86120B-02
SERVICE NOTE
SUPERSEDES: None
86120B Multi-Wavelength Meter
Serial Numbers: US38400000 /38401200
Firmware Revision 2.00 Available
To Be Performed By: Agilent-Qualified Personnel
Parts Required:
P/N Description Quantity
86120-60041 KIT-FIRMWARE UPGRADE 1
Situation:
The 86120B firmware revision 1.00 may not correctly read the wavelength of a directly
modulated (chirped) laser or a broad band device such as a filter or Bragg grating because
the linewidth exceeds the instrument specifications. For example, this effect will show up as
a "stair step" on a graph of temperature vs wavelength for a directly modulated, temperature
tuned laser.
Solution / Action:
The new release of firmware, revision 2.00 offers a menu selection to allow the user to
select either NARROW (CW laser) or BROAD (filters, chirped lasers, LEDs). The
BROAD selection will correctly read the wavelength of the device and will not exhibit the
"stair step" effect when the device is tuned.
This firmware revision is installable by Agilent Service Centers and is set up for
internal sale only. This upgrade does not require re-calibration of the instrument.
A customer can order the upgrade by contacting their local Service Center.
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
MODIFICATION AVAILABLE
ACTION
CATEGORY:
LOCATION
CATEGORY:
AUTHOR:
DS
AGREEABLE TIME
CUSTOMER INSTALLABLE
ON-SITE
SERVICE CENTER
ENTITY:
5360
DATE: March 1999
PERFORMANCE ENHANCEMENT
SERVICE/RELIABILITY ENHANCEMENT
AVAILABLE UNTIL:
Product Support Life
ADDITIONAL INFORMATION:
© 1999 AGILENT TECHNOLOGIES
PRINTED IN U.S.A.
1 of 1
