E3616A-01
SUPERSEDES: None
DATE: 04 January 1994
E3616A 60W Lab Bench DC Power Supply
Serial Numbers: KR34200101 / KR34700170
Duplicate Service Notes:
E3614A-01
E3615A-01
E3616A-01
E3617A-01
To eliminate intermittent blowing of line fuse in the option 0E3 (230
Vac input).
To Be Performed By: Agilent-Qualified Personnel or Customer
Parts Required:
P/N Description
2110-0457 Fuse (METRIC) 1A 250V FE IEC
Situation:
The surge current of the E3616A power supply with opt 0E3 (230 Vac input) is 22A at 5
msec width. The anti-surge current limit of the installed line fuse is 16A at 10 msec. So,
1 of 2
AUTHOR: NKP
ENTITY: Y300
© 1994 AGILENT TECHNOLOGIES
PRINTED IN U.S.A.
SERVICE NOTE
ADMINISTRATIVE INFORMATION
MODIFICATION RECOMMENDED
SERVICE NOTE CLASSIFICATION:
ACTION
CATEGORY:
LOCATION
CATEGORY:
CUSTOMER INSTALLABLE
ON-SITE
SERVICE CENTER
AGILENT RESPONSIBLE UNTIL: 31 January 1997
ADDITIONAL INFORMATION:
IMMEDIATELY
ON SPECIFIED FAILURE
AGREEABLE TIME
AVAILABILITY:
PRODUCT’S SUPPORT LIFE
RETURN
SCRAP
SEE TEXT
SERVICE
INVENTORY:
RETURN
SCRAP
SEE TEXT
USED
PARTS:
STANDARDS:
Labor 0.5 Hour
Continued
Page 2 Service Note E3616A-01
the line fuse often blows when the supply is powered on and off.
Solution/Action:
Replace the line fuse on the E3616A (opt 0E3) to eliminate frequent blowing of the line
fuse. Use replacement fuse p/n 2110-0457
Old Part No. New Part No.
2110-0599 2110-0457
