89410A-11
SERVICE NOTE
SUPERSEDES: NONE
89410A Vector Signal Analyzer
Serial Numbers: US40514521 / US405147 02
Ground plane glitches cause display colors to change.
To Be Performed By: Agilent-Qualifi ed Personne l
Parts Required:
P/N Description Quantity
89410-69547 Exchange Display/DSP Assembly 1
Situation:
High frequency vo ltage glitche s on the ground plane of the A47 assemblies ha ve be en fou nd
to cause two problems noticeable in the LCD display. Changes can occur in the color map
entries of the display RAMDAC causing the default colors to change on the display. Bright
dots can also appe a r randomly on the display. A47 assembl ies with date code 4119 o r grea ter
have improved gr ounding to preve nt the gr ound plane glitches.
Solution/Action:
Replace the A47 Display/DSP Assembly with an exchange assembly that has date code
4119 or greater.
DATE: June 2001
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
MODIFICATION RECOMMENDED
ACTION
CATEGORY:
LOCATION
CATEGORY:
AVAILABILITY: PRODUCT’S SUPPORT LIFE AGILENT RESPONSIBLE UNTIL: June 2003
AUTHOR: DWH ENTITY: A100 ADDITIONAL INFORMATION: CO A100-10105525
IMMEDIATELY
ON SPECIFIED FAILURE
AGREEABLE TIME
CUSTOMER INSTALLABLE
ON-SITE
SERVICE CENTER
STANDARDS:
LABOR 1.0 Hours
SERVICE
INVENTORY:
RETURN
SCRAP
SEE TEXT
USED
PARTS:
RETURN
SCRAP
SEE TEXT
© 2001 AGILENT TECHNOLOGIES
PRINTED IN U.S.A.
1 of 1
