA
Ethernet PHY Transceiver: IEEE-802.3/ 802.3u compliant 10/100 base-T, SMSC LAN8710A
Operating System: Microsoft Windows® CE 6.0 R3
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States or other countries.
Page 16 of 17
Product Declassification and Security Product Name: Truevolt Series of Digital Multimeters Model Numbers: 34460A, 34461A, 34465A, 34470A
Procedure for Declassifying a Faulty Instrument
If the instrument is not functioning and the user is unable to use the security functions to declassify the instrument, the user must physically remove the front panel printed circuit assembly from the instrument. Once this assembly is removed, proceed with one of these options:
Destroy the front panel printed circuit assembly using a DSS/NISPOM approved
destruction method
OR
Remove the NAND flash memory component located on the front panel printed
circuit assembly (U203), and destroy it using a DSS/NISPOM approved destruction method
Refer to the Truevolt Series Operating and Service Guide procedures for removing the front panel printed circuit assembly.
Send the instrument to a Keysight repair facility. If the unit has option SEC and is still under warranty, the repair facility will replace the front panel printed circuit assembly. If this restores instrument functionality, the user will not be charged for the new assembly. If a different assembly is at fault, the user will be charged for the new front panel assembly even though the instrument is still under warranty.
Page 17 of 17
Loading...
