Keysight BT2152A Self-Discharge Analyzer

Operating and

Service Guide

Legal and Safety Information 6

Legal Notices 6 Safety Symbols 8 Safety Notices 9

1 Quick Reference 11

Welcome 12

What is self-discharge? 12 Advantages of the Keysight BT2152A Self-Discharge Analyzer 12 Contact Keysight Technologies 12

Models and Specifications 13

Models 13 Front and Rear Views 13 Specifications 14 Characteristics 15 Self-Discharge Measurement Criteria 16 External Temperature Measurement 16 Dimensions and Airflow 17

Command Quick Reference 18

2 Installing the Analyzer 23

Before Installation 24

Inspect the Unit 24 Check for Items Supplied 24 Accessories 24 Review Safety Information 25 Observe Environmental Conditions 25 Provide Adequate Air Flow 25

Connect the Power Cord 26 Connect the Interfaces 27

LAN Connections 27 USB Connections 28 Digital Port Connections 28 Thermistor Connections 28

Connect the Cell Cables 29

Makingthe Cables 29 RJ45 WIre Color Codes and Pinout Numbers 30 32-Channel Mapping to RJ45 Connectors 31

3 Operating the Analyzer 33

Understanding Front Panel Operation 34

What happens at power-on? 34 What happens when a test is initiated? 35 What happens when a test stops? 35 What happens when the reference temperature exceeds its specification? 35 What happens when a protection event or error occurs? 35

Using the Digital Port 36

Digital Control Port 36 Bi-Directional Digital I/O 36

3 Keysight BT2152A Operating and Service Guide

Digital Input 37 Fault Output 38 Inhibit Input 38 Fault/Inhibit System Protection 39

Maintaining Cell Stability During Testing 40

A Cell's Percent State of Charge 40 Charge Redistribution and Equilibrium 40 Expected Self-Discharge Current and Temperature Dependency 41 Temperature Impact on Current Measurement 41 Impact of Stress and Vibration on Current Measurement 42

4 Programming Reference 43

Introduction to the SCPI Language 44

Command Types 44 Keywords 44 Queries 45 Syntax Conventions 45 Parameter Types 46 Device Clear 47

Programming Samples 48

Setting up and running a test 48 Retrieving all test values 49 Stopping/aborting a test 50 Clearing protection events and errors 50

Commands by Subsystem 51

Calibration Commands 52 Common Commands 58 Digital Commands 61 Fetch Commands 63 Format Command 68 Initiate Commands 69 LXI Command 71 Output Commands 72 Sense Commands 73 Status Commands 75 System Commands 79

Status Tutorial 87

Status Registers 87 Alarm Channel Groups 87 Alarm Status Group 88 Standard Operation Group 88 Status Byte Register 89 Error and Output Queues 90 Status Diagram 91

Reset (*RST) and Interface Settings 92 SCPI Error Messages 93

Error List 93

Keysight BT2152A Operating and Service Guide 4

5 Verification and Calibration 97

Verification Procedure 98

Introduction 98 External DMM Connections and Setup 98 Zero-Scale Current Accuracy Verification 99 Full-Scale Current Accuracy Verification 100 Voltage Accuracy Verification 101 Verification Assembly 102

Reference Calibration 103

Introduction 103 External DMM Connections and Setup 103 Enter Calibration Mode 104 Voltage Calibration 104 Current Calibration 104 End Calibration and Store Results 105

Channel Calibration 106

Prerequisites 106 Running Channel Calibration 106 If Problems Occur with Channel Calibration 106 Aborting Channel Calibration 106

Wire Resistance Calibration 107

Benefits of Wire Resistance Calibration 107 Wire Resistance Compensation Constraints 107 Wire Resistance Calibration Procedure 107

Calibration Security Reset 109

Electrostatic Discharge (ESD) Precautions 109 Tools Required 109 Cover Removal 109 Password Reset 110

Maintenance 111

Index 112

5 Keysight BT2152A Operating and Service Guide

Legal and Safety Information

Legal Notices

Safety Notices

Safety Symbols

Legal Notices

No part of this manual may be reproduced in any form or by any means (including electronic storage and retrieval or translation into a foreign language) without prior agreement and written consent from Keysight Technologies Inc. as governed by United States and international copyright laws.

Manual Part Number

BT2152A-90001

Edition

Edition 3, September, 2017 Updated August, 2018

Published By

Keysight Technologies 550 Clark Drive, Suite 101 Budd Lake, New Jersey 07828 USA

Warranty

The material contained in this document is provided "as is," and is subject to being changed, without notice, in future editions. Further, to the maximum extent permitted by applicable law, Keysight disclaims all warranties, either express or implied, with regard to this manual and any information contained herein, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. Keysight shall not be liable for errors or for incidental or consequential damages in connection with the furnishing, use, or performance of this document or of any information contained herein. Should Keysight and the user have a separate written agreement with warranty terms covering the material in this document that conflict with these terms, the warranty terms in the separate agreement shall control.

Keysight BT2152A Operating and Service Guide 6

Legal and Safety Information

Certification

Keysight Technologies certifies that this product met its published specifications at time of shipment from the factory. Keysight Technologies further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed by the Institute's calibration facility, and to the calibration facilities of other International Standards Organization members.

U.S. Government Rights

The Software is "commercial computer software," as defined by Federal Acquisition Regulation (“FAR”) 2.101. Pursuant to FAR 12.212 and 27.405-3 and Department of Defense FAR Supplement (“DFARS”) 227.7202, the U.S. government acquires commercial computer software under the same terms by which the software is customarily provided to the public. Accordingly, Keysight provides the Software to U.S. government customers under its standard commercial license, which is embodied in its End User License Agreement (EULA), a copy of which can be found at http://www.keysight.com/find/sweula. The license set forth in the EULA represents the exclusive authority by which the U.S. government may use, modify, distribute, or disclose the Software. The EULA and the license set forth therein, does not require or permit, among other things, that Keysight: (1) Furnish technical information related to commercial computer software or commercial computer software documentation that is not customarily provided to the public; or (2) Relinquish to, or otherwise provide, the government rights in excess of these rights customarily provided to the public to use, modify, reproduce, release, perform, display, or disclose commercial computer software or commercial computer software documentation. No additional government requirements beyond those set forth in the EULA shall apply, except to the extent that those terms, rights, or licenses are explicitly required from all providers of commercial computer software pursuant to the FAR and the DFARS and are set forth specifically in writing elsewhere in the EULA. Keysightshall be under no obligation to update, revise or otherwise modify the Software. With respect to any technical data as defined by FAR 2.101, pursuant to FAR 12.211 and 27.404.2 and DFARS 227.7102, the U.S. government acquires no greater than Limited Rights as defined in FAR 27.401 or DFAR 227.7103-5 (c), as applicable in any technical data

Declaration of Conformity

Declarations of Conformity for this product and for other Keysight products may be downloaded from the Web. Go to http://www.keysight.com/go/conformity and click on "Declarations of Conformity". You can then search by product number to find the latest Declaration of Conformity.

Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

This product complies with the WEEE Directive 2002/96/EC marketing requirement. The affixed product label (see below) indicates that you must not discard this electrical/electronic product in domestic household waste.

Product Category: With reference to the equipment types in the WEEE directive Annex 1, this product is classified as "Monitoring and Control instrumentation" product.

Do not dispose in domestic household waste.

To return unwanted products, contact our local Keysight office.

7 Keysight BT2152A Operating and Service Guide

Safety Symbols

A WARNING notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, could result in personal injury or DEATH. Do not proceed beyond a WARNING notice until the indicated conditions are fully understood and met.

A CAUTION notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, could result in damage to the product or loss of important data. Do not proceed beyond a CAUTION notice until the indicated conditions are fully understood and met.

Direct current

Alternating current

Frame or chassis terminal

Standby supply. Unit is not completely disconnected from AC mains when switch is off.

Legal and Safety Information

Risk of electric shock

Refer to accompanyingdocuments

Earth ground terminal

The CE mark is a registered trademark of the European Community.

The ETL mark is a registered trademark ofIntertek.

The RCM mark is a registered trademark of the Spectrum Management Agency of Australia. This signifies compliance with the Australian EMC Framework regulations under the terms ofthe Radio Communications Act of 1992.

South Korean Class A EMC Declaration This equipment is Class A suitable for professional use and is for use in electromagnetic environments outside of the home.

Contains one or more ofthe 6 hazardous substances above the maximum concentration value (MCV), 40 Year EPUP.

ISM1-A This text indicates that the instrument is an Industrial Scientific and Medical Group 1

Class A product (CISPER 11, Clause 4).

ICES/NMB001

This text indicates product compliance with the Canadian Interference- Causing Equipment Standard (ICES-001).

Keysight BT2152A Operating and Service Guide 8

Legal and Safety Information

Safety Notices

The following general safety precautions must be observed during all phases of operation of this instrument. Failure to comply with these precautions or with specific warnings or instructions elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability of the customer’s failure to comply with the requirements.

General Do not use this product in any manner not specified by the manufacturer. The protective features of this product may be impaired if it is used in a manner not specified in the operating instructions.

Environmental Conditions Never use the instrument outside of the specified environmental conditions described under Environmental Conditions.

Ground the Instrument This product is provided with protective earth terminals. To minimize shock hazard, the instrument must be connected to the AC mains through a grounded power cable, with the ground wire firmly connected to an electrical ground (safety ground) at the power outlet. Any interruption of the protective (grounding) conductor or disconnection of the protective earth terminal will cause a potential shock hazard that could result in injury or death.

Do Not Operate in an Explosive Atmosphere Do not operate the instrument in the presence of flammable gases or fumes.

Do Not Remove the Instrument Cover Only qualified, service-trained personnel who are aware of the hazards involved should remove covers. Always disconnect external power.

Do Not Modify the Instrument Do not install substitute parts or perform any unauthorized modification to the product. Return the product to a Keysight Sales and Service Office for service and repair to ensure that safety features are maintained.

Fuses The instrument contains an internal fuse, which is not customer accessible.

9 Keysight BT2152A Operating and Service Guide

Legal and Safety Information

Cleaning To prevent electric shock, always unplug the unit before cleaning. Use a dry cloth or one slightly dampened with water to clean the external case parts. Do not use detergent or chemical solvents. Do not attempt to clean internally.

In Case of Damage Instruments that are not functioning correctly, appear damaged or defective should be made inoperative and secured against unintended operation until they can be repaired by qualified service personnel.

Keysight BT2152A Operating and Service Guide 10

Keysight BT2152A Operating and Service Guide

1 Quick Reference

Welcome

Models and Specifications

Command Quick Reference

1 Quick Reference

Welcome

What is self-discharge?

Self-discharge of an electrical cell is the loss of charge over time while not connected to any load. Some amount of self-discharge is a normal attribute resulting from chemical reactions taking place within the cell. Additional self-discharge can result from leakage current paths existing within the cell. Particulate contaminants and dendrite growths produce internal “micro-shorts”, creating such leakage current paths. These are not normal attributes and they can lead to catastrophic failure of the cell. For this reason it is a priority to evaluate cells for self-discharge.

Electrically, self-discharge can be modeled as a high-value resistance existing in parallel across the cell. Note that self-discharge current is very difficult to measure in practice. Usually a defective cell can only be detected after days or weeks of aging. This is where the proprietary technology of the Keysight BT2152A Self-Discharge Analyzer provides a superior method of measuring self-discharge over other traditional methods.

Advantages of the Keysight BT2152A Self-Discharge Analyzer

The Keysight BT2152A Self-Discharge Analyzer uses a proprietary measurement technique to determine the open-circuit discharge of the cell due to its internal parallel resistance. This proprietary direct measurement technique lets you determine the quality of the cell within one to two hours after the cell has been initially charged and rested. This can significantly reduce the test time required to determine the self-discharge characteristic of the cell due to internal parallel resistance. Key test features are as follows:

l The voltage applied to the cell is quickly matched (±5 μV) to the actual cell voltage. This minimizes

any new charge or discharge and limits any new RC settling to a minimum.

l The voltage applied to the cell is very stable (±10 μV

current noise on the self-discharge current measurement.

l The Measurement System accurately measures low-level self-discharge currents to ± (0.33% of read-

ing + 1 μA).

) to minimize continuing charge redistribution

peak

Contact Keysight Technologies

You can contact Keysight Technologies for warranty, service, or technical support.

Use www.keysight.com/find/assist for information on contacting Keysight worldwide, or contact your Keysight Technologies representative.

12 Keysight BT2152A Operating and Service Guide

Models and Specifications

Front and Rear Views

Specifications

Characteristics

Self-Discharge Measurement Criteria

External Temperature Measurement

Dimensions and Airflow

Models

l Keysight BT2152A - 32 channel Self-Discharge Analyzer

1 Quick Reference

Front and Rear Views

1. Line switch Turns the unit on or off

2. Status Indicators and switches

Power: Green LED indicates power is on. LAN: Green LED indicates the LAN connection is active. Flashing green indicates an LXI identification query is sent. Flashing blue indicates a SCPI command is received. Red indicates a LAN fault. Ready: Amber indicates the unit is warming up. A warmup time of 1 hour is required. Green indicates the unit is ready to start the test. Test: Flashing blue indicates that cell matching has been initiated. Blue indicates a test is running. Off indicates no test is running. Flashing orange indicates calibration. Error: Red indicates an error has occurred. Off indicates protection is cleared. LANreset: This recessed switch performs a software system LAN reset. Aux: This switch is reserved for future use. Stop: This switch aborts any current measurements and sequences. The unit returns to a state of being ready for initialization.

3. Air Inlet Air inlet requires a minimum of 6 inch (15 cm) clearance

Keysight BT2152A Operating and Service Guide 13

1 Quick Reference

4. Digital connector An 8-pin digital IO interface

5. USB USB interface connector

6. LAN 10/100/1000 Base-T Left LED indicates link speed (Green 1 Gbps, Orange is 100 Mbps, Off is 10 Mbps with activity blinking) Right LED indicates activity

7. Universal AC input Standard IEC 320 connector

8. Calibration port Calibration port

9. Temperature sensor Temperature sensor input (requires an external 10 kΩ thermistor)

10. RJ45 connectors Eight RJ45 connectors for 32-channel cell connections (4 cell connections are available on each RJ45 connector)

11. Air Outlets

The rear air outlet requires a minimum of 6 inch (15 cm) clearance

Specifications

Unless otherwise noted, specifications are warranted over the ambient temperature range of 20°C to 30°C after a 1 hour warm-up period.

Parameter Specification

Number of channels: Standard 32 channels

Optional configurations available in 4- channel increments

Current measurement accuracy:

Voltage measurement accuracy: ± (0.05% + 1 mV)

Current measurement accuracy is measured at 1 minute integration.

± (0.33% + 1 μA)

14 Keysight BT2152A Operating and Service Guide

1 Quick Reference

Characteristics

Characteristics are not warranted but are descriptions of performance determined either by design or by type testing. Characteristics are typical unless otherwise noted.

Parameter Characteristic

Voltage measurement and output range: 0.5 V to + 4.5 V

Current measurement range: ± 10 mA

Programmable resistance range: 0.1 Ω to 10 Ω

Initial cell voltage matching ± 5 μV

Voltage sourcing stability (typical)

Warm-up timeafter power-on: 1 hour

Environmental conditions: Operating environment: Ambient temperature range: Relative humidity: Altitude: Storage temperature:

Digital Port Max voltage rating:

Pins 1 &2 as FLT:

Pins 1-7 as outputs:

Pins 1-7 as inputs:

1,2

± 10 μVpeak

Indoor use, installation category II (for AC input), pollution degree 2 20°C to 30°C Up to 80% (non-condensing) Up to 2000 meters

-30°C to 70°C

+16.5 VDC/- 5 VDC between pins

Maximum low-level output voltage = 0.5 V @ 4 mA Maximum low-level sink current = 4 mA Typical high-level leakage current = 1 mA @ 16.5 VDC

Maximum low-level output voltage = 0.5 V @ 4 mA; 1 V @ 50 mA; 1.75 V @ 100 mA Maximum low-level sink current = 100 mA Typical high-level leakage current = 0.8 mA @ 16.5 VDC

Maximum low-level input voltage= 0.8 V Minimum high-level input voltage= 2 V Typical low-level current = 2 mA @ 0 V (internal 2.2k pull-up) Typical high-level leakage current = 0.12 mA @ 16.5 VDC

Pin 8:

AC input Range: Frequency: VA:

Output voltage stability is measured over 24 hours at 1 minute integration.

Specification applies at output terminals. Cabling and interconnect errors may degrade this significantly.

Maximum rate-of-change (dT/dt) must be <5°C/hour.

Pin 8 is common (internally connectedto chassis ground)

100-240 VAC 50/60 Hz 170 VA Max

Keysight BT2152A Operating and Service Guide 15

1 Quick Reference

Self-Discharge Measurement Criteria

To quickly measure the self-discharge behavior of a Lithium ion cell requires characterizing a number of test parameters, and verifying that their effect will result in a valid self-discharge measurement.

The following inequality describes the parameter constraints that must be satisfied for a valid selfdischarge measurement, one that results in a voltage value between 0.5 V and 4.5 V.

0.5V ≤ V

+ I*(6.2Ω + R

CELL

CABLES

+ R

- <res>) ≤ 4.5V

ESR

where

is the open circuit voltage of the cell. This can be provided by the user, or measured with the

CELL

Keysight BT2152A.

I is the instantaneous current obtained during the self-discharge test. This is the Keysight BT2152A’s current measurement value. The inequality constraints must be satisfied for all measured current results, both positive and negative. This includes the initial current, final settled current value, and any transients that may occur. Note that the current measurement range for the unit is ±10 mA; however, the resultant value should be positive and much lower than 10 mA -- usually in the 10 to 100 microampere range.

CABLES

is the resistance of the total cable wiring from the Keysight BT2152A to the cell under test.

This can be provided by the user through external measurements, or it can be calibrated directly by the Keysight BT2152A’s CALibration:WIRE:RESistance:AUTO command. It can also be modified using the SENSe:WIRE:RESistance:CONFigure command.

is cell’s internal equivalent series resistance. This can be provided by the user if necessary by

ESR

adding it to the resistance of the total cabling wiring from the Keysight BT2152A to the cell under test, using the SENSe:WIRE:RESistance:CONFigure command. Typically this value is less than 10 mΩ.

<res> is the user-selected output resistance from 0.1 Ω to 10 Ω. This is the same value entered using the INITiate:TEST:MATChed command.

External Temperature Measurement

The external temperature sensor input on the rear panel requires an external 10 kΩ thermistor.

Measurement Input Characteristic

Thermistor Requirements: Negative Temperature coefficient (NTC)

10 kΩ Nominal Resistanceat 25°C Programmable Beta value (4073 default)

Temperature measurement range: 5°C to 100°C

Temperature measurement uncertainty: ± 1.5°C

Maximum total lead resistanceallowed: 10 Ω

16 Keysight BT2152A Operating and Service Guide

Dimensions and Airflow

Do not block the air intake at the front and side, or the exhaust at the rear of the instrument.

1 Quick Reference

l The front air inlet requiresa minimum of 6 inches (15 cm) clearance. Inlet air temperature must be

within the temperature range of 20°C to 30°C.

l The rear air outlet requires a minimum of 6 inches (15 cm) clearance.

l The small air outlet on the left side of the unit must also be unrestricted, with a minimum clearance of

1.25 inches (30 mm) or more. Clearance to the instrument support rail could be as small as 10 mm if rack mounted.

l The instrument should not be installed in a pressured rack or enclosure.

Keysight BT2152A Operating and Service Guide 17

1 Quick Reference

Command Quick Reference

CALibration

:DATE <date> Sets the calibration date :END Ends calibration :LOAD Loads the previous calibration values :RESult? <value> Enters the resulting measurement for calibration :SECure :CODE <code> Sets a calibration security code :STATe 0|OFF|1|ON Secures or unsecures calibration :STARt Initiates calibration :STEP <step> Steps through the different calibration processes :STORe Stores the cal constants in the EEPROM :STRing <string> Stores a message in calibration memory :VALue? <step> Returns the calibration constants of the step :VERification :END Ends the verification process :STARt <channel> Starts the verification process :VOLTage <voltage> Enters the output voltage for verification :MEASure :INITiate <time>, <tint> Starts a verification measurement :WIRE :RESistance :AUTO Runs auto-calibration of the wire resistance :CLEar Resets all wiring resistance values to zero :LOAD <value> Loads the wiring resistance values from a file :SAVE <value> Saves the wiringresistance values to a file

Common Commands

ABORt Aborts the measurement in progress *CAL? Initiates auto-calibration on all channels *CLS Clears status *IDN? Returns instrument identification *OPC? Returns "1" to the output buffer when all pending operations complete *RST Resets the instrument *STB? Status byte query *TST? Self-test query *WAI Pauses command processing until all pending operations are complete

18 Keysight BT2152A Operating and Service Guide

1 Quick Reference

[SOURce:]DIGital [SOURce:] is optional :INPut :DATA? Reads the state of the digital control port :OUTPut :DATA <value> Sets the state of the digital control port :PIN<1-7> :FUNCtion DIO|DINPut|FAULt|INHibit Specifies the pin function :POLarity POSitive|NEGative Specifies the pin polarity

FETCh

:CURRent :LATest? (@<chanlist>) Returns the most recent measurements :LOG? <values/chan> [,<offset/chan>], (@<chanlist>) Returns the measurement log in ASCii :BINary? <values/chan>, (@<chanlist>) Returns the measurement log in binary :POINts? Returns the number ofreadings available :PROBecheck? (@<chanlist>) Returns results of the probe check test :TEMPerature :LATest? Returns the most recent temperature :LOG? <values> [,<offset>] Returns the temperature log in ASCii :LOG :BINary? <values> Returns the temperature log in binary :POINts? Returns the number ofreadings available :VOLTage :LATest? (@<chanlist>) Returns the most recent measurements :LOG? <values/chan> [,<offset/chan>], (@<chanlist>) Returns the measurement log in ASCii :LOG :BINary? <values/chan>, (@<chanlist>) Returns the measurement log in binary :POINts? Returns the number ofreadings available :OCV? (@<chanlist>) Retrieves the open-circuit voltage values

FORMat

:BORDer NORM|SWAP Selects the byte order for binary block transfers

INITiate

:TEST :MATChed <time><units>, <ovp>, <uvp>, <res>

[,<tint>[,<curr>[,<ocp>]]], (@<chanlist>) :OCV (@<chanlist>) Initiates an open-circuit voltage test :PROBecheck (@<chanlist>) Initiates a probe check test

Keysight BT2152A Operating and Service Guide 19

Sets parameters for the voltage matched discharge current measurement

1 Quick Reference

LXI

:IDENtify[:STATe] 0|OFF|1|ON Turns the front panel LXI identify indicator on or off

OUTPut

:INHibit :MODE LATChing|LIVE|OFF Sets the operating mode of the Inhibit Input digital pin :PROTection :CLEar Resets any protection events that have occurred

SENSe

:OCV :AVAIlable? Returns availability of the OCV measurement :PROBecheck :AVAIlable? Returns availability of the probe check test :THERmistor :CONFigure <temp>, <resistance>, <beta> Specifies parameters for the external thermistor :TTIMe :REMaining? Returns the remaining time for the present test :VERification :AVAIlable? Returns availability of the calibration verification :WIRE :RESistance :AVAIlable? Returns availability of the wire resistance values :CONFigure <resistance>, (@<chanlist>) Specifies the wiring resistance of each channel

STATus

:ALARm

[:EVENt]? Queries the alarm event register :CONDition? Queries the alarm condition register :CURRent? Returns the sum ofthe over-current condition bits :VOLTage? Returns the sum of the over-voltage condition bits :UNDer? Returns the sum of the under-voltage condition bits :ENABle <value> Sets the alarm enable register. :OPERation

[:EVENt]? Queries the operation event register :CONDition? Queries the operation condition register :ENABle <value> Sets the operation enable register

20 Keysight BT2152A Operating and Service Guide

1 Quick Reference

SYSTem

:COMMunicate :ENABle 0|OFF|1|ON <interface> Enables or disables the remote interface :LAN :CONTrol? Reads the initial control connection port number :DHCP 0|OFF|1|ON Enables or disables DHCP :DNS[1|2] "<address>" Assigns static IP addresses of DNS servers :DOMain? Returns the domain name :GATeway "<address>" Assigns a default gateway address :HOSTname "<name>" Assigns a hostname :IPADdress "<name>" Assigns a static IP address :MAC? Returns the instrument's MAC address :SMASk "<mask>" Assigns a subnet mask :TELNet :PROMpt "<string>" Sets the command prompt for Telnet :WMESsage "<string>" Sets the welcome message for Telnet :UPDate Saves any changes made to the LAN settings :WINS[1|2] "<address>" Assigns the static IP addresses of WINS servers :DATE <yyyy>, <mm>, <dd> Sets the date of the system clock :ERRor? Reads and clears one error from the error queue :TIME <hh>, <mm>, <ss> Sets the time ofthe system clock :TEMPerature? Returns the external sensor's temperature value

Keysight BT2152A Operating and Service Guide 21

Keysight BT2152A Operating and Service Guide

2 Installing the Analyzer

Before Installation

Connect the Power Cord

Connect the Interfaces

Connect the Cell Cables

2 Installing the Analyzer

Before Installation

Inspect the Unit

When you receive your Keysight BT2152A Self-Discharge Analyzer, inspect it for any obvious damage that may have occurred during shipment. If there is damage, notify the shipping carrier and nearest Keysight Sales and Support Office immediately. Refer to www.keysight.com/find/assist.

Until you have checked out the unit, save the shipping carton and packing materials in case the unit has to be returned.

Check for Items Supplied

Before getting started, check the following list and verify that you have received these items.

BT2152A Items Description Part Number

Power cord A power cord suitable for your location Call Keysight Sales & Support Office

LANcable LANinterface cable - cable is installed Keysight 8121-3010

L-COM TRD815OR-7

Digital connector 8-pin connector for the digital port Keysight 1253-6408;

Phoenix Contact 1840421

Thermistor connector 2-pin connector for an external thermistor Keysight 0360-3009

Phoenix Contact 1840366

Calibration connector 3-pin connector for an calibration connections Keysight 0360-3038

Phoenix Contact 1840379

Thermistor cable 2-meter cable with 10 k thermistor - used with thermistor con-

nector 0360-3009

Safety booklet Includes safety information Keysight 9320-6797

Calibration certificate Calibration certificatereferenced to serial number None

Keysight BT2152-61607

Refer to the box packing list for any additional items that may be included with your shipment. If anything is missing, please contact your nearest Keysight Sales and Support Office.

Accessories

Items Description Part Number

Verification Kit Verification kit to simplify instrument verification Keysight BT2152-60002

24 Keysight BT2152A Operating and Service Guide

2 Installing the Analyzer

Review Safety Information

This instrument is a Safety Class 1 instrument, which means it has a protective earth terminal. That terminal must be connected to earth ground through a power source equipped with an earth ground. Refer to the Safety Notices page for general safety information. Before installation or operation, check the instrument and review this guide for safety warnings and instructions. Safety warnings for specific procedures are located at appropriate places throughout this guide.

Observe Environmental Conditions

Do not operate the instrument in the presence of flammable gases or fumes.

The environmental conditions of the instrument are documented under Characteristics. Basically, the unit should only be operated indoors in a controlled environment. Do not operate the unit in areas where the ambient temperature is outside the 20°C to 30°C range. This applies for rack-mounting as well as for bench use.

Provide Adequate Air Flow

Do not block the air intake at the front and side, or the exhaust at the rear of the instrument.

The dimensions of your instrument as well as an outline diagram are given under Dimensions. Fans cool the unit by drawing air through the front and exhausting it out the side and back. The unit must be installed in a location that allows sufficient space of at least 6 inches (15 cm) at the front and back of the unit for adequate air circulation.

Keysight BT2152A Operating and Service Guide 25

2 Installing the Analyzer

Connect the Power Cord

FIRE HAZARD Use only the power cord that was supplied with your instrument. Using other types of power cords may cause overheating of the power cord, resulting in fire.

SHOCK HAZARD The power cord provides a chassis ground through a third conductor. Be certain that your power outlet is of the three-conductor type with the correct pin connected to earth ground.

Connect the power cord to the IEC 320 connector on the rear of the unit. If the wrong power cord was shipped with your unit, contact your nearest Keysight Sales and Support Office.

The AC input on the back of your unit is a universal AC input. It accepts nominal line voltages in the range of 100 VAC to 240 VAC. The frequency can be 50 Hz or 60 Hz.

The detachable power cord may be used as an emergency disconnecting device. Removing the power cord will disconnect AC input power to the unit.

26 Keysight BT2152A Operating and Service Guide

2 Installing the Analyzer

Connect the Interfaces

LAN Connections

USB Connections

DIgital Port Connections

Thermistor Connections

If you have not already done so, install the Keysight IO Libraries Suite, which can be found at

www.keysight.com/find/iolib .

For detailed information about GPIB, USB, and LAN interface connections, refer to the documentation included with the Keysight IO Libraries Suite.

LAN Connections

Equipment Damage Never insert any cell cables (RJ45) into the LAN connector. The LAN and RJ45 terminals are NOT compatible.

1. Connect the instrument to the site LANor to your computer using the LAN cable that is connected to the unit. The cable comes connected to prevent any output cables from being accidentally inserted into the LAN connector.

The LAN cable comes installed to prevent any cell cables from being accidentally inserted into the LAN connector. If you need to remove the LAN cable, insert a small screwdriver or equivalent into the hole and push down on the cable latch to release it.

2. The as-shipped LAN settings are configured to automatically obtain an IP address from the network using a DHCP server (DHCP is set On). The DHCP server will register the instrument's hostname with the dynamic DNS server. The hostname as well as the IP address can then be used to communicate with the instrument. If you are using a private LAN, you can leave all LAN settings as they are. Most Keysight products and most computers will automatically choose an IP address using auto-IP if a DHCP server is not present. Each assigns itself an IP address from the block 169.254.nnn. The frontpanel Lan indicator will come on when the LAN port has been configured.

3. Use the Connection Expert utility of the Keysight IO Libraries Suite to add the instrument and verify a connection. To add the instrument, you can request the Connection Expert to discover the instrument. If the instrument cannot be found, add the instrument using the instrument’s hostname or IP address.

4. You can now use Interactive IO within the Connection Expert to communicate with your instrument, or program the instrument directly using the applicable SYSTem:COMMunicate:LAN commands.

Keysight BT2152A Operating and Service Guide 27

2 Installing the Analyzer

USB Connections

1. Connect the instrument to the USB port on your computer using a customer-supplied USB cable. .

2. With the Connection Expert utility of the Keysight IO Libraries Suite running, the computer will automatically recognize the instrument. This may take several seconds. When the instrument is recognized, your computer will display the VISA alias, IDN string, and VISA address. This information is located in the USB folder.

3. You can now use Interactive IO within the Connection Expert to communicate with your instrument, or program the instrument directly using the applicable SYSTem:COMMunicate:LAN commands.

Digital Port Connections

Twist and shield all signal wires to and from the digital connector. With shielded wire, connect only one end of the shield to chassis ground to prevent ground loops.

An 8-pin connector and a quick-disconnect connector plug are provided for accessing the digital port functions. Refer to Items Supplied for part numbers. Disconnect the connector plug to make your wire connections. The connector plug accepts wires sizes from AWG 14 (1.5 mm2) to AWG 28 (0.14 mm2). Strip the wire insulation back 7 mm.

Insert wires

Tighten screws

Fault/Inhibit configurable pins (observe INH polarity)

Digital IO-configurable pins

Signal common

Information on using the digital port is found under Usingthe Digital Port. The electrical characteristics are described under Common Characteristics.

Thermistor Connections

A 2-pin connector and a quick-disconnect connector plug are provided for the thermistor cable connections. Use the provided thermistor cable. Refer to Items Supplied for the thermistor cable part number.

Insert wires

Tighten screws

The thermistor provided with the cable is Keysight p/n 0837-4194; Amphenol Advanced Sensors RL1005-5744-103-SA. Refer to SENse:THERmistor:CONFigure for additional information.

28 Keysight BT2152A Operating and Service Guide

2 Installing the Analyzer

Connect the Cell Cables

Making the Cables

RJ45 WIre Colors Codes and Pinout Numbers

32-Channel Mapping to RJ45 Connectors

This section describes how to make and connect the cell cables.

Making the Cables

Two methods of cabling are available:

1. RJ45 to bare wire

Obtain off-the-shelf RJ45 CAT6+ shielded cables. Many lengths are available. For example: Manufacturer = Belden. Part number = C6F1106010. Maximum allowable cable length = 25 meters.

Cut the cable in the middle. Now, you have two pieces half the previous length. Each piece has an RJ45 on one side and bare wires on the other.

Connect the RJ45 CAT6+ cables from the instrument to the test fixture.

When using shielded cables like Cat 6A or Cat 7, leave the shield floating at the cell end of the cable. The cable shield connects to the instrument chassis at the BT2152A end of the cable.

Wire resistance calibration is recommended when all RJ45 cables have been installed in the

instrument to allow for more accurate output resistance selections. Wire resistance calibration is also recommended whenever any RJ45 connector is unplugged, reinserted, or reseated. Wire resistance must be between 0Ω and 5Ω.

2. RJ45 to RJ45

Obtain off-the-shelf RJ45 CAT6+ shielded cables. Many lengths are available. For example: Manufacturer = Belden. Part number = C6F1106010. Maximum allowable cable length = 25 meters.

Obtain off-the-shelf RJ45 board mount receptacles. For example: Manufacturer = Amphenol. Part number = RJSSE-5380-04.

Mount the RJ45 receptacle on the test fixture. Connect the RJ45 CAT6+ cables from the instrument to the receptacle.

Keysight BT2152A Operating and Service Guide 29

2 Installing the Analyzer

When using shielded cables like Cat 6A or Cat 7, leave the shield floating at the cell end of the cable. The cable shield connects to the instrument chassis at the BT2152A end of the cable.

Wire resistance calibration is recommended when all RJ45 cables have been installed in the

RJ45 WIre Color Codes and Pinout Numbers

The following figures illustrate the color codes and pin-outs of two types of RJ45 connectors, as viewed from the bottom of the connector.

The following table shows the mapping of the color-coded wires into both T-568A and T-568B connectors. The table also shows the channel-assignment mapping of channels 1 through 4.

RJ45 Pin 8

Channels 1 to 4 -1 +1 -3 -2 +2 +3 -4 +4

T- 568A brown wht/brn orange wht/blu blue wht/org green wht/grn

T- 568B brown wht/brn green wht/blu blue wht/grn orange wht/org

RJ45

Pin 7

RJ45

Pin 6

RJ45

Pin 5

RJ45

Pin 4

RJ45 Pin 3

RJ45

Pin 2

RJ45

Pin 1

30 Keysight BT2152A Operating and Service Guide

2 Installing the Analyzer

32-Channel Mapping to RJ45 Connectors

The following figure shows the channel assignments for the 32-channel self-discharge analyzer.

The following table shows the channel-assignment mapping of all 32 channels.

RJ45 #1 Channels 1 to 4

RJ45 #2 Channels 5 to 8

RJ45 #3 Channels 9 to 12

RJ45 #4 Channels 13 to 16

RJ45 #5 Channels 17 to 20

RJ45 #6 Channels 21 to 24

RJ45 #7 Channels 25 to 28

RJ45

Pin 8

-1 +1 -3 -2 +2 +3 -4 +4

-5 +5 -7 -6 +6 +7 -8 +8

-9 +9 -11 -10 +10 +11 -12 +12

-13 +13 -15 -14 +14 +15 -16 +16

-17 +17 -19 -18 +18 +19 -20 +20

-21 +21 -23 -22 +22 +23 -24 +24

-25 +25 -27 -26 +26 +27 -28 +28

RJ45

Pin 7

RJ45

Pin 6

RJ45

Pin 5

RJ45

Pin 4

RJ45

Pin 3

RJ45

Pin 2

RJ45

Pin 1

RJ45 #8 Channels 29 to 32

-29 +29 -31 -30 +30 +31 -32 +32

Keysight BT2152A Operating and Service Guide 31

Keysight BT2152A Operating and Service Guide

3 Operating the Analyzer

Understanding Front Panel Operation

Using the Digital Port

Maintaining Cell Stability During Testing

3 Operating the Analyzer

Understanding Front Panel Operation

What Happens at power-on?

What happens whena test is initiated?

What happens whena test stops?

What happens whenthe reference temperature exceeds its specification?

What happens whena protection event or error occurs?

The following indicators and controls are on the front panel.

The AUX button is not active, and is reserved for future use.

What happens at power-on?

Turn the unit on with the front-panel Line switch.

It may take about 60 seconds or so for the unit to completely boot up.

When the unit is first turned on, the Power LED turns green, indicating that power is on.

The LAN indicator turns green when the LAN connection is active. Flashing green indicates an active LXI identification state. Red indicates the LAN is disconnected. Pressing the LAN reset button on the front panel will attempt to restore the LAN connection. If this does not work, restoring LAN communication must be done using the test program.

The Ready indicator turns orange, indicating that the unit is warming up. A warm up time of about 1 hour is required for the unit to meet its specified performance. It is possible to send commands and operate the unit during the warm up time, but it is advisable to allow the unit to fully warm up before running any test. If power was cycled and off for less than 5 minutes after warmup, subsequent warm up will be about 30 minutes.

The Ready status is driven by elapsed time. If the unit is powered off and then powered on again, the Ready LED will again turn orange for about one hour.

The Test and Error indicators should be off. If the Error LED is red, either a protection event or an error has occurred (see What happens when a protection event or error occurs?).

34 Keysight BT2152A Operating and Service Guide

3 Operating the Analyzer

What happens when a test is initiated?

Before initiating a test, wait for the Ready indicator to change from orange to green, which means the unit is warmed up and ready for testing. It is possible to send commands and operate the unit prior to the LED changing to green, but it is advisable to let the unit warm up to meet specified performance.

The LAN indicator flashes blue when any SCPI commands or queries are sent.

The Test indicator flashes blue when the cell matching process has been initiated and is running.

The Test indicator stops flashing and turns solid blue when the cell measurement test is running and data logging is occurring.

The Test indicator turns off when the measurement logging has completed.

What happens when a test stops?

Normally, a test runs for the duration of its programmed test time and then stops. A test can also be stopped before the completion of its programmed time by pushing the Stop button or sending an Abort command.

When a test stops or is stopped, the Test indicator turns off.

The Power, LAN, and Ready indicators are green. The Test and Error indicators are off.

What happens when the reference temperature exceeds its specification?

The Ready indicator turns orange when the internal reference temperature is slightly out of regulation. There may be a problem with the airflow. Check that the airflow at the vents is unobstructed. Once the internal temperature is restored, the Ready indicator will turn to green.

The Ready indicator flashes red when the internal reference temperature has increased to a point where damage could occur. When this happens the internal heaters are disabled and the operating temperature range will not be maintained. Turn the unit off, let it cool down, then turn it on to clear the condition.

What happens when a protection event or error occurs?

The Error indicator turns red when either a protection event or an error has occurred.

If a protection event occurs on a channel, that channel is disconnected from the cell. You can continue running the test on other channels. The channel that tripped protection remains disconnected from the cell until protection is cleared.

If an error occurs, the instrument will continue to operate with errors present.

Clearing the protection event or error can only be done using the test program. There is no front panel control to clear protection events or errors. Once the test program clears the protection event or error, the Error LED turns off.

Keysight BT2152A Operating and Service Guide 35

3 Operating the Analyzer

Using the Digital Port

Bi-Directional Digital I/O

Digital Input only

Fault Output

Inhibit Input

Fault/Inhibit System Protection

Digital Control Port

A Digital Control Port consisting of seven I/O pins is provided to access various control functions. Each pin is user-configurable. The following control functions are available for the I/O pins.

The following table describes the possible pin configuration for the digital port functions. For a complete description of the electrical characteristics of the digital control port, refer to the

Characteristics section.

Function Description

DIO General-purpose ground-referenced digital input/output function. The output can be setwith

[SOURce:]DIGital:OUTPut:DATA.

DINPut Digital input-only mode. The digital output dataof the pin is ignored.

FAULt Applies only to pin 1. Pin 1 functions as an isolated fault output. The fault signal is true when any output isin

a protected state. Pin 2 serves as theisolated common for pin 1. When pin 1 is setto the FAULtfunction, the instrument ignores any commands to program pin 2. Queries of pin 2 will return FAULt. If pin 1 ischanged from FAULtto another function, pin 2 is setto DINPut.

INHibit Applies only to pin 3. When pin 3 isconfigured as an inhibit input; a true signal at thepin will disable the out-

put.

Common Applies only to pin 8. Connected to ground.

In addition to the configurable pin functions, the signal polarity (Positive or Negative) for each pin is also configurable. For level signals, POSitive indicates a voltage high at the pin. NEGative indicates a voltage low at the pin. For edge signals, POSitive means a rising edge and NEGative means a falling edge.

Bi-Directional Digital I/O

Each of the seven pins can be configured as general purpose bi-directional digital inputs and outputs. The polarity of the pins can also be configured. Pin 8 is the signal common for the digital I/O pins. Data is programmed according to the following bit assignments:

36 Keysight BT2152A Operating and Service Guide

3 Operating the Analyzer

Pin 7 6 5 4 3 2 1

Bit Weight 6 (msb) 5 4 3 2 1 0 (lsb)

The digital I/O pin can be used to control both relay circuits as well as digital interface circuits. The following figure illustrates typical relay circuits as well as digital interface circuit connections using the digital I/O functions

To configure the pins for digital I/O:

DIG:PIN1:FUNC DIO DIG:PIN2:FUNC DIO DIG:PIN3:FUNC DIO DIG:PIN4:FUNC DIO DIG:PIN5:FUNC DIO DIG:PIN6:FUNC DIO DIG:PIN7:FUNC DIO \\ sets the function for all 7 pins to digital IO DIG:PIN1:POL POS DIG:PIN2:POL POS DIG:PIN3:POL POS DIG:PIN4:POL POS DIG:PIN5:POL POS DIG:PIN6:POL POS DIG:PIN7:POL POS \\ sets the function for all 7 pins to positive DIG:OUTP:DATA 7 \\ configures pins 1 through 7 as “0000111”

Digital Input

Each of the seven pins can be configured as digital input only. The polarity of the pins can also be configured. Pin 8 is the signal common for the digital input pins. The pin status reflects the true condition of the external signal that is applied to the pin. The pin state is not affected by the setting of DIGital:OUTPut:DATA.

To configure the pins for digital input only:

Keysight BT2152A Operating and Service Guide 37

3 Operating the Analyzer

DIG:PIN1:FUNC DINP DIG:PIN2:FUNC DINP DIG:PIN3:FUNC DINP DIG:PIN4:FUNC DINP DIG:PIN5:FUNC DINP DIG:PIN6:FUNC DINP DIG:PIN7:FUNC DINP\\ sets the function for all 7 pins to digital input DIG:PIN1:POL POS DIG:PIN2:POL POS DIG:PIN3:POL POS DIG:PIN4:POL POS DIG:PIN5:POL POS DIG:PIN6:POL POS DIG:PIN7:POL POS \\ sets the function for all 7 pins to positive DIG:INP:DATA? \\ reads the data on the pins

Fault Output

Pins 1 and 2 can be configured as a fault-output pair. The Fault Output function enables a fault condition to generate a protection fault signal from the Alarm Status Group on the digital port.

Both pins 1 and 2 are dedicated to this function. Pin 1 is the Fault output; pin 2 is the common for pin 1. This provides for an optically-isolated output. The polarity of pin 1 can also be configured. When the pin polarity is positive, a fault condition causes the isolated output to conduct. Note that the Fault output signal remains latched until the fault condition is removed and the protection circuit is cleared using OUTput:PROTection:CLEar.

Pin 2's selected function is ignored. Pin 2 should be connected to the ground of the external circuit.

To configure the Fault Output function:

DIG:PIN1:FUNC FAUL \\ sets the function for all 7 pins to digital IO DIG:PIN1:POL POS \\ sets the function for all 7 pins to positive

Inhibit Input

Pin 3 can be configured as a remote inhibit input. The Inhibit input function lets an external input signal disconnect or connect the input channels. The Inhibit input is level triggered. Pin 8 is the common for pin 3.

Use the OUTput:INHibit:MODE command to specify the following non-volatile Inhibit input modes: Latching, Live, or Off.

To configure the Inhibit Input function:

DIG:PIN3:FUNC INH \\ sets the function for pin 3 to Inhibit DIG:PIN3:POL POS \\ sets the polarity for pin 3 to positive OUTP:INH:MODE LIVE \\ sets the inhibit mode to Live

38 Keysight BT2152A Operating and Service Guide

3 Operating the Analyzer

OUTP:INH:MODE LATC \\ sets the inhibit mode to Latched OUTP:INH:MODE OFF \\ sets the inhibit mode to Off

Fault/Inhibit System Protection

As shown in the following figure, when the Fault outputs and Inhibit inputs of several instruments are daisy-chained, an internal fault condition in one of the units will disconnect all channels without intervention by either the controller or external circuitry. Note that when using the Fault/Inhibit signals in this manner, both signals must be set to the same polarity.

Also, as shown in the figure, you can also connect the Inhibit input to a manual switch or external control signal that will short the Inhibit pin to common whenever it is necessary to disconnect all channels. Negative polarity must be programmed for all pins in this case. You can also use the Fault output to drive an external relay circuit or signal other devices whenever a protection fault occurs.

Clearing a System Protection Fault

To restore all instruments to a normal operating condition when a fault condition occurs in a daisychained system protection configuration, two fault conditions must be removed:

The initial protection fault or external Inhibit signal.

The subsequent daisy-chained fault signal (which is sourced by the Inhibit signal).

Even when the initial fault condition or external signal is removed, the fault signal is still active and will continue to disconnect the channels of all the units.

To clear the daisy-chained fault signal if the operating mode of the Inhibit input is Live, simply clear the output protection on any ONE unit as explained under Clearing Protection Functions. If the operating mode of the Inhibit input is Latched, turn off the Inhibit input on ALL units individually. To re-enable the chain, re-program the Inhibit input on each unit to Latched mode.

Keysight BT2152A Operating and Service Guide 39

3 Operating the Analyzer

Maintaining Cell Stability During Testing

A Cell's Percent State of Charge

Charge Redistribution and Equilibrium

Expected Self-Discharge Current and Temperature Dependency

Temperature Impact on Current Measurement

Impact of Stress and Vibration on Current Measurement

The voltage of most Lithium Ion cells is very sensitive to vibration and mechanical stress or deflection. Once a self-discharge test has started, it is important that the cell not be moved or disturbed, and is not subjected to vibration. The temperature sensor must be mounted on or attached to the cell before the test and not touched or have its connection adjusted during the test. Cells are microphonic – any touching or tapping them, or any vibration or shock will affect the cell’s voltage and thus the measured current value.

A Cell's Percent State of Charge

Self-discharge current is somewhat less for lower levels of percent state of charge (% SOC), falling off at a greater rate below ~45% SOC. The cell’s voltage tends to be less stable and more temperature sensitive at lower levels of % SOC. For these reasons, it is generally recommended that the cells should ideally be at 60% SOC or higher for achieving good self-discharge current measurements.

Charge Redistribution and Equilibrium

Right after a cell is charged or discharged, it takes a considerable amount of time for the electron charge to uniformly distribute itself within the cell and be at equilibrium. During this time, the cell’s voltage is dropping or rising at an exponential rate, depending on whether it had been charged or discharged. In comparison, when a cell’s charge is fully distributed and at equilibrium, its voltage falls off at a much lower and linear rate, due to the internal self-discharge current. Depending on the cell’s makeup, it can take from several days to two weeks for a cell to reach charge equilibrium.

When the cell is connected to the Keysight BT2152A, the system holds its output voltage constant after it goes through the cell voltage matching process. If the cell is at charge equilibrium, the only influence on the cell’s voltage is due to self-discharge. As the BT2152A holds its voltage constant, the net result is the BT2152A needs to only replenish the self-discharge current to maintain constant voltage. However, when a cell has recently been charged or discharged and then connected to the BT2152A, additional charging current will be drawn from the BT2191A (after charging) or discharging current will be sourced back into the BT2152A (after discharging) in addition to the self-discharge current. The peak of this current can be several orders of magnitude greater than the self-discharge current alone.

40 Keysight BT2152A Operating and Service Guide

3 Operating the Analyzer

Expected Self-Discharge Current and Temperature Dependency

It is normal for cells to exhibit a small amount of self-discharge. It is difficult to definitively state what a cell’s expected self-discharge current should be, as many factors exist regarding a cell’s design and makeup that can affect this value. Notwithstanding, for cells at a room temperature of typically 23 °C, testing has shown it can typically range from just a few micro-amperes for sub 1 Ah cells to 50 to 100 micro-amperes for 10 to 20 Ah cells.

All other things being equal, a cell’s self-discharge current can approximately double for a 10 °C increase in temperature. This applies to good cells not exhibiting excessive self-discharge leakage current caused by internal defects or other problems.

Temperature Impact on Current Measurement

A cell’s voltage temperature dependency can be expressed as a temperature coefficient of voltage (TCV), and can be quantified in microvolts per degree C (μV/ °C). Since the BT2152A's method to measure a cell’s self-discharge current relies on matching its internal voltage source to the cell’s voltage and then connecting them together, it is easy to see how the self-discharge current measurement is impacted by any change of the cell’s voltage afterward. Several things can be done to reduce the effect of temperature on self-discharge current measurements:

l It turns out a cell’s TCV isdependent on its % SOC. It can vary from as low as zero at certain points to

as much as 100’s of μV/oC, typically at very low % SOC levels. Generally having the cell charged to 70% SOC or better helps reduce the cell’s TCV. Still, you may have to contend with a TCV in the range of 20 to 100 μV/ °C

l An indoor test environment can experience a few degrees temperature cycle each day. The series res-

istance between the BT2152A and the cell affects the measurement’s sensitivity to the cell’s TCV

l Increasing this series resistance reduces the sensitivity to a cell’s TCV but increases the time it

takes for the measurement to settle to the final self-discharge current value.

l The BT2152A has a programmable series resistance for this purpose.

l Temperature sensitivity is a significant factor for larger cells, as they usually require a longer meas-

urement settling time due to their proportionally larger capacity.

l Depending on how long the self-discharge measurement takes, it may be necessary to take further

steps to hold the cell’s temperature steady. Possibilities include:

l Surrounding the cell with thermal insulation.

l Incorporating a substantial thermal mass (metal plate) that the cell is held against, to dampen tem-

perature change. The thermal mass can be passive or actively temperature regulated.

l Using a thermal chamber having a regulated temperature.

Keysight BT2152A Operating and Service Guide 41

3 Operating the Analyzer

Impact of Stress and Vibration on Current Measurement

A cell’s voltage can be altered by mechanical stress and vibration. Any change of the cell’s voltage impacts the self-discharge current. Static stress can induce a relatively fixed voltage shift while vibrations can create substantial peak-to-peak deviations in the measurement. Take care to:

l not subject the cell to stress.

l isolate the cell from any direct vibration that may exist.

42 Keysight BT2152A Operating and Service Guide

Keysight BT2152A Operating and Service Guide

4 Programming Reference

Introduction to the SCPI Language

Programming Samples

Commands by Subsystem

Status Tutorial

Reset and Interface Settings

SCPI Error Messages

4 Programming Reference

Introduction to the SCPI Language

Command Types

Keywords

Queries

Syntax Conventions

Parameter Types

Device Clear

Command Types

SCPI (Standard Commands for Programmable Instruments) is an ASCII-based instrument command language designed for test and measurement instruments. SCPI has two types of commands, common and subsystem.

Common commands are defined by the IEEE 488.2 standard to perform common interface functions such as reset, status, and synchronization. All common commands consist of a three-letter mnemonic preceded by an asterisk: *RST, *IDN?

Subsystem commands perform specific instrument functions. They can be a single command or a group of commands. The groups are comprised of commands that extend one or more levels below the root. Subsystem commands are arranged alphabetically according to the function they perform. The following figure shows a portion of a subsystem command tree, from which you access the commands located along the various paths.

INITiate :TEST :OCV (@1)

Keywords

Keywords, also referred to as headers, are instructions recognized by the instrument. Common commands are also keywords.

INITiate is the root keyword, TEST is a second-level keyword, OCV is a third-level keyword. Colons ( : ) separate the keyword levels.

The command syntax shows most commands (and some parameters) as amixture of upper- and lower-case letters. The upper-case letters indicate the abbreviated spelling for the command. For shorter program lines, you can send the abbreviated form. For better program readability, you can send the long form.

44 Keysight BT2152A Operating and Service Guide

4 Programming Reference

In the above examples, INIT and INITiate are both acceptable forms. You can use upper- or lowercase letters. Therefore, INITIATE, init, and Init are all acceptable. Other forms such as INITiat, are not valid and will generate an error.

Queries

Following a keyword with a question mark (?) turns it into a query (Example: FETCh:CURRent:LATest?). If a query contains parameters, place the query indicator at the end of the last keyword, before the parameters. Insert a space between the query indicator and the first parameter.

You can query the programmed value of most parameters. For example, you can query the latest current reading by sending:

FETCh:CURRent:LATest? (@1)

You must read back all the results of a query before sending another command to the instrument. Otherwise, a Query Interrupted error will occur and the unreturned data will be lost.

Syntax Conventions

l Colons ( : ) separate keyword levels. Blank spaces must be used to separate command parameters

from their corresponding keyword. Note the space between VALue and the <voltage> parameter. If a command requires more than one parameter, use a comma to separate adjacent parameters. In the following calibration command, the voltage and current value parameters must be separated with a comma.

CALibration:VALue <voltage>, <current>

Triangle brackets ( < > ) indicate that you must specify a value for the enclosed parameter. In the example above, the <voltage> parameter is enclosed in triangle brackets. The brackets are not sent with the command string. You must specify a value for the parameter.

A vertical bar ( | ) separates multiple parameter choices for a given command string.

Square brackets ( [ ]) enclose some syntax elements - nodes and parameters for example. Thisindic- ates that the element is optional and can be omitted. Thebrackets are not sent with the command string. Any keyword enclosed in brackets is optional and can be omitted. However, if you are combining several commands within the same message string, you must include the optional commands to place the command parser at the correct level in the hierarchy.

Keysight BT2152A Operating and Service Guide 45

4 Programming Reference

Parameter Types

The SCPI language defines several data formats to be used in commands and queries.

Channel Parameter

The channel parameter <chanlist> is required to address one or more cell channels. Cell channels are numbered from 1 to 32. It has the following syntax for the entire range of channels:

(@1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24,25,26,27,28, 29,30,31,32) or (@1:32)

You can specify any combination of channels and ranges, provided the channels are in ascending order, as follows:

(@1:8,10,12,14,16,18,20:32)

The channel list, shown as <chanlist> throughout this document, must be preceded with the @ symbol and must be enclosed in parentheses (). Query results are channel list order-sensitive. Results are returned in the order they are specified in the list.

When adding a channel list parameter to a query, you must include a space character between the query indicator (?) and the channel list parameter. Otherwise error –103, Invalid separator will occur.

Numeric Parameters

Commands that require numeric parameters will accept all commonly used decimal representations of numbers including optional signs, decimal points, and scientific notation. If a command accepts only certain specific values, the instrument will automatically round the input numeric parameters to the accepted values. The following command requires a numeric parameter to enable channels 1 through 4 in the alarm register:

STATus:ALARm:ENABle 15

Boolean Parameters

Boolean parameters represent a single binary condition that is either true or false. For a false condition, the instrument will accept "OFF" or "0". For a true condition, the instrument will accept "ON" or "1". When you query a Boolean setting, the instrument will always return "0" or "1". The following command requires a Boolean parameter:

SYSTem:COMMunicate:LAN:DHCP OFF|0|ON|1

46 Keysight BT2152A Operating and Service Guide

4 Programming Reference

ASCII String Parameters

String parameters can contain virtually any set of ASCII characters. A string must begin and end with matching quotes; either with a single quote or a double quote. You can include the quote delimiter as part of the string by typing it twice without any characters in between. The following command uses a string parameter:

SYSTem:COMMunicate:LAN:DNS "198.105.232.4"

Device Clear

Device Clear is an IEEE-488 low-level bus message that you can use to return the instrument to a responsive state. Different programming languages and IEEE-488 interface cards provide access to this capability through their own unique commands. The status registers, theerror queue, and all configuration states are left unchanged when aDevice Clear message is received.

Device Clear performs the following actions:

l If a measurement isin progress, it is aborted.

l The instrument returns to the trigger idle state.

l The instrument's input and output buffers are cleared.

l The instrument is prepared to accept a newcommand string.

The ABORt command is the recommended method to terminate an instrument operation.

Keysight BT2152A Operating and Service Guide 47

4 Programming Reference

Programming Samples

Setting up and running a test

Retrieving all test values

Stopping/aborting a test

Clearing protection events and errors

The unit requires a warm-up time of 1 hour for the measurement circuits to stabilize so that the test results meet specifications. When the unit is fully warmed up, the front panel Ready indicator changes from amber to green. You can send programming commands to the unit while it is warming up; you just cannot calibrate the unit.

Setting up and running a test

You need only one command to set up and run a test. For example, send:

INITiate:TEST:MATChed 75, 4.2, 2.8, 1, 1, 0.0001, 0.001, (@1:16)

This command matches the cell open-circuit voltage at the start of the test and runs according to the following settings: Test duration in minutes: 75 Maximum voltage: 4.2 Minimum voltage: 2.8 Output resistance in ohms: 1.0 Time interval in seconds: 1.0 Initial cell current in amps: 0.0001 Over-current protection in amps: 0.001 Cell channels: 1 through 16.

The test begins immediately after sending this command.

The front panel Test indicator flashes blue when cell matching has been initiated. The indicator stops flashing and remains blue during the entire time the discharge test is running. After about 75 minutes, the test will stop, the Test indicator turns off, and the final discharge values are stored in the unit until the host computer reads the data out.

INIT:TEST:PROB probe check and query sequence

The following initiates a probe check test and returns the status of the channel probes.

INIT:TEST:PROB (@1:16) While(SENS:PROB:AVAIlable? == 0) \\ wait for data to become available Sleep(1000); FETC:PROB? (@1:16) \\ return comma-separated boolean values

48 Keysight BT2152A Operating and Service Guide

4 Programming Reference

INIT:TEST:OCV measurement and query sequence

The following initiates an open-circuit voltage test and returns the measured open-circuit voltage.

INIT:TEST:OCV 4.2, 2.8, 0.001, 1, (@1:16) While(SENS:OCV:AVAIlable? == 0) \\ wait for data to become available Sleep(1000); FETC:VOLT:OCV? (@1:16)

INIT:TEST:MATC measurement and query sequence

The following matches the cell open-circuit voltage, initiates a test sequence, and returns the latest current and voltage measurement.

INIT:TEST:MATC 75, 4.2, 2.8, 1, 0.125, 0.0001, 0.001, (@1:16) While(SENSe:TTIMe:REMaining? > 0) \\ wait for test to finish Sleep(1000); FETC:VOLT:LAT? (@1:16) FETC:CURR:LAT? (@1:16)

Retrieving all test values

One command returns all test values from all specified cell channels. You can first query the number of available measurement points. Then retrieve the measurements.

FETCh:CURRent:LOG:POINts? \\ returns the number of available points FETCh:CURRent:LOG? 100, (@1:16)

This command retrieves 100 current measurements from channel 1 to 16. The readings are returned sequentially in channel groups (i.e. x,x,x,x,x,x,x,x, ... y,y,y,y,y,y,y,y, ...) where x represents all the measurements for channel 1, y represents all the measurements for channel 2 etc.

Measurement array query and retrieval

The intent here is to query how many points are available, then use that information to query UP TO 200 but not more than the number of points available per channel. If the FETCh command is sent immediately after the INITiate:TEST command is sent, there may be no data to fetch for quite a while.

numCurrPointsPerChannel = 200; numCurrPointsPerChannel = min(numCurrPointsPerChannel , FETC:CURR:LOG:POIN? ) FETC:CURR:LOG? numCurrPointsPerChannel, (@1:16)

numVoltPointsPerChannel = 200; numVoltPointsPerChannel = min(numVoltPointsPerChannel , FETC:VOLT:LOG:POIN? ) FETC:VOLT:LOG? numVoltPointsPerChannel, (@1:16)

Keysight BT2152A Operating and Service Guide 49

4 Programming Reference

Stopping/aborting a test

Because the INITiate:TEST commands could take hours to execute, it may be necessary to stop the test in the middle to debug or fixa problem like a damaged fixture or cell installed backwards.

If the host computer is located in another building in a distributed factory environment, stopping the program may not be practical.

The front panel Stop button can be used to immediately stop a test. This will safely stop the test without losing test data or test configuration. Note that the ABORt command performs the same function as the front panel Stop button.

Clearing protection events and errors

When the Error LED is red, either a protection event or an error has occurred and need to be cleared.

Protection events occur due to an over-voltage (OV), under-voltage (UV), or over current (OC) condition. The unit will latch off and cannot be operated until the fault is cleared. To clear the fault the cause of the fault must first be removed and then the protect status then needs to be cleared. These faults are part of the Alarm Status Group.

To query if a protection event has occurred, send:

STATus:ALARm:EVENt?

The value returned indicates the type of protection event: Over-voltage = 1; Over-current = 2; Undervoltage = 512. The command reads and clears the fault when it is sent to the instrument. To determine if the protection condition still exists, send:

STATus:ALARm:CONDition:CURRent? STATus:ALARm:CONDition:VOLTage? STATus:ALARm:CONDition:VOLTage:UNDer?

If a value other than zero is returned when these commands are sent, the condition is still present and must be removed. if the condition is no longer present, send the following command to clear protection status. This will turn the front panel Error LED off.

OUTPut:PROTection:CLEar

Errors occur due to a variety of command processing errors, such as failing to read back the result from a query command. The instrument will continue to operate with errors present. Note that the front panel Error light does not turn on from command precessing errors.

To read and clear error codes send:

SYSTem:ERRor?

Each time this command is sent, one error is removed from the error queue. When the query returns a zero, all error have been removed from the queue.

50 Keysight BT2152A Operating and Service Guide

Commands by Subsystem

Calibration

CommonCommands

Digital

Fetch

Format

Initiate

LXI

Output

Sense

Status

4 Programming Reference

System

Keysight BT2152A Operating and Service Guide 51

4 Programming Reference

Calibration Commands

Read the calibration section before calibrating. Improper calibration can reduce accuracy and reliability.

CALibration:DATE <"date"> CALibration:DATE?

Stores the calibration date in nonvolatile memory. Enter any ASCII string up to 16 characters. The query returns the date. If no date is stored, an empty quoted string ("") is returned.

Parameter Typical Return

<"date">String program data. Enclose string parameters in single or double quotes.

Enter a calibration date: CAL:DATE "2/2/2017"

dateof last calibration

CALibration:END

Ends the calibration process. This command should be used after the calibration constants have been set, but before storing the calibration using CAL:STOR.

Parameter Typical Return

(none) (none)

End calibration: CAL:END

CALibration:LOAD

Loads the previous calibration values. For example, this can be used if there has been an error in the calibration procedure. This command is only valid prior to executing the CALibration:STORe command. Once the CALibration:STORe command has been executed, the previous calibration values are overwritten.

Parameter Typical Return

(none) (none)

Loads the previous calibration values: CAL:LOAD

CALibration:RESult? <value>

Used to enter the resulting measurement for calibration. The value entered depends on the calibration step. The command returns a zero (0) if the calibration step was successful.

52 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Parameter Typical Return

<value> is the measured result 0

Enter a calibration result: CAL:RES? 1.234567

l If a value other than zero is returned, an error has occurred. Send SYST:ERR? to return the error.

CALibration:SECure:CODE <code>

Sets the security code to prevent unauthorized calibration.

Parameter Typical Return

<code> integer from 1 to 10E32 (none)

Enter a calibration code: CAL:SEC:CODE 1223334444

l Once set, you must unsecure the unit to calibrate it, or change the calibration string or security code.

l When shipped from the factory the instrument is unsecured, with the security code set to 0 (zero).

l You cannot update the firmware using the Keysight utility without the code if calibration islocked.

CALibration:SECure:STATe 0|OFF|1|ON ,<code> CALibration:SECure:STATe?

Parameter Typical Return

0|OFF|1|ON 0or1

<code> 0, or an integer from 1 to 10E32 0

Enable thesecure code: CAL:SEC:STATON, 0

CALibration:STARt

Initiates the calibration procedure. The command does the following:

l Sends a *RST command

l Closes the output relays on all channels

l Disables the OVP, UVP, OCP, and UCP protections

l Sets all instrument DACs to 3.5 V.

l Sets the calibration status bit

Parameter Typical Return

(none) (none)

Startcalibration: CAL:STAR

Keysight BT2152A Operating and Service Guide 53

4 Programming Reference

CALibration:STEP <step> CALibration:STEP?

Steps through the different calibration processes; executes a reset after the command is sent. The query returns 0 (zero) if no step is sent.

Step Calibrating:

1 Voltage value

2 Voltage offset value

3 10 mA value

Parameter Typical Return

<step> number from 1-3 0-3

Execute calibration step 1: CAL:STEP 1

CALibration:STORe

Stores the calibration constants in the EEPROM. This step overwrites the previous calibration constants. This command should be used after calibration has ended using CAL:END.

Parameter Typical Return

(none) (none)

Store thecalibration constants: CAL:STOR

CALibration:STRing <"string"> CALibration:STRing?

Stores a message in calibration memory. Common messages include the last calibration date, calibration due date, or calibration contact information. You can perform this query regardless of whether the instrument is secured.

Parameter Typical Return

Quoted string of up to 128 characters "Default Calibration"

To store a cal string: CAL:STR: "Calibration must be performed in the cal lab."

CALibration:VALue? <step>

Returns the reference calibration constants of the specified step. Values are either in volts or amps, depending on the step. This allows you to query the reference calibration values before doing a new calibration to see how far the references have shifted.

54 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Parameter Typical Return

<step> number from 1- 3 calibration constant (Vor I)

Returns the calibration constant for step 1: CAL:VAL? 1

CALibration:VERification:END

Ends the verification process. This command should be used after the SENSe:VERify:AVAIlable command returns a one (1) to indicate that the calibration verification has completed.

Parameter Typical Return

(none) (none)

End channel verification: CAL:VER:END

l If an ABORt, *RST or device clear command is sent while verification is in progress, all channel settings

will revert to their default settings.

CALibration:VERification:STARt <channel>

Initiates the channel verification procedure on the specified channels.

Parameter Typical Return

<channel> the channel to verify: from 1 - 32 1

Startchannel verification: CAL:VER:STAR 1

CALibration:VERification:VOLTage <voltage> CALibration:VERification:VOLTage?

Used to enter the voltage limit for verification. All channels included in channel verification will be set to this limit.

Parameter Typical Return

<voltage> thevoltagelimitfor the activechannels <voltage>

Setthe voltage limit for channel verification: CAL:VER:VOLT4.5)

l An error is returned if the channel voltage exceeds the voltage limit.

CALibration:VERification:MEASure:INITiate <time>, <tint>

Initiates a measurement with the specified input parameters. The front panel Test light flashes orange when this command is executed.

Keysight BT2152A Operating and Service Guide 55

4 Programming Reference

Parameter Typical Return

<time> verification duration in seconds 1

<tint> between samples in seconds, from 1 to 250 1

Setthe time limitand time interval for verification: CAL:MEAS:TINT 10, 10

l The results can be returned with the FETCh commands (i.e. FETC:VOLT:LAT?, FETC:CURR:LOG?).

CALibration:WIRE:RESistance:AUTO

Runs auto-calibration of cable resistance on all 32 channels. This command takes about 18 minutes.

IMPORTANT Disconnect all LI cells from the cell cables. Short the ends of the cell cables together.

Parameter Typical Return

(none) (none)

Startwireresistancecalibration: CAL:WIRE:RES:AUTO

Wire resistance values can be retrieved using SENSe:WIRE:RESistance:CONFigure? query.

l CALibration:WIRE:RESistance:SAVE must be sent to place the values in non-volatile memory.

Flashes the Test light orange, and sets the calibration bit while running.

CALibration:WIRE:RESistance:SAVE <value>

Saves the wire resistance values to the specified file location in non-volatile memory.

IMPORTANT Wire resistance values are reset to 0 after a factory reset (*RST) and at instrument power on. If this occurs before the new calibration values are saved they will be irretrievably lost.

Parameter Typical Return

<value> resistancefile name from 1- 5 (none)

Save the wireresistance values in location 1: CAL:WIRE:RES:SAVE 1

This includes any changed values from the SENSe:WIRE:RESistance:CONFigure command.

To use the wire resistances after having performed the wire resistance calibration, a subsequent INITi-

ate:TEST:MATChed command must be performed without issuing a factory reset *RST.

56 Keysight BT2152A Operating and Service Guide

4 Programming Reference

CALibration:WIRE:RESistance:LOAD <value>

Loads the wire resistance values from the specified file location.

Parameter Typical Return

<value> resistancefile name from 1- 5 (none)

Loads the wire resistancevalues in location 1: CAL:WIRE:RES:LOAD 1

To use the wire resistances from a loaded resistance file, a subsequent INITiate:TEST:MATChed command must be performed without issuing a factory reset *RST.

CALibration:WIRE:RESistance:CLEar

Resets all the volatile wiring resistance values to 0 (zero). You must load a wire resistance file or run auto-calibration in order to use non-zero resistance values.

Parameter Typical Return

(none) (none)

Resets thewireresistancecalibration values to zero: CAL:WIRE:RES:CLE

l Turning power on and the *RST will also reset all wiring resistance values to zero.

l Values saved to non-volatile memory are not cleared.

Keysight BT2152A Operating and Service Guide 57

4 Programming Reference

Common Commands

ABORt

Aborts a measurement in progress, returning the instrument to the trigger idle state.

Parameter Typical Return

(none) (none)

Abort the measurement in progress: ABOR

*CAL?

Transfers the calibration values to the instrument channels. This calibration is automatic and can take up to 1 hour. Returns a 0 (zero) when successful, and an error code otherwise.

IMPORTANT Remove all connections from the CAL connector on the rear panel of the BT2152A before performing the channel calibration.

Parameter Typical Return

(none) 0

Initiatetransfer of calibration values to channels: *CAL?

l The unit must pass self-test, which is run at the start of channel calibration. If self-test (*TST?) does

not pass, channel calibration will abort.

The unit must be warmed up. A warm up time of 1 hour is required before the unit can be calibrated. The Ready indicator must be green, otherwise *CAL? will abort.

l If channel calibration fails, an error will be placed in the error queue with the channel number that

failed along with measurement information detailing the issue. Use SYSTem:ERRor? to read the error queue. See SCPI Error Messages for more information.

l Sets the calibration status bit.

*CLS

Clear Status Command. Clears the event registers in all register groups. Also clears the Status Byte and Error Queue. If *CLS immediately follows a program message terminator (<NL>), then the Output Queue and the MAV bit are also cleared. Refer to Status Tutorial for more information.

Parameter Typical Return

(none) (none)

Clear Event register bits, Status byte, and Error queue: *CLS

58 Keysight BT2152A Operating and Service Guide

4 Programming Reference

*IDN?

Identification Query. Returns instrument’s identification string, which contains four comma-separated fields. The first field is the manufacturer's name, the second field is the instrument model number, the third field is the serial number, and the fourth field is the firmware revision.

Parameter Typical Return

(none) <ASCII string with comma-separated fields>

Return the instrument's identification string: *IDN?

l Response format: Keysight Technologies,BTxxxxA,<serial number>,<revision codes>

l Typical return: Keysight Technologies,BT2152A,MY06009010,A.01.51-60-04-10

where:

A.01 = major firmware revision

.51 = minor firmware revision

-60 = primary FPGA revision

-04 = secondary FPGA revision

-10 = mainboard ID

*OPC?

Returns a 1 to the output buffer when all pending operations complete. The response is delayed until all pending operations such as the INIT:TEST or calibration commands complete.

Parameter Typical Return

(none) 1

Return a 1 when commands complete: *OPC?

l The purpose of this command is to synchronize your application with the instrument.

l Other commands cannot be executed until this command completes.

*RST

Reset Command Resets the instrument to pre-defined values that are either typical or safe. These settings are described in Factory Reset State.

Parameter Typical Return

(none) (none)

Reset the instrument: *RST

l *RST forces the ABORt command. This cancels any measurement actions presently occurring.

l Allow at least 4 seconds for the *RST to complete. Set the IO timeout to >4 seconds.

Keysight BT2152A Operating and Service Guide 59

4 Programming Reference

*STB?

Status byte query. Reads the Status Byte Register, which contains the status summary bits and the Output Queue MAV bit. The Status Byte is a read-only register and the bits are not cleared when it is read. Refer to Status Tutorial for more information.

Parameter Typical Return

(none) <bit value>

Read status byte: *STB?

*TST?

SelfTest Query. Performs an instrument self-test. A 0 (zero) indicates the instrument passed self-test. If self-test fails, one or more error messages will provide additional information. Use SYSTem:ERRor? to read the error queue. See SCPI Error Messages for more information.

Parameter Typical Return

(none) 0 or 1

Perform self-test: *TST?

*WAI

Pauses additional command processing until all pending operations such as the INIT:TEST commands are complete. See OPC for more information.

Parameter Typical Return

(none) (none)

Wait until all pending operations complete. *WAI

l *WAI can only be aborted by sending the instrument a Device Clear command.

60 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Digital Commands

Digital commands program the digital control port on the rear panel of the instrument. The [SOURce:] keyword is optional.

[SOURce:]DIGital:INPut:DATA?

Reads the state of the digital control port. Returns the binary-weighted value of the state of pins 1 through 7 in bits 0 through 6 respectively.

Parameter Typical Return

(none) <bit value>

Reads the stateof the digital control port: DIG:INP:DATA?

[SOURce:]DIGital:OUTPut:DATA <value> [SOURce:]DIGital:OUTPut:DATA?

Sets the state of the digital control port. This only affects the pins whose function has been set to Digital IO operation. The port has seven signal pins and a digital ground pin. In the binary-weighted value that is written to the port, the pins are controlled according to the following bit assignments:

Pin 1 2 3 4 5 6 7

Bit number 0 1 2 3 4 5 6

Decimal value 1 2 4 8 16 32 64

Bit values corresponding to digital port pins that are not configured as DIO are ignored.

Parameter Typical Return

0 – 127, *RST 0 <bit value>

Programs pins 1, 3, and 5 on: DIG:OUTP:DATA?

[SOURce:]DIGital:PIN<1-7>:FUNCtion <function> [SOURce:]DIGital:PIN<1-7>:FUNCtion?

Sets the pin function. The functions are saved in non-volatile memory.

DIO Digital input/output mode

DINPut Digital input-only mode.

FAULt Pin 1 functions as an isolated fault output. Pin 2 is common for pin 1

INHibit Pin 3 functions as an inhibit input.

Keysight BT2152A Operating and Service Guide 61

4 Programming Reference

Parameter Typical Return

DIO | DINPut | FAULt| INHibit DIO, DINP, FAUL, INH

Sets pin 1 to FAULtmode: DIG:PIN1:FUNC FAUL

[SOURce:]DIGital:PIN<1-7>:POLarity POSitive|NEGative [SOURce:]DIGital:PIN<1-7>:POLarity?

Sets the pin polarity. POSitive means a logical true signal is a voltage high at the pin. For trigger inputs and outputs, POSitive means a rising edge. NEGative means a logical true signal is a voltage low at the pin. For trigger inputs and outputs, NEGative means a falling edge. The pin polarities are saved in non-volatile memory.

Parameter Typical Return

POSitive|NEGative POS or NEG

Sets pin 1 to POSitive polarity: DIG:PIN1:POL POS

62 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Fetch Commands

Fetch commands return measurement data that has been acquired once a test has been started using the INITiate:TEST commands. They also return measurement data from an external thermistor connected to the rear panel TEMP input.

FETCh:CURRent:LATest? (@<chanlist>) FETCh:VOLTage:LATest? (@<chanlist>)

Returns the most recent measurement for the specified channels in ASCii.

Parameter Typical Return

(none) Comma-separated values

from specified channels

<chanlist> activechannels from 1 - 32 (none)

Returns the latestcurrent measurement: FETC:CURR:LAT? (@1:32) Returns the latestvoltage measurement: FETC:VOLT:LAT?(@1:32)

l The FETCh? query does not erase measurements from the reading memory. You can send the query

multiple times to retrieve the same data. 8192 is the maximum number of ASCii values that can be returned in any one call.

l The instrument clears all measurements from reading memory whenever INIT is executed.

l If INITiate:TEST:MATChed hasbeen configured for a different channel group than the channel group

specified in this command, non-active channels will return +9.91000000e37 (not a number).

FETCh:CURRent:LOG? <values/chan> [,<offset/chan>], (@<chanlist>) FETCh:VOLTage:LOG? <values/chan> [,<offset/chan>], (@<chanlist>)

Returns the current or voltage measurement log for the specified channels in ASCii.

Parameter Typical Return

<values/chan> number of readings returned per channel Multiple comma-separated

values from specified channels

<offset/chan> optional value thatoffsets or skips the number of readings returned from the beginning of the datalog

<chanlist> activechannels from 1 - 32 (none)

(none)

Returns 10 current readings per channel: FETC:CURR:LOG? 10, (@1:32) Returns 10 voltage readings per channel: FETC:VOLT:LOG? 10, (@1:32)

l The readings are returned sequentially in channel groups (i.e. x,x,x,x,x,x,x,x, y,y,y,y,y,y,y,y, ….)

Where x represents all measurements for channel 1, y represents all measurements for channel 2 etc.

Keysight BT2152A Operating and Service Guide 63

4 Programming Reference

l The <values/chan> parameter specifies the number of readings. So, for example, if (@1:4) is the spe-

cified channel list and values/chan is specified as 10, a total of 40 values will be returned.

l If an <offset/chan> value of 5 had been specified, the first 5 readings in each channel log would not

have be returned.

l The FETCh? query does not erase measurements from the reading memory. You can send the query

multiple times to retrieve the same data. 8192 is the maximum number of ASCii values that can be returned in any one call.

l Use FETCh:CURRent:LOG:POINts? or FETCh:VOLTage:LOG:POINts? to query how many meas-

urement points are available.

l The instrument clears all measurements from reading memory whenever INIT is executed.

l If INITiate:TEST:MATChed hasbeen configured for a different channel group than the channel group

specified in this command, non-active channels will return +9.91000000e37 (not a number).

FETCh:CURRent:LOG:BINary? <values/chan> (@<chanlist>) FETCh:VOLTage:LOG:BINary? <values/chan> (@<chanlist>)

Returns the current or voltage measurement log for the specified channels in binary. These commands allow you to return all the data instead of being limited to 8192 values like ASCii readings. Use the FORMat:BORDer command to format the binary data.

Parameter Typical Return

<values/chan> number of readings returned per channel <binary data string>

<chanlist> activechannels from 1 - 32 (none)

Returns 10 current readings per channel in binary: FETC:CURR:LOG:BIN? 10, (@1:32) Returns 10 voltage readings per channel in binary: FETC:VOLT:LOG:BIN? 10, (@1:32)

l The readings are returned sequentially in channel groups (i.e. xxxxxxxxyyyyyyyy ….)

Where x represents all measurements for channel 1, y represents all measurements for channel 2 etc. Each data point takes up 64 bits. The values returned are 64-bit floating point numbers.

l The <values/chan> parameter specifies the number of readings. So, for example, if (@1:4) is the spe-

cified channel list and values/chan is specified as 10, a total of 40 values will be returned.

l The FETCh? query does not erase measurements from the reading memory.

l Use FETCh:CURRent:LOG:POINts? or FETCh:VOLTage:LOG:POINts? to query how many meas-

urement points are available.

l The instrument clears all measurements from reading memory whenever INIT is executed.

l If INITiate:TEST:MATChed hasbeen configured for a different channel group than the channel group

specified in this command, non-active channels will return +9.91000000e37 (not a number).

64 Keysight BT2152A Operating and Service Guide

4 Programming Reference

FETCh:CURRent:LOG:POINts? FETCh:VOLTage:LOG:POINts?

Returns the number of readings available per channel of the active channels specified in the INIT command.

Parameter Typical Return

(none) 4020

Returns the number of current readings available: FETC:CURR:LOG:POIN? Returns the number of voltage readings available: FETC:VOLT:LOG:POIN?

l If you attempt to return more readings than are available, an error will be generated. You must include

any offset/chan values in the total number of readings available.

FETCh:PROBecheck? (@<chanlist>)

Returns the boolean results of the probe check test.

Parameter Typical Return

(none) Comma-separated boolean values

for the specified channels

0 indicates acell is NOT present

1 indicates acell is present

<chanlist> activechannels from 1 - 32 (none)

Returns the probe checkresults for channels 1-32: FETC:PROB? (@1:32)

l If INITiate:TEST has been configured for a different channel group than the channel group specified in

this command, non-active channels will return 0.

FETCh:TEMPerature:LATest?

Returns the most recent temperature of the external thermistor connected to the rear panel TEMP input (see Rear View).

Parameter Typical Return

(none) Comma-separatedvalues

from specified channels

Returns the latestexternal temperature: FETC:TEMP:LAT?

Same as SYSTem:TEMPerature? EXTernal

l The FETCh? query does not erase measurements from the reading memory. You can send the query

multiple times to retrieve the same data. 8192 is the maximum number of ASCii values that can be returned in any one call.

l The instrument clears all measurements from reading memory whenever INIT is executed.

Keysight BT2152A Operating and Service Guide 65

4 Programming Reference

FETCh:TEMPerature:LOG? <values> [,<offset>]

Returns the temperature measurement log of the external thermistor in ASCii.

Parameter Typical Return

<values> the number of reading to return Multiple comma-separated values

<offset> optional value that offsets or skips the number of readings returned from the beginning of the data log

Skips 5, then returns the next 10 temperature readings: FETC:TEMP:LOG? 10, 5

l The FETCh? query does not erase measurements from the reading memory. You can send the query

(none)

multiple times to retrieve the same data. 8192 is the maximum number of ASCii values that can be returned in any one call.

l Use FETCh:TEMP:LOG:POINts? to query how many measurement points are available.

l The instrument clears all measurements from reading memory whenever INIT is executed.

FETCh:TEMPerature:LOG:BINary? <values>

Returns the temperature measurement log of the external thermistor in binary. This command allows you to return all the data instead of being limited to 8192 values like ASCii readings. Use the

FORMat:BORDer command to format the binary data.

Parameter Typical Return

<values> number of reading to return <binary data string>

Returns 10 temperature readings in binary: FETC:TEMP:LOG:BIN? 10

l Each data point (value) takes up 64 bits. The values returned are 64-bit floating point numbers.

l The FETCh? query does not erase measurements from the reading memory.

l Use FETCh:TEMP:LOG:POINts? to query how many measurement points are available.

l The instrument clears all measurements from reading memory whenever INIT is executed.

FETCh:TEMPerature:LOG:POINts?

Returns the number of readings available in the temperature measurement log of the external thermistor.

Parameter Typical Return

(none) 4020

Returns the number of temperature readings available: FETC:TEMP:LOG:POIN?

l If you attempt to return more readings than are available, an error will be generated. You must include

any offset values in the total number of readings available.

66 Keysight BT2152A Operating and Service Guide

4 Programming Reference

FETCh:VOLTage:OCV? (@<chanlist>)

Retrieves the open-circuit voltage (OCV) values. This command is only applicable when used in conjunction with the INITiate:TEST:OCV command.

Parameter Typical Return

(none) Comma-separated OCV values

for the specified channels

<chanlist> activechannels from 1 - 32 (none)

Returns the OCV values atthe startof the test: FETC:VOLT:OCV? (@1:32)

l If INITiate:TEST:MATChed hasbeen configured for a different channel group than the channel group

specified in this command, non-active channels will return +9.91000000e37 (not a number).

Keysight BT2152A Operating and Service Guide 67

4 Programming Reference

Format Command

FORMat:BORDer NORMal|SWAPped FORMat:BORDer?

Used for binary block transfers only. Selects the byte order for binary block transfers using FETCh?

Parameter Typical Return

NORMal|SWAPped; Default: SWAP SWAP

Selectthe normal byte order: FORM:BORD NORM

l In the NORMal byte order, the most-significant byte (MSB) of each data point is returned first and the

least significant byte is returned last.

l In the SWAPped byte order the least-significant byte (LSB) of each data point is returned first and the

most significant byte is returned last.

l The byte order setting is stored in non-volatile memory and does not change when power has been

off. The default value is restored after a reset (*RST).

l The most common setting for this command isSWAPped.

68 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Initiate Commands

These commands initialize and start the discharge test.

You can only execute one INIT:TEST at a time. For example, you cannot run INIT:TEST:OCV on channel 1 while running INIT:TEST:MATCH on channel 2.

INITiate:TEST:MATChed<time>, <ovp>, <uvp>, <res>[,<tint>[,<curr>[,<ocp>]]],

(@<chanlist>)

INITiate:TEST:MATChed? (@<chanlist>)

Sets all parameters for the voltage matched discharge current measurement. The query form returns the present INIT:TEST:MATC parameters for each channel in the list.

Parameter Typical Return

<time> test duration in minutes (seetime interval between samples) 5

<ovp> over-voltage protection in volts: from 0.5 V to 4.5 V; resolution: 0.1 mV 4.0

<uvp> under-voltageprotection in volts: from 0.5 V to 4.5 V; resolution: 0.1 mV 3.0

<res> output resistancein ohms: from 0.1 Ω to 10 Ω; resolution: 0.001 Ω 1.0

optional <tint>time interval between samples in seconds: from 1 to 250 1

optional <curr> initial cell current in amperes: from -10 mA to +10 mA; resolution: 0.1 μA 0.001

optional <ocp> over-current protection in amperes: from -10 mA to +10 mA; resolution: 0.1 μA 0.01

<chanlist> activechannels: from 1 - 32 (none)

Configures channels 1:16 for a 6 hour test with OVPset to 4.2V, UVP setto 1.8V, output resistance 9 Ω , time interval 2s, initial cell current 0.5mA, over-current protect1mA: INIT:TEST:MATC 360, 4.2, 1.8, 9, 2, 0.0005, 0.001, (@1:16)

Time Interval Parameter

The time interval <tint> parameter lets you specify an average time or time-between-samples where the samples are averaged to return a single value. The range is from 1 to 250 seconds. The default time interval is 1 second. The following table describes maximum test times for some typical time intervals. To calculate the maximum test time in hours use Hours=(<tint> * 72)

Timeinterval Maximum test time

1 second (default) 3 days

10 seconds 30 days

60 seconds 180 days

250 seconds 750 days

Keysight BT2152A Operating and Service Guide 69

4 Programming Reference

The following table gives the rate at which data can be returned based on the specified time interval

Timeinterval

in seconds

1 - 4 4

5-8 8

9- 16 16

17-32 32

33-64 64

65-128 128

129-250 256

Dataupdaterate

in seconds

INITiate:TEST:OCV <ovp>, <uvp>, <ocp>, <tint>, (@<chanlist>) INITiate:TEST:OCV? (@<chanlist>)

Initiates an open-circuit voltage test. The results can be retrieved with FETCh:VOLTage:OCV?. The query form returns the present INIT:TEST:OCV parameters for each channel in the list.

Parameter Typical Return

<ovp> over-voltage protection in volts: from 0.5 V to 4.5 V; resolution: 0.1 mV 4.0

<uvp> under-voltageprotection in volts: from 0.5 V to 4.5 V; resolution: 0.1 mV 3.0

<ocp> over-current protection in amperes: from -10 mA to +10 mA; resolution: 0.1 μA 0.01

<tint> time interval between samples in seconds: from 1 to 250 1

<chanlist> activechannels: from 1 - 32 (none)

Configures channels 1:16 for an open-circuitvoltagetest with OVPset to 4.2V, UVP setto 1.8V, over-current protect1mA, and timeinterval 2s: INIT:TEST:OCV 4.2, 1.8, 0.001, 2, (@1:16)

INITiate:TEST:PROBecheck (@<chanlist>)

Initiates a probe check test to determine if a cell is connected to the specified channels in the channel list. Send FETCh:PROBecheck? to return the results of the probe check. Send

SENSe:PROBecheck:AVAIlable? to check whether a probe check test has completed.

Parameter Typical Return

(none) (none)

Initiatea probe checktest on 16 channels: INIT:TEST:PROB (@1:16)

70 Keysight BT2152A Operating and Service Guide

4 Programming Reference

LXI Command

LXI:IDENtify[:STATe] 0|OFF|1|ON LXI:IDENtify[:STATe]?

Turns the front panel LXI identify indicator on or off. When turned on, the "LAN" status indicator on the front panel blinks on and off to identify the instrument that is being addressed.

Parameter Typical Return

0|OFF|1|ON 0or1

To blink the front panel LXI indicator: LXI:IDENT ON

Keysight BT2152A Operating and Service Guide 71

4 Programming Reference

Output Commands

OUTPut:INHibit:MODE LATChing|LIVE|OFF OUTPut:INHibit:MODE?

Sets the operating mode of the Inhibit Input digital pin (pin 3). The inhibit function disconnects or connects the input channels in response to an external signal on the Inhibit input pin. See Using the

Digital Port.

LATChing - a logic-true signal on the Inhibit input causes the input channels to disconnect. The channels remain disconnected until the Inhibit input is returned to logic-false and the latched INH status bit is cleared by sending the OUTPut:PROTection:CLEar command.

LIVE - allows the input channels to follow the state of the Inhibit input. When the Inhibit input is true, the channels are disconnected. When the Inhibit input is false, the channels are re-connected.

OFF - The Inhibit input is ignored.

Parameter Typical Return

LATChing|LIVE|OFF; *RSTOFF LATC, LIVE, or OFF

Sets the Inhibit Input to Live mode: OUTP:INH:MODE LIVE

OUTPut:PROTection:CLEar

Resets any protection events that have occurred. The protection settings are specified in the

INIT:TEST commands.

Parameter Typical Return

(none) (none)

Clear instrument protection: OUTP:PROT:CLE

72 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Sense Commands

SENSe:OCV:AVAIlable?

Returns the availability of the open-circuit voltage measurement. This command is only applicable when used in conjunction with the INITiate:TEST:OCV command.

A one (1) is returned when the OCV measurement is completed. A zero (0) is returned when the OCV measurement is unavailable or if the command was used with any other INIT command besides INITiate:TEST:OCV.

Parameter Typical Return

(none) 0 or 1

Returns the availability of OCV : SENS:OCV:AVAI?

SENSe:PROBecheck:AVAIlable?

Returns the availability of the probe check test.

A one (1) is returned when the probe check command is completed. A zero (0)is returned when the probe check command is unavailable.

Parameter Typical Return

(none) 0or 1

Returns the availability of the Probe checktest: SENS:PROB:AVAI?

SENSe:THERmistor:CONFigure <temp>, <resistance>, <beta> SENSe:THERmistor:CONFigure?

Specifies the parameters for the external thermistor connected to the rear panel temperature sensor input (see Thermistor Connections).

Parameter Typical Return

<temp> the nominal temperature of the thermistor in degrees C, from -272.15° C to 273.15° C 25° C

<resistance> thenominal resistancein ohms, from 1 Ω to 1,000,000 Ω 10,000

<beta> value from 1 to 1,000,000 4073

Specifies the nominal temperature and resistance: SENS:THER:CONF 25, 10000, 4073

Keysight BT2152A Operating and Service Guide 73

4 Programming Reference

SENSe:TTIMe:REMaining?

Returns the remaining test time in minutes for the test that is presently running.

Parameter Typical Return

(none) 2.200000E+02

Returns the remaining testtime: SENS:TTIM:REM?

SENSe:VERification:AVAIlable?

Returns the state of the verification procedure. A one (1) is returned when the verification procedure is completed. A zero (0) is returned when the verification is in progress.

Parameter Typical Return

(none) 0or 1

Returns the stateof the verification procedure: SENS:VER:AVAI?

SENSe:WIRE:RESistance:AVAIlable?

Returns the state of the wire resistance calibration. A one (1) is returned when the wire resistance calibration is completed and the wire resistance values are available. A zero (0) is returned when the calibration is in progress.

Parameter Typical Return

(none) 0or 1

Returns the stateof the wire resistance calibration: SENS:WIRE:RES:AVAI?

SENSe:WIRE:RESistance:CONFigure <resistance>, (@<chanlist>) SENSe:WIRE:RESistance:CONFigure? (@<chanlist>)

Specifies the resistance of the wiring of each channel. Refer to Wire resistance calibration for moere information.

Parameter Typical Return

<resistance> theresistance of the wire in ohms, from 0 Ω to 5 Ω; resolution: 0.001 Ω; Default: 0

<chanlist> activechannels from 1 - 32 (none)

Specifies a wire resistanceof 0.188 Ω for channel 1: SENS:WIRE:RES:CONF 0.188, (@1)

Wire resistance calibration is required when all RJ45 connectors have been installed in the

instrument. Wire resistance calibration is also required whenever any RJ45 connector is unplugged, reinserted, or reseated.

74 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Status Commands

Status commands let you determine the operating condition of the instrument at any time. Refer to

Status Tutorial for more information.

STATus:ALARm[EVENt]?

Returns the sum of the bits in the event register for the Status Alarm Register group. An event register is a read-only register that latches events from the condition register. While an event bit is set, subsequent events corresponding to that bit are ignored. The register bits are cleared when you read the register.

Parameter Typical Return

(none) <bit value>

Read theevent alarm register: STAT:ALAR?

l Once a bit is set, it remains set until cleared by reading the event register or by sending *CLS (clear

status).

l The value returned is the binary-weighted sum of all bits set in the register.

STATus:ALARm:CONDiton?

Returns the sum of the bits in the condition register for the Status Alarm Register group. Condition register bits are updated in real time; they are neither latched nor buffered. This register is read-only; bits are not cleared when read. The alarm status group consists of the OVP, UVP, and OCP status bits in the Status Questionable registers.

Parameter Typical Return

(none) <bit value>

Read theevent alarm register: STAT:ALAR:COND?

l The condition register bits reflect the current condition. If a condition goes away, the corresponding

bit is cleared in the condition register.

l The value returned is the binary-weighted sum of all bits set in the register.

STATus:ALARm:ENABle <value> STATus:ALARm:ENABle?

Enables bits in the condition register for the Status Alarm Register group. The selected bits are then reported to the Status Byte. An enable register defines which bits in the event register will be reported to the Status Byte register group. You can write to or read from an enable register.

Keysight BT2152A Operating and Service Guide 75

4 Programming Reference

Parameter Typical Return

A decimal value thatcorresponds to the binaryweighted sum of thebits in theregister.

Enable bits1, 2, and 8 in the enable register: STAT:ALAR:ENAB 259

l Use the <value> parameter to specify which bits will be reported to the Status Byte. The decimal value

+259 (bit 1, 2 and 8 set)

specified corresponds to the binary-weighted sum of the bits you wish to enable in the register.

l The enable setting value is stored in nonvolatile memory.

STATus:ALARm:CONDiton:CURRent?

Returns the sum of the bits feeding the over-current (OCP) condition bit in the Status Alarm Register group. This is a 32-bit unsigned value, where each bit represents one channel. Channel 1 is represented by bit 0; channel 32 by bit 31.

Parameter Typical Return

(none) <bit value>

Read theevent alarm register: STAT:ALAR:COND:CURR?

l The condition register bits reflect the current condition. If a condition goes away, the corresponding

bit is cleared in the condition register.

l The value returned is the binary-weighted sum of all bits set in the register.

STATus:ALARm:CONDiton:VOLTage?

Returns the sum of the bits feeding the over-voltage (OVP) condition bit in the Status Alarm Register group. This is a 32-bit unsigned value, where each bit represents one channel. Channel 1 is represented by bit 0; channel 32 by bit 31.

Parameter Typical Return

(none) <bit value>

Read theevent alarm register: STAT:ALAR:COND:VOLT?

l The condition register bits reflect the current condition. If a condition goes away, the corresponding

bit is cleared in the condition register.

l The value returned is the binary-weighted sum of all bits set in the register.

STATus:ALARm:CONDiton:VOLTage:UNDer?

Returns the sum of the bits feeding the under-voltage (UVP) condition bit in the Status Alarm Register group. This is a 32-bit unsigned value, where each bit represents one channel. Channel 1 is represented by bit 0; channel 32 by bit 31.

76 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Parameter Typical Return

(none) <bit value>

Read theevent alarm register: STAT:ALAR:COND:VOLT:UND?

l The condition register bits reflect the current condition. If a condition goes away, the corresponding

bit is cleared in the condition register.

l The value returned is the binary-weighted sum of all bits set in the register.

STATus:ALARm:ENABle <value> STATus:ALARm:ENABle?

Parameter Typical Return

A decimal value thatcorresponds to the binaryweighted sum of thebits in theregister.

Enable bit4 (value 16) in the enable register: STAT:ALAR:ENAB 16

l Use the <value> parameter to specify which bits will be reported to the Status Byte. The decimal value

+16 (bit 4 set)

specified corresponds to the binary-weighted sum of the bits you wish to enable in the register. For example, to enable bit 4 (decimal value = 16) and bit 8 (decimal value = 256), the corresponding decimal value would be 272 (16 + 256).

l The enable setting value is stored in nonvolatile memory.

STATus:OPERation[:EVENt]?

Returns the sum of the bits in the event register for the Standard Operation Register group. An event register is a read-only register that latches events from the condition register. While an event bit is set, subsequent events corresponding to that bit are ignored. The register bits are cleared when you read the register.

Parameter Typical Return

(none) <bit value>

Read theoperation eventstatus register: STAT:OPER?

l Once a bit is set, it remains set until cleared by reading the event register or by sending *CLS (clear

status).

l The value returned is the binary-weighted sum of all bits set in the register.

Keysight BT2152A Operating and Service Guide 77

4 Programming Reference

STATus:OPERation:CONDition?

Returns the sum of the bits in the condition register for the Standard Operation Register group. This register is read-only; bits are not cleared when read.

A condition register continuously monitors the state of the instrument. Condition register bits are updated in real time; they are neither latched nor buffered

Parameter Typical Return

(none) <bit value>

Read theoperation status condition register: STAT:OPER:COND?

l The condition register bits reflect the current condition. If a condition goes away, the corresponding

bit is cleared.

l The value returned is the binary-weighted sum of all bits set in the register.

STATus:OPERation:ENABle <value> STATus:OPERation:ENABle?

Sets and queries bits in the enable register for the Standard Operation Register group. The enable register is a mask for enabling specific bits from the Operation Event register to set the OPER (operation summary) bit of the Status Byte register. STATus:PRESet clears all bits in the enable register.

Parameter Typical Return

A decimal value thatcorresponds to the binaryweighted sum of thebits in theregister.

Enable bit4 in theenable register: STAT:OPER:ENAB 16

*CLS does not clear the enable register, but does clear the event register.

+16 (bit 4 set)

78 Keysight BT2152A Operating and Service Guide

4 Programming Reference

System Commands

SYSTem:COMMunicate:ENABle 0|OFF|1|ON, <interface> SYSTem:COMMunicate:ENABle? <interface>

Disables or enables the USB or LAN interface. You must cycle power for the changes to take effect.

Parameter Typical Return

0|OFF|1|ON Default: ON for all interfaces 0or1

<interface>USB|LAN (none)

Disable theUSB interface: SYST:COMM:ENAB OFF,USB

l If you disable the LAN interface, none of the associated LAN services will start at power-on.

l The interface enable settings are stored in nonvolatile memory.

SYSTem:COMMunicate:LAN:CONTrol?

Returns the initial socket control connection port number. This connection is used to send and receive commands and queries.

Parameter Typical Return

(none) <port #>

(0 if sockets not supported)

Query the Control connection port number: SYST:COMM:LAN:CONT?

l Use the Control socket connection to send a Device Clear (DCL) to the instrument or to detect

pending Service Request (SRQ) events.

SYSTem:COMMunicate:LAN:DHCP 0|OFF|1|ON SYSTem:COMMunicate:LAN:DHCP?

Disables or enables instrument's use of DHCP. DHCP stands for Dynamic Host Configuration Protocol, a protocol for assigning dynamic IP addresses to networked devices. With dynamic addressing, a device can have a different IP address every time it connects to the network.

ON - the instrument tries to obtain an IP address from a DHCP server. If a DHCP server is found, it assigns a dynamic IP address, Subnet Mask, and Default Gateway to the instrument.

OFF or DHCP unavailable - the instrument uses the static IP address, Subnet Mask, and Default Gateway during power-on.

Parameter Typical Return

0|OFF|1|ON, Default: ON 0or1

Disable DHCP: SYST:COMM:LAN:DHCP OFF

Keysight BT2152A Operating and Service Guide 79

4 Programming Reference

l If a DHCP LAN address is not assigned by a DHCP server, then an Auto-IP address is obtained after

approximately 2 minutes. An Auto-IP addresshas the form 169.254.nnn.nnn.

l The DHCP setting is stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:COMMunicate:LAN:DNS[1|2] "<address>" SYSTem:COMMunicate:LAN:DNS[1|2]? [CURRent|STATic]

Assigns the static IP addresses of Domain Name System (DNS) servers. A primary and a secondary server address may be assigned. If DHCP is available and enabled, DHCP will auto-assign these server addresses. These auto-assigned server addresses take precedence over the static addresses assigned with this command. Contact your LAN administrator for details.

The optional query CURRent parameter returns the address currently being used by the instrument. The optional query STATic parameter returns the static address from non-volatile memory. This address is used if DHCP is disabled or unavailable.

Parameter Typical Return

Command: "nnn.nnn.nnn.nnn". Default: "0.0.0.0".

Query: [CURRent|STATic]. Default: CURRent "198.105.232.4"

To seta static primary DNS address: SYST:COMM:LAN:DNS "198.105.232.4"

l The assigned DNS server addresses are used if DHCP is disabled or unavailable. Otherwise, the DNS

(none)

server addresses are auto-assigned by DHCP.

l The DNS server addresses are stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:COMMunicate:LAN:DOMain?

Returns the domain name assigned to the instrument.

Parameter Typical Return

(none) "example.com"

Return the domain name used by the instrument: SYST:COMM:LAN:DOM?

l If Dynamic Domain Name System (DNS) is available on your network and your instrument uses DHCP,

the domain name is assigned by the Dynamic DNS service at power-on.

l A null string ("") indicates that no domain name is assigned.

80 Keysight BT2152A Operating and Service Guide

4 Programming Reference

SYSTem:COMMunicate:LAN:GATeway "<address>" SYSTem:COMMunicate:LAN:GATeway? [CURRent|STATic]

Assigns a default gateway for the instrument. The specified IP Address sets the default gateway, which allows the instrument to communicate with systems that are not on the local subnet. Thus, this is the default gateway where packets are sent that are destined for a device not on the local subnet, as determined by the Subnet Mask setting. Contact your LAN administrator for details.

Parameter Typical Return

Command: "nnn.nnn.nnn.nnn". Default: "0.0.0.0". (none)

Query: [CURRent|STATic]. Default: CURRent "198.105.232.1"

To seta static primary DNS address: SYST:COMM:LAN:GAT "198.105.232.1"

l If DHCP is enabled, the specified default gateway is not used. However, if the DHCP server fails to

assign a valid IP address, the currently configured default gateway is used.

l The gateway address is stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:COMMunicate:LAN:HOSTname "<name>" SYSTem:COMMunicate:LAN:HOSTname? [CURRent|STATic]

Assigns a hostname to the instrument. A hostname is the host portion of the domain name, which is translated into an IP address. If Dynamic Domain Name System (Dynamic DNS) is available on your network and your instrument uses DHCP, the hostname is registered with the Dynamic DNS service at power-on. If DHCP is enabled, the DHCP server can change the specified hostname. Contact your LAN administrator for details.

The optional query CURRent parameter returns the name currently being used by the instrument. The optional query STATic parameter returns the name from non-volatile memory. This may not be the actual name used by the instrument if DHCP is enabled.

Parameter Typical Return

String of up to 15 characters. Must startwithletter (A-Z) May contain letters, numbers (0-9), or dashes ("-").

Query: [CURRent|STATic]. Default: CURRent "Keysight BT2152A"

To definea hostname: SYST:COMM:LAN:HOST"Keysight BT2152A "

(none)

Keysight BT2152A Operating and Service Guide 81

4 Programming Reference

l If no hostname exists, the query returns a null string ("").

l The hostname is stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:COMMunicate:LAN:IPADdress "<address>" SYSTem:COMMunicate:LAN:IPADdress? [CURRent|STATic]

Assigns a static Internet Protocol (IP) address for the instrument. If DHCP is enabled, the specified static IP address is not used. Contact your LAN administrator for details.

Parameter Typical Return

Command: "nnn.nnn.nnn.nnn". (none)

Query: [CURRent|STATic]. Default: CURRent "169.254.149.35"

To seta static IPaddress: SYST:COMM:LAN:IPAD "169.254.149.35"

l The IP address is stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:COMMunicate:LAN:MAC?

Returns the instrument's Media Access Control (MAC) address as an ASCII string of 12 hexadecimal characters (0-9 and A-F) enclosed in quotation marks.

Parameter Typical Return

(none) "0030D3001041"

To return the MAC address: SYST:COMM:LAN:MAC?

l The MAC address is also known as the link-layer address, the Ethernet (station) address, LANIC ID or

Hardware Address. This is an unchangeable 48-bit address assigned by the manufacturer to each unique Internet device.

Your LAN administrator may need the MAC address to assign a static IP address for this device.

82 Keysight BT2152A Operating and Service Guide

4 Programming Reference

SYSTem:COMMunicate:LAN:SMASk "<mask>" SYSTem:COMMunicate:LAN:SMASk? [CURRent|STATic]

Assigns a subnet mask for the instrument to use in determining whether a client IP address is on the same local subnet. When a client IP address is on a different subnet, all packets must be sent to the Default Gateway. Contact your LAN administrator for details.

Parameter Typical Return

Command: "nnn.nnn.nnn.nnn". Default: "255.255.0.0". (none)

Query: [CURRent|STATic]. Default: CURRent "255.255.0.0"

To seta subnet mask: SYST:COMM:LAN:IPAD "255.255.0.0"

l If DHCP is enabled (SYSTem:COMMunicate:LAN:DHCP ON), the specified subnet mask is not used.

However, if the DHCP server fails to assign a valid IP address, the instrument uses the Auto-IP subnet mask.

l A value of "0.0.0.0" or "255.255.255.255" indicates that subnetting is not being used.

l The subnet mask setting is stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:COMMunicate:LAN:TELNet:PROMpt "<string>" SYSTem:COMMunicate:LAN:TELNet:PROMpt?

Specifies the command prompt seen when communicating with the instrument via Telnet.

Parameter Typical Return

Quoted string of up to 15 characters. Default: "BT2152A".

To seta command prompt: SYST:COMM:LAN:TELN:PROM "BT2152A"

l The instrument uses LAN port 5024 for SCPI Telnet sessions and port 5025 for SCPI Socket sessions.

l Telnet sessions are typically started from a host computer shell (telnet <IP_address> <port>).

For example: telnet 169.254.4.10 5024 To exit a Telnet session, press<Ctrl-D>.

"BT2152A"

l This setting isstored in non-volatile memory.

Keysight BT2152A Operating and Service Guide 83

4 Programming Reference

SYSTem:COMMunicate:LAN:TELNet:WMESsage "<string>" SYSTem:COMMunicate:LAN:TELNet:WMESsage?

Specifies the welcome message seen when communicating with the instrument via Telnet.

Parameter Typical Return

Quoted string of up to 63 characters. Default: "Welcome to theTelnet Session".

To seta command prompt: SYST:COMM:LAN:TELN:WMES "Welcome to the TelnetSession"

l The instrument uses LAN port 5024 for SCPI Telnet sessions and port 5025 for SCPI Socket sessions.

l This setting isstored in non-volatile memory.

"Welcome to theTelnet Session"

SYSTem:COMMunicate:LAN:UPDate

Stores any changes made to the LAN settings into non-volatile memory and restarts the LAN driver with the updated settings.

Parameter Typical Return

(none) (none)

The following configures theinstrument to use statically assigned LAN settings: SYST:COMM:LAN:DHCP OFF SYST:COMM:LAN:DNS "198.105.232.4" SYST:COMM:LAN:DNS2 "198.105.232.5" SYST:COMM:LAN:GAT "198.105.232.1" SYST:COMM:LAN:HOST "LAB1-DMM" SYST:COMM:LAN:IPAD "198.105.232.101" SYST:COMM:LAN:SMAS "255.255.255.0" SYST:COMM:LAN:WINS "198.105.232.4" SYST:COMM:LAN:WINS "198.105.232.5" SYST:COMM:LAN:UPD

The following configures theinstrument back to use DHCP: SYST:COMM:LAN:DHCP ON

SYST:COMM:LAN:UPD

l This command must be sent after changing the settings for DHCP, DNS, gateway, hostname, IP

address, subnet mask, or WINS.

l Make all changes to the LAN settings before sending this command.

SYSTem:COMMunicate:LAN:WINS[1|2] "<address>" SYSTem:COMMunicate:LAN:WINS[1|2]? [CURRent|STATic]

Assigns the static IP addresses of the Windows Internet Name System (WINS) servers. A primary and a secondary server address may be assigned. If DHCP is available and enabled, DHCP will autoassign these server addresses. These auto-assigned server addresses take precedence over the static addresses assigned with this command. Contact your LAN administrator for details.

84 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Parameter Typical Return

Command: "nnn.nnn.nnn.nnn". Default: "0.0.0.0". (none)

Query: [CURRent|STATic]. Default: CURRent "198.105.232.4"

To seta static primary WINSaddress: SYST:COMM:LAN:DNS "198.105.232.4"

l The WINS addresses are stored in non-volatile memory.

If you change this setting, you must send SYSTem:COMMunicate:LAN:UPDate to activate the new setting.

SYSTem:DATE <yyyy>, <mm>, <dd> SYSTem:DATE? SYSTem:TIME <hh>, <mm>, <ss> SYSTem:TIME?

SYSTem:DATE -Sets the date of the system clock. Specify the year (2000 to 2099), month (1 to 12), and day (1 to 31).

SYSTem:TIME -Sets the time of the system clock. Specify hours (0 to 23), minutes (0 to 59), and seconds (0 to 59).

Parameter Typical Return

<yyyy>,<mm>,<dd> +2017,+06,+30

<hh>,<mm>,<ss> 20,30,00.000

Setthe dateto June 30, 2017: SYST:DATE 2017,06,30 Setthe clock to 8:30 PM: SYST:TIME 20,30,0

l The real-time clock does not adjust itself for time zone changes or daylight savings time.

SYSTem:ERRor?

Reads and clears one error from the error queue.

Parameter Typical Return

(none) +0,"No error"

Reads and clears the firsterror in error queue: SYST:ERR?

Keysight BT2152A Operating and Service Guide 85

4 Programming Reference

l Error retrieval is first-in-first-out (FIFO), and errors are cleared asyou read them.

l If more have accumulated than the queue can hold, the last error stored in the queue (the most recent

error) is replaced with -350,"Error queue overflow". No additional errors are stored until you remove errors from the queue. If no errors have occurred when you read the error queue, the instrument responds with +0,"No error".

l The error queue is cleared when power is cycled. It is not cleared by a *RST.

l Errors have the following format (the error string may contain up to 80 characters).

<error code>,<error string> For a list of error codes and message strings, see SCPI Error Messages.

SYSTem:TEMPerature? EXTernal

Returns the temperature sensed across a 10 kΩ thermistor, which must be connected to the rear panel TEMP input in °C (see Rear View).

Parameter Typical Return

EXTernal +2.41923802E+001

Return the temperature of the external thermistor: SYST:TEMP? EXT

Same as FETCh:TEMPerature:LATest?

l If nothing is connected to the external temperature connector, the command will return 9.91E37.

86 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Status Tutorial

Status Registers

Alarm Channel Groups

Alarm Status Group

Standard Operation Group

Status Byte Register

Error and Output Queues

Status Diagram

This section provides a detailed description of the individual registers and register groups. The status diagram at the end of this topic shows how the status registers and groups are interconnected.

Status Registers

The Alarm Channle, Alarm Status, and Standard Operation groups use three different type of registers to track qualify, flag, and enable instrument events.

l A Condition register continuously monitors the state of the instrument. The bits in the condition

l An Event register latches the various events from the condition register. There is no buffering in this

register; while an event bit is set, subsequent events corresponding to that bit are ignored. Thisis a read-only register.

l An Enable register defines which bits in the event register will be reported to the Status Byte register

group. You can write to or read from an enable register.

To program individual bits in any register group, you must send a value that corresponds to the binaryweighted value of all the bits that you wish to enable. For example, to enable bit 2 (decimal value = 4) and bit 4 (decimal value = 16), the corresponding decimal value would be 20 (4 + 16).Similarly, any register queries return the binary-weighted value of the bits that have been set. For example, with bit 3 (value 8) and bit 5 (value 32) being set, the query returns +40.

Alarm Channel Groups

These registers record signals that indicate abnormal conditions on specific channels. There are three condition groups - one for each abnormal condition: over-voltage, over-current, and under-voltage.

The group channel assignments are 32-bit unsigned values where each bit represents one channel. Channel 1 is represented by bit 0; channel 32 by bit 32. A “1” in a bit position indicates that the indicated alarm condition is true. When true, the affected channel is shut down.

The channel bits are logically-ORed into bits 0, 1, and 9 of the Alarm Status Group. The following table describes the bit assignments.

Keysight BT2152A Operating and Service Guide 87

4 Programming Reference

Bit BitName Decimal Value

0 Channel 1 1

1 Channel 2 2

2 Channel 3 4

. . .

29 Channel 30 536870912

30 Channel 31 1073741824

31 Channel 32 2147483648

. . .

Alarm Status Group

These register groups record signals that indicate abnormal operation. The group consists of a Condition, Event, and Enable register. The outputs of the Alarm Status group are logically-ORed into the QUEStionable summary bit (3) of the Status Byte register. Refer to Status Registers for a description of each register. The following table describes the bit assignments.

Bit BitName Decimal Value Definition

0 OVP 1 Over-voltage protection

1 OCP 2 Over-current protection

2-8 not used not used 0 is returned

9 UVP 512 Under-voltage protection

10-15 not used not used 0 is returned

Standard Operation Group

These register groups record signals that indicate the present operating status of the instrument. The group consists of a Condition, Event, and Enable register. The Standard Operation event register latches events relating to the operation of the unit. It is a read-only register that is cleared when read. The Standard Operation enable register functions similarly to the enable registers of the Alarm Status group. Refer to Status Registers for a description of each register. The following table describes the bit assignments.

88 Keysight BT2152A Operating and Service Guide

4 Programming Reference

Bit BitName Decimal Value Definition

0 Calibrating 1 Instrument calibration has been initiated.

1 Warm Up 2 The instrument is warming up.

2 Emergency Stop 4 An emergency stop condition has been activated.

3 not used not used 0 is returned

4 Measuring 16 A cell measurement is in progress.

5-7 not used not used 0 is returned

8 Config changed 256 The cell configuration has changes since the previous testhas run.

9-11 not used not used

12 Temperature

unregulated

13 Global Error 8192 A remote interface has errors in the error queue. SYSTem:ERRor? reads and deletes

14-15 not used not used 0 is returned

4096 The referencetemperature of the instrument cannot be maintained within specifications

during the execution of an INIT command.

errors.

Status Byte Register

This register summarizes the information from all other status groups as defined in the IEEE 488.2 Standard Digital Interface for Programmable Instrumentation. The following table describes the bit assignments.

Bit BitName Decimal Value Definition

0 not used not used 0 isreturned

1 Alarm Status

Summary

2 Error Queue 4 One or more errors in the Error Queue. SYSTem:ERRor? reads and deleteserrors.

2 One or more Status Alarm conditions have occurred. Use STATus:ALARm:EVENt? to

read and deleteerrors.

3 not used not used 0 isreturned

4 Message

Available

5 not used not used 0 isreturned

6 Master Status

Summary

7 Operation Status

Summary

16 Data is available in the instrument's output buffer.

64 One or more bits are setin the Status Byte Register and may generate a Service

Request. Bits must beenabled, see *SRE.

128 One or more bits are set in the Operation Status Register. Bitsmust be enabled, see

STATus:OPERation:ENABle.

Keysight BT2152A Operating and Service Guide 89

4 Programming Reference

Error and Output Queues

The Error Queue is a first-in, first-out (FIFO) data register that stores numerical and textual description of an error or event. Error messages are stored until they are read with SYSTem:ERRor? If the queue overflows, the last error/event in the queue is replaced with error -350,"Queue overflow".

The Output Queue is a first-in, first-out (FIFO) data register that stores instrument-to-controller messages until the controller reads them. Whenever the queue holds messages, it sets the MAV bit (4) of the Status Byte register.

MSS Bit

MSS is a real-time (unlatched) summary of all Status Byte register bits that are enabled by the Service Request Enable register. MSS is set whenever the instrument has one or more reasons for requesting service. *STB? reads the MSS in bit position 6 of the response but does not clear any of the bits in the Status Byte register.

90 Keysight BT2152A Operating and Service Guide

Status Diagram

4 Programming Reference

Keysight BT2152A Operating and Service Guide 91

4 Programming Reference

Reset (*RST) and Interface Settings

Reset State settings are set when the unit is reset.

Parameter Setting

Over-current protection: 1.00e-2

Over-voltageprotection: 4.0

Under-voltage protection: 3.0

Output resistance: 1.0

Open-circuit voltage: 3.5

Initial cell current: 1.00e-3

Output inhibitmode: OFF

Testduration: 5 minutes

Timeinterval <tint>: 1 second

Interface Settings are the default factory settings.

Parameter Setting

LANinterface: enabled

USB interface: enabled

DHCP: On

Auto IP: On

IP Address: 169.254.4.61

Subnet Mask: 255.255.0.0

Default Gateway: 0.0.0.0

DNS Server: 0.0.0.0

Host Name: K-2152A-nnnnn (where nnnnn is last 5 digitsof

the serial number)

LANServices: All enabled

Telnetprompt: "BT2152A> "

IP addresses of Windows Internet Name System

0.0.0.0

Power must cycled for interface enable or LAN service changes to take effect. LAN settings changes require a LAN restart.

92 Keysight BT2152A Operating and Service Guide

4 Programming Reference

SCPI Error Messages

l Up to 20 errors can be stored in the error queue.

l A global error queue holds all power-on and hardware-related errors (example: over-temperature).

l Error retrieval is first-in-first-out (FIFO), and errors are cleared asyou read them. Once you have read

all interface-specific errors, the errors in the global error queue are retrieved.

l If more than 20 errors have occurred, the last error stored in the queue (the most recent error) is

replaced with -350,"Error queue overflow". No additional errors are stored until you remove errors from the queue. If no errors have occurred when you read the error queue, the instrument responds with +0,"No error".

Error conditions are also summarized in the Status Byte Register. See Status Subsystem for details.

l Interface-specific error queues are cleared by power cycles. The error queue is not cleared by *RST.

l The SYSTem:ERRor? query reads and clears one error from the error queue. Errors have the following

format -113,"Undefined header". The error string may contain up to 255 characters.

Error List

Device-dependent Errors (these errors set Standard Event Status register bit #3)

201, "Memory lost: time and date";

Internal calibration time and date is lost

202, "Selftest failed";

The power-on self-test has failed

204, "NVRAM checksum error";

A non-volatile RAM checksum error has occurred in the instrument

205, "NVRAM full";

The non-volatile RAM memory in the instrument is full

206, "File not found";

The internal calibration file was not found in NVRAM

207, "Power rail fault";

One or more of the internal power rails have failed

208, "Power supply fault";

One or more of the internal power supplies have failed

210, "diagnostic error";

An internal diagnostic error has occurred in the instrument

Keysight BT2152A Operating and Service Guide 93

4 Programming Reference

220, "data is not available";

Measurement data is not available. No measurement readings have occurred

230, "External temperature sensor not connected.";

The external temperature sensor is not connected to the TEMP input

231, "Internal temperature not within limits.";

The internal reference temperature is not within the specified limit

250, "Error during self-discharge measurement";

A self-discharge measurement error has occurred. Error condition specific messages will be appended to this generic message.

270, "Readings not being collected";

Measurement readings are not being collected as the collection engine is not running.

271, "Not enough reading points collected";

Not enough reading points have been collected to return a measurement

309, "Incorrectly formatted channel list";

The channel list is incorrectly formatted. Check channel syntax -should be (@1:32) or similar.

316, "Mass storage error";

The mass storage memory has been exceeded

320, "Exceeded max number of licensed channels";

The command is specifying more channels than are supported by the installed license.

610, "Self Test Failure: Multiple errors during self test";

Multiple errors have occurred during self-test

611, "Self Test Failure: Voltage reference failed";

The internal reference voltage has failed during self-test.

612, "Self Test Failure: 10 mA Reference failed";

The internal 10 mA reference has failed during self-test.

613, "Self Test Failure: 100 mA Reference failed";

The internal 100 mA reference has failed during self-test.

680, "Incorrect cal password";

An incorrect calibration password has been entered

700, "Unknown calibration error occurred";

94 Keysight BT2152A Operating and Service Guide

4 Programming Reference

An unknown calibration error occurred

701, "Calibration has not been started.";

The command used requires the instrument to be in calibration mode.

702, "The calibration result is out of the expected range.";

The calibration value entered from the DVM is outside of the expected range

703, "Error during auto calibration.";

An error has occurred during transfer calibration. Try running auto calibration again

800, "Nonvolatile memory write failure";

The instrument could not write to nonvolatile memory

Command Errors (these errors set Standard Event Status register bit #5)

-123, "Numeric overflow"

The numeric value returned is larger than the expected value

-203, "Command protected; instrument must be unsecured";

Calibration mode requires a password to unsecure the instrument

-213, "INIT ignored";

The INIT:TEST command is ignored. There is already an init running.

-221, "Settings conflict; invalid tint. ";

A test could not be executed because of invalid time interval parameter.

-221, "Settings conflict; invalid test duration. ";

A test could not be executed because of invalid test duration parameter.

-221, "Settings conflict; lower limit > upper limit. ";

A test could not be executed because the lower limit is greater than the upper limit parameter.

-221, "Settings conflict; cell open circuit voltage must be between over and under voltage. ";

A test did not execute because the open circuit voltage must be between the over and under voltage.

-222, "Data out of range; value clipped to upper limit";

The measured data is out of range; the returned value is clipped to the upper limit.

-222, "Data out of range; value clipped to lower limit";

The measured data is out of range; the returned value is clipped to the lower limit.

-222, "Parameter 1 out of range";

The command could not be executed because the 1st parameter is out of range.

Keysight BT2152A Operating and Service Guide 95

4 Programming Reference

-222, "Parameter 2 out of range";

The command could not be executed because the 2nd parameter is out of range.

-222, "Parameter 3 out of range";

The command could not be executed because the 3rd parameter is out of range.

-222, "Parameter 4 out of range";

The command could not be executed because the 4th parameter is out of range.

-222, "Parameter 5 out of range";

The command could not be executed because the 5th parameter is out of range.

-222, "Parameter 6 out of range";

The command could not be executed because the 6th parameter is out of range.

-222, "Parameter 7 out of range";

The command could not be executed because the 7th parameter is out of range.

-222, "Parameter 8 out of range";

The command could not be executed because the 8th parameter is out of range.

-222, "Parameter 9 out of range";

The command could not be executed because the 9th parameter is out of range.

-250, "Mass storage error; internal file system could not be opened";

The command could not be executed because the internal file system could not be opened

-250, "Mass storage error; USB file system could not be opened";

The command could not be executed because the USB file system could not be opened

-253, "Corrupt media; internal file system scan failed";

The command could not be executed because the internal file system scan failed

-253, "Corrupt media; internal file system format failed";

The command could not be executed because the internal file system format failed

-253, "Corrupt media; file system corruption detected; reformat needed";

The command could not be executed because the internal file system is corrupted

-253, "Corrupt media; USB file system scan failed";

The command could not be executed because the USB file system scan failed

-350, "Error queue overflow";

The error queue is full. No additional errors can be stored until errors are removed from the queue.

96 Keysight BT2152A Operating and Service Guide

Keysight BT2152A Operating and Service Guide

Verification and Calibration

Verification Procedure

Reference Calibration

Channel Calibration

Wire Resistance Calibration

Calibration Security Reset

Maintenance

5 Verification and Calibration

Verification Procedure

Introduction

Verification is recommended to verify that the instrument is working properly during incoming inspection - as an acceptance test. Verification is also recommended if you notice suspicious instrument behavior or if there is a question about the performance of the instrument. Verification procedures can be time consuming as they verify the operation of a single channel at a time.

Performing a reference calibration and a channel calibration provides the same high level of confidence as the manual channel-by-channel verification process.

Verification is not necessary as part of a standard maintenance cycle. It is also not necessary after performing any of the calibration procedures, as the calibration processes verify that the reference and channels are functioning within specification.

Verification commands set each channel to a specific output level, which can then be used to verify the specified accuracy of the channel at that operating point. If the instrument fails any of the verification tests, try performing the Reference and Channel calibrations again. If verification is still unsuccessful, return the unit to a Keysight Technologies Service Center.

Verification Equipment and Considerations

l A 7½-digit DMM, Keysight 34470A (Run auto-calibration on the DMM prior to starting)

l A 442-ohm ¼ watt through-hole resistor, Keysight P/N 0698-4591 or equivalent

l The ambient temperature is stable and between 23 °C ±2 °C. Relative humidity is <80%

l The BT2152A must be warmed up for at least 1 hour prior to verification tests

External DMM Connections and Setup

The verification setup shown for channel 1 on a single RJ45 connector. Channels are verified one at a time. Channels are in groups of four, each group connected to one RJ45 connector.

Zero-current verification

Full-scale current verification

Voltage verification

98 Keysight BT2152A Operating and Service Guide

5 Verification and Calibration

Building a multi-channel breakout board assembly can simplify verification, especially when planning to verify all the channels. This can be constructed by wiring all BT2152A channels in parallel at the breakout board. Only one channel can be tested at a time with this arrangement (see Optional

Verification Assembly).

Zero-Scale Current Accuracy Verification

Verifying the measurement system at zero, the bottom of the range, verifies contribution due to offset errors in the system. A significant consideration here is verifying the extremely low + 1 µA offset specification of BT2152A’s current measurement system. Noise inherent in the BT2152’s output typically requires a 1-minute measurement integration time be used with the DMM to average the noise out down to a + 1 µA level. However, this can be circumvented by testing the channel at zero by using an open circuit. For this reason, the BT2152A’s zero-scale current measurement is verified prior to making any connection to any channel.

The zero-scale current measurement accuracy procedure is a s follows:

No channel connections are required for the zero-scale current accuracy verification.

Step 1. Start the verification. Send CAL:VER:STAR <channel>

Verification Step 1 Setting

Selectthe channel to verify 1

Step 2. Wait 15 seconds for the unit to settle before proceeding with measurements

Step 3. Start the zero-scale current verification. Send CAL:VER:MEAS:INIT <time>, <tint>. The front panel TEST light flashes orange when this command is executed.

Verification Step 3 Setting

Setthe time for the measurement in seconds <time> = 10

Setthe interval the measurement in seconds <tint> = 10

Step 4. Wait for the measurement time set in step 3 to complete. Either send SENS:VER:AVAI? until the query returns a "1", or wait until the front panel TEST light turns off.

Step 5. Fetch the measurement reading from the BT2152A. Send FETC:CURR:LAT? (@channel)

Verification Step 5 Setting

Return the measurement data from achannel @1

Step 6. Verify that the zero-scale current error is within the specified accuracy provided in the Quick Reference section of this guide.

Step 7. If verifying multiple channels, repeat steps 1 through 7 for the rest of the channels.

Step 8. End the zero-scale current verification. Send CAL:VER:END

Keysight BT2152A Operating and Service Guide 99

5 Verification and Calibration

Full-Scale Current Accuracy Verification

Current measurement accuracy is verified near or at the 10-mA full-range current. Gain error is significant at the top of the range and adds to any offset error in the system.

Step 1. Connect a 7.5 digit (or better) DMM to the RJ45 connector as shown under the Full-scale current verification figure. Place the external resistor in series with the DMM.

Step 2. Set the DMM for DC current measurement, 10 mA range, and 10 PLCs (to integrate noise).

Step 3. Start the verification. Send CAL:VER:STAR <channel>

Verification Step 3 Setting

Selectthe channel to verify 1

Step 4. Set an output voltage. Send CAL:VER:VOLT <voltage>

Verification Step 4 Setting

Setthe top-end current measurement range. (4.5 V provides approximately 10 mA with the 442-ohm resistor in place.)

Specify the channel to be tested channel 1

<voltage> = 4.5

Step 5. Wait 15 seconds for the BT2152A to settle before proceeding with measurements.

Step 6. Initiate a measurement. Send CAL:VER:MEAS:INIT <time>, <tint>. The front panel TEST light flashes orange when this command is executed.

Verification Step 6 Setting

Setthe time for the measurement in seconds <time> = 10

Setthe interval the measurement in seconds <tint> = 10

Step 7. While the BT2152A is performing its measurements, take a current reading with the DMM and record this value.

Step 8. Wait for the measurement time set in step 6 to complete. Either send SENS:VER:AVAI? until the query returns a "1", or wait until the front panel TEST light turns off.

Step 9. Fetch the measurement reading from the BT2152A. Send FETC:CURR:LAT? (@channel)

Verification Step 9 Setting

Return the measurement data from achannel @1

Step 10. Subtract the reference reading from the DMM obtained in step 7 from the reading from the BT2152A measurement obtained in step 9. Verify if it within the specified accuracy provided in the Quick Reference section of this guide.

100 Keysight BT2152A Operating and Service Guide

Keysight Technologies BT2152A Operating And Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Legal and Safety Information

Legal Notices

Safety Symbols

Safety Notices

1 Quick Reference

Welcome

What is self-discharge?

Advantages of the Keysight BT2152A Self-Discharge Analyzer

Contact Keysight Technologies

Models and Specifications

Front and Rear Views

Models

Specifications

Characteristics

Self-Discharge Measurement Criteria

External Temperature Measurement

Dimensions and Airflow

Command Quick Reference

2 Installing the Analyzer

Before Installation

Inspect the Unit

Check for Items Supplied

Accessories

Review Safety Information

Observe Environmental Conditions

Provide Adequate Air Flow

Connect the Power Cord

Connect the Interfaces

LAN Connections

USB Connections

Digital Port Connections

Thermistor Connections

Connect the Cell Cables

Making the Cables

RJ45 WIre Color Codes and Pinout Numbers

32-Channel Mapping to RJ45 Connectors

3 Operating the Analyzer

Understanding Front Panel Operation

What Happens at power-on?

What happens when a test is initiated?

What happens when a test stops?

What happens when the reference temperature exceeds its specification?

What happens when a protection event or error occurs?

Using the Digital Port

Bi-Directional Digital I/O

Digital Control Port

Digital Input

Fault Output

Inhibit Input

Fault/Inhibit System Protection

Maintaining Cell Stability During Testing

A Cell's Percent State of Charge

Charge Redistribution and Equilibrium

Expected Self-Discharge Current and Temperature Dependency

Temperature Impact on Current Measurement

Impact of Stress and Vibration on Current Measurement

4 Programming Reference

Introduction to the SCPI Language

Command Types

Keywords

Queries

Syntax Conventions

Parameter Types

Device Clear

Programming Samples

Setting up and running a test

Retrieving all test values

Stopping/aborting a test

Clearing protection events and errors

Commands by Subsystem

Calibration Commands

Common Commands

Digital Commands

Fetch Commands

Format Command

Initiate Commands
