Keysight (Agilent) 8920B Programmers Guide

HP 8920B Option 800, 801 RF Communications Test Set

Condensed Programming Reference Guide

Firmware Version B.06.00 and above

HP Part No. 08920-90239

Printed in U. S. A.

October 1999

Rev. A

1

Copyright © Hewlett-Packard Company 1999

Notice Information contained in this document is subject to change without notice.

All Rights Reserved. Reproduction, adaptation, or translation without prior written
permission is prohibited, except as allowed under the copyright laws.

This material may be reproduced by or for the U.S. Government pursuant to the
Copyright License under the clause at DFARS 52.227-7013 (APR 1988).

Hewlett-Packard Company
Learning Products Department
24001 E. Mission
Liberty Lake, WA 99019-9599
U.S.A.

2

Manufacturer’s Declaration

This statement is provided to comply with the requirements of the German Sound
Emission Directive, from 18 January 1991.

This product has a sound pressure emission (at the operator position) < 70 dB(A).

• Sound Pressure Lp < 70 dB(A).

• At Operator Position.

• Normal Operation.

• According to ISO 7779:1988/EN 27779:1991 (Type Test).

Herstellerbescheinigung

Diese Information steht im Zusammenhang mit den Anforderungen der

Maschinenlärminformationsverordnung vom 18 Januar 1991.

• Schalldruckpegel Lp < 70 dB(A).

• Am Arbeitsplatz.

• Normaler Betrieb.

• Nach ISO 7779:1988/EN 27779:1991 (Typprüfung).

3

Safety
Considerations

GENERAL
This product and related documentation must be reviewed for familiarization with

safety markings and instructions before operation.
This product has been designed and tested in accordance with IEC Publication

1010, "Safety Requirements for Electronic Measuring Apparatus," and has been
supplied in a safe condition. This instruction documentation contains information
and warnings which must be followed by the user to ensure safe operation and to
maintain the product in a safe condition.

SAFETY EARTH GROUND
A uninterruptible safety earth ground must be provided from the main power

source to the product input wiring terminals, power cord, or supplied power cord
set.

CHASSIS GROUND TERMINAL
To prevent a potential shock hazard, always connect the rear-panel chassis ground

terminal to earth ground when operating this instrument from a dc power source.
SAFETY SYMBOLS
Indicates instrument damage can occur if indicated operating limits are exceeded.

!

Refer to the instructions in this guide.
Indicates hazardous voltages.
Indicates earth (ground) terminal

WARNING A WARNING note denotes a hazard. It calls attention to a procedure, practice, or the

like, which, if not correctly performed or adhered to, could result in personal injury.
Do not proceed beyond a WARNING sign until the indicated conditions are fully un­derstood and met.

CAUTION A CAUTION note denotes a hazard. It calls attention to an o peration proce dure, practice,

4

or the like, which, if not correctly performed or adh ered to, could result in damag e to or
destruction of part or all of the product. Do not proceed beyond an CAUTION n ote until
the indicated conditions are fully understood and met.

Safety
Considerations for
this Instrument

WARNING This product is a Safety Class I instrument (provided with a protective

earthing ground incorporated in the power cord). The mains plug shall only
be inserted in a socket outlet provided with a protective earth contact. Any
interruption of the protective conductor inside or outside of the product is
likely to make the product dangerous. Intentional interruption is
prohibited..

Whenever it is likely that the protection has been impaired, the instrument
must be made inoperative and be secured against any unintended operation.

If this instrument is to be energized via an autotransformer (for voltage
reduction), make sure the common terminal is connected to the earth
terminal of the power source.

If this product is not used as specified, the protection provided by the
equipment could be impaired. This product must be used in a normal
condition (in which all means for protection are intact ) only.

No operator serviceable parts in th is product. Refer servicing to qualified
personnel. To prevent electrical shock, do not remove covers.

Servicing instructions are for use by qualified personnel only. To avoid
electrical shock, do not perform any servicing unless you are qualified to do
so.

The opening of covers or removal of parts is likely to expose dangerous
voltages. Disconnect the product from all voltage sources while it is being
opened.

Adjustments descr ibed in the manua l are performed with power supplied to
the instrument while protective covers are removed. Energy available at
many points may, if contacted, result in personal injury.

The power cord is connected to internal capacitors that my remain live for
5 seconds after disconnecting the plug from its power supply.

For Continued protection against fire hazard, replace the line fuse(s) only
with 250 V fuse(s) or the same current rating and type (for example, normal
blow or time delay). Do not use r e paired fuses or short circu i ted fu seh ol d ers.

5

CAUTION: Always use the three-prong ac power cord supplied with this product. Failu re to ensure

adequate earth grounding by not using this cord may cause product damage.
This product is designed for use in Inst allati on Categ ory I I and Pollu ti on Degree

2 per IEC 1010 and IEC 664 respectively. For indoor use only.
This product has autoranging line voltage input, be sure the supply voltage is

within the specified range.
Ventilation Requirements: When installing the product in a cabinet, the

convection into and out of the product must not be restricted. The ambient
temperature (outside the cabinet) must be less than the maximum operating

temperature of the product by 4° C for every 100 watts dissipated in the cabinet.
If the total power dissipated in the cabinet is greater than 800 watts, then forced
convection must be used.

Product Markings CE - the CE mark is a registered trademark of the European Community. A CE

6

mark accompanied by a year indicated the year the design was proven.
CSA - the CSA mark is a registered trademark of the Canadian Standards Associ-

ation.

Hewlett-Packard Warranty Statement for Commercial Products

HP 8920B Opt 80 0
and Opt 801 RF
Communication s
Test Set

Duration of
Warranty: One
Year

1. HP warrants HP hardware, accessories and supplies against defects in materials and

workmanship for the period specified above. If HP receives notice of such defects
during the warranty period, HP will, at its option, either repair or replace products
which prove to be defective. Replacement products may be either new or like-new.

2 HP warrants that HP software will not fail to execute its programming instructions, for

the period specified a bov e , due to defects in material and w or kma ns hip w hen properly
installed and used. If HP receives notice of such defects during the warranty period, HP
will replace software media which does not execute its programmin g instructions due
to such defects.

3. HP does not warrant that the operation of HP products will be uninterrupted or error

free. If HP is unable, within a reasonable time, to repair or replace any product to a
condition as warranted, customer will be entitled to a refund of the purchase price upon
prompt return of the product.

4 HP products may contain remanufactured parts equivalent to new in performance or

may have been subject to incidental use.

5. The warranty period begins on the date of delivery or on the date of installation if

installed by HP. If cu stomer sche dules or delays HP in stallati on more than 3 0 days aft er
delivery, warranty begins on the 31st day from delivery.

6 Warranty does not apply to defects resulting from (a) improper or inadequate mainte-

nance or calibration, (b) soft ware, i nterfaci ng, parts or suppl ies not su pplie d by HP, (c)
unauthorized modification or misuse, (d) operation outside of the published environ­mental specifications for the product, or (e) improper site preparation or maintenance.

7 TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE WARRANTIES

ARE EXCLUSIVE AND NO OTHER WARRANTYOR C ONDITI ON, WHETHER
WRITTEN OR ORAL IS EXPRESSED OR IMPLIED AND HP SPECIFICALLY
DISCLAIMS ANY IMPLIED WARRANTIES OR CONDITIONS OR MERCHANT­ABILITY, SATISFACTORY QUALITY, AND FI TNESS FOR A PARTICULAR
PURPOSE.

8 HP will be liable for damage to tang ible property per incident up to the greater of

$300,000 or the actual amount pa id for the product that is the sub ject of the cl ai m, a nd
for damages for bodily injury o r death, to the extent that all such damages are deter­mined by a court of competent jurisdiction to have been directly caused by a defective
HP product.

7

9. TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS

WARRANTY STATEMENT ARE CUSTOMER’S SOLE AND EXCLUSIVE
REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL HP OR ITS
SUPPLIERS BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL,
INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR
OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR
OTHERWISE.

FOR CONSUMER TRANSACTIONS IN AUSTR ALI A AND NEW ZEALAND:
THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO
THE EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE RESTRICT OR
MODIFY AND ARE IN ADDITION TO THE MANDATORY STATUTORY
RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.

8

DECLARATION OF CONFORMITY

according to ISO/IEC Guide 22 and EN 45014

Manufacturer’s Name:

Manufacturer’s Address:

declares that the product

Product Name:
Model Number:
Product Options:

conforms to the following Product specifications:

Safety: IEC 1010-1:1990+A1 / EN 61010-1:1993

CAN/CSA-C22.2 No. 1010.1-92

EMC: CISPR 11:1990/EN 55011:1991 Group 1, Class A

IEC 801-2:1984/EN 50082-1:1992 4 kV CD, 8 kV AD
IEC 801-3:1984/EN 50082-1:1992 3V/m
IEC 801-4:1988/EN 50082-1:1992 0.5 kV Sig. Lines, 1 kV Power Lines

Supplementary Information:

This product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/EEC.

Spokane, Washington USA November 20, 1995

Hewlett-Packard Co.
Spokane Division

24001 E. Mission Avenue
Liberty Lake, Washington 99019-9599
USA

RF Communicatio ns Test Set
HP 8920B

This declaration covers all options of the above
product.

Date Vince Roland/Quality Manager

European Contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH
Department ZQ /Standards Europe, Herrenberger Strasse 130, D-71034 B

9

ö

blinger, Germany (FAX[phone])

Table 1 Regional Sales and Service Offices

Eastern USA
Sales Office
Hewlett-Packard Company
2101 Gather Rd.
Rockville, MD 20850
Tel: [phone]

Southern USA
Sales and Service
Hewlett-Packard Company
1995 North Park Place
Atlanta, GA 30339

Sales
Tel: [phone]
Fax: [phone]

Service
Tel: [phone]
Fax: [phone]

Western USA
Sales and Service
Hewlett-Packard Company
24 Inverness Place East
Englewood, CO 80112

Sales
Tel: [phone]
Fax: [phone]

Service
Tel: [phone]
Fax: [phone]

South Eastern Europe
Sales and Service
Hewlett-Packard Ges. m.b.h.
Liebigasse 1
P.O . B o x 72
A-1222 Vienna, Austria

Telephone: [phone]
Telex: 13 4425

Eastern USA
Service Center
Hewlett-Packard Company
150 Green Pond Road
Rockaway, NJ 07866
Tel: [phone]

Southern USA
Service Center
Hewlett-Packard Company
930 E. Campbell Road
Richardson, TX 75081
Tel: [phone]

Western USA
Sales and Service
Hewlett-Packard Company
1421 South Manhattan Avenue
Fullerton, CA 92631

Sales
Tel: [phone]
Fax: [phone]

Service
Tel: [phone]
Fax: [phone]

European Multicountry Region
Sales and Service
Hewlett-Packard S.A.
P.O. Box 95
150, Route dv Nant_dl_AVRIL
CH-1217 Meyrin 2
Geneva, Switzerland

Telephone: [phone]
Fax: [phone]

Midwestern USA
Sales and Service
Hewlett-Packard Company
5201 Tollview Drive
Rolling Meadows, IL 60008
Tel: [phone]

Western USA
Service Center
Hewlett-Packard Company
301 E. Evelyn Avenue
Mountain View, CA 94041
Tel: [phone]
Fax: [phone]

United States of America
Customer Information Center
Hewlett-Packard Company
Tel: [phone]

6:00 am to 5:00 pm Pac ific Time
Parts Direct: 1-800-227-8164

Northern Europe
Sales and Service
Hewlett-Packard Nederland B.V.
Startbaan 16
1187 XR
Amstelveen, The Netherlands
P.O. Box 667

Telephone: [phone] X 6631
Fax: [phone]NL

10

Table 1 Regional Sales and Service Offices

Asia
Sales and Service
Hewlett-Packard Asia Ltd.
22-30/F Peregrine T ower
Lippo Center
89 Queensway, Central
Hong Kong
G.P.O. Box 863 Hong Kong

Telephone: [phone]
Fax: [phone]

Australia, New Zealand
Sales and Service
Hewlett-Packard Ltd.
P.O. Box 221
31-41 Joseph Street
Blackburn, Victoria 3130

Telephone: [phone]
Fax: [phone]

Canada
Service Cente r
Hewlett-Packard Ltd.
11120 178 Street
Edmonton, Alberta T5S 1P2
Canada

Telephone: [phone]
Fax: [phone]

Japan
Hewlett-Packard, Ltd.
Measurement Assistance Center
9-1, Takakua-Cho,
Hachioji-Shi
Tokyo 192-8510
Japan

Telephone: [phone]
Fax [phone]

Canada
Sales and Service
Hewlett-Packard (Canada) Ltd.
5150 Spectrum Way
Mississauga, Ontario L4W 5G1
Canada

Telephone: [phone]
Fax: [phone]

Latin America
Hewlett-Packard Company
LAHQ Mexico City
Col. Lomas de Virreyes
11000 Mexico D.F.
Mexico

Telephone: [phone]
Fax: [phone]

International Sales Branch Headquarters
Sales and Service
Hewlett-Packard S.A.
39 Rue Veyrot
P.O. Box 365
1217 Meyrin 1
Geneva, Switzerland

Telephone: [phone]
Fax: [phone]

Canada
Service Center
Hewlett-Packard Company
17500 Transcanada Highway
S. Serv Road
Kirkland, Quebec H9J 2X8
Canada

Telephone: [phone]
United Kingdom

Sales and Service
Hewlett-Packard Ltd.
Cain Road
Amen Corner
Bracknell, Berkshire
RG12 1HN
United Kingdom

Telephone: [phone]
Fax: [phone]

HP 8920B Support
Contacts

For further information about programming the HP 8920B Test Set, refer to the
HP 8920B HP-IB Programmer’s Guide, HP part number 08920-90222.

If you have used the manuals and still have application questions, contact the
Hewlett-Packard Test and Measurement Call Center at 1 800 452 4844. Or visit our
website at http://www.tmo.hp.com

11

12

Contents

Remote/Local Modes 19

HP-IB Command Syntax 23

Remote/Local Modes 20

HP-IB Command Syntax Listings 24

Adjacent Channel Power (ACP) 27

AF Analyzer 29

AF Generator 1 35

AFGenerator2|Encoder 37

AF Generator 2 Pre-Modulation Filters 45

Call Processing 47

Configure 99

Decoder 109

Display 111

Measure 113

Oscilloscope 123

Program 129

Radio Interface 131

RF Analyzer 133

RF Generator 135

13

Contents

GPIB Common Commands 169

RF Path Control 139

Save/Recall Registers 141

Special (GPIB Only Commands) 143

Spectrum Analyzer 145

Status 147

System 151

Tests 153

Trigger

157

Integer Number Setting Syntax 159

Real Number Setting Syntax 161

Multiple Real Number Setting Syntax 163

Number Measurement Syntax 165

Multiple Number Measurement Syntax 167

IEEE 488.2 Common Commands 170

Common Command Descriptions 171

Remote Capabilities 181

Remote Operating Capabilities 182

Remote Interface Functions 183

14

Contents

Front-Panel Control Fields to
GPIB Command Cross-Reference 187

A 188

B 195

C 197

D 204

E 209

F211

G 214

H 215

I216

L 219

M222

N 227

O 229

P 232

R 239

S 246

T 257

U 264

15

Contents

V 265

W 267

X 269

Numerals or Symbols 270

Which Control Order Command Should I Use? 271

272

16

Contents

Index 275

17

Contents

18

1

Remote/Local Modes

19

Remote/Local Modes

Remote/Local M odes

“Control Annunciators” on page 20
“Remote Mode” on page 20
“Local Mode” on page 20
“Remote or Local Mode” on page 21
“Local To Remote Transitions” on page 21
“Remote T o Local Transitions” on page 21
“Local Lockout” on page 21
“Clear Lockout/Set Local” on page 22

Control Annunciators

The letters and symbols at the top right corner of the display indicate these conditions:

•R indicates the Test Set is in remote mode. The Test Set can be put into the remote mode
by an external controller or by an IBASIC program runn ing on the bu ilt-in IBASIC con­troller.

•L indicates the Test Set has been addressed to Listen.

•T indicates the Test Set has been addressed to Talk.

•S indicates the Test Set has sent the Require Service message by setting the Service Re­quest (SRQ) bus line true.

•C indicates the Test Set is currently the Acti ve Controller on the bus.

•* indicates an IBASIC program+ is running.

•? indicates an IBASIC program is waiting for a user response.

•- indicates an IBASIC program is paused.

Remote Mode

In Remote mode all front panel keys are disabled (except for the LOCAL key, POWER switch, Volume
control and Squelch control). The LOCAL key is only disabled by the Local Lockout bus command. When
in Remote mode and addressed to Listen the Test Set responds to the Data, Remote, Local, Clear(SDC),

and Trigger messages. When the Test Set is in Remote mode, the “R” annunciator will be displayed in the
upper right corner of the display screen and triggering is set to the state it was last set to in Remote mode
(if no previous setting the default is FULL SETTling and REPetitive RETRiggering). When the Test Set is
being addressed to Listen or Talk the “L” or “T” annunciators will be displayed in the upper right corner of
the display screen.

Local Mode

In Local mode the Test Set’s front panel controls are fully operational. The Test Set uses FULL SETTling
and REPetitive RETRiggering in Local mode. When the Test Set is being addressed to Listen or Talk the
“L” or “T” annunciators will be displayed in the upper right corner of the display screen.

20

20

S:\HP8920B\Qkref_20-206\BOOK\CHAPTERS\remmodes.fb

Remote/Local Modes

Remote or Local Mode

When addressed to Talk in Remote or Local mode , the Test Set can issue the Data and Status Byte
messages and responds to the Take Control message. In addition the Test Set can issue the Service Request
Message (SRQ). Regardless of whether it is addressed to talk or listen, the Test Set will respond to the
Clear(DCL), Local Lockout, Clear Lockout/Set Local, and Abort messages.

Local To Remote Transitions

The Test Set switches from Local to Remote mode upon receipt of the Remote message (REN bus line true
and Test Set is addressed to listen). No instrument settings are changed by the transition from Local to
Remote mode, but triggering is set to the state it was last set to in Remote mode (if no previous setting the

default is FULL SETTling and REPetitive RETRiggering). The “R” annunciator in the upper right corner
of the display is turned on.

When the Test Set makes a transition from local to remote mode all currently active measurements are
flagged as invalid causing any currently available measurement results to become unavailable. If the
HP-IB trigger mode is RETR:REP then a new measurement cycle is started and measurement results will
be available for all active measurements when valid results have been obtained. If the HP-IB trigger mode
is RETR:SING then a measurement cycle must be started by issuing a trigger event.

Remote To Local Transitions

The Test Set switches from Remote to Local operation (full front panel control) upon receipt of the Local
message (Go To Local (GTL) bus message and Test Set is addressed to listen) or the Clear Lockout/Set
Local message (REN bus line false). No instrument settings are changed by the transition from Remote to
Local mode, but triggering is reset to FULL SETTling and REPetitive RETRiggering. The “R”
annunciator in the upper right corner of the display is turned off.

If it is not in Local Lockout mode the Test Set switches from Remote to Local mode whenever the front­panel LOCAL key is pressed.

If the Test Set was in Local Lockout mode when the Local message was received, front-panel control is
returned, but Local Lockout mode is not cleared. Unless the Test Set receives the Clear Lockout/Set Local
message, the Test Set will still be in Local Lockout mode the next time it goes to the Remote mode.

Local Lockout

The Local Lockout mode disables the front-panel LOCAL key and allows return to Local mode only by
commands from the System Controller (Clear Lockout/Set Local message).

When a data transmission to the Test Set is interrupted, which can happen if the LOCAL key is pressed, the
data being transmitted may be lost. This can leave the Test Set in an unknown state. The Local Lockout
mode prevents loss of data or system control due to someone unintentionally pressing front-panel keys.

21

S:\HP8920B\Qkref_20-206\BOOK\CHAPTERS\remmodes.fb

Remote/Local Modes

NOTE: Return to Local mode can also be accomplished by setting the POWER switch to OFF and

back to ON. However, returning to Local mode in this way has the following
disadvantages:

1 It defeats the purpose of the Local Lockout mode in that the Active Controller will loose

control of the Test Set,.

2 Instrument configuration is r eset to the power up condition thereby loosing the instru-

ment configuration set by the Active Controller

Clear Lockout/Set Local

The Test Set returns to Local mode (full front panel control) when it receives the Clear Lockout/Set Local
message. No instrument settings are changed by the transition from Remote mode with Local Lockout to
Local mode but triggering is reset to FULL SETTling and REPetitive RETRiggering.

22

22

S:\HP8920B\Qkref_20-206\BOOK\CHAPTERS\remmodes.fb

2

HP-IB Command Syntax

23

HP-IB Command Syntax Listings

HP-IB Command Syntax Listings

Instrument Command Syntax Listings

“Adjacent Channel Power (ACP)” on page 27
“AF Analyzer” on page 29
“AF Generator 1” on page 35
“AF Generator 2 Pre-Modulation Filters” on page 45
“AFGenerator2|Encoder” on page 37
“Call Processing” on page 47
“Decoder” on page 109
“Oscilloscope” on page 123
“RF Analyzer” on page 133
“RF Generator” on page 135
“Spectrum Analyzer” on page 145

Instrument Numbe r Se tting Command Syntax Listings

“Integer Number Setting Syntax” on page 159
“Real Number Setting Syntax” on page 161
“Multiple Real Number Setting Syntax” on page 163

Measurement Command Syntax Listings

“Measure” on page 113
“Trigger” on page 157

Measurement Number Setting Command Syntax Listings

“Number Measurement Syntax” on page 165
“Multiple Number Measurement Syntax” on page 167

Instrument Funct i on Command Syntax Li stings

“Configure” on page 99
“Display” on page 111
“Program” on page 129
“Save/Recall Registers” on page 141
“Status” on page 147
“System” on page 151
“Tests” on page 153

HP-IB Only Command Syntax Listings

“Special (GPIB Only Commands)” on page 143

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

.

24

24

S:\HP8920B\Qkref_20-206\BOOK\CHAPTERS\syntax2.fb

HP-IB Command Syntax Listings

Command Listing Conventions

Command listings are used to define the Test Set’s HP-IB commands. The listing shows the commands,
their hierarchical relationships, related parameters (if any), and associated notes (if any).

The Test Set’s commands are based upon a hierarchical structure, also known as a tree system. In such a
system, associated commands are grouped together under a common node in the hierarchy, analogous to
the way leaves at a same level are connected at a common branch. This and similar branches are connected
to fewer and thicker branches, until they meet at the root of the tree. The closer to the root, the higher a
node is considered in the hierarchy.

The command listing is divided into columns, as indicated by light gray vertical lines. The root node is the
leftmost column. Lower nodes in the hierarchy are indented one position to the right, below the root node.
To obtain a particular command, the full path to it must be specified. For example: to set the low side of the
audio input on the Audio Analyzer to float you would generate the following command:

:AFANalyzer: AI N ’Float’

:AFANalyzer

:AIN ’Gnd’

’Float’
’600 to Hi’

:AIN? (Returns quoted string)

:ELResistor (See Real Number Setting Syntax, :STATe not included)

Directs the user to a specific Instrument Command,
Measurement Command, or Number Setting Command
syntax listing.
Notes indicate which, if any, Number Setting Commands are
not supported by this particular path.

Square brackets([]) are used to enclose a keyword that is optional when programming the command; that
is, the Test Set will process the command to have the same effect whether the option keyword is omitted by
the programmer or not.

Letter case (uppercase or lowercase) in listings is used to differentiate between the accepted short form (the
uppercase characters) and the long form (the whole keyword). The Test Set accepts only the exact short
and the exact long forms. Sending a keyword that is not the exact short form or the exact long form will
generate an error.

In the parameter section of the listing a number of characters have special significance. Square brackets
([]) are used to enclose one or more parameters that are optional when controlling the Test Set. Braces({}),
or curly brackets, are used to enclose one or more parameters that may be included zero or more times. The
vertical bar (|) can be read as “or” and is used to separate alternative parameter options.

The query form of a command is generated by appending a question mark to the last keyword. However,
not all commands have a query form, and some commands exist only in the query form. The listings
include, where applicable, the command form and the query form of each command.

25

S:\HP8920B\Qkref_20-206\BOOK\CHAPTERS\syntax2.fb

HP-IB Command Syntax Listings

CAUTION: When changing a field’s setting, a space must always precede the settin g value in the

command string, regardless of the field type. For example:

:RFG:FREQ<sp ace>850MHZ
:EFG:ATT<SPA CE>’On’

Improper punctuation will result in the following error :

HP-IB Error: -102 Syntax Error.

26

26

S:\HP8920B\Qkref_20-206\BOOK\CHAPTERS\syntax2.fb

Adjacent Channel Power (ACP)

Adjacent Channel Power (ACP)

:ACPower

:CBW|CBANdwidth (See "Real Number Setting Syntax" on page 161, :STATe not

HIS COMMAND SETS THE BANDWIDTH OF THE CARRIER AND ADJACENT

T

CHANNELS TO BE MEASURED IN ADJACENT CHANNEL POWER MEASUREMENTS.

HE CHANNEL BW FIELD IS FOUND ON THE ADJACENT CHANNEL POWER

T

SCREEN.

:COFFset (See "Real Number Setting Syntax" on page 161, :STATe not included)

HIS COMMAND SETS THE FREQUENCY DIFFERENCE BETWEEN THE TUNE FREQ OR RF

T

HANNEL FIELD SETTINGS AND THE CENTER OF THE ADJACENT CHANNEL TO BE

C

MEASURED IN ADJACENT CHANNEL POWER MEASUREMENTS. THE CH OFFSET FIELD IS
FOUND ON THE ADJACENT CHANNEL POWE R SCREEN.

included)

:MEASurement ’Ratio’

:MEASurement? (Returns quoted string)

:RBW|RBANdwidth ’300 Hz’

:RBW?|RBANdwidth? (Returns quoted string)

:RMODulation ’Unmod’

:RMODulation? (Returns quoted string)

’Level’

HESE COMMANDS SET/QUERY THE FORMAT FOR DISPLAYING ADJACENT

T

CHANNEL POWER MEASUREMENTS. THE ACP MEAS FIELD IS FOUND ON THE

ADJACENT CHAN NE L POWER SCREEN

’1 kHz’

HESE COMMANDS SET/QUERY THE RESOLUTION BANDWIDTH FOR ADJACENT CHANNEL POWER

T

MEASUREMENTS. THE RES BW FIELD IS FOUND ON THE ADJACENT CHANNEL POWER
SCREEN.

’Mod’

HESE COMMANDS SET/QUERY THE CARRIER REFERENCE SETTING, INDICATING WHETHER

T

THE CARRIER BEING MEASURED DURING ADJACENT CHANNEL POWER REFERENCE
MEASUREMENTS WILL BE UNMODULATED OR MODULATED. THE CARRIER REF FIELD IS
FOUND ON THE ADJACENT CHANNEL POWE R SCREEN.

27

S:\HP8920B\Qkref_20-206\BOOK\SECTIONS\acpower.sec

Adjacent Channel Power (ACP)

28

S:\HP8920B\Qkref_20-206\BOOK\SECTIONS\acpower.sec

AF Analyzer

:AFANalyzer

:AIN’Gnd’

’Float’
’600 to Hi’

:AIN? (Returns quoted string)

HESE COMMANDS SET/QUERY THE INPUT STATE OF THE AUDIO IN (LO)

T

CONNECTOR. THE AUDIO IN LO FIELD IS FOUND ON THE AF ANALYZER SCREEN.

:CURRent

[:ZERO]

HIS COMMAND ZEROES THE DC CURRENT MEASUREMENT. THE DC CURRENT

T

FIELD IS FOUND ON THE AF ANALYZER SCREEN.

:DEMPhasis’750 us’

:DEMPhasis? (Returns quoted string)

:GAIN’0 dB’

:GAIN? (Returns quoted string)

’Off’

HESE COMMANDS SET/QUERY THE STATE OF DE-EMPHASIS NETWORKS IN THE AUDIO

T

ANALYZER AND SPEAKER CIRCUITRY. THE DE-EMPHASIS FIELD IS FOUND ON THE AF

NALYZER SCREEN.

A

’10 dB’
’20 dB’
’30 dB’

HESE COMMANDS SET/QUERY THE AF ANALYZER DE-EMPHASIS AMPLIFIER GAIN. THE

T
DE-EMP GAIN FIELD IS FOUND ON THE AF ANALYZER SCREEN.

AF Analyzer

29

S:\HP8920B\Qkref_20-206\BOOK\SECTIONS\afanalyr.sec

AF Analyzer

:AFAN

:DETector’RMS’

:DETector? (Retur ns qu oted string)

’RMS*SQRT2’
’PK+’
’PK-’
’PK+-/2’
’PK+-MAX’
’PK+ HOLD’
’PK- HOLD’
’PK+-/2 Hd’
’PK+-MX Hd’

HESE COMMANDS SET/QUERY THE TYPE OF DETECTOR USED WHEN MEASURING AND

T

DISPLAYING AF SIGNAL LEVELS. THE DETECTOR FIELD IS FOUND ON THE AF

NALYZER SCREEN.

A

:PKLocation’Filters’

:PKLocation? (Returns quoted string)

T

MEASUREMENTS. THE PK DET TO FIELD IS FOUND ON THE AF ANALYZER

SCREEN.

:SETTling’Fast’

:SETTling? (Returns qu ot ed string)

T
(U

SETTLING FIELD IS FOUND ON THE AF ANALYZER SCREEN.

:ELResistor (See "Real Number Setting Syntax" on page 161, :STATe not

T

THE AUDIO IN CONNECTORS. THE EXT LOAD R FIELD IS FOUND ON THE AF

A

’De-Emp’

HESE COMMANDS SET/QUERY THE SIGNAL SOURCE FOR THE PEAK DETECTOR

’Slow’

HESE COMMANDS SET/QUERY THE SETTLING TIME FOR AUDIO MEASUREMENTS.

SE “FAST” WHEN MEASURING SIGNALS GREATER THAN 200 HZ). THE

included)

HIS COMMAND SETS THE EXTERNAL LOAD RESISTANCE FOR MEASUREMENTS USING

NALYZER SCREEN. VALID RANGE IS 1 OHM TO 1 MEGOHM.

30

S:\HP8920B\Qkref_20-206\BOOK\SECTIONS\afanalyr.sec
