Installation Guide
Agilent Technologies
PSG Signal Generators
This guide applies to the following signal generator models:
E8267C PSG Vector Signal Generator
E8257C PSG Analog Signal Generator
E8247C PSG CW Signal Generator
Due to our continuing efforts to improve our products through firmware and hardware revisions, signal
generator design and operation may vary from descriptions in this guide. We recommend that you use the
latest revision of this guide to ensure you have up-to-date product information. Compare the print date of this
guide (see bottom of page) with the latest revision, which can be downloaded from the following website:
www.agilent.com/find/psg
Manufacturing Part Number:E8251-90252
Printed in USA
December 2003
© Copyright 2002, 2003 Agilent Technologies, Inc.
Notice
The material contained in this document is provided “as is”, and is subject to being changed, without no tice,
in future editions.
Further, to the maximum extent permitted by applicable law, Agilent disclaims all warranties, either express
or implied with regard to this manual and to any of the Agilent products to which it pertains, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose. Agilent shall not
be liable for errors or for incidental or consequential damages in connection with the furnishing, use, or
performance of this document or any of the Agilent products to which it pertains. Should Agilent have a
written contract with the User and should any of the contract terms conflict with these terms, the contract
terms shall control.
Questions or Comments about our Documentation?
We welcome any questions or comments you may have about our documentation. Please send us an E-mail
at sources_manuals@am.exch.agilent.com.
ii
Contents
1. Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Instrument Markings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Warnings, Cautions, and Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2. Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Checking the Shipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Meeting Electrical and Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Line Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Connecting the AC Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
AC Power Cord Localization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Configuring Global Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Adjusting the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Configuring for Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
GPIB Interface Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
LAN Interface Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
RS-232 Interface Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Ordering Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Front Handles and Rack Mount Flanges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
PSG Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Proper Usage and Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cleaning Suggestions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Contacting Agilent Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Returning a Signal Generator to Agilent Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3. Operation Verification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Performing a Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Self-Test Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Checking the Maximum Leveled Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Maximum Leveled Power Check Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Checking the Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Problems with Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
4. Regulatory Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
iii
Contents
Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Compliance with German Noise Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Compliance with Canadian EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
iv
1 Safety Information
Instrument Markings
The following markings are used on the signal generator. Familiarize yourself with each marking and its
meaning before operating the signal generator.
The instruction manual symbol . The product is marked with this symbol when it is necessary for
the user to refer to the instructions in the manual.
The CE mark is a registered trademark of the European Community. If this symbol is
accompanied by a year, it is the year when the desi gn was proven.
The CSA mark is a registered trademark of t he Canadian Standards Association.
The C-Tick Mark is a trademark registered to the Aust ralian Spectrum Management Agency.
This indicates compliance with all Australian EMC regulatory informatio n.
This symbol is used to mark the on position of the power line switch.
This symbol is used to mark the standby position of the power line switch.
This symbol indicates that the input power required is ac.
This is a symbol of an Industrial Scientific and Medical Group 1 Class A product. (CISPER 11,
Clause 4)
1
Safety Information
Warnings, Cautions, and Notes
Warnings, Cautions, and Notes
The following safety notations are used throughout this manual. Familiarize yourself with each notation and
its meaning before operating the signal generator.
WARNING Warning denotes a hazard. It calls attention to a condition or situation that could
result in personal injury or loss of life. Do not proceed beyond a warning until the
indicated conditions or situ ations are fully understood.
CAUTION Caution calls attention to a possible condition or situation that could result in the loss of a
user’s work, damage, or destruction of the signal generator. Do not proceed beyond a
caution until the indicated conditions are fully understood.
NOTE Note calls the user’s attention to an important point, or special information, within the text.
It provides operational information or additional instructions of which the user should be
aware.
General Safety Considerations
WARNING Personal injury may result if the signal generator covers are removed. There are no
operator serviceable parts inside. T o avoid electrical shock, refer servicing t o qualified
personnel.
2 Chapter 1
2 Getting Started
3
Getting Started
Checking the Shipment
Checking the Shipment
1. Inspect the shipping container for damage.
Signs of damage may in clude a dented or torn shi pping contai ner or cus hioning mater ial that show s signs
of unusual stress or compacting.
2. Carefully remove the contents from the shipping container and verify that your order is complete.
The following items are shipped standard with each signal generator:
• installation guide
• documentation CD-ROM
CD-ROM contents are also available in hard copy format. Refer to
“PSG Document ation” on pag e 12 for more information.
• service software
• three-prong ac power cord specific to geographic location
3. Verify that any options ordered are included with the sh ipment by checking the packing literature
included with the shipment.
NOTE The serial number label on the signal generator only verifies hardware/firmware options.
The packing literature verifies all items shipped.
Front handles and rack mounting hardware are also available for your signal generator. Refer to “Front
Handles and Rack Mount Flanges” on page 12 for more information.
4 Chapter 2
Getting Started
Meeting Electri cal and Environmental Requirements
Meeting Electrical and Environmental Requirements
Environment
The signal generator is designed for use in the following environmental conditions:
• indoor use
• < 15,000 feet (4,572 meters) altitude
•0 to 55° C temperature, unless otherwise specified
• 80% relative humidity (maximum) for temperatures up to 31° C, decreasing linearly to 50% relative
humidity at 40° C
CAUTION This product is designed for use in INSTALLATION CATEGORY II and POLLUTION
DEGREE 2, per IEC 61010 and 664, respectively.
Ventilation
Ventilation holes are located on the left side of the signal generator cover and the rear of th e signal gener ator
chassis. Do not allow these holes to be obstructed, as they allow air flow through the signal generator.
When installing the signal generator in a cabinet, the convection into and out of the signal generator must
not be restricted. The ambient temperature outside the cabinet must be less than the maximum operating
temperature of the signal generator by 4° C for every 100 watts dissipated within the cabinet .
CAUTION Damage to the signal generator may result when the total power dissipated in the cabinet is
greater than 800 watts. When this condition exists, forced convection must be applied.
Chapter 2 5
Getting Started
Meeting Electrical and Environmental Requirements
Line Settings
The signal generator has an autoranging line vol tage input. The available ac power source must meet the
following conditions:
Voltage: 100/115 volts nominal (90-132 volts)
230/240 volts nominal (198-254 volts)
Frequency: for 100/115 volts: 50/60/400 Hz nominal
for 230/240 volts: 50/60 Hz nominal
Power: E8247C PSG CW models: 300 watts maximum
E8257C PSG analog models: 300 watts maximum
E8267C PSG vector models: 600 watts maximum
CAUTION Damage to the signal generator may result if the supply voltage is not within the specified
range.
Connecting the AC Power Cord
This is a Safety Class 1 Product provided with a protective earth ground incorporated into the power cord.
The front panel switch is only a standby switch; it is not a line switch. The ac power cord is the
disconnecting device that disconnects the signal generator mains circuits from the mains supply.
Alternatively, an external switch or circuit breaker, readily identifiable and easily reached by the operator,
may also be used as a disconnecting device.
Disconnecting power to an instrument with a high stability timebase m a y require a longer warm-up period
before it meets specifications. Perform the following steps when connecting the ac power cord:
WARNING Personal injury may occur if there is any interruption of the protective conductor
inside or outside of the signal generator. Intentional interruption is prohibited.
CAUTION Damage to the signal generator may result without adequate earth grounding. Always use
the three-prong ac power cord supplied with the signal generator. See, “AC Power Cord
Localization” on page 7 for a list of available power cords.
1. Ensure that the power cord is not damaged.
2. Install the signal generator so that one of the following items is readily identifiable and easily reached by
the operator: ac power cord, alternative switch, or circuit breaker.
3. Insert the mains plug into a socket outlet provided with a protective earth grounding.
6 Chapter 2
Getting Started
Meeting Electri cal and Environmental Requirements
AC Power Cord Localization
The ac power cord included with the signal generator is appropriate to its geographic location. However, you
can order additional ac power cords for use in different areas.
The following table lists the available ac power cords, illustrates plug configurations, and identifies the
geographic area in which each cord is appropriate.
Chapter 2 7
