8673A-02
SERVICE NOTE
SUPERSEDES:
8673A Synthesized Signal Generator
Serial Numbers: 0000A00000 / 9999A99999
Duplicate Service Notes:
8673A-02
8673B-07B
8673C-08A
8673D-09A
8673H-02
Part Numbers For A1A10 YTMs (YIG Tuned Multipliers)
The part number for a replacement YTM is based on the instrument s model number, its
option configuration, its serial number, and whether you wish a new part or a restored part.
The list in this service note will help you consider these factors and determine the right part
number. The list contains YTM part numbers for all instruments in the 8673 family.
The YTM in your instrument has a part number on it. Do not automatically order this part
number. You might not get the correct replacement part for your instrument. Instead, you
should order the replacement part from the list in this service note. Here is why.
In the factory, the production line orders the part number that is on the YTM. Then, if
the instrument has pulse capability, the production line adds unique calibration data to an
EPROM for Pulse Amplitude Control.
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
INFORMATION ONLY
AUTHOR:
DH
ENTITY:
0400
Continued
DATE: 01 October 1990
ADDITIONAL INFORMATION:
Additional information text has changed to clarify
material and part numbers have changed in the list.
1990 AGILENT TECHNOLOGIES
PRINTED IN U.S.A.
1 of 3
Page 2 Service Note 8673A-02
If you were to order the same part and not have the added data, your pulse modulation
would not work right. That is why the part number in your instrument might be different than
the part number for the replacement part.
List Of All YTM Replacement Parts For the 8673 Family of Signal Generators
8673A, all serial numbers:
New Part, 08673-67019
Restored Part, 08673-69019
8673B Option 008, 2629A, 2626A, 2608A, and 2536A and below:
New Part, 08673-67022
Restored Part, 08673-69022
8673B Option 008, 2552A, and 2634A and above:
New Part, 08673-60187
Restored Part, 08673-69013
8673B, 2629A, 2626A, 2608A, and 2536A and below, but not Option 008:
New Part, 08673-67019
Restored Part, 08673-69019
8673B, 2552A, and 2634A and above, but not Option 008:
New Part, 08673-60165
Restored Part, 08673-69011
8673C, 2626A, 2608A, and 2540A and below:
New Part, 08673-67020
Restored Part, 08673-69020
8673C, 2552A, and 2634A and above:
New Part, 08673-60166
Restored Part, 08673-69012
8673D, 2626A, 2608A, and 2540A and below:
New Part, 08673-67019
Restored Part, 08673-69019
8673D, 2552A, and 2634A and above:
New Part, 08673-60152
Restored Part, 08673-69014
